Desmon GBF-12GN2-1 User Manual
DESMON S.p.A.
Zona Ind. F3 Sup.
83051 Nusco (AV)
ITALIA
Tel.: +39 0827 607318
Fax: +39 0827 607009
info@desmon.it
www.desmon.it
Project Name:
Location:
AIA #
SIS #
Item #: Qty:
Model: GBF-12 GN2-1+ HCFCs and CFCs Free
GBF-12 GN2-1+
Specifications
Desmon Blastchiller are manufactured with
enduring ergonomic features to protect your
long term investment.
Standard Features
Blast Chiller/ Shock Freezer GN2/1- EN
(400x600)
Electronic control - H.A.C.C.P. function as
standard - Slide out refrigeration System Auto defrost with hot gas - Water
condensing tray - Gas R404a - Push-fit
magnetic door seal - Poliurethane
insulation 60mm CFC/HCFC free - AISI
304 Grade Stainless Steel interior/exterior Interior rounded corner - Easy-Clean coved
interior- Adjustable inox feet - Reversible Self closing doors - Stainless Steel back as
standard. Distance between racks 68mm.
Electronic control
H.A.C.C.P. function as standard
Optional Accessories
Racks - Trays - Stainless Steel
shelfs - Castors - Removable
sterilizer - Heated core probe
Environment
(CFC & HCFC free) R404A
refrigerant.
High-tech environmentally
friendly CFC-HCFC free,
Cyclopentane foaming, keeping
insulation properties for longer.
Lower energy consumption and
less CO2 emissions.
Made of almost 99% recyclable
materials.ISO 14001 Certified
Designed using the highest technologies,
quality materials and components to provide
the user with colder product temperatures,
lower utility costs, exceptional food safety and
the best value in today’s food service
marketplace. Push-fit magnetic door
seal
Poliurethane insulation 60mm
CFC/HCFC free
AISI 304 Grade Stainless Steel
Stainless Steel interior/exterior
Interior rounded corner
Easy-Clean rounded corners interior
Adjustable inox feet
Reversible Self closing doors
Stainless Steel back as standard
Warranty
Two year warranty on parts
Slide out refrigeration System
Auto defrost with hot gas
Water condensing tray
Gas R404a
Output Chilling (+
90min.
Output Fre
within 270min.
Ready for : nr. 12 shelves GN2/1 (530x650)
Not included or nr. 12 shelves EN (400x600)
Not included
90°C / +3°C) Kg 46 within
ezing (+90°C / -18°C) Kg 35
Approvals: Available at:
Desmon S.p.A. - Rev.
0
25/10/2012
del
Specification subject to change without notice
DESMON S.p.A.
ARCHITECT CORNER
Zona Ind. F3 Sup.
83051 Nusco (AV)
ITALIA
Tel.: +39 0827 607318
Fax: +39 0827 607009
info@desmon.it
www.desmon.it
Project Name:
Location:
AIA #
SIS #
Item #: Qty:
Model: GBF-12 GN2-1+ HCFCs and CFCs Free
380V/50Hz/3P
Ship Weight
Desmon S.p.A. - Rev.
Voltage
160Kg
Abs. Power
2700W
Dimensions
810x1100x1825
0
25/10/2012
del
Comp. H.P. Total Max Amps
Packing
850x1140x1975
Specification subject to change without notice
Ambient Temp.
38 °C
