Page 1
1
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Dericam Camera CGI & RTSP User
Guide
V1.0.2
Page 2
2
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Contents
Intorduction ...................................................................................................................................... 6
1. Video & Audio .......................................................................................................................... 7
getvideoattr .............................................................................................................................. 7
setvideoattr .............................................................................................................................. 8
getvencattr ............................................................................................................................... 9
setvencattr ............................................................................................................................. 10
getimageattr .......................................................................................................................... 11
setimageattr ........................................................................................................................... 12
getldcattr ................................................................................................................................ 13
setldcattr ................................................................................................................................ 13
getircutattr .............................................................................................................................. 14
setircutattr .............................................................................................................................. 14
getoverlayattr ........................................................................................................................ 14
setoverlayattr ......................................................................................................................... 15
getmobilesnapattr ................................................................................................................. 15
setmobilesnapattr ................................................................................................................. 16
getaencattr ............................................................................................................................. 16
setaencattr ............................................................................................................................. 16
getaudioinvolume ................................................................................................................. 17
setaudioinvolume.................................................................................................................. 17
getaudiooutvolume ............................................................................................................... 18
setaudiooutvolume ............................................................................................................... 18
getaudiooutvolume ............................................................................................................... 18
setaudiooutvolume ............................................................................................................... 19
requestifrm ............................................................................................................................. 19
2. IR Led control ........................................................................................................................... 19
getinfrared ............................................................................................................................. 19
setinfrared .............................................................................................................................. 20
3. Network ..................................................................................................................................... 20
getnetattr ................................................................................................................................ 20
setnetattr ................................................................................................................................ 21
gethttpport ............................................................................................................................. 21
sethttpport .............................................................................................................................. 22
getrtspport ............................................................................................................................. 22
setrtspport .............................................................................................................................. 22
getrtspauth ............................................................................................................................. 23
setrtspauth ............................................................................................................................. 23
getinterip ................................................................................................................................ 23
getupnpattr ............................................................................................................................ 24
setupnpattr ............................................................................................................................. 24
getonvifattr ............................................................................................................................. 24
setonvifattr ............................................................................................................................. 25
Page 3
3
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
4. Wireless ..................................................................................................................................... 26
getwirelessattr ....................................................................................................................... 26
setwirelessattr ....................................................................................................................... 26
searchwireless ...................................................................................................................... 27
chkwirelessattr ...................................................................................................................... 28
getchkwireless ...................................................................................................................... 29
5. DDNS ......................................................................................................................................... 29
get3thddnsattr ....................................................................................................................... 29
set3thddnsattr ....................................................................................................................... 30
6. PTZ control ............................................................................................................................... 31
ptzctrl ...................................................................................................................................... 31
preset ..................................................................................................................................... 31
getmotorattr ........................................................................................................................... 32
setmotorattr ........................................................................................................................... 33
getmotorrange ....................................................................................................................... 33
setmotorrange ....................................................................................................................... 34
getptzcomattr ........................................................................................................................ 34
setptzcomattr ......................................................................................................................... 35
ptzup.cgi ................................................................................................................................. 36
ptzdown.cgi ........................................................................................................................... 36
ptzleft.cgi ................................................................................................................................ 36
ptzright.cgi ............................................................................................................................. 37
ptzzoomin.cgi ........................................................................................................................ 37
ptzzoomout.cgi ...................................................................................................................... 37
getlightattr .............................................................................................................................. 37
setlightattr .............................................................................................................................. 38
7. Motion detection and I/O alram .............................................................................................. 38
getmdattr ................................................................................................................................ 38
setmdattr ................................................................................................................................ 39
getioattr .................................................................................................................................. 40
setioattr .................................................................................................................................. 40
getaudioalarmattr.................................................................................................................. 41
setaudioalarmattr .................................................................................................................. 41
getmdalarm ........................................................................................................................... 42
setmdalarm ............................................................................................................................ 43
getrelayattr ............................................................................................................................. 44
setrelayattr ............................................................................................................................. 44
getmotorattr ........................................................................................................................... 45
setmotorattr ........................................................................................................................... 45
getalarmsnapattr ................................................................................................................... 45
setalarmsnapattr ................................................................................................................... 45
getscheduleex ....................................................................................................................... 46
setscheduleex ....................................................................................................................... 47
getalarmsnapattr ................................................................................................................... 48
Page 4
4
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
setalarmsnapattr ................................................................................................................... 48
getplanrecattr ........................................................................................................................ 49
setplanrecattr ........................................................................................................................ 49
getalarmserverattr ................................................................................................................ 50
setalarmserverattr ................................................................................................................ 50
relayctrl ................................................................................................................................... 51
8. Privacy masking ....................................................................................................................... 51
getcover ................................................................................................................................. 51
setcover ................................................................................................................................. 52
9. Multi-screens ............................................................................................................................ 53
getdevices ............................................................................................................................. 53
setdevices .............................................................................................................................. 54
10. User management. ................................................................................................................ 55
getuserattr ............................................................................................................................. 55
setuserattr .............................................................................................................................. 55
getsetupflag ........................................................................................................................... 56
getstreamflag ........................................................................................................................ 56
getptzflag ............................................................................................................................... 56
getuserinfo ............................................................................................................................. 57
11. Scheduled snapshot .............................................................................................................. 57
getsnaptimerattrex................................................................................................................ 57
setsnaptimerattrex ................................................................................................................ 58
12. FTP .......................................................................................................................................... 59
getftpattr ................................................................................................................................. 59
setftpattr ................................................................................................................................. 59
testftp ...................................................................................................................................... 60
13. SMTP ....................................................................................................................................... 60
getsmtpattr ............................................................................................................................. 60
setsmtpattr ............................................................................................................................. 61
testsmtp ................................................................................................................................. 62
14. System setting ........................................................................................................................ 62
getserverinfo ......................................................................................................................... 62
getdevtype ............................................................................................................................. 63
getstreamnum ....................................................................................................................... 63
getservertime ........................................................................................................................ 63
setservertime ......................................................................................................................... 64
getntpattr ................................................................................................................................ 64
setntpattr ................................................................................................................................ 65
web/tmpfs/auto.jpg ............................................................................................................... 66
Sysreset.cgi ........................................................................................................................... 66
Sysreboot.cgi ........................................................................................................................ 66
backup.cgi ............................................................................................................................. 66
restore.cgi .............................................................................................................................. 67
logsync ................................................................................................................................... 67
Page 5
5
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
cleanlog .................................................................................................................................. 67
15. RTSP URL .............................................................................................................................. 68
1. Verify the authorization by client. ................................................................................... 68
2. Include the authorization in the URL. ............................................................................ 68
16. Appendix ................................................................................................................................. 68
Appendix I Defines for device type .................................................................................... 68
Appendix II Time zone list ................................................................................................... 70
History
Ver
Auth
Edit Date
Remark
1.0.0
Dericam
2016-4-29
Baseline Version
1.0.1
Dericam
2016-5-5
Formatting edits
Page 6
6
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Introduction
All CGI commands listed in this document are based on the HTTP protocol, which can be
executed in a web browser or software client.
Authentication
All cgi commands need authentication before they can be executed. There are 3
different authentications which can be configured in your IP camera:
administrator/user/guest. There are 2 kinds of authentications mechanism. The first
one is the Basic authentication mechanism declared by HTTP protocol. The second
one is including the username/password in the paramaters of CGI command URL.
We only support GET and POST method of HTTP CGI. The command upgrade.cgi
and restore.cgi are used for the POST method, all others commands are GET
methods.
Example for GET method:
<form name="form2" method="get" action="cgi-bin/hi3510/cleanlog.cgi">
<input name="cururl" type="hidden" >
<input name="name" type="hidden" value="access">
</form>
Example for POST method:
<form name="form5" method="post" target="retframe" enctype="multipart/form-data"
action="cgi-bin/hi3510/upgrade.cgi" onSubmit="return upgrade()">
<td colspan="3"><input type="file" name="setting_file" >
<input type="submit" value=" submit" >
</form>
CGI execute return information
For the commands to get information from the IP camera, such as the running
status or configurations.
If the command is executed successfully, there will return a text to show the
information from the IP camera. Each status or parameter is defined as text
variables; you can get its values from the return information after the CGI was
executed. For example:
var bps_1="2048";
var fps_1="25";
var gop_1="50";
var brmode_1="1";
var imagegrade_1="1";
var width_1="704";
var height_1="576";
If the command is execution fails, it will return information with an error code. For
example, “[Error]Get video attribution error! errcode is 0xa10e6008” 。
For the command to set configurations to the IP camera. If success, it will return
the executing result information, such as “HTTP/1.0 200 OK”. If fail, it will return
Page 7
7
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
the error promoting, such as “[Error][Data-Length:91] unrecongnized or
incomplete command line.”
CGI can be executed in the URL of web bowser, which are as follows:
http://192.168.1.88/cgi-bin/hi3510/param.cgi?cmd=getvencattr&-chn=11
http://192.168.1.6/cgi-bin/hi3510/param.cgi?cmd=setvencattr&-chn=11&-fps=15
http://192.168.1.6/cgi-bin/hi3510/param.cgi?cmd=getwirelessattr
Or you can include the username/password of the IP camera directly:
http://192.168.1.88/cgi-bin/hi3510/param.cgi?cmd=getvencattr&-chn=11&-usr=admin
&-pwd=admin
http://192.168.1.6/cgi-bin/hi3510/param.cgi?cmd=getwirelessattr&-usr=admin&-pwd=
admin
1. Video & Audio
getvideoattr
Function
Get the properties of camera video, such as resolution, format and
H.264 profile.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getvideoattr]
Param.
None
Return
videomode
31: 720P_Q720P_QQ720P
32: 720P_QQ720P_QQ720P
33: Q720P_Q720P_QQ720P
34: Q720P_QQ720P_QQ720P
41: 1080P_Q720P_QQ720P
42: 1080P_QQ720P_QQ720P
51: 960P_VGA_QVGA
52: 960P_QVGA_QVGA
53:VGA_VGA_QVGA
54: VGA_QVGA_QVGA
17: D1_CIF_CIF
20: CIF_CIF_CIF
vinorm
P: 50Hz(PAL)
N: 60Hz(NTSC)
profile
0: baseline
1: mainprofile
Note
Note:
The resolution of 720P is 1280x720
Page 8
8
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
The resolution of Q720P is 640x352
The resolution of QQ720P is 320x176
The resolution of 960P is 1280x960
The resolution of VGA is 640x480
The resolution of QVGA is 320x240
The resolution of 1080P is 1920x1080
Note:
720P_Q720P_QQ720P: It is 720P for first stream, Q720P for second
stream.
Example
/cgi-bin/hi3510/param.cgi?cmd=getvideoattr
setvideoattr
Function
Set the properties of camera video.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setvideoattr&-vinorm=&-profile=&-vide
omode=]
Param.
vinorm
P: 50Hz(PAL)
N: 60Hz(NTSC)
profile
0: baseline
1: mainprofile
videomode
31: 720P_Q720P_QQ720P
32: 720P_QQ720P_QQ720P
33: Q720P_Q720P_QQ720P
34: Q720P_QQ720P_QQ720P
41: 1080P_Q720P_QQ720P
42: 1080P_QQ720P_QQ720P
51: 960P_VGA_QVGA
52: 960P_QVGA_QVGA
53:VGA_VGA_QVGA
54: VGA_QVGA_QVGA
17: D1_CIF_CIF
20: CIF_CIF_CIF
Return
Success: Success
Fail: Error
Note:
The resolution of 720P is 1280x720
Page 9
9
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
The resolution of Q720P is 640x352
The resolution of QQ720P is 320x176
The resolution of 960P is 1280x960
The resolution of VGA is 640x480
The resolution of QVGA is 320x240
The resolution of 1080P is 1920x1080
Note:
720P_Q720P_QQ720P: It is 720P for first stream, Q720P for second
stream.
Note: This command will take some time for return value.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setvideoattr&-vinorm=N&-profile=1&-
videomode=32
getvencattr
Function
Get encoding information for camera video.
Privilege
admin, user, guest
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getvencattr &-chn=]
Param.
chn
Channel No.
11: The first stream.
12: The second stream.
Return
bps_1, bps_2
Bit rate.
fps_1, fps_2
Frame rate.
gop_1, gop_2
Key frame interval.
brmode_1, brmode_2
Encode mode:
0: CBR
1: VBR
imagegrade_1
imagegrade_2
Image quality.
width_1, width_2
The width of the video.
height_1, height_2
The hight of the video.
Note
Note: “_1” is for the first stream, “_2” is for the second stream.
Example
/cgi-bin/hi3510/param.cgi?cmd=getvencattr&-chn=11
Page 10
10
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
setvencattr
Function
Set encoding information for camera video.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setvencattr&-chn=&-bps=&-fps=&-b
rmode=&-imagegrade=&-gop=]
Param.
chn
Channel No.
11 is the first stream.
12 is the second stream.
bps
Bit rate
720P: The range is [32 ~ 6144 kbps]
1080P: The range is [32 ~ 8192 kbps]
D1: The range is [32 ~ 2048 kbps]
CIF: The range is [32 ~ 512 kbps]
QCIF: The range is [32 ~ 256 kbps]
VGA: The range is [32 ~ 2048 kbps]
QVGA: The range is [32 ~ 512 kbps]
QQVGA: The range is [32 ~ 256 kbps]
fps
Frame rate
PAL: The range is [1 ~ 25]
NTSC: The range is [1 ~ 30]
brmode
Encode mode value:
0: CBR
1: VBR
imagegrade
Image quality value: The range is [1 ~ 6]
Note: The smaller the value, the better the
image, and the greater to affect the video bit
rate.
gop
Key frame interval value: The range is [2 ~ 150]
Return
Success: Success
Fail: Error
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setvencattr&-chn=11&-bps=1536&-f
ps=25&-brmode=1&-imagegrade=1&-gop=50
/cgi-bin/hi3510/param.cgi?cmd=setvencattr&-chn=12&-bps=1536&-f
ps=25&-brmode=1&-imagegrade=1&-gop=50
/cgi-bin/hi3510/param.cgi?cmd=setvencattr&-chn=11&-bps=1536&-f
Page 11
11
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
ps=25
getimageattr
Function
Get the attributes of the image.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getimageattr]
Param.
None.
Return
brightness
The value for brightness.
saturation
The value for saturation.
contrast
The value for contrast.
sharpness
The value for sharpness.
hue
The value for hue.
targety
The value for target.
flip
The value for flip status:
on: enable.
off: disable
mirror
The status for mirror:
on: enable.
off: disable
night
The status for night vision:
on: enable.
off: disable
shutter
The value for shutter.
wdr
The status for WDR:
on: enable.
off: disable
noise
The status for denoise:
on: enable.
off: disable
gc
The value for gain control, the range is
[0-4294967295]
imgmode
The mode to improve the video:
0: Improve the video frame rate first.
1: Improve the image light first.
aemode
The value for AE control mode:
0: Auto, 1: Indoor, 2: Outdoor.
Page 12
12
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
display_mode
The current video mode for camera:
0: Black/White, 1: Colorful.
Note
Different devices will have different image parameters, please see
Appendix I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=getimageattr
setimageattr
Function
Set the attributes of the image.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setimageattr&-brightness=&-saturat
ion=&-contrast=&-hue=&-targety=&-flip=&-mirror=&-noise=&-imgmo
de=&-aemode=&-display_mode=&]
Param.
brightness
The value for brightness.
saturation
The value for saturation.
contrast
The value for contrast.
sharpness
The value for sharpness.
hue
The value for hue.
targety
The value for target.
flip
The value for flip status:
on: enable.
off: disable
mirror
The status for mirror:
on: enable.
off: disable
night
The status for night vision:
on: enable.
off: disable
shutter
The value for shutter.
wdr
The status for WDR:
on: enable.
off: disable
noise
The status for denoise:
on: enable.
off: disable
gc
The value for gain control, the range is
[0-4294967295]
Page 13
13
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
imgmode
The mode to improve the video:
0: Improve the video frame rate first.
1: Improve the image light first.
aemode
The value for AE control mode:
0: Auto, 1: Indoor, 2: Outdoor.
display_mode
The current video mode for camera:
0: Black/White, 1: Colorful.
Return
Success: Success.
Fail: Error.
Note
Different devices will have different image parameters, please see
Appendix I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=setimageattr&-brightness=1&-saturatio
n=1&-contrast=1&-hue=1&-flip=on&-mirror=on&-noise=on&-imgmode=
0&-aemode=0&-display_mode=1
getldcattr
Function
Get the distortion value of lens.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getldcattr]
Param.
None.
Return
ldc_ratio
The value for distortion, from 0 to 511.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getldcattr
setldcattr
Function
Set the distortion value of lens.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setldcattr&- ldc_ratio =]
Param.
ldc_ratio
The value for distortion, from 0 to 511.
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setldcattr&- ldc_ratio=1
Page 14
14
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
getircutattr
Function
Get the value for the automatic switch of the IR-CUT.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getircutattr]
Param.
None
Return
saradc_switch_value
The value for IR_Cut switch, from 1 to 1024.
Note
None.
Example
/cgi-bin/hi3510/param.cgi?cmd=getircutattr
setircutattr
Function
Set the value for the automatic switch of the IR-CUT.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setircutattr&-saradc_switch_value=]
Param.
saradc_switch_value
The value for IR_Cut switch, from 1 to 1024.
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setircutattr&-saradc_switch_value=700
getoverlayattr
Function
Get the imformation for OSD region.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getoverlayattr&-region=]
Param.
region
Region
0: OSD camera time.
1: OSD camera name.
Return
x_[region]
The x-coordinate for OSD region.
y_[region]
The y-coordinate for OSD region.
w_[region]
The width for OSD region.
h_[region]
The height for OSD region.
show_[region]
Whether to display the OSD region
0: Hidden
1: Diaplay
Page 15
15
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
name_[region]
OSD name
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getoverlayattr&-region=0
setoverlayattr
Function
Set the imformation for OSD region.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setoverlayattr&-region=&show=&name
=]
Param.
region
Region
0: OSD camera time.
1: OSD camera name.
show
Whether to display the OSD region
0: Hidden
1: Diaplay
name
OSD name, only support English, less then 16
characters.
Return
Success: Success.
Fail: Error.
Note
Note: region_0 time OSD region do support to set name.
Example
/cgi-bin/hi3510/param.cgi?cmd=setoverlayattr&-region=0&-show=0
/cgi-bin/hi3510/param.cgi?cmd=setoverlayattr&-region=1&-show=1&-na
me=IPCam
getmobilesnapattr
Function
Get image attributes for mobile phone.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getmobilesnapattr]
Param.
None
Return
msize
1: The max. resolution for the second stream.
2: The min. resolution for the second stream.
Note
Some kinds of devices do not support to set this attributes, please see
Appendix I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=getmobilesnapattr
Page 16
16
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
setmobilesnapattr
Function
Set image attributes for mobile phone.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setmobilesnapattr&-msize=]
Param.
msize
1: The max. resolution for the second stream.
2: The min. resolution for the second stream.
Return
Success: Success.
Fail: Error.
Note
Some kinds of devices do not support to set this attributes, please see
Appendix I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=setmobilesnapattr&-msize=1
getaencattr
Function
Get the encode attributes of audio.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getaencattr&-chn=]
Param.
chn
Channel No.:
11: The first stream.
12: The second stream.
Return
aeswitch_1, aeswitch_2
Whether to enable the switch for audio
encode:
0: Disable
1: Enable
aeformat_1, aeformat_2
The format for audio encode:
g711a: G711A, bit rate is 64Kbps
g726: G726 bit rate is 16Kbps
Note
1. _1 represents the first stream, _2 represents the second stream.
2. The sampling rate for audio is 8K, single track, 16 bit wide.
Example
/cgi-bin/hi3510/param.cgi?cmd=getaencattr&-chn=11
setaencattr
Function
Set the encode attributes of audio.
Privilege
admin
Page 17
17
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setaencattr&-chn=]
Param.
chn
Channel No.:
11: The first stream.
12: The second stream.
aeswitch
Whether to enable the switch for audio
encode:
0: Disable
1: Enable
aeformat
The format for audio encode:
g711a: G711A, bit rate is 64Kbps
g726: G726 bit rate is 16Kbps
Return
Success: Success.
Fail: Error.
Note
The sampling rate for audio is 8K, single track, 16 bit wide.
Example
/cgi-bin/hi3510/param.cgi?cmd=setaencattr&-chn=11&-aeswitch=0
/cgi-bin/hi3510/param.cgi?cmd=setaencattr&-chn=12&-aeswitch=1&-a
eformat=g726
getaudioinvolume
Function
Get the volume of the input audio.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getaudioinvolume]
Param.
None
Return
volume
The value of volumn, the range is [1-100]
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getaudioinvolume
setaudioinvolume
Function
Set the volume of the input audio.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setaudioinvolume&-volume=]
Param.
volume
The value of volumn, the range is [1-100]
Return
Success: Success.
Fail: Error.
Note
None
Page 18
18
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Example
/cgi-bin/hi3510/param.cgi?cmd=setaudioinvolume&-volume=80
getaudiooutvolume
Function
Get the volume of the output audio.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getaudiooutvolume]
Param.
None
Return
ao_volume
The value of volumn, the range is [1-100]
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getaudiooutvolume
setaudiooutvolume
Function
Set the volume of the output audio.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setaudiooutvolume&-volume=]
Param.
volume
The value of volumn, the range is [1-100]
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setaudiooutvolume&-volume=80
getaudiooutvolume
Function
Get the input type for audio.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getaudiooutvolume]
Param.
None
Return
volin_type
0: Line in
1: Mac in
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getaudiooutvolume
Page 19
19
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
setaudiooutvolume
Function
Set the input type for audio.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setaudiooutvolume&-volin_type=]
Param.
volin_type
0: Line in
1: Mac in
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setaudiooutvolume&-volin_type=0
requestifrm
Function
Request the key frame of next frame group.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=requestifrm&-chn=]
Param.
chn
Channel No.
11: The first stream. 12: The second stream.
Return
Success: Success.
Fail: Error.
Note
None.
Example
/cgi-bin/hi3510/param.cgi?cmd=requestifrm&-chn=11
2. IR Led control
getinfrared
Function
Get the status of IR LED switch.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getinfrared]
Param.
None
Return
infraredstat
IR Led status:
auto: Automatical switch as the changing of
outside light.
open: Force to open permanently.
Page 20
20
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
close: Force to close permanently.
Note
Some kinds of devices do not support to set this attribute, please see
Appendix I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=getinfrared
setinfrared
Function
Set the status of IR LED switch.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setinfrared]
Param.
None
Return
infraredstat
IR Led status:
auto: Automatical switch as the changing of
outside light.
open: Force to open permanently.
close: Force to close permanently.
Note
Some kinds of devices do not support to set this attributes, please see
Appendix I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=setinfrared&-infraredstat=auto
3. Network
getnetattr
Function
Get the attributes of camera network.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getnetattr]
Param.
None
Return
dhcpflag
DHCP status:
On: Enable
Off: Disable
ip
IP address
netmask
Subnet mask
gateway
Gatway
dnsstat
DNS Status:
0: Set manually.
Page 21
21
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
1: Obtain automatically.
fdnsip
First DNS
sdnsip
Reserve DNS
macaddress
MAC address
networktype
Network type:
LAN: Wired
WiFi: Wireless
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getnetattr
setnetattr
Function
Set the attributes of camera network.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setnetattr&-dhcp=&-ipaddr=&-netmask
=&-gateway=&-dnsstat=&-fdnsip=&-sdnsip=]
Param.
dhcp
DHCP status:
On: Enable
Off: Disable
ipaddr
IP address
netmask
Subnet mask
gateway
Gatway
dnsstat
DNS Status:
0: Set manually.
1: Obtain automatically.
fdnsip
First DNS
sdnsip
Reserve DNS
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setnetattr&-dhcp=off&-ipaddr=192.168.
1.88&-netmask=255.255.255.0&-gateway=192.168.1.1&-dnsstat=0&-fd
nsip=192.168.1.1&-sdnsip=
gethttpport
Function
Get the port of HTTP.
Page 22
22
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=gethttpport]
Param.
None
Return
httpport
HTTP port number.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=gethttpport
sethttpport
Function
Set the port of HTTP.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=sethttpport&-httpport=]
Param.
httpport
HTTP port number, the range is [80~65535]
Return
Success: Success.
Fail: Error.
Note
The camera will reboot automatically after modify its HTTP port.
Example
/cgi-bin/hi3510/param.cgi?cmd=sethttpport&-httpport=80
getrtspport
Function
Get the ports for RTSP and RTP.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getrtspport]
Param.
None
Return
rtspport
RTSP port
rtpport
RTP port
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getrtspport
setrtspport
Function
Set the ports for RTSP and RTP.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setrtspport&-rtspport=&-rtpport=]
Param.
rtspport
RTSP port number, the range is [80~65535]
rtpport
RTP port number, the range is [5000~8000]
Page 23
23
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Return
Success: Success.
Fail: Error.
Note
The camera will reboot automatically after modify its ports.
Example
/cgi-bin/hi3510/param.cgi?cmd=setrtspport&-rtspport=554&-rtpport=660
0
getrtspauth
Function
Get the status to verify authorization.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getrtspauth]
Param.
None
Return
rtsp_aenable
0: Disable
1: Enable
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getrtspauth
setrtspauth
Function
Set the status to verify authorization.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setrtspauth&- rtsp_aenable=]
Param.
rtsp_aenable
0: Disable
1: Enable
Return
Success: Success.
Fail: Error.
Note
The camera will reboot automatically after modify this status.
Example
/cgi-bin/hi3510/param.cgi?cmd=setrtspauth&-rtsp_aenable=1
getinterip
Function
Get the internet IP address of the camera network.
Privilege
admin
Usage
/ cgi-bin/param.cgi?cmd=getinterip
Param.
None
Return
interip
Internet IP, such as interip = "220.112.14.173"
Page 24
24
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Note
None
Example
/cgi-bin/param.cgi?cmd=getinterip
getupnpattr
Function
Get the status of UPNP enable.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getupnpattr]
Param.
None
Return
upm_enable
0: Disable
1: Enable
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getupnpattr
setupnpattr
Function
Set the status of UPNP enable.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setupnpattr&-upm_enable=]
Param.
upm_enable
0: Disable
1: Enable
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setupnpattr&-upm_enable=1
getonvifattr
Function
Get the attributes of Onvif.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getonvifattr]
Param.
None
Return
ov_enable
Onvif enable status:
1: Enable
0: Disable
ov_port
Onvif port number.
Page 25
25
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
ov_authflag
Authorization check status:
1: Enable
0: Disable
ov_forbitset
Enable status for onvif parameters:
0: Enable to set time zone, enable to set image
parameters.
1: Disable to set time zone, enable to set image
parameters.
2: Enable to set time zone, Disable to set image
parameters.
3: Disable to set time zone, Disable to set
image parameters.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getonvifattr
setonvifattr
Function
Set the attributes of Onvif.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setonvifattr&-ov_enable=&-ov_port=&
-ov_authflag=&-ov_forbitset=]
Param.
ov_enable
Onvif enable status:
1: Enable
0: Disable
ov_port
Onvif port number.
ov_authflag
Authorization check status:
1: Enable
0: Disable
ov_forbitset
Enable status for onvif parameters:
0: Enable to set time zone, enable to set image
parameters.
1: Disable to set time zone, enable to set image
parameters.
2: Enable to set time zone, Disable to set image
parameters.
3: Disable to set time zone, Disable to set image
parameters.
Page 26
26
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Return
Success: Success.
Fail: Error.
Note
The camera will reboot automatically after modify this onvif settings.
Example
/cgi-bin/hi3510/param.cgi?cmd=setonvifattr&-ov_enable=1&-ov_port=8
080&-ov_authflag=0&-ov_forbitset=0
4. Wireless
getwirelessattr
Function
Get the attributes of wireless.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getwirelessattr]
Param.
None
Return
wf_enable
Wireless status:
0: Disable
1: Enable
wf_ssid
SSID, less then 32 characters.
wf_auth
Security Mode:
0: None
1: WEP
2: WPA-PSK
3: WPA2-PSK
wf_key
Password
wf_enc
WPA Algorithm
0: TKIP
1: AES
wf_mode
Connection mode:
0: Router mode
1: Point to Point mode
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getwirelessattr
setwirelessattr
Function
Set the attributes of wireless.
Privilege
admin
Page 27
27
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setwirelessattr&-wf_enable=&-wf_ssid
=&-wf_auth=&-wf_key=&-wf_enc=&-wf_mode=]
Param.
wf_enable
Wireless status:
0: Disable
1: Enable
wf_ssid
SSID, less then 32 characters.
wf_auth
Security Mode:
0: None
1: WEP
2: WPA-PSK
3: WPA2-PSK
wf_key
Password
wf_enc
WPA Algorithm
0: TKIP
1: AES
wf_mode
Connection mode:
0: Router mode
1: Point to Point mode
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setwirelessattr&-wf_ssid=linksys&-wf_e
nable=1&-wf_auth=2&-wf_key=1234567890&-wf_enc=0&-wf_mode=0
searchwireless
Function
Search wireless AP.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=searchwireless]
Param.
None
Return
waccess_points
AP counts.
wchannel
Channel
wrssi
Signal strength
wessid
SSID
wenc
Security mode
wauth
WPA Algorithm
wnet
Connection mode (Router or Point to Point)
Page 28
28
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Note: If the waccess_points > 1, it means there are several AP, then it
will return a value for each segmens from wchannel to wnet of every AP.
For example:
var waccess_points="2" ;
var wchannel=new Array();
var wrssi=new Array();
var wessid=new Array();
var wenc=new Array();
var wauth=new Array();
var wnet=new Array();
wchannel[0]="6" ;
wrssi[0]="-82" ;
wessid[0]="Fumax wireless" ;
wenc[0]="AES" ;
wauth[0]="WPA(2)-PSK" ;
wnet[0]="Infra" ;
wchannel[1]="11" ;
wrssi[1]="-62" ;
wessid[1]="linksys" ;
wenc[1]="TKIP" ;
wauth[1]="WPA(2)-PSK" ;
wnet[1]="Infra" ;
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=searchwireless
chkwirelessattr
Function
Check wireless configuration is right or not.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=chkwirelessattr&-wf_ssid=&-wf_auth=&
-wf_key=&-wf_enc=&-wf_mode=]
Param.
wf_ssid
SSID, less then 32 characters.
wf_auth
Security mode :
0: None
1: WEP
2: WPA-PSK
Page 29
29
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
3: WPA2-PSK
wf_key
Password
wf_enc
WPA Algorithm
0: TKIP
1: AES
wf_mode
Connection mode:
0: Router mode
1: Point to Point mode
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=chkwirelessattr&-wf_ssid=linksys&-wf_
auth=3&-wf_key=1234567890&-wf_enc=0&-wf_mode=0
getchkwireless
Function
Get the check result for wifi configurations.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getchkwireless]
Param.
None
Return
chkres
The status for wifi connection:
0: Fail
1: Success
Note
Please run chkwirelessattr command first before use this cgi.
Example
/cgi-bin/hi3510/param.cgi?cmd=getchkwireless
5. DDNS
get3thddnsattr
Function
Get the DDNS attributes of third paryt.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=get3thddnsattr]
Param.
None
Return
d3th_enable
The status for third-party DDNS:
0: Disable
Page 30
30
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
1: Enable
d3th_service
The type of third-party DDNS provider:
0: dyndns.org
1: 322.org
2: dynddns.us
3: No-ip.com
d3th_uname
Username
d3th_passwd
Password
d3th_domain
Domain
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=get3thddnsattr
set3thddnsattr
Function
Set the DDNS attributes of third paryt.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=set3thddnsattr.&-d3th_enable=&-d3th_
service=&-d3th_uname=&-d3th_passwd=&-d3th_domain=]
Param.
d3th_enable
The status for third-party DDNS:
0: Disable
1: Enable
d3th_service
The type of third-party DDNS provider:
0: dyndns.org
1: 322.org
2: dynddns.us
3: No-ip.com
d3th_uname
Username
d3th_passwd
Password
d3th_domain
Domain
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=set3thddnsattr&-d3th_enable=1&-d3th_
service=1&-d3th_uname=sample&-d3th_passwd=1234&-d3th_domain=
sample.dyndns.org
Page 31
31
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
6. PTZ control
ptzctrl
Function
The control for PTZ motion.
Privilege
admin, user
Usage
/cgi-bin/hi3510/param.cgi?cmd=ptzctrl.cgi[&-step=&-act=&-speed=]
Param.
step
Stepping mode:
0: Signle step and stop until stop command.
1: Single step and stop automatically.
act
Command strings for motion control:
left: Go to left.
right: Go to right.
up: Go to up.
Down: Go to down
upleft, upright, downleft, downright: Go to upleft,
upright, downleft, downright
home: Back to center point.
zoomin: Zoom in.
zoomout: Zoom out.
hscan: The curise of horizontal.
vscan: The curise of vertical.
stop: Stop.
speed
Speed for motion, the value is [1~63].
Return
Success: Success.
Fail: Error.
Note
Different device types may have different parameters for PTZ, please
see Appendix I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=ptzctrl&-step=0&-act=left&-speed=45
preset
Function
Set the attributes for preset.
Privilege
admin, user
Usage
/cgi-bin/hi3510/param.cgi?cmd=preset[&-act=&-status=&-number=]
Param.
act
Command strings:
goto: Call and go to the preset point.
Page 32
32
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
set: Set the preset point.
status
Set the status for preset point:
0: Clear the preset point.
1: Save the preset point.
number
The No for the preset.
Return
Success: Success.
Fail: Error.
Note
Different device type may have different count of preset.
Example
/cgi-bin/hi3510/param.cgi?cmd=preset&-act=goto&-number=1
/cgi-bin/hi3510/param.cgi?cmd=preset&-act=set&-status=1&-number=1
getmotorattr
Function
Get the attributes for PTZ.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getmotorattr]
Param.
None
Return
panspeed
Speed of Pan:
0: Fast
1: Medium
2: Slow
tiltspeed
Speed of Tilt
0: Fast
1: Medium
2: Slow
panscan
The number for horizontal cruise.
tiltscan
The number for vertical cruise.
movehome
Back to center after self-check:
on: Enable
off: Disable
ptzalarmmask
Close the motion alarm while PTZ is moving.
on: Enable
off: Disable
alarmpresetindex
Alarm link action for going to preset, the preset
number is [1-8].
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getmotorattr
Page 33
33
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
setmotorattr
Function
Set the attributes for PTZ.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setmotorattr&-panspeed=&-tiltspeed=&
-panscan=&-tiltscan=&-movehome=&-ptzalarmmask=&-alarmpresetind
ex=]
Param.
panspeed
Speed of Pan:
0: Fast
1: Medium
2: Slow
tiltspeed
Speed of Tilt
0: Fast
1: Medium
2: Slow
panscan
The number for horizontal cruise.
tiltscan
The number for vertical cruise.
movehome
Back to center after self-check:
on: Enable
off: Disable
ptzalarmmask
Close the motion alarm while PTZ is moving.
on: Enable
off: Disable
alarmpresetindex
Alarm link action for going to preset, the preset
number is [1-8].
Return
Success: Success.
Fail: Error.
Note
They must be the same for the speed of Pan and Tilt. And they must be
the same for the number of horizontal and vertical curise.
Example
/cgi-bin/hi3510/param.cgi?cmd=setmotorattr&-panspeed=1&-tiltspeed=
1&-panscan=1&-tiltscan=1&-movehome=on&-ptzalarmmask=on&-alar
mpresetindex=1
getmotorrange
Function
Get the attributes of PTZ motor type.
Page 34
34
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getmotorrange]
Param.
None
Return
motortype
0: Default, include a travel switch.
1: Do not have a travel switch.
panrange
Step length for pan.
tiltrange
Step length for Tilt.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getmotorrange
setmotorrange
Function
Set the attributes of PTZ motor type.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setmotorrange&-motortype=&-panrang
e=&-tiltrange=]
Param.
motortype
0: Default, include a travel switch.
1: Do not have a travel switch.
panrange
Step length for pan.
tiltrange
Step length for Tilt.
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setmotorrange&-motortype=0&-panran
ge=580&-tiltrange=150
getptzcomattr
Function
Get the PTZ common attributes.
Privilege
admin, user
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getptzcomattr]
Param.
None
Return
protocal
Protocol type:
0：PELCO-D
1：PELCO-P
address
Address code, the range is [0~255].
Page 35
35
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
baud
Baud rate, 1200, 2400, 4800, 9600, 19200,
38400, 57600.
databit
Data bits, 7 or 8.
stopbit
Stop bits, 1 or 2.
check
The method to verify:
0: None
1: Odd parity check.
2: Even parity check.
3: Mark
4: Blank space.
Note
Some kinds of device do not support this attribute, please see Appendix
I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=getptzcomattr
setptzcomattr
Function
Set the PTZ common attributes.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setptzcomattr&-protocal=&-address=&baud=&-databit=&-stopbit=&-check=]
Param.
protocal
Protocol type:
0：PELCO-D
1：PELCO-P
address
Address code, the range is [0~255].
baud
Baud rate, 1200, 2400, 4800, 9600, 19200,
38400, 57600.
databit
Data bits, 7 or 8.
stopbit
Stop bits, 1 or 2.
check
The method to verify:
0: None
1: Odd parity check.
2: Even parity check.
3: Mark
4: Blank space.
Return
Success: Success.
Fail: Error.
Note
Some kinds of device do not support this attribute, please see Appendix
Page 36
36
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=setptzcomattr&-protocal=0&-address=1
&-baud=9600&-databit=8&-stopbit=1&-check=0
ptzup.cgi
Function
Let the PT go to up, used for the control on mobile phone.
Privilege
admin, user
Usage
/cgi-bin/hi3510/ptzup.cgi
Param.
None
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/ptzup.cgi
ptzdown.cgi
Function
Let the PT go to down, used for the control on mobile phone.
Privilege
admin, user
Usage
/cgi-bin/hi3510/ptzdown.cgi
Param.
None
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/ptzdown.cgi
ptzleft.cgi
Function
Let the PT go to left, used for the control on mobile phone.
Privilege
admin, user
Usage
/cgi-bin/hi3510/ptzleft.cgi
Param.
None
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/ptzleft.cgi
Page 37
37
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
ptzright.cgi
Function
Let the PT go to right, used for the control on mobile phone.
Privilege
admin, user
Usage
/cgi-bin/hi3510/ptzright.cgi
Param.
None
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/ptzright.cgi
ptzzoomin.cgi
Function
Let the PTZ to zoom in, used for the control on mobile phone.
Privilege
admin, user
Usage
/cgi-bin/hi3510/ptzzoomin.cgi
Param.
None
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/ptzzoomin.cgi
ptzzoomout.cgi
Function
Let the PTZ to zoom out, used for the control on mobile phone.
Privilege
admin, user
Usage
/cgi-bin/hi3510/ptzzoomout.cgi
Param.
None
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/ptzzoomout.cgi
getlightattr
Function
Get the status for indicator light LED.
Page 38
38
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getlightattr]
Param.
None
Return
light_enable
The status for indocator light:
on: The LED always light.
off: The LED always go out.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getlightattr
setlightattr
Function
Set the status for indicator light LED.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setlightattr]
Param.
None
Return
light_enable
The status for indocator light:
on: The LED always light.
off: The LED always go out.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setlightattr&-light_enable=on
7. Motion detection and I/O alram
getmdattr
Function
Get the attributes for motion detection.
Privilege
admin
Usage
cgi-bin/hi3510/param.cgi[?cmd=getmdattr]
Param.
None
Return
m1_enable
The status of motion detection of area 1:
0: Disable
1: Enable
m1_x
X-coordinate for area 1.
m1_y
Y-coordinate for area 1.
m1_w
The width for area 1.
m1_h
The height for area 1.
Page 39
39
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
m1_sensitivity
The sensitivity for area 1.
m1_threshold
Reserved
m2_enable
The status of motion detection of area 2:
0: Disable
1: Enable
m2_x
X-coordinate for area 2.
m2_y
Y-coordinate for area 2.
m2_w
The width for area 2.
m2_h
The height for area 2.
m2_sensitivity
The sensitivity for area 2.
m2_threshold
Reserved
m3_enable
The status of motion detection of area 3:
0: Disable
1: Enable
m3_x
X-coordinate for area 3.
m3_y
Y-coordinate for area 3.
m3_w
The width for area 3.
m3_h
The height for area 3.
m3_sensitivity
The sensitivity for area 3.
m3_threshold
Reserved
m4_enable
The status of motion detection of area 4:
0: Disable
1: Enable
m4_x
X-coordinate for area 4.
m4_y
Y-coordinate for area 4.
m4_w
The width for area 4.
m4_h
The height for area 4.
m4_sensitivity
The sensitivity for area 4.
m4_threshold
Reserved
Note
The width and height for the area is based on the max. resolution of
camera.
Example
/cgi-bin/hi3510/param.cgi?cmd=getmdattr
setmdattr
Function
Set the attributes for motion detection.
Privilege
admin
Page 40
40
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setmdattr&-enable=&-s=&-name=&-x=
&-y=&-w=&-h=]
Param.
enable
The status of motion detection:
0: Disable
1: Enable
s
Sensitivity, the range is [1 ~ 100].
name
Area number, the rang is [1 ~ 4]
x
X-coordinate for detection area.
y
Y-coordinate for detection area.
w
The width for detection area.
h
The height for detection area.
Return
Success: Success.
Fail: Error.
Note
The width and height for the area is based on the max. resolution of
camera.
Example
/cgi-bin/hi3510/param.cgi?cmd=setmdattr&-enable=1&-s=50&-name=1
&-x=0&-y=0&-w=60&-h=60
getioattr
Function
Get the attributes for I/O alarm.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getioattr]
Param.
None
Return
io_enable
Whether to allow the I/O alarm or not:
0: Disable, do not allow.
1: Enable, allow.
io_flag
The trigger mode for I/O alarm:
0: Always close.
1: Always open.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getioattr
setioattr
Function
Set the attributes for I/O alarm.
Privilege
admin
Page 41
41
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setioattr &-io_enable=&-io_flag=]
Param.
io_enable
Whether to allow the I/O alarm or not:
0: Disable, do not allow.
1: Enable, allow.
io_flag
The trigger mode for I/O alarm:
0: Always close.
1: Always open.
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setioattr&-io_enable=0&-io_flag=1
getaudioalarmattr
Function
Get the attributes for audio alarm.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getaudioalarmattr]
Param.
None
Return
aa_enable
Whether to allow the audio alarm or not:
0: Disable, do not allow.
1: Enable, allow.
aa_value
Sensitivity value, the range is [1-100]. Much
bigger will be much more sensitivity.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getaudioalarmattr
setaudioalarmattr
Function
Set the attributes for audio alarm.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setaudioalarmattr&-aa_enable=&-aa_v
alue=]
Param.
aa_enable
Whether to allow the audio alarm or not:
0: Disable, do not allow.
1: Enable, allow.
aa_value
Sensitivity value, the range is [1-100]. Much
bigger will be much more sensitivity.
Page 42
42
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setaudioalarmattr&-aa_enable=0&-aa_
value=50
getmdalarm
Function
Get the attributes for alarm link actions.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getmdalarm&-aname=]
Param.
aname
Link action name:
Email: E-mail alarm
Emailsnap: E-mail alarm with snapshots.
Snap: Save snapshots to SD card.
Ftpsnap: Save snapshots to FTP server.
record: Save video to SD card.
ftprec: Save video to FTP server.
relay: Relay output.
server: Alarm server.
preset: Actions for preset of PT.
Return
md_email_switch
Whether to allow the email alarm:
on: Enable, allow.
off: Disable, do not allow.
md_emailsnap_switch
Whether to allow the email alarm with
snapshots:
on: Enable, allow.
off: Disable, do not allow.
md_snap_switch
Whether to allow to save snapshots to SD
card:
on: Enable, allow.
off: Disable, do not allow.
md_ ftpsnap _switch
Whether to allow to save snapshots to FTP
server:
on: Enable, allow.
off: Disable, do not allow.
md_record_switch
Whether to allow to save video to SD card:
Page 43
43
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
on: Enable, allow.
off: Disable, do not allow.
md_ftprec_switch
Whether to allow to save video to FTP server:
on: Enable, allow.
off: Disable, do not allow.
md_relay_switch
Whether to allow the relay output:
on: Enable, allow.
off: Disable, do not allow.
md_server_switch
Whether to allow to enable the alarm server:
on: Enable, allow.
off: Disable, do not allow.
md_preset_switch
Whether to allow the preset action for alarm:
on: Enable, allow.
off: Disable, do not allow.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getmdalarm&-aname=email&cmd=get
mdalarm&-aname=emailsnap&cmd=getmdalarm&-aname=ftpsnap&cm
d=getmdalarm&-aname=snap&cmd=getmdalarm&-aname=emailrec&c
md=getmdalarm&-aname=record&cmd=getmdalarm&-aname=ftprec&c
md=getmdalarm&-aname=relay&cmd=getmdalarm&-aname=server&c
md=getmdalarm&-aname=preset
setmdalarm
Function
Set the attributes for alarm link actions.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setmdalarm &-aname=&-switch=]
Param.
aname
Link action name:
Email: E-mail alarm
Emailsnap: E-mail alarm with snapshots.
Snap: Save snapshots to SD card.
Ftpsnap: Save snapshots to FTP server.
record: Save video to SD card.
ftprec: Save video to FTP server.
relay: Relay output.
server: Alarm server.
preset: Actions for preset of PT.
Page 44
44
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
switch
Action status:
on: Enable
off: Disable
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setmdalarm&-aname=email&-switch=of
f&cmd=setmdalarm&-aname=emailsnap&-switch=off&cmd=setmdalarm
&-aname=ftprec&-switch=off&cmd=setmdalarm&-aname=snap&-switch
=off&cmd=setmdalarm&-aname=ftpsnap&-switch=off&cmd=setmdalar
m&-aname=record&-switch=off&cmd=setmdalarm&-aname=relay&-swit
ch=off&cmd=setmdalarm&-aname=server&-switch=off&cmd=setmdalar
m&-aname=preset&-switch=off
getrelayattr
Function
Get the relay output time for alarm link action.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getrelayattr]
Param.
None
Return
time
Output time, the unit is second, var time="10";
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getrelayattr
setrelayattr
Function
Set the relay output time for alarm link action.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setrelayattr&-time=]
Param.
time
Output time, the unit is second , include [5, 10,
20, 30]
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setrelayattr&-time=10
Page 45
45
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
getmotorattr
Function
Get the preset number for alarm action.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getmotorattr]
Param.
None
Return
alarmpresetindex
Preset name or number, the range is [1-8].
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getmotorattr
setmotorattr
Function
Set the preset number for alarm action.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setmotorattr&-alarmpresetindex=]
Param.
alarmpresetindex
Preset name or number, the range is [1-8].
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setmotorattr&-alarmpresetindex=2
getalarmsnapattr
Function
Get the count for alarm snapshots.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getalarmsnapattr]
Param.
None
Return
snap_count
The count for snapshots of alarm.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getalarmsnapattr
setalarmsnapattr
Function
Set the count for alarm snapshots.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setalarmsnapattr&-snap_count=]
Page 46
46
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Param.
snap_count
Count for snapshots, the range is [1、2、3]
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setalarmsnapattr&-snap_count=2
getscheduleex
Function
Get the time schedule for motion alarm and scheduled snap.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getscheduleex&-ename=]
Param.
ename
Schedule name:
md : Schedule for motion detection.
Snap: Schedule for planed snap.
Return
week0=PPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
P
week1=PPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
P
week3=PPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
P
week4=PPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
P
week5=PPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
week0: Sunday
week1: Monday
week2: Tuesday
week3: Wednesday
week4: Thursday
week5: Friday
week6: Saturday
P : Represents enable
N : Represents disable
Page 47
47
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
PPPPPPPPPPPPP
P
week6=PPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
P
Note
48 characters in –week0~-week6 represent 24 hours for one day from
0:00-23:30, each character represents a half hour. Character P means
enable alarm in this half a hour, N means disable alarm in this half a
hour.
Example
/cgi-bin/hi3510/param.cgi?cmd=getscheduleex&-ename=md
/cgi-bin/hi3510/param.cgi?cmd=getscheduleex&-ename=snap
setscheduleex
Function
Set the time schedule for motion alarm and scheduled snap.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setscheduleex&-ename=&-week0=&-w
eek1=&-week2=&-week3=&-week4=&-week5=&-week6=]
Param.
ename
Schedule name:
md : Schedule for motion detection.
Snap: Schedule for planed snap.
week0=PPPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
PPPPPPPPPPPPP
48 characters in –week0~-week6 represent 24
hours for one day from 0:00-23:30, each
character represents a half hour. Character P
means enable alarm in this half a hour, N
means disable alarm in this half a hour.
week0
week1
week2
week3
week4
week5
week6
week0: Sunday
week1: Monday
week2: Tuesday
week3: Wednesday
week4: Thursday
week5: Friday
week6: Saturday
P : Represents enable
N : Represents disable
Return
Success: Success.
Page 48
48
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Fail: Error.
Note
48 characters in –week0~-week6 represent 24 hours for one day from
0:00-23:30, each character represents a half hour. Character P means
enable alarm in this half a hour, N means disable alarm in this half a
hour.
Example
/cgi-bin/hi3510/param.cgi?cmd=setscheduleex&-ename=md&-week0=
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
PPP&-week1=PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
PPPPPPPPPPPPP&
/cgi-bin/hi3510/param.cgi?cmd=setscheduleex&-ename=snap&-week0
=PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
PPPP &
getalarmsnapattr
Function
Get the attributes for snapshot.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getalarmsnapattr]
Param.
None
Return
snap_name_mode
How to name the snapshot?
0 : Name by date.
1: A fixed name.
snap_alarm_name
File name for snapshot of alarm.
snap_timer_name
File name for snapshot of planning snap.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getalarmsnapattr
setalarmsnapattr
Function
Set the attributes for snapshot.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setalarmsnapattr&-snap_name_mode
=&-snap_alarm_name=&-snap_timer_name=]
Param.
snap_name_mode
How to name the snapshot?
0 : Name by date.
1: A fixed name.
snap_alarm_name
File name for snapshot of alarm.
Page 49
49
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
snap_timer_name
File name for snapshot of planning snap.
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setalarmsnapattr&-snap_name_mode=
1&-snap_alarm_name=snapalarm&-snap_timer_name=snaptime
getplanrecattr
Function
Get the attributes for scheduled recording.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd= getplanrecattr]
Param.
None
Return
planrec_enable
Whether to enable the recording:
0: Disable
1: Enable
planrec_time
Time length for recoding, the range is [15-900]
seconds.
planrec_chn
The stream channel for recording, 11, 12, 13
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getplanrecattr
setplanrecattr
Function
Set the attributes for scheduled recording.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setplanrecattr&-planrec_enable=&-pla
nrec_time&-planrec_chn]
Param.
planrec_enable
Whether to enable the recording:
0: Disable
1: Enable
planrec_time
Time length for recoding, the range is [15-900]
seconds.
planrec_chn
The stream channel for recording, 11, 12, 13
Return
Success: Success.
Fail: Error.
Page 50
50
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Note
The camera will reboot automatically after modify the recording channel.
Example
/cgi-bin/hi3510/param.cgi?cmd=setplanrecattr&-planrec_enable=1&-pl
anrec_time=30&-planrec_chn=12
getalarmserverattr
Function
Get the attributes for alarm server.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getalarmserverattr]
Param.
None
Return
as_server
Server address.
as_port
Server port, the range is [1-65535]
as_username
Username
as_password
Password
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getalarmserverattr
setalarmserverattr
Function
Set the attributes for alarm server.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setalarmserverattr&-as_server=&-as_
port=&-as_username=&-as_password=]
Param.
as_server
Server address.
as_port
Server port, the range is [1-65535]
as_username
Username
as_password
Password
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setalarmserverattr&-as_server=alarm.n
et&-as_port=8990&-as_username=asdf&-as_password=1234
Page 51
51
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
relayctrl
Function
Enable or disable the relay manually.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=relayctrl&-act=]
Param.
act
on: Enable
off: Disable
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=relayctrl&-act=on
8. Privacy masking
getcover
Function
Get the attributes for masking.
Privilege
admin
Usage
cgi-bin/hi3510/param.cgi[?cmd=getcover]
Param.
None
Return
show_1
Whether to enable privacy masking for area 1:
0: Disable
1: Enable
color_1
The masking color for area 1.
x_1
X-coordinate for area 1.
y_1
Y-coordinate for area 1.
w_1
The width for area 1.
h_1
The heigth for area 1.
show_2
Whether to enable privacy masking for area 2:
0: Disable
1: Enable
color_2
The masking color for area 2.
x_2
X-coordinate for area 2.
y_2
Y-coordinate for area 2.
w_2
The width for area 2.
h_2
The heigth for area 2.
Page 52
52
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
show_3
Whether to enable privacy masking for area 3:
0: Disable
1: Enable
color_3
The masking color for area 3.
x_3
X-coordinate for area 3.
y_3
Y-coordinate for area 3.
w_3
The width for area 3.
h_3
The heigth for area 3.
show_4
Whether to enable privacy masking for area 4:
0: Disable
1: Enable
color_4
The masking color for area 4.
x_4
X-coordinate for area 4.
y_4
Y-coordinate for area 4.
w_4
The width for area 4.
h_4
The heigth for area 4.
Note
The coordinate/width/height are based on the max. resolution of the
camera.
Example
/cgi-bin/hi3510/param.cgi?cmd=getcover
setcover
Function
Set the attributes for masking.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setcover&-show=&-region=&-color=&x=&-y=&-w=&-h=]
Param.
show
Whether to enable privacy masking:
0: Disable
1: Enable
region
Area number for maksing, [1 ~ 4]
color
Masking color.
x
X-coordinate for masking.
y
Y-coordinate for masking.
w
The width for masking.
h
The heigth for masking.
Return
Success: Success.
Fail: Error.
Page 53
53
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Note
The coordinate/width/height are based on the max. resolution of the
camera.
Example
/cgi-bin/hi3510/param.cgi?cmd=setcover&-show=1&-region=1&-color=0
00000&-x=0&-y=0&-w=50&-h=50
9. Multi-screens
getdevices
Function
Get the attributes for multi-screen.
Privilege
admin, user, guest
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getdevices]
Param.
None
Return
d_host[0]=""
d_alias[0]=""
d_port[0]="80"
d_username[0]=""
d_password[0]=""
d_host[1]=""
d_alias[1]=""
d_port[1]="80"
d_username[1]=""
d_password[1]=""
d_host[2]=""
d_alias[2]=""
d_port[2]="80"
d_username[2]=""
d_password[2]=""
d_host[3]=""
d_alias[3]=""
d_port[3]="80"
d_username[3]=""
d_password[3]=""
Camera IP address for screen-x.
Camera name for screen-x.
Camera HTTP port for screen-x.
Camera username for screen-x.
Camera password for screen-x.
X should be 1-9 which represents the screen
from channel 1 to channel 9.
Page 54
54
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
d_host[4]=""
d_alias[4]=""
d_port[4]="80"
d_username[4]=""
d_password[4]=""
d_host[5]=""
d_alias[5]=""
d_port[5]="80"
d_username[5]=""
d_password[5]=""
d_host[6]=""
d_alias[6]=""
d_port[6]="80"
d_username[6]=""
d_password[6]=""
d_host[7]=""
d_alias[7]=""
d_port[7]="80"
d_username[7]=""
d_password[7]=""
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getdevices
setdevices
Function
Set the attributes for multi-screen.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setdevices&-d_number=&-d_alias=
&-d_host=&-d_port=&-d_username=&-d_password=]
Param.
d_number
Screen number, the range is 0-8.
d_host
The IP address of camera.
d_alias
Camera name.
d_port
The HTTP port for camera.
d_username
The username of camera.
Page 55
55
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
d_password
The password of camera.
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setdevices&-d_number=0&-d_alias=I
PCamer&-d_host=192.168.1.88&-d_port=80&-d_username=admin&-d
_password=admin
10. User management.
getuserattr
Function
Get the attributes of users.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getuserattr]
Param.
None
Return
at_name
The username of camera.
at_password
The password of camera.
Note
This command will return all user information, such as username and
password:
var at_name0="admin";
var at_password0="admin";
var at_name1="user";
var at_password1="user";
var at_name2="guest";
var at_password2="guest";
Example
/cgi-bin/hi3510/param.cgi?cmd=getuserattr
setuserattr
Function
Set the attributes of users.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setuserattr&-at_username=&-at_new
name= &-at_password =]
Param.
at_username
The current username, less then 16 characters.
at_newname
The new username, less then 16 characters.
at_password
The password, less then 16 characters.
Page 56
56
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setuserattr&-at_username=admin&-at_
newname=newname&-at_password=admin
getsetupflag
Function
Get the attributes of admin user.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi?cmd=getsetupflag
Param.
None
Return
name0
Username
password0
Password
authLevel0
Reserved
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getsetupflag
getstreamflag
Function
Get the attributes of guest user.
Privilege
guest
Usage
/cgi-bin/hi3510/ param.cgi?cmd=getstreamflag
Param.
None
Return
name2
Username
password2
Password
authLevel2
Reserved
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getstreamflag
getptzflag
Function
Get the attributes of user account.
Privilege
user
Usage
/cgi-bin/hi3510/param.cgi?cmd=getptzflag
Param.
None
Page 57
57
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Return
name1
Username
password1
Password
authLevel1
Reserved
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getptzflag
getuserinfo
Function
Get the online user information.
Privilege
admin, user, guest
Usage
/cgi-bin/hi3510/param.cgi?cmd=getuserinfo
Param.
None
Return
name
Username
password
Password
authLevel
The authorization level:
15: admin
3: user
1: guest
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getuserinfo
11. Scheduled snapshot
getsnaptimerattrex
Function
Get the attributes for scheduled snapshot.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getsnaptimerattrex]
Param.
None
Return
as_snap_enable
as_snap_interval
Whether to save snapshots to SD card:
0: Disable
1: Enable
Time interval, the unit is second, the range is
[5~86400].
Page 58
58
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
as_email_enable
as_email_interval
Whether to send snapshots to E-mail:
0: Disable
1: Enable
Time interval, the unit is second, the range is
[5~86400].
as_ftp_enable
as_ftp_interval
Whether to upload snapshots to FTP server:
0: Disable
1: Enable
Time interval, the unit is second, the range is
[5~86400].
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getsnaptimerattrex
setsnaptimerattrex
Function
Set the attributes for scheduled snapshot.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setsnaptimerattrex&-as_enable=&-as
_interval=&-as_type=]
Param.
as_enable
Whether to enable the scheduled snapshot?
0: Disable
1: Enable
as_interval
Time interval for snap, the range is [5~86400]
seconds.
as_type
Link actions:
snap: Save snapshots to SD card.
email: Send snapshots to E-mail.
ftp: Upload snapshots to FTP server.
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setsnaptimerattrex&-as_enable=1&as_interval=60&-as_type=snap
Page 59
59
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
12. FTP
getftpattr
Function
Get the attributes of FTP setting.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getftpattr]
Param.
None
Return
ft_server
Server address.
ft_port
Server port.
ft_username
Username.
ft_password
Password.
ft_dirname
Storage path.
ft_mode
Whether to enable the passive mode?
0: Diasble
1: Enable
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getftpattr
setftpattr
Function
Set the attributes of FTP setting.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getftpattr&-ft_server=&-ft_port=&-ft_
username=&-ft_password=&- ft_dirname =&-ft_mode=]
Param.
ft_server
Server address.
ft_port
Server port.
ft_username
Username.
ft_password
Password.
ft_dirname
Storage path.
ft_mode
Whether to enable the passive mode?
0: Diasble
1: Enable
Return
Success: Success.
Fail: Error.
Note
None
Page 60
60
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Example
/cgi-bin/hi3510/param.cgi?cmd=setftpattr&-ft_server=220.112.14.173
&-ft_port=21&-ft_username=FTPUsername&-ft_password=FTPPasswo
rd&- ft_dirname =Program Files&-ft_mode=1
testftp
Function
Test the FTP setting.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=testftp]
Param.
None
Return
result
Return value:
0: Success.
-1: Unknow error.
-2: Can not connect the FTP server.
-3: Username and password do not match.
-4: The storage path is error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=testftp
13. SMTP
getsmtpattr
Function
Get the SMTP setting.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getsmtpattr]
Param.
None
Return
ma_server
SMTP server address.
ma_port
Server port.
ma_ssl
Authentication link:
0: None.
1: SSL.
2: TLS.
3: STARTTLS.
ma_logintype
Whether to enable the check of authentication:
1: Enable
Page 61
61
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
3: Disable
ma_username
Username
ma_password
Password
ma_from
The email address of sender.
ma_to
The email address of receiver.
ma_subject
The email subject.
ma_text
The email content.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getsmtpattr
setsmtpattr
Function
Set the SMTP setting.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setsmtpattr&-ma_server=&-ma_port=
&-ma_ssl=&-ma_logintype=&-ma_username=&-ma_password=&-ma_
from=&-ma_to=&-ma_subject=&-ma_text=]
Param.
ma_server
SMTP server address.
ma_port
Server port.
ma_ssl
Authentication link:
0: None.
1: SSL.
2: TLS.
3: STARTTLS.
ma_logintype
Whether to enable the check of authentication:
1: Enable
3: Disable
ma_username
Username
ma_password
Password
ma_from
The email address of sender.
ma_to
The email address of receiver.
ma_subject
The email subject.
ma_text
The email content.
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setsmtpattr&-ma_server=stmp.sdf.co
Page 62
62
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
m&[email protected]&[email protected]&-ma_subject=de
mosubject&-ma_text=demotext&-ma_logintype=1&-ma_username=de
mo&-ma_password=123456&-ma_port=25&-ma_ssl=0
testsmtp
Function
Test the SMTP setting.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=smtp]
Param.
None
Return
result
Return value:
0: Success.
-1: Unknow error.
-2: SSL error.
-3: None, can not to connect the server.
-4: The username and password do not match.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=testsmtp
14. System setting
getserverinfo
Function
Get the attributes of camera.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getserverinfo]
Param.
None
Return
model
Model SN number of camera.
hardVersion
Hardware version.
softVersion
Software version.
webVersion
Web version.
name
Camera name.
startdate
The start date of system running.
upnpstatus
Ok: Success
off: Disable
Page 63
63
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
failed: Fail
facddnsstatus
The status of the DDNS from camera factory.
Ok: Success
off: Disable
failed: Fail
th3ddnsstatus
The status of the DDNS from third-party.
Ok: Success
off: Disable
failed: Fail
runtimes
Reserved
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getserverinfo
getdevtype
Function
Get the device type of camera.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getdevtype]
Param.
None
Return
devtype
Device type.
Note
See appendix I for reference.
Example
/cgi-bin/hi3510/param.cgi?cmd=getdevtype
getstreamnum
Function
Get the count of users online.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getstreamnum]
Param.
None
Return
stream_num
Count for users, var stream_num = "1" ;
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getstreamnum
getservertime
Function
Get the start time of system running.
Page 64
64
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getservertime]
Param.
None
Return
time
The current time,
[yyyy][mm][dd][hh][mm][ss]
For example, time="20110802182638";
timeZone
Time zone, timeZone="Asia/Hong_Kong";
dstmode
Whether to enable the DST:
on: Enable
off: Disable
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getservertime
setservertime
Function
Set the time of camera system.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setservertime&-time=&-timezone=&-ds
tmode=]
Param.
stime
Current time:
[yyyy].[mm].[dd].[hh].[mm].[ss]
For example, 2011.08.23.10.35.08
timezone
Time zone, like timeZone="Asia/Hong_Kong"；
Please see appendix II for reference.
dstmode
Whether to enable the DST:
on: Enable
off: Disable
Return
Success: Success.
Fail: Error.
Note
The DST is not used for all time zone.
Example
/cgi-bin/hi3510/param.cgi?cmd=setservertime&-time=2011.08.23.10.35.
08&-timezone=Asia%2FHong_Kong&-dstmode=off
getntpattr
Function
Get the attributes of NTP.
Privilege
admin
Page 65
65
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Usage
/cgi-bin/hi3510/param.cgi[?cmd=getntpattr]
Param.
None
Return
ntpenable
Whether to enable the NTP:
1: Enable
0: Disable
ntpserver
NTP Server name:
time.nist.gov
time.kriss.re.kr
time.windows.com
time.nuri.net
ntpinterval
The interval for NTP time synchronization.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=getntpattr
setntpattr
Function
Set the attributes of NTP.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=setntpattr&-ntpenable=&-ntpserver=&ntpinterval=]
Param.
ntpenable
Whether to enable the NTP:
1: Enable
0: Disable
ntpserver
NTP Server name:
time.nist.gov
time.kriss.re.kr
time.windows.com
time.nuri.net
ntpinterval
The interval for NTP time synchronization, the
range is [1-24] hours.
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=setntpattr&-ntpenable=1&-ntpinterval=2
&-ntpserver=time.nuri.net
Page 66
66
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
web/tmpfs/auto.jpg
Function
Snap pictures in web browser.
Privilege
Admin, user, guest
Usage
/web/tmpfs/auto.jpg
Param.
None
Return
Note
None
Example
http://192.168.1.183/cgi-bin/hi3510/web/tmpfs/auto.jpg
Sysreset.cgi
Function
Restore the camera settings to default values.
Privilege
admin
Usage
/cgi-bin/hi3510/sysreset.cgi
Param.
None
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/sysreset.cgi
Sysreboot.cgi
Function
Reboot the camera system.
Privilege
admin
Usage
/ cgi-bin/hi3510/sysreboot.cgi
Param.
None
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/sysreboot.cgi
backup.cgi
Function
Backup the camera configurations.
Privilege
admin
Page 67
67
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Usage
/cgi-bin/hi3510/backup.cgi
Param.
None
Return
config_backup.bin
Note
None
Example
/cgi-bin/hi3510/backup.cgi
restore.cgi
Function
Restore the camera configurations.
Privilege
admin
Usage
/cgi-bin/hi3510/restore.cgi[?-setting_file=]
Param.
setting_file
The path of the configurations file.
Return
None
Note
This command should use the POST HTTP method.
Example
<form name="form6" method="post" enctype="multipart/form-data"
action="cgi-bin/hi3510/restore.cgi" >
<input type="file" name="setting_file" >
<input type="submit" value="restore" >
</form>
logsync
Function
Get the log of system running.
Privilege
admin
Usage
/cgi-bin/hi3510/param.cgi[?cmd=logsync]
Param.
None
Return
None
Note
1. This command will read the log from /log/syslog.txt.
2. The log will be cleared automatically after reboot.
Example
/cgi-bin/hi3510/param.cgi?cmd=logsync
/log/syslog.txt
cleanlog
Function
Clear the log of system running.
Privilege
admin
Page 68
68
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Usage
/cgi-bin/hi3510/param.cgi[?cmd=cleanlog&-name=]
Param.
name
sys
Return
Success: Success.
Fail: Error.
Note
None
Example
/cgi-bin/hi3510/param.cgi?cmd=cleanlog&-name=sys
15. RTSP URL
1. Verify the authorization by client.
rtsp://IP address:port/11 or 12 or 13.
-11 represents the first stream.
-12 represents the second stream.
-13 represents the third stream
-The default port for RTSP is 554
For example, rtsp://192.168.1.108:444/11
2. Include the authorization in the URL.
rtsp://username:password@IP address:port/11 or 12 or 13.
For example, rtsp://admin:[email protected]:444/11
16. Appendix
Appendix I Defines for device type
1. The device type is a 32 bytes ACSII code, which is used to distinguish between different
devices with different features.
2. Each field has 2 bytes. The first byte represents the general type and the second byte
represends the sub type.
Field 3
Field 4
Lens
PTZ
‘S’
‘Z’
3. The field for lens ‘S’
‘e’
CMOS 720P
Brightness [0-100], Saturation [0-255], Contrast [0-100],
Hue [0-100], Sharpness [0-100], Shutter [0-65535],
Page 69
69
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Flip, Mirror, WDR, Night vision mode.
The first stream: 720P, Q720P.
The second stream: Q720P, QQ720P.
The third stream: QQ720P.
Snapshots for mobile phone: Q720P, QQ720P.
‘f’
CMOS 720P
CMOS 960P
Brightness [0-100], Saturation [0-255], Contrast [0-100],
Hue [0-100], Sharpness [0-100], Shutter [0-65535],
Flip, Mirror, WDR, Night vision mode.
720P:
The first stream: 720P.
The second stream: Q720P, QQ720P.
The third stream: QQ720P.
Snapshots for mobile phone: Q720P, QQ720P.
960P:
The first stream: 960P.
The second stream: VGA, QVGA.
The third stream: QVGA.
Snapshots for mobile phone: VGA, QVGA.
‘g’
CMOS 1080P
CMOS 720P
Brightness [0-100], Saturation [0-255], Contrast [0-100],
Hue [0-100], Sharpness [0-100], Shutter [0-65535],
Flip, Mirror, WDR, Night vision mode.
1080P:
The first stream: 1080P.
The second stream: Q720P, QQ720P.
The third stream: QQ720P.
Snapshots for mobile phone: Q720P, QQ720P.
720P:
The first stream: 720P.
The second stream: Q720P, QQ720P.
The third stream: QQ720P.
Snapshots for mobile phone: Q720P, QQ720P.
‘h’
CMOS 720P WDR
Brightness [0-6], Saturation [0-6], Contrast [0-8], Hue
[0-255], Sharpness [0-4], Shutter [0-3], WDR, Night
vision mode.
The first stream: 720P, Q720P.
The second stream: Q720P, QQ720P.
The third stream: QQ720P.
Snapshots for mobile phone: Q720P, QQ720P.
‘I’
CMOS 1080P
CMOS 720P
Brightness [0-100], Saturation [0-255], Contrast [0-100],
Hue [0-100], Sharpness [0-100], Shutter [0-65535],
Flip, Mirror, WDR, Night vision mode.
1080P:
The first stream: 1080P.
Page 70
70
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
The second stream: Q720P, QQ720P.
The third stream: QQ720P.
Snapshots for mobile phone: Q720P, QQ720P.
720P:
The first stream: 720P.
The second stream: Q720P, QQ720P.
The third stream: QQ720P.
Snapshots for mobile phone: Q720P, QQ720P.
‘j’
CMOS 1080P
CMOS 720P
Brightness [0-100], Saturation [0-255], Contrast [0-100],
Hue [0-100], Sharpness [0-100], Shutter [0-65535],
Flip, Mirror, WDR, Night vision mode.
1080P:
The first stream: 1080P.
The second stream: Q720P, QQ720P.
The third stream: QQ720P.
Snapshots for mobile phone: Q720P, QQ720P.
720P:
The first stream: 720P.
The second stream: Q720P, QQ720P.
The third stream: QQ720P.
Snapshots for mobile phone: Q720P, QQ720P.
‘k’
D1
Brightness [0-100], Saturation [0-255], Contrast [0-100],
Hue [0-100], Sharpness [0-100], Shutter [0-65535],
Flip, Mirror, Night vision mode.
The first stream: D1, CIF.
The second stream: CIF.
The third stream: CIF.
Snapshots for mobile phone: D1.
4. The field for PTZ ‘Z’
‘0’
User-defined PTZ
Up, Down, Left, Right, Horizontal Curise, Vertical
Curise, Back to center point, Call preset point (Up to 8
points). Do not suppor set by serial port, and set the
PTZ speed.
‘3’
485 PTZ
Up, Down, Left, Right, Zoom in, Zoom out, Call preset
points. Supports to set 485 attributes.
Appendix II Time zone list
Time zone
Descriptions
Etc/GMT-12
(GMT-12:00) Date line in the west
Pacific/Apia
(GMT-11:00) Midway Islands, Samoan Islands
Pacific/Honolulu
(GMT-10:00) Hawaii
America/Anchorage
(GMT-09:00) Alaska
Page 71
71
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
America/Los_Angeles
(GMT-08:00) Pacific Standard(US and Canada)
America/Denver
(GMT-07:00) Mountain Standard(US and Canada)
America/Tegucigalpa
(GMT-07:00) Chihuahua, LA PAZ, Mazatlan.
America/Phoenix
(GMT-07:00) Arizona
America/Winnipeg
(GMT-06:00) Saskatchewan
America/Mexico_City
(GMT-06:00) Guadalajara, Mexico City, Monterey
America/Chicago
(GMT-06:00) Central Standard(US and Canada)
America/Costa_Rica
(GMT-06:00) Central America
America/Indianapolis
(GMT-05:00) Indiana (East)
America/New_York
(GMT-05:00) Estern Standard (US and Canada)
America/Bogota
(GMT-05:00) Bogota, Lima, Rio Branco
America/Santiago
(GMT-04:00) San Diego
America/Caracas
(GMT-04:00) LA PAZ
America/Montreal
(GMT-04:00) Atlantic time (Canada)
America/St_Johns
(GMT-03:30) Newfoundland
America/Thule
(GMT-03:00) Greenland
America/Buenos_Aires
(GMT-03:00) Buenos Aires, Georgetown
America/Sao_Paulo
(GMT-03:00) Brasilia
Atlantic/South_Georgia
(GMT-02:00) Mid-Atlantic
Atlantic/Cape_Verde
(GMT-01:00) Cape Verde Islands
Atlantic/Azores
(GMT-01:00) Azores Islands
Europe/Dublin
(GMT) Greenwich Mean Time: Dublin, Edinburgh,
London, Lisbon
Africa/Casablanca
(GMT) Dj TK Remix, Monrovia, Reykjavik
Europe/Amsterdam
(GMT+01:00) Amsterdam, Berlin, Berne, Roman,
Stockholm, Vienna
Europe/Belgrade
(GMT+01:00) Belgrade, Bratislava, Budapest, Ljubljana,
Prague
Europe/Brussels
(GMT+01:00) Brussels, Copenhagen, Madrid, Paris
Europe/Warsaw
(GMT+01:00) Sarajevo, Skopje, Warsaw, Zagreb
Africa/Lagos
(GMT+01:00) In central west Africa
Europe/Athens
(GMT+02:00) Athens, Istanbul, Minsk
Europe/Bucharest
(GMT+02:00) Bucharest
Africa/Cairo
(GMT+02:00) Cairo
Africa/Harare
(GMT+02:00) Harare, Pretoria
Europe/Helsinki
(GMT+02:00) Helsinki, Kiev, Riga, Sofia, Tallinn, Vilnius
Asia/Jerusalem
(GMT+02:00) Jerusalem
Asia/Baghdad
(GMT+03:00) Baghdad
Asia/Kuwait
(GMT+03:00) Kuwait, Riyadh
Europe/Moscow
(GMT+03:00) Moscow, St.Petersburg, Volgograd
Africa/Nairobi
(GMT+03:00) Nairobi
Asia/Tehran
(GMT+03:30) Teheran
Page 72
72
www.dericam.com
Shenzhen Dericam Technology Co,.Ltd
Asia/Dubai
(GMT+04:00) Abu Dhabi, Muscat
Asia/Baku
(GMT+04:00) Baku, Tbilisi, Yerevan
Asia/Kabul
(GMT+04:30) Kabul
Asia/Yekaterinburg
(GMT+05:00) Ekaterinburg
Asia/Karachi
(GMT+05:00) Islamabad, Karachi, Tashkent
Asia/Calcutta
(GMT+05:30) Madras, Calcutta, Bombay, New Delhi
Asia/Katmandu
(GMT+05:45) Katmandu
Asia/Almaty
(GMT+06:00) Alma-Ata, Novosibirsk
Asia/Dhaka
(GMT+06:00) Astana, Dacca
Asia/Colombo
(GMT+06:00) Colombo
Asia/Rangoon
(GMT+06:30) Rangoon
Asia/Bangkok
(GMT+07:00) Bangkok, Hanoi, Djakarta
Asia/Krasnoyarsk
(GMT+07:00) Krasnoyarsk
Asia/Hong_Kong
(GMT+08:00) Beijing, Chongqing, Hong Kong, Urumchi
Asia/Irkutsk
(GMT+08:00) Irkutsk, Ulan Bator
Asia/Kuala_Lumpur
(GMT+08:00) Kuala Lumpur, Singapore
Australia/Perth
(GMT+08:00) Perth
Asia/Taipei
(GMT+08:00) Taipei
Asia/Tokyo
(GMT+09:00) Osaka, Sapporo,Tokyo
Asia/Seoul
(GMT+09:00) Seoul
Asia/Yakutsk
(GMT+09:00) Yakutsk
Australia/Adelaide
(GMT+09:30) Adelaide
Australia/Brisbane
(GMT+10:00) Brisbane
Australia/Sydney
(GMT+10:00) Canberra, Melbourne, Sydney
Pacific/Guam
(GMT+10:00) Guam, Port Moresby
Australia/Hobart
(GMT+10:00) Hobart
Asia/Vladivostok
(GMT+10:00) Vladivostok
Asia/Magadan
(GMT+11:00) Magadan, Solomon Islands, New
Caledonia
Pacific/Auckland
(GMT+12:00) Auckland, Wellington
Pacific/Fiji
(GMT+12:00) Fiji, Kamchatka Peninsula, Marshall
Islands
Pacific/Tongatapu
(GMT+13:00) Nukualofa
