Denver OC-11 User Manual

25 Litre Electronic Microwave

Owner sI n struction M anual

DENVER OC-11

Read the Instructions carefully and Keep for Future Reference

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

- WARNING: when the appliance is operated in the combination mode,
children should only use the oven under adult supervision due to
the temperatures generated;

- WARNING: if the door or door seals are damaged, the oven must not be

operated until it has been repaired by a competent person;

- WARNING: it is hazardous for anyone other than a competent person to

carry out any service or repair operation that involves the removal

of a cover which gives protection against exposure to microwave
energy;

- WARNING: liquids and other foods must not be heated in sealed
containers since they are liable to explode

- WARNING: Only allow children to use the oven without supervision

when adequate instructions have been given so that the child is

able to use the oven in a safe way and understands the hazards of
improper use;

- only use utensils that are suitable for use in microwave ovens

- when heating food in plastic or paper containers, keep an eye on the

oven due to the possibility of ignition;

- if smoke is observed, switch of or unplug the appliance and keep the

door closed in order to stifle any flames;

- microwave heating of beverages can result in delayed eruptive boiling,

therefore care must be taken when handling the container;

- the contents of feeding bottles and baby food jars shall be stirred or

shaken and the temperature checked before consumption, in order to
avoid burns;

- eggs in their shell and whole hard-boiled eggs should not be heated in

microwave ovens since they may explode, even after microwave
heating has ended;

- the oven should be cleaned regularly and any food deposits removed;

- failure to maintain the oven in a clean condition could lead to

deterioration of the surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation;

- if the supply cord is damaged, it must be replaced by the manufacturer,

its service agent or similarly qualified persons in order to avoid a
hazard.

- The temperature of accessible surfaces may be high when the appliance

is operating.

-2-

SPECIFICATIONS

Power consumption:
Output:
Grill Heater:
Convection:

Operating Frequency:
Outside Dimensions:
Oven Cavity Dimensions:
Oven Capacity:
Uncrated Weight:

BEFORE YOU CALL FOR SERVICE

1. If the oven will not perform at all, the display does not
appear or the display disappears:
a) Check to ensure that the oven is plugged in securely. If it
is not, remove the plug from the outlet, wait 10 seconds
and plug it in again securely.
b) Check the premises for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be operating properly,

230V~50Hz,1400W
900W

1200W
1350W

2,450MHz

510mm(W) X 455mm(D) X 303mm(H)
330mm(W) X 330mm(D) X 230mm(H)

25litres
Approx. 19kg

test the outlet with another appliance.

2. If the microwave power does not function:
a) Check to see whether the timer is set.
b) Check to make sure that the door is securely closed to
engage the safety interlocks. Otherwise, the microwave
energy will not flow into the oven.

IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT THE AUTHORIZED SERVICE AGENT.

Note:
The appliance is for household use for heating food and beverages using electromagnetic energy and for indoor
use only.

RADIO INTERFERENCE

Microwave oven may cause interference to your radio, TV, or similar equipment. When interference occurs, it may be
eliminated or reduced by the following procedures.
a. Clean the door and sealing surface of the oven.
b. Place the radio, TV, etc. as far away from your microwave oven as possible.
c. Use a properly installed antenna for your radio, TV, etc. to get a strong signal reception.

-3-

INSTALLATION

1. Make sure all the packing materials are removed from
the inside of the door.

2. Inspect the oven after unpacking for any visual
damage such as:
Misaligned Door
Damaged Door
Dents or Holes in Door Window and Screen
Dents in Cavity
If any of the above are visible, DO NOT use the
oven.

3. This Microwave Oven weighs 19 kg and must be
placed on a horizontal surface strong enough to

WARNING-THIS APPLIANCE MUST BE EARTHED.

1. The plug socket should be within easy reach

support this weight.

4. The oven must be placed away from high temperature
and steam.

5. DO NOT place anything on top of the oven.

6. Keep the oven at least 8 cm away from both sidewalls
and 10 cm away from rear wall to ensure the correct
ventilation.

7. DO NOT remove the turn -table drive shaft.

8. As with any appliance, close supervision is necessary
when used by children.

of the power cord

2. This oven requires 1.5 KVA for its input.
consultation with service engineer is
suggested when installing the oven.

IMPORTANT

The wires in this mains lead are coloured in accordance with the following code:
Green-and-yellow : Earth
Blue : Neutral
Brown : Live

As the colours of the wires in the mains leads of the appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:

CAUTION:This oven is protected internally by
a 250V,10 Amp Fuse.

The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked with the
letter E or by the earth symbol coloured green of green-and-yellow.

The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

-4-

IMPORTANT SAFETY INSTRUCTIONS

-WARNING: When the appliance is operated in the combination mode, children should only use the oven under adult
supervision due to the temperatures generated; (Only for the model with grill function)

-WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a
competent person;

-WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation
that involves the removal of a cover which gives protection against exposure to microwave energy;

-WARNING: liquids and other foods must not be heated in sealed containers since they are liable to explode.

-WARNING: Only allow children to use the oven without supervision when adequate instructions have been given
so that the child is able to use the oven in a safe way and understands the hazards of improper use;

- The oven must have sufficient air flow.Keep 10 cm space at back;15 cm at both sides and 30cms from top of the
oven.Don't remove oven's feet, do not block air events of the oven.

- Only use utensils that are suitable for use in microwave ovens.

- When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition;

- If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames;

- Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling
the container;

- The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before
consumption, in order to avoid burns;

- Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode,
even after microwave heating has ended;

- When cleaning surfaces of door, door seal, cavity of the oven, use only mild, nonabrasive soaps, or detergents
applied with a sponge or soft cloth.

- The oven should be cleaned regularly and any food deposits removed;

- Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect
the life of the appliance and possibly result in a hazardous situation;

- If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.

SAFETY INSTRUCTIONS FOR GENERAL USE
Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from
this oven:

1. Always have the glass tray, roller arms, coupling and roller track in place when operating the oven.

2. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any
other nonfood items, or for sterilizing purposes.

3. Do not operate the oven when empty. This could damage the oven.

4. Do not use the oven cavity for any type of storage,such a papers, cookbooks, etc.

5.Do not cook any food surrounded by a membrane,such as egg yolks,potatoes,chicken livers,etc without
first being pierced several times with a fork.

-5-

6. Do not insert any object into the openings on the outer
case.

7. Do not at any time remove parts from the oven such as
the feet, coupling, screws, etc.

8. Do not cook food directly on the glass tray. Place food
in/on proper cooking utensil before placing in the oven.

9. IMPORTANT-COOKWARE NOT TO USE IN YOUR
MICROWAVE OVEN
Do not use metal pans or dishes with metal handles.
Do not use anything with metal trim.
Do not use paper covered wire twist-ties on plastic bags.
Do not use melamine dishes as they contain a material
which will absorb microwave energy. This may cause
the dishes to crack or char and will slow down the
cooking speed.
Do not use Centura Tableware. The glaze is not suitable
for microwave use. Corelle Livingware closed handle
cups should not be used.
Do not cook in a container with a restricted opening,
such as a pop bottle or salad oil bottle, as they may
explode if heated in a microwave oven.
Do not use conventional meat or candy thermometers.
There are the thermometers available specifically for
microwave cooking. These may be used.

10. Microwave utensils should be used only in
accordance with manufacturer's instructions.

11. Do not attempt to deep-fry foods in this oven.

12. Please remember that a microwave oven only
heats the liquid in a container rather than the
container itself.Therefore, even though the lid
of a container is not hot to the touch when

FEATURE DIAGRAM

5

3

6

removed from the oven, please remember that
the food/liquid inside will be releasing the same
amount of steam and/or spitting when the lid is
removed as in conventional cooking.

13. Always test the temperature of cooked food
yourself especially if you are heating or cooking
food/liquid for babies. It is advisable never to
consume food/liquid straight from the oven but
allow it to stand for a few minutes and stir food/
liquid to distribute heat evenly.

14. Food containing a mixture of fat and water,
e.g.stock,should stand for 30-60 seconds in the
oven after it has been turned off. This is to allow
the mixture to settle and to prevent bubbling when
a spoon is placed in the food/liquid or a stock cube
is added.

15. When preparing/cooking food/liquid and remember
that there are certain foods, e.g. Christmas
puddings, jam and mincemeat, which heat up very
quickly. When heating or cooking foods with a high
fat or sugar content do not use plastic containers.

16. Cooking utensil may become hot because of heat
transferred from the heated food. This is especially
true if plastic wrap has been covering the top and
handles of the utensil. Potholders may be needed
to handle the utensil.

17.To reduce the risk of fire in the oven cavity:
(a)Do not overcook food. Carefully attend microwave
oven if paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
(b)Remove wire twist-ties from bags before placing
bag in oven.
(c)If materials inside the oven should ignite, keep oven
door closed, turn the oven off at the wall switch, or
shut off power at the fuse or circuit breaker panel.

(1) Door Safety Lock System
(2) Oven Window
(3) Oven Air Vent
(4) Roller Ring

4

2

1

1

7

(5) Glass Tray
(6) Control Panel
(7) Grill rack

-6-

DISPLAY WINDOW AND OPERATION INSTRUCTION

(1) (2) (3) (4)

CONTROL PANEL

(5) (6)

(9)(10)(11)

(7)

(8)

(1) Grill
(2) Combination
(3) Microwave
(4) Convection
(5) Defrost
(6) Temperature
(7) Percentage
(8) Weight (kg)
(9) Child-lock
(10) Time
(11) Start

Micro/Defrost

/Grill/Conve

/Comb

10 Min

1 Min

10 Sec

(1)DISPLAY WINDOW

(2)

Micro/Defrost/Grill/Convection/Combination

(3)10Min

)1 Min

(4

(5

)10 Sec

)Start/Reset

(6

Start/Reset

-7-

OPERATION INSTRUCTION

1.SIMPLE COOKING

etc.

milk

milk

b) Press the button "Start/Reset", the microwave oven will work on 100% power for 1 minutes.

completed.

2.MICROWAVE COOKING
(A) Fast cooking method

(For example: Select 100% power to cook foods for 5 minutes.)
a) Set the time "5:00"
b) Press "Start/Reset" button
(B) Control by hand
(For example: Select 70% power to cook foods for 10 minutes)
a) Press "Micro/Grill" button to select 70% power.
b) Press time button to set cooking time "10:00"

c) Press "

Start/Reset" button.

You can press "MICRO/GRILL" button to select power.

Step

1 P100 100%
2
3

4
5

Display Micro power

P70
P50

P30
P10

70%
50%
30%
10%

3.AUTO DEFROST FUNCTION
You need to press "1Min" (1.0kg) and "10Sec" (0.1kg) according to the weight of the food.The oven can

select defrosting program and auto start defrosting.
For example: defrost 0.4kg frozen foods

1) Press "Micro/Grill" to choose defrost function, display "DEF".

2) Set weight "0.4kg" by pressing "1Min" and "10Sec" buttons.

3).Press "Start/Reset" button.
Remark: the maximum weight is 2kgs.

4. Grill
You may press "Grill" button to select such functions: (the longest cooking time is 59'50'' minutes).
Pattern 1: 85% grill power, display G-1

Example: cooking food with grill for 20 minutes
A) Press "Micro/Grill" until the LED displayed "G-1".
B) Set cooking time "20:00"
C) Press "Start/Reset"

-8-

When grilling, the food isn't heated by microwave, heat is radiated from the metal heater at the top of the oven.
When grill is working, the cooking time has 2 stages, After the 1st half of the cooking, the program will automatically
pause and sound 2 beeps, indicating you to open the oven and turn food over, after turning over, close the door,
press "Start/Reset" button, the cooking will continue for the 2nd half. If you do not want to turn the food over, the oven
will re-start after 1 min pause.

5. Combination Cooking
This appliance offers you a choice of three methods of combination cooking.
Option 1 : Convection + Microwave (200 C convection + 50% microwave), display "C-1"
This is ideal for roasting and baking etc.
Option 2 : Grill and Convection (50% grill + 210 C convection, display "C-2" )
For fast crisping etc.
Option 3 : Grill and Microwave (50% grill + 50% microwave), display "C-3"

For fast grilling etc.
Example : Cooking food using option 3 for 30 minutes.
a) Press "Comb" button to select "C-3"
b) Set cooking time for 30 minutes
c) Press "Start/Reset"

6. Convection Cooking
This oven can be used as a convection oven and can be programmed to reach a desired temperature for
pre-heating. you may press "Micro/Conve" button to set the different temperature.

Example:To set the oven to pre-heat to 200
a) Press the "Micro/Conve" button to set 200 C temperature.

b) Press "Start/Reset".
You can press "Micro/Conve" button to select temperature: 230 C,220 C, 200 C, 180 C, 160 C.

When the pre-heating is completed, the appliance will stop work and emit 2 bleeps to remind you to place
the food in the oven. Set the convection cooking temperature and time and start cooking.The longest
pre-heating time will be 30 minutes.)
Example: Convection cooking,To set the pre-heated oven to cook for 20 minutes at 200
a) Press "Micro/Conve" button to choose 200 C temperature.
b) Set cooking time for 20 minutes
c) Press "Start/Reset"

7. Child-safely lock
To activate the child safely lock, press "1Min" and "10Sec" button at the same time for 2 seconds.

Press "1Min" and "10Sec" button, at the same time for 2 seconds again, it will unlock this function.

8. Start/Reset
a) In the course of operation, pressing "Start/Reset" button will stop operation.
b) If any program was set before pressing start, pressing this button will cancel all the set program.

C

.

C

-9-

CARE OF YOUR MICROWAVE OVEN

1.Turn the oven off and remove the power plug from the wall socket before cleaning.

2.Keep the inside of the oven clean.When food splatters or spilled liquids adhere to oven walls,wipe with a
damp cloth.The use of harsh detergent or abrasives is not recommended.

3.The outside oven surface should be cleaned with a damp cloth.To prevent damage to the operating parts
inside the oven,water should not be allowed to seep into the ventilation openings.

4.Do not allow the Control Panel to become wet. Clean with a soft, damp cloth, Do not use detergents,
abrasives or spray-on cleaners on the control Panel.

5.If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth.This may occur
when the microwave oven is operated under high humidity conditions and in no way indicates malfunction

of the unit.

6.It is occasionally necessary to remove the glass tray for cleaning.Wash the tray in warm sudsy water or in
a dishwasher.

7.The roller ring and oven cavity floor should be cleaned regularly to avoid excessive noise.Simply wipe the
bottom surface of the oven with mild detergent,water or window cleaner and dry.The roller ring may be

washed in mild sudsy water or dish washer.Cooking vapour collect during repeated use but in no way
affect the bottom surface or roller ring wheels.
When removing the roller ring from cavity floor for cleaning,be sure to replace it in the proper position.

8.Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in a
deep microwaveable bowl. Microwave for 5 minutes,wipe thoroughly and dry with a soft cloth.

9.When it becomes necessary to replace the oven light,please consult a dealer to have it replaced.

Instructions on environment protection

Do not dispose of this product in the usual household garbage at the end of its lifecycle;
hand it over at a collection point for the recycling of electrical and electronic appliances.
The symbol on the product, the instructions for use or the packing will inform about the
methods for disposal.
The materials are recyclable as mentioned in this marking. By recycling, material
recycling or other forms of re-utilization of old appliances, you are making an

DENVER ELECTRONICS

important contribution to protect our environment.
Please inquire at the community administration for the authorized disposal location.

-10-

Elektronisk Mikrobølgeovn, 25 Liter

Betjeningsvejledning

DENVER OC-11

Læs vejledningen omhyggeligt og gem den, så du kan slå op i den senere.

-11-

VIGTIGE SIKKERHEDSOPLYSNINGER

LÆS DISSE RETNINGSLINJER OMHYGGELIGT OG GEM DEM, SÅ DU KAN SLÅ OP I DEM

SENERE

- ADVARSEL: Når ovnen anvendes som kombinationsovn, bør børn ikke betjene ovnen
uden, at der er voksne til stede, da ovnen når høje temperaturer, når denne funktion er
aktiveret.

- ADVARSEL: Hvis ovnlågen eller forseglingen omkring ovnlågen bliver beskadiget, bør du
ikke anvende ovnen, før den er blevet repareret af en autoriseret reparatør.

-

ADVARSEL: Det er forbundet med fare at forsøge selv at foretage reparationer af ovnen,
der indebærer at ovnens kabinet åbnes. Kabinettet beskytter mod den mikrobølgeenergi,
som ovnen anvender.

- ADVARSEL: Væsker og andre fødeemner må aldrig opvarmes i forseglede beholdere, da
disse kan eksplodere under opvarmningen.

- ADVARSEL: Sørg for, at børn kun anvender og betjener ovnen under opsyn fra voksne.
Lad ikke børn betjene ovnen uden først at have fået en instruktion i betjeningen, således at
de forstår faren ved ikke at anvende ovnen i overensstemmelse med be tjeningsvejledningen.

-

Anvend kun tilbehør, der er specielt beregnet til anvendelse i mikrobølgeovn.

- Når du opvarmer fødeemner, der er i plastik- eller papirbeholdere, bør du være ekstra
påpasselig, da der er risiko for, at sådanne beholdere kan bryde i brand.

- Hvis du ser røg komme ud af ovnen, skal du omgående slukke på stikkontakten, tage
stikket ud og lade ovnen stå med lågen lukket, således at evt. flammer kan blive kvalt.

- Når du opvarmer drikkevarer i mikrobølgeovnen, kan det forekomme, at væsken koger
over "med forsinkelse". Beholdere indeholdende væsker bør derfor håndteres med
forsigtighed, når de tages ud af ovnen.

-

Af hensyn til risikoen for forbrænding skal indholdet i sutteflasker og glas med babymad
omrøres eller rystes inden brugen, lige som temperaturen skal kontrolleres nøje, inden du
giver indholdet til barnet.

- Du bør ikke opvarme hele æg med skal eller hele hårdkogte æg i mikrobølgeovnen, da
disse kan eksplode selv efter, at opvarmningen er til ende.

- Ovnen bør rengøres regelmæssigt, således at evt. madrester fjernes fra ovnrummet og fra
ovnens ydre.

-

Hvis du ikke holder ovnen ren, kan det medføre, at ovnens overflader tager skade, hvilket
nedsætter ovnens levetid og kan føre til, at der opstår farlige situationer.

- Hvis netledningen beskadiges, skal den udskiftes af producenten eller af anden autoriseret
reparatør. Forsøg aldrig selv at reparere eller modificere ovnens netledning af hensyn til
faren for elektrisk stød.

-

Temperaturen uden på ovnen kan være høj, når ovnen er i brug.

-12-
