Page 1

Bar Code Handy Terminal

BHT-700-WM

GPRS Class Library

Reference Manual

Page 2

Specifications are subject to change without prior notice.

All products and company names mentioned in this manual are trademarks or registered trademarks of their respective holders.

Page 3

Update

Version Date Detail

1.0 March, 2009 First Release

2.0 July, 2009 Added “Operating Precautions”

Modified following parameters of functions.

- GetSIMPINPUKCounter

- SetNecessarySIMPIN

- SetRadioBand

- GetOperatorInfo

- SendSMS

3.0 September, 2009 Added “1. Programing”

Page 4

Introduction

This reference manual is intended for software developers using VB.NET or C# to develop software applications using GPRS(EDGE) functions for the BHT-700.

 Operating Precautions When you develop software applications using GPRS(EDGE) functions, you need to copy GPRSLIB.dll supplied with GPRS Class Library to a Windows folder of BHT-700. Otherwise the applications you developed can’t operate properly.

 Related Manuals Please refer to the following related manuals for further information.

• BHT-700-WM Class Library Reference Manual

 Contacts Please forward any opinions or questions that you may have regarding this manual to the address below or contact us

by telephone.

DENSO WAVE INCORPORATED MT Bldg. Hall No.2, 4-2-12,Toranomon, Minato-ku, Tokyo, 105-0001 Japan Tel: +81-3-5472-0477

 Latest Information Please access our Web site using the following URL for the latest information on this manual and our full range of

products.

http://www.denso-wave.com/

More detailed information is available for product owners at our dedicated Web site (QBNet) for registered users. Please access the above URL for user registration and details on QBNet.

- i -

Page 5

Contents

1. Programing ......................................................................................................................................................................................... 1

2. GPRS class........................................................................................................................................................................................ 2

3. SMS information structure........................................................................................................................................................31

4. Operator list structure................................................................................................................................................................ 35

5. Operator structure .......................................................................................................................................................................36

6. Time structure................................................................................................................................................................................37

7. error code.........................................................................................................................................................................................38

- ii -

Page 6

1. Programing

Procedure for GRPS's connection

Step1 : Insert SIM card into BHT

Step2 : Power on GPRS module. use "PowerOn" method

Step3 : Open COM port to send a control command to the GPRS module. use "OpenCom" method

Step4 : Check the authentication status of SIM PIN authentication. use "GetSIMPINStatus" method

Step5 : Input PIN code If PIN code is necessary at 4. use "SetSIMPIN" method

Step6 : Set a radio frequency band. use "SetRadioBand" method

Step7 : After within around 60 sec, GPRS complete to connect to a base station. (Notes)

(Notes) It is long time to connect to a base station at the first time.

- 1 -

Page 7

2. GPRS class

 Constructor

There is no need to create an instance because all the members are static members

 Methods

Method Name Description

PowerOn Turn ON GPRS module

PowerOff Turn OFF GPRS module

OpenCom Open GPRS COM port

CloseCom Close GPRS COM port

GetSIMPINStatus Get the SIM PIN authentication status

GetSIMPINPUKCounter Get the number of attempts still available for entering the

PIN/PUK code

SetSIMPIN Set the SIM PIN for GSM network registration

ChangeSIMPIN Change SIM PIN for GSM network registration

SetNecessarySIMPIN Select whether SIM PIN is necessary or not

SetSIMPUK Set the SIM PUK to unlock the PIN-lock issue and assign a

new PIN code for next registration

SetRadioBand Select radio frequency band

GetSignalStrength Get the RSSI

GetModuleVersion Get the firmware version of module

GetAllOperatorCnt Acquire the number of total operator

GetAllOperatorInfo Acquire all the operator name

GetOperatorListCnt Acquire the number of visible operator

GetOperatorListInfo Acquire all the visible operator name

GetOperatorInfo Get the operator name

SetSMSStorageDest Specify destination storing received short message

DeleteSMS Delete short message

ReadSMS Read short message

SendSMS Send short message

WriteSMSToMem Write short message into the memory

SendSMSFromMem Send short message stored in the memory

GetSMSListCnt Acquire the number of SMS stored in the memory or UIM

 Enumeration

Enumeration Name Description

EN_SIMSTATUS SIM authentication state

EN_RADIOBAND Radio band

EN_STORAGESMS Storage area to save short message

- 2 -

Page 8

PowerOn

Turn the power of GPRS module on.

￭ Syntax

[VB] Public Shared Function PowerOn() As UInt32

[C#]

public static UInt32 PowerOn();

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 3 -

Page 9

PowerOff

Turn the power of GPRS module off.

￭ Syntax

[VB] Public Shared Function PowerOff() As UInt32

[C#]

public static UInt32 PowerOff();

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 4 -

Page 10

OpenCom

Open the COM port for GPRS function.

￭ Syntax

[VB] Public Shared Function OpenCom() As UInt32

[C#]

public static UInt32 OpenCom();

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 5 -

Page 11

CloseCom

Close the COM port of GPRS.

￭ Syntax

[VB] Public Shared Function CloseCom() As UInt32

[C#]

public static UInt32 CloseCom();

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 6 -

Page 12

GetSIMPINStatus

Get the SIM PIN authentication state.

￭ Syntax

[VB] Public Shared Function GetSimPINStatus( _

ByRef status As EN_SIMSTATUS) As UInt32

[C#]

public static UInt32 GetSimPINStatus(out EN_SIMSTATUS staus);

￭ Parameters

status

[out] Authentication state

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 7 -

Page 13

GetSIMPINPUKCounter

Get the number of attempts still available for entering the PIN/PUK code.

￭ Syntax

[VB] Public Shared Function GetSIMPINPUKCounter( _

ByRef PINCount As UInt32, _

ByRef PUKCount As UInt32) As UInt32

[C#]

public static UInt32 GetSIMPINPUKCounter(

out UInt32 PINCount, out UInt32 PUKCount);

￭ Parameters

PINCount

[out] available attempts number for entering the PIN code

PUKCount

[out] available attempts number for entering the PUK code

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 8 -

Page 14

SetSIMPIN

Set the SIM PIN for GSM network registration.

￭ Syntax

[VB] Public Shared Function SetSIMPIN(ByVal PIN As String) As UInt32

[C#]

public static UInt32 SetSIMPIN(string PIN);

￭ Parameters

[in ] SIM PIN

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 9 -

Page 15

ChangeSIMPIN

Change SIM PIN for GSM network registration.

￭ Syntax

[VB]

Public Shared Function ChangeSIMPIN _

(ByVal PIN As String, ByVal newPIN As String) As UInt32

[C#] public static UInt32 ChangeSIMPIN(string PIN, string newPIN);

￭ Parameters

[in ] (old)PIN

newPIN

[in ] new PIN

Settable value : string which length is from 4 digits to 8 digits.

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 10 -

Page 16

SetNecessarySIMPIN

Select whether SIM PIN is necessary or not.

￭ Syntax

[VB]

Public Shared Function SetNecessarySIMPIN _

(ByVal req As Boolean, ByVal PIN As String) As UInt32

[C#] public static UInt32 SetNecessarySIMPIN(bool req, string PIN);

￭ Parameters

req

[in ] PIN is necessary(=true) or unncessary(=false)

[in ] SIM PIN

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 11 -

Page 17

SetSIMPUK

Set the SIM PUK to unlock the PIN-lock issue and assign a new PIN code for next registration.

￭ Syntax

[VB] Public Shared Function SetSIMPUK( _

ByVal puk As String, ByVal pin As String) As UInt32

[C#]

public static UInt32 SetSIMPUK(string puk, string pin);

￭ Parameters

puk

[in ] PUK code

[in ] new SIM PIN code

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 12 -

Page 18

SetRadioBand

Select radio frequency band.

￭ Syntax

[VB] Public Shared Function SetRadioBand( _

ByVal prefBand As EN_RADIOBAND, _

ByVal enableBand As EN_RADIOBAND) As UInt32

[C#]

public static UInt32 SetRadioBand(

EN_RADIOBAND prefBand, EN_RADIOBAND enableBand);

￭ Parameters

prefBand

[in ] preference band selection.

The selectable band is as following table.

enableBand

[in ] permitted band selection.

The selectable band is as following table.

band specification

GSM900 GSM900MHz GSM1800 GSM1800MHz GSM900 + GSM1800 GSM900MHz and GSM1800MHz GSM1900 GSM1900MHz GSM900 + GSM1900 GSM900MHz and GSM1900MHz GSM850 GSM850MHz GSM850 + GSM1800 GSM850MHz and GSM1800MHz GSM850 + GSM1900 GSM850MHz and GSM1900MHz

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 13 -

Page 19

GetSignalStrength

Get the signal strength.

￭ Syntax

[VB] Public Shared Function GetSignalStrength( _

ByRef RSSI As UInt32, ByRef BER As UInt32) As UInt32

[C#]

public static UInt32 GetSignalStrength( out UInt32 RSSI, out UInt32 BER);

￭ Parameters

RSSI

[out] signal strength

rssi specification

0 -113 dBm or less 1 -111 dBm 2…30 -109…-53 dBm 31 -51 dBm or greater 99 Not known or not detectable

BER

[in ] Bit Error Rate

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 14 -

Page 20

GetModuleVersion

Get the firmware version of module.

￭ Syntax

[VB] Public Shared Function GetModuleVersion( _

ByVal version As System.Text.StringBuilder) As UInt32

[C#]

public static UInt32 GetModuleVersion( System.Text.StringBuilder version);

￭ Parameters

version

[out] F/W version

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 15 -

Page 21

GetAllOperatorCnt

Acquire the number of total operator.

￭ Syntax

[VB] Public Shared Function GetAllOperatorCnt( _

ByRef opeCount As UInt32) As UInt32

[C#] public static UInt32 GetAllOperatorCnt(out UInt32 opeCount);

￭ Parameters

opeCount

[out] the number of operator

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 16 -

Page 22

GetAllOperatorInfo

Acquire all the operator name.

￭ Syntax

[VB] Public Shared Function GetAllOperatorInfo( _

ByVal opeInfo As OperatorInfo()) As UInt32

[C#]

public static UInt32 GetAllOperatorInfo(OperatorInfo[] opeInfo);

￭ Parameters

opeInfo

[out] array storing operator information (refer to

5. Operator structure)

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

￭ note

Element count of opeInfo should be equal to or larger than the number of operator. Call GetAlloperatorCnt method before calling this method to acquire the number of operator.

- 17 -

Page 23

GetOperatorListCnt

Acquire the number of visible operator.

￭ Syntax

[VB] Public Shared Function GetOperatorListCnt( _

ByRef listCnt As UInt32) As UInt32

[C#]

public static UInt32 GetOperatorListCnt(out UInt32 listCnt);

￭ Parameters

listCnt

[out] the number of operator

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 18 -

Page 24

GetOperatorListInfo

Acquire all the visible operator name.

￭ Syntax

[VB] Public Shared Function GetOperatorListInfo( _

ByVal opeInfo As OperatorListInfo()) As UInt32

[C#]

public static UInt32 GetOperatorListInfo(

OperatorListInfo[] opeInfo);

￭ Parameters

opeInfo

[out] array storing operator information (refer to

4. Operator list structure)

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

￭ note

Element count of opeInfo should be equal to or larger than the number of visible operator. Call GetOperatorListCnt method before calling this method to acquire the number of visible operator.

- 19 -

Page 25

GetOperatorInfo

Get the operator name.

￭ Syntax

[VB] Public Shared Function GetOperatorInfo( _

ByVal opeInfo As System.Text.StringBuilder) As UInt32

[C#]

public static UInt32 GetOperatorInfo( System.Text.StringBuilder opeInfo);

￭ Parameters

opeInfo

[out] operator name

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 20 -

Page 26

SetSMSStorageDest

Specify the destination storing received short message.

￭ Syntax

[VB] Public Shared Function SetSMSStorageDest( _

ByVal store As EN_STORAGESMS) As UInt32

[C#]

public static UInt32 SetSMSStorageDest(EN_STORAGESMS store);

￭ Parameters

store

[in ] destination

Settable value : One of EN_STORAGESMS member

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 21 -

Page 27

DeleteSMS

Delete a short message.

￭ Syntax

[VB] Public Shared Function DeleteSMS( _

ByVal storeDelSMS As EN_STORAGESMS, _

ByVal index As UInt32) As UInt32

[C#]

public static UInt32 DeleteSMS

(EN_STORAGESMS storeDelSMS, UInt32 index);

￭ Parameters

storeDelSMS

[in ] storage area storing delting SMS

Settable value : one of EN_STORAGESMS member

index

[in ] index of SMS

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 22 -

Page 28

ReadSMS

Read out a short message.

￭ Syntax

[VB] Public Shared Function ReadSMS( _

ByVal SMSDest As EN_STORAGESMS, _

ByVal index As UInt32, ByRef info As SMSInfo) As UInt32

[C#]

public static UInt32 ReadSMS

(EN_STORAGESMS SMSDest, UInt32 index, out SMSInfo info);

￭ Parameters

SMSDest

[in ] destination storing short message

settable value : one of EN_STORAGESMS member

index

[in ] index of short message

info

[out] read SMS information

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 23 -

Page 29

SendSMS

Send a short message.

￭ Syntax

[VB]

Public Shared Function SendSMS( _

ByVal SMSDest As String, ByVal SMSText As String, _ ByRef msgRef As UInt32) As UInt32

[C#]

public static UInt32 SendSMS

(string SMSDest, string SMSText, out UInt32 msgRef);

￭ Parameters

SMSDest

[in ] destination of short message

SMSText

[in ] contents of short message

msgRef

[out] SMS reference

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 24 -

Page 30

WriteSMSToMem

Write short message into the memory.

￭ Syntax

[VB] Public Shared Function WriteSMSToMem( _

ByVal SMSDestStorage As EN_STORAGESMS, _

ByVal SMSDestAddr As String, ByVal SMSText As String, _ ByRef index As UInt32) As UInt32

[C#]

public static UInt32 WriteSMSToMem

(EN_STORAGESMS SMSDestStorage, string SMSDestAddr,

string SMSText, out UInt32 index);

￭ Parameters

SMSDestStorage

[in ] destination storing short message

settable value : one of EN_STORAGESMS member

SMSDestAddr

[in ] destination of short message

SMSText

[in ] contents of short message

index

[out] index of stored short message

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 25 -

Page 31

SendSMSFromMem

Send short message stored in the memory.

￭ Syntax

[VB] Public Shared Function SendSMSFromMem( _

ByVal SMSSrcStorage As EN_STORAGESMS, _

ByVal index As UInt32, ByRef msgRef As UInt32) As UInt32

[C#]

public static UInt32 SendSMSFromMem(

EN_STORAGESMS SMSSrcStorage, UInt32 index, out UInt32 msgRef);

￭ Parameters

SMSSrcStorage

[in ] source storage

settable value : one of EN_STORAGESMS member

index

[in ] index of send short message

msgRef

[out] message reference

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 26 -

Page 32

GetSMSListCnt

Acquire the number of SMS stored in the memory or UIM.

￭ Syntax

[VB] Public Shared Function GetSMSListCnt( _

ByRef inSIM As UInt32, ByRef totalInSMS As UInt32, _

ByRef inME As UInt32, ByRef totalInME As UInt32) As UInt32

[C#]

public static UInt32 GetSMSListCnt(

out UInt32 inSIM, out UInt32 totalInSMS, out UInt32 inME, out UInt32 totalInME);

￭ Parameters

inSIM

[out] the number of SMS stored in SIM

totalInSMS

[out] the number of SMS that can be stored in SIM

inME

[out] the number of SMS stored in ME

totalInME

[out] the number of SMS that can be stored in ME

￭ Return value

error code

0 : Normal end Other than 0 : Abnormal end. For more detail, refer to

7. error code.

- 27 -

Page 33

EN_SIMSTATUS

Specifies the SIM authentication satate.

￭ Syntax

[VB]

Public Enum EN_SIMSTATUS

[C#]

public enum EN_SIMSTATUS

￭ Members

Member Name Description

NEED Wait for SIM PIN enter

READY PIN has already been entered

LOCK PIN was disabled after three failed attempts to enter PIN and wait

for PUK entering

￭ Class

DNWA.BHT700CL.GPRS

- 28 -

Page 34

EN_RADIOBAND

Specifies the Radio band.

￭ Syntax

[VB]

Public Enum EN_RADIOBAND

[C#]

public enum EN_RADIOBAND

￭ Members

Member Name Description

GSM900 GSM 900 MHz

GSM1800 GSM 1800 MHz

GSM1900 GSM 1900 MHz

GSM850 GSM 850 MHz

￭ Class

DNWA.BHT700CL.GPRS

- 29 -

Page 35

EN_STORAGESMS

Specify destination storing short message.

￭ Syntax

[VB]

Public Enum EN_STORAGESMS

[C#]

public enum EN_STORAGESMS

￭ Members

Member Name Description

SIM SIM card

ME ME(terminal)

￭ Class

DNWA.BHT700CL.GPRS

- 30 -

Page 36

3. SMS information structure

 Fields

Field Name Description

Status Status of SMS

DestAddr Destination address

SMSData Contents of short message

tm Times stamp of short message

 Enumeration

Enumeration Name Description

EN_STATUS Status of short message

- 31 -

Page 37

Status

Status of short message

￭ Syntax

[VB] Public Status As EN_STATUS

[C#]

public EN_STATUS Status;

DestAddr

Destination address.

￭ Syntax

[VB] Public DestAddr As string

[C#]

public string DestAddr;

- 32 -

Page 38

SMSData

Contents of short message.

￭ Syntax

[VB] Public SMSData As String

[C#]

public string SMSData;

Time Stamp of short message.

￭ Syntax

[VB] Public SCTimeStamp As tm

[C#]

public tm SCTimeStamp;

Refer to 6. Time structure.

- 33 -

Page 39

EN_STATUS

Specify status of short message.

￭ Syntax

[VB]

Public Enum EN_STATUS

[C#]

public enum EN_STATUS

￭ Members

Member Name Description

REC_UNREAD not read yet

REC_READ already read

STO_UNSENT not sent yet

STO_SENT already sent

￭ Class

DNWA.BHT700CL.GPRS

- 34 -

Page 40

4. Operator list structure

 Fields

Field Name Description

OpeInfo operator information

OpeInfo

Operator information.

￭ Syntax

[VB] Public OpeInfo As OperatorInfo

[C#]

public OperatorInfo OpeInfo;

- 35 -

Page 41

5. Operator structure

 Fields

Field Name Description

OperatorName Operator name

OperatorName

Operator name

￭ Syntax

[VB] Public OperatorName As String

[C#]

public string OperatorName;

- 36 -

Page 42

6. Time structure

 Fields

Field Name Description

tm_year Year

tm_mon Month

tm_mday Date

tm_hour Hour

tm_min Minute

tm_sec second

- 37 -

Page 43

7. error code

Value Explanation

0 normal end

20000 COM port has not been opened.

20001 Fail to open COM port

20003 Argument value is invalid

20005 Timeout error

- 38 -

Page 44

BHT-700-WM GPRS Class Library Reference Manual

DENSO WAVE INCORPORATED Automatic Data Capture Division

Third Release September, 2009

- 39 -
