PORTABLE PREMIUM SOUND
BLUETOOTH SPEAKER
Quick Start Guide
1.DSB-200EM_QSG_ENG_00A_final_140221.indd 1 2014/02/24 11:10:36
SVENSKAESPAÑOLFRANÇAIS NEDERLANDSITALIANODEUTSCHENGLISH
РУССКИЙ POLSKI
日本語
中文简体字
1
1. Unpacking the Speaker
Carefully unpack your new Envaya speaker and verify that you
have the following items.
2. Placing the Speaker
Place the speaker on a fl at surface facing towards you
supporting it with one hand.
Place the fi ngers of your other hand across the back top of the
speaker and gently “squeeze” to extend the built-in stand from
the back of the speaker.
3. Powering the Speaker
q
Insert the appropriate adapter into the power supply.
w
Connect the power cord to the speaker a wall outlet.
Note: The speaker will automatically turn on the fi rst time you
connect the power cord and automatically enter Bluetooth
Pairing Mode, indicated by a two note beep. The Bluetooth
button on the speaker will begin to fl ash as it waits for a
wireless connection from your mobile device.
IMPORTANT
Looking at the white battery status indicator on the top of
the speaker (next to the power button), make sure your
speaker is fully charged before using it for the fi rst time
under battery power.
Charging status (Approximate)
0 – 30% 30 – 70% 70 – 100% Fully charged
1.DSB-200EM_QSG_ENG_00A_final_140221.indd 1 2014/02/24 11:10:37
SVENSKA ESPAÑOL FRANÇAISNEDERLANDS ITALIANO DEUTSCH ENGLISH
РУССКИЙPOLSKI
日本語
中文简体字
2
4. Playing Music from your Bluetooth Device
(Pairing and Connecting)
q
Activate the Bluetooth settings on you mobile phone.
Bluetooth ON
w
Select “Envaya” from the list of available Bluetooth
devices.
In a few seconds you will hear a fast 3 note tone from
the speaker indicating that it is connected to your device.
The Bluetooth button remains illuminated.
Envaya
e
Play music using any app on your device.
The sound will now play from the Envaya wireless
speaker.
For more information, please visit www.denon.com
to view the complete Owner’s Manual for the Envaya
wireless speaker.
Basic Troubleshooting
Speaker does not turn on
• To turn on the speaker press and hold the power button for 2 seconds.
• The battery is completely discharged. Connect the AC adapter and recharge
the battery.
Cannot pair a Bluetooth device with the speaker
• The Bluetooth device is malfunctioning. Power cycle the device, remove the
pairing information and re-pair the speaker to the device.
• This speaker cannot be paired with a 4th device when it is connected
simultaneously to 3 Bluetooth devices. Disconnect one of the connected
Bluetooth devices before pairing another device.
Speaker is turning o automatically
• No audio is played via Bluetooth for approximately 15 minutes. Power on
the speaker by pressing and holding the power button for 2 seconds.
Speaker is malfunctioning
• The speaker needs to be reset. Using a small paper clip, press and release
the reset button located on the side of the speaker.
• The speaker needs to be reset to the factory default settings. Turn on the
speaker. Press and hold the POWER and VOLUME + buttons together for
approximately 4 seconds. The status indicator will blink 4 times to indicate a
reset. (Note : All pairing information from Bluetooth devices will be erased.)
1.DSB-200EM_QSG_ENG_00A_final_140221.indd 2 2014/02/24 11:10:38
D&M Holdings Inc.
5411 11162 00AD
www.denon.com
