Denon DVM-725 User Manual

Download

Page 1

DVM-725

DVD VIDEO AUTO CHANGER

Page 2

WARNING

PORTABLE CART WARNING

(Symbol provided by RETAC)

S3125A

: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PA RTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Read Instructions - All the safety and operating instructions should be read before the product is operated.

2) Retain Instructions - The safety and operating instructions should be retained for future reference.

3) Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.

4) Follow Instructions - All operating and use instructions should be followed.

5) Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

6) Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards.

7) Water and Moisture - Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

8) Accessories - Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

10)

Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.

11) Power Sources - This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

12)

Grounding or Polarization - This product may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

IMPORTANT SAFEGUARDS

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

13)

Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

14) Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the product due to lightning and power-line surges.

15)

Power lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16) Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

17) Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

18) Servicing - Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19) Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) When the power-supply cord or plug is damaged. b) If liquid has been spilled, or objects have fallen into

the product. c) If the product has been exposed to rain or water. d)

If the product does not operate normally by following the

operating instructions. Adjust only those controls that

are covered by the operating instructions as an improp-

er adjustment of other controls may result in damage

and will often require extensive work by a qualified tech-

nician to restore the product to its normal operation. e) If the product has been dropped or damaged in

any way.

f) When the product exhibits a distinct change in per-

formance - this indicates a need for service.

20) Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

21) Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

22)

Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

–2–

Page 3

PRECAUTIONS

DVD VIDEO AUTO CHANGER

DVM-725

OPEN / CLOSE

DISC SELECT

DISC EXCHANGE

SKIP

STILL / PAUSE

PLAY

STOP

10 cm or more

Wall

Laser Safety

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE

SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE

INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

English

FCC WARNING-

This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003.

CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Non-use periods - Turn off the unit when it is not in use. Unplug the unit from the household AC outlet if it is not to be used for a long time. Unplug the unit during lightning storms.

Please read this operating instructions carefully before using your DVD player, and keep it for future reference.

Important

Use only discs marked with logos listed on page 6.

Power Supply

The main power supply is engaged when the main plug is plugged in a 120V, 60Hz AC outlet. To operate the unit, press the ON/STANDBY button to turn on the unit.

Warning

To avoid fire or electric shock, do not expose this unit to rain or moisture.

WARNING: LIVE PARTS INSIDE.

Cautions on Installation

Noise or disturbance of the picture may be generated if this unit or any other electronic equipment using microprocessors is used near a tuner or TV. If this happens, take the following steps:

• Install this unit as far as possible from the tuner or TV.

• Set the antenna wires from the tuner or TV away from this unit’s power cord and input/output connection cords. Noise or disturbance tends to occur particularly when using

• indoor antennas or 300Ω/ohms feeder wires. We recommend using outdoor antennas and 75Ω/ohms coaxial cables.

NOTE:

• For heat dispersal, do not install this equipment in a confined space such as a book case or similar unit.

DO NOT REMOVE ANY SCREWS.

Installation Location

For safety and optimum performance of this unit:

•

Do not stand the unit up vertically. Install the unit in a horizontal and stable position. Do not place anything directly on top of the unit. Do not place the unit directly on top of the TV. Shield it from direct sunlight and keep it away from sources

• of intense heat. Avoid dusty or humid places. Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes on the sides of the unit. Avoid locations subject to strong vibration or strong magnetic fields.

• Be sure to remove a disc and unplug the AC power cord from the outlet before carrying the unit.

–3–

Page 4

PRECAUTIONS

Dew Warning

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. Do not use the DVD Player at least for 2 hours until its inside is dry.

Avoid the Hazards of Electrical Shock and Fire

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting it from AC wall outlet. Grasp it by the plug.

• If, by accident, water is spilled on this unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

Caution

1) Do not attempt to open the cabinet.There are no parts you can service inside. Refer all servicing to qualified service personnel.

Slot and openings in the cabinet and at the side or bottom are provided for ventilation. To ensure reliable operation and to protect the unit from overheating these opening must not be blocked or covered. Avoid enclosed spaces such as book cases unless proper ventilation is provided.

TABLE OF CONTENTS

■

IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . 2

■

PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

■

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

About Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Notice for the Progressive Scan Outputs . . . . . . . . . . . . 5

Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Symbols Used in this Manual. . . . . . . . . . . . . . . . . . . . . 5

■

ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Playable Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

■

FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

■

FUNCTIONAL OVERVIEW . . . . . . . . . . . . . . . . . . . . . . 8

FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . 8

Tour of the remote control . . . . . . . . . . . . . . . . . . . . . . . 9

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Displays During Operation . . . . . . . . . . . . . . . . . . . . . . 11

Loading the Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . 11

■

HOOK UPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Description - rear panel . . . . . . . . . . . . . . . . . . . . . . . . 12

Connection to an audio system . . . . . . . . . . . . . . . . . . 13

Connection to a TV (for video) . . . . . . . . . . . . . . . . . . . 14

■

PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Basic Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

General Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Brightness of the Front Display . . . . . . . . . . . . . . . . . . 15

Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Disc Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

CALLING UP A MENU SCREEN DURING

PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Step by Step Playback. . . . . . . . . . . . . . . . . . . . . . . . . 15

Resume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Fast Forward / Reverse Search . . . . . . . . . . . . . . . . . . 16

Slow Forward / Slow Reverse . . . . . . . . . . . . . . . . . . . 16

Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Tr ack Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Title / Chapter Search . . . . . . . . . . . . . . . . . . . . . . . . . 17

Time Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3) Keep the unit away from the radiator heat sources.

4) Avoid using near strong magnetic fields.

5) Do not push objects of any kind into this through the cabinet slot as they could touch current carrying parts or short circuit parts resulting in a fire or electric shock.

6) Never spill liquid of any kind on this unit. If liquid is spilled into the unit, consult qualified service engineer.

7) Use this unit in a horizontal (flat) position only.

8) This equipment is in Stand-by mode when it turns off whilst the power cord is connected.

9) Keep the set free from moisture,water and dust.

10) Handle the power cord carefully. Hold the plug when unplugging the code.

11) All the safety cautions and operating instructions should be read before the DVD player is operated.

12) Use caution not to pinch your finger in the disc slot.

13) Do not put heavy objects on the AC power cord.

14) K eep the AC power cord away from heat appliances.

15) Be sure to remove a disc and unplug the AC power cord from the outlet before carrying the DVD player.

16) Do not put any pressure to the DVD player when carrying.

17) Do not use the DVD player outdoors.

Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

REPEAT TITLE / CHAPTER. . . . . . . . . . . . . . . . . . . 17

REPEAT TRACK . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

A-B REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Program Playback (CD) . . . . . . . . . . . . . . . . . . . . . . . . 18

Random Playback (CD) . . . . . . . . . . . . . . . . . . . . . . . . 18

MP3 / JPEG / WMA Playback . . . . . . . . . . . . . . . . . . . 19

Slide Show Mode (JPEG) . . . . . . . . . . . . . . . . . . . . . . 20

On-Screen Information. . . . . . . . . . . . . . . . . . . . . . . . . 20

Tr ack Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Random Playback (MP3 / JPEG / WMA) . . . . . . . . . . . 20

Program Playback (MP3 / JPEG / WMA) . . . . . . . . . . . 21

Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Stereo Sound Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Camera Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Changing the On-Screen Display . . . . . . . . . . . . . . . . . 22

Marker Setup Screen. . . . . . . . . . . . . . . . . . . . . . . . . . 23

Black Level Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Virtual Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

■

DVD SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Language Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Display Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Audio Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Ratings Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

RATING LEVEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

IF YOU FORGET THE PASSWORD . . . . . . . . . . . . . 25

CONTROL LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . 25

■

MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

■

TROUBLESHOOTING GUIDE. . . . . . . . . . . . . . . . . . . 28

■

SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

–4–

Page 5

654

+10

ENTER

INTRODUCTION

The serial number of this product may be found on the back of the DVD player. No others have the same serial number as yours.You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase

Dealer Purchase from

Dealer Address

Dealer Phone No.

Model No.

Serial No.

About Copyright

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Apparatus Claims of U. S. Patent Nos, 4,631,603, 4,819,098, 4,907,093, 5,315,448 and 6,516,132 licensed for limited viewing uses only.

Notice for the Progressive Scan Outputs

Consumers should note that not all high definition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of picture problems with 525 progressive scan output, it is recommended that the user switch the connection to the ‘standard definition’ output. If there are questions regarding your TV set compatibility with this 525p DVD player, please contact our customer service center.

English

Supplied Accessories

Please check to make sure the following items are included with the main unit in the carton.

Remote control

• • • • • •

“AA” (R6P)

batteries

• • • •

Audio cable

• • • • • • •

Video cable

• • • • • • • •

Operating Instructions

Service Station

• •

• • • • • • • • •

List

Warranty

Card

Symbols Used in this Manual

The following symbols appear below in some headings and notes in this manual, with the following meanings.

:Description refers to playback of DVD-Video discs. (including DVD-R/RW discs)

DVD

:Description refers to playback of Audio CDs.

:Description refers to playback of discs formatted with MP3.

MP3

JPEG

WMA

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

:Description refers to viewing of JPEG discs.

:Description refers to playback of discs formatted with WMA.

Make your contribution to the environment!!!

• Used up batteries do not belong in the dust bin.

• You can dispose of them at a collection point for used up batteries or special waste. Contact your council for details.

–5–

• • • • • • • •

Page 6

ABOUT THE DISCS

Playable Discs

Playable

discs

DVD-Video

* 1, 2, 3, 5

DVD-RW

DVD-R

* 1, 3, 4, 5, 6, 7, 8

Mark (logo)

Region code

Recorded

signals

Digital video

(MPEG2)

Disc size

12 cm

8 cm

Disc types

Example

Chapter 1 Chapter 2 Chapter 1

Title 1 Title 2

Chapter 3 Chapter 4

Chapter 2

Audio CD

* 3, 5

CD-RW

CD-R

* 3, 4, 5, 7, 8

Picture CD

* 3, 4, 5, 7, 8

is a trademark of DVD Format/Logo Licensing Corporation.

Digital audio

MP3

WMA

Digital picture

(JPEG)

12 cm

8 cm

12 cmJPEG

Audio CD

MP3,

JPEG,

WMA

Example

Tra c k 2

Tra c k 1

Example

Tra c k 1

Tra c k 3 Track 4

Group 1 Group 2

Tra c k 3

Tra c k 2 Track 5

Tra c k 4

is trademark of Eastman Kodak Company.

Tra c k 5

Tra c k 6

Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

If you cannot play back a disc which bears one of the marks above, check the following notes.

*1: This unit conforms to the NTSC color system. Discs recorded in other color systems such as PAL cannot

be played back. Certain DVD discs do not operate as described in this manual due to the intentions of the disc’s producers.

*2: *3: Scratched or stained discs may not be played back. *4: Some discs cannot be played back because of incompatible recording conditions, characteristics of the

recorder or special properties of discs.

*5: You can play back discs which bear the marks above. If you use nonstandardized discs, this unit may not

play them back. Even if they are played back, the sound or video quality will be compromised.

*6: Only the discs recorded in the video format and finalized can be played back.

Unfinalized discs cannot be played back. Depending on the recording status of a disc, the disc may not be played back at all or normally (the picture or sound may be distorted, etc.).

*7: If there is too much recording space left on a disc (the used portion is less than 55mm across), it may not

play back properly. Do not glue paper or put stickers on to the disc. These may damage the disc, and the unit may not read it correctly.

*8: *9: This player cannot play the disc contents protected by Windows Media Digital Rights Management (DRM).

¡ NEVER play back the following discs. Otherwise, malfunction may result!

DVD-RAM / CD-i / Photo CD / Video CD / DVD with region codes other than 1 or ALL / DVD-ROM for personal computers / CD-ROM for personal computers

¡ On the following disc, the sound MAY NOT be heard.

Super Audio CD

NOTES:

• Only the sound recorded on the normal CD layer can be delivered.

• The sound recorded on the high density Super Audio CD layer cannot be delivered.

¡ Any other discs without compatibility indications

CAUTION:

• Use caution not to pinch your finger in the disc slot.

• Be sure to remove a disc and unplug the AC power cord from the outlet before carrying the DVD player.

–6–

Page 7

FEATURES

¡Progressive Scan system

Unlike conventional interlace scanning, the progressive scan system provides less flickering and images in higher resolution than that of traditional television signals.

¡Dolby Digital sound

This player can handle Dolby Digital surround sound having Multi-channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Var ious playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for Audio CD, MP3, JPEG, and

WMA

This player can shuffle the order of tracks to play them in random order.

¡Program playback for Audio CD, MP3, JPEG, and

WMA

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Auto standby

When the screen saver program is activated for 35 minutes, the power is automatically turned off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode if different languages and modes are available on a disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This player automatically detects if a loaded disc is DVD-Video, Audio CD, MP3, JPEG, or WMA.

¡Playing an MP3 disc

You can enjoy MP3 files which are recorded on CDR/RW.

¡Direct Search

You can search the desired title, chapter, and track with the numeric buttons during playback or in stop mode.

¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), using the remote control.

¡DTS (Digital Theater System)

When this player is connected to a DTS decoder, you can enjoy Multi-channel surround system is developed by the Digital Theater Systems, Inc. which reproduces the original sound as truthfully as possible.

¡Search

Chapter search:Search for the chapter designated by

Title search: Search for the title designated by user

Tr ack search: Search for the track designated by

Time search: Search for the time designated by

¡Repeat

Chapter: Repeated playback of the chapter of

Title: Repeated playback of the title of the

Tr ack: Repeated playback of the track of the

Disc

(Audio CD)

(MP3/JPEG/WMA)

A-B: The part between A and B designated

Group: Repeated playback of the folder of the

5 Disc: Repeated playback of Audio CD/

¡Zoom

2-time or 4-time magnified screen can be displayed.

¡Marker

The part designated by user can be called back.

¡Resume playback

User can resume playback from the part at which the play was stopped even if the power is turned off.

¡Component Video Out Jacks

Jacks located on the back of the DVD Player which are used to send high-quality video to a TV via Component Video In Jacks.

¡Dimmer

Brightness of the display can be adjusted.

¡Bit rate indication ¡DRC (Dynamic range control)

You can control the range of sound volume.

¡Displaying a JPEG picture

Kodak Picture CD can be played. Still images stored in JPEG format on CD-R/RW can also be played.

¡Reproducing WMA data

You can enjoy WMA files which are recorded on CD-R/RW.

“WMA” (Windows Media Audio) is an audio codec developed by Microsoft®in the United States of America.

user is possible.

is possible.

user is possible.

the disc being played is possible.

disc being played is possible.

disc being played is possible. : Repeated playback is possible. : Repeated playback is possible.

by user is possible.

MP3/JPEG/WMA disc being played is

possible.

MP3/ JPEG/ WMA discs is possible.

English

–7–

Page 8

321

654

987

+10

ENTER

27 26

31 3

16 17

18 19

22 14

FUNCTIONAL OVERVIEW

DVD VIDEO AUTO CHANGER

DVM-725

OPEN / CLOSE

DISC SELECT

DISC EXCHANGE

SKIP

STILL / PAUSE

PLAY

STOP

11/25

13 1412/24

FRONT PANEL

REMOTE CONTROL

The buttons with circled numbers can only be operated with the remote control.

1. ON/STANDBY (POWER ON/OFF) Buttons [page 15]

2. Disc loading tray

3. OPEN/CLOSE Button [page 15]

4. PLAY Button [page 15]

5. STILL/PAUSE Button [page 15]

6. STOP Button [page 15]

7. Cursor Buttons [page 15]

Use when making settings while watching the display on a TV screen.

8. MENU Button [page 15]

9. SETUP Button [page 24]

10. ENTER Button [page 15]

11. G (SKIP) Button [page 17]

Plays back from the beginning of the next chapter or track.

12. H (SKIP) Button [page 17]

Plays back from the beginning of the current chapter or track.

13. DISC EXCHANGE Button [page 15]

Press to change discs during playback.

14. DISC SKIP Button [page 15]

Press to select a desired disc or disc tray.

15. Display, Remote Sensor Window

16. A-B REPEAT Button [page 18]

17. REPEAT Button [page 17]

18. RANDOM Button [page 18,20]

19. ZOOM Button [page 16]

20. CLEAR Button [page 17]

21. ANGLE Button [page 22]

Press to change the camera angle to see the sequence being played back from a different angle.

22. RETURN Button [page 21]

23. SEARCH MODE Button [page 17]

24. h (Fast Reverse SEARCH) Button [page 16]

Press more than 2 seconds when you use the front panel button for this function.

25. g (Fast Forward SEARCH) Button [page 16]

Press more than 2 seconds when you use the front panel button for this function.

26. SUBTITLE Button [page 22]

Press to select a desired subtitle language.

27. TOP MENU Button [page 15]

28. DISPLAY Button [page 20]

29. AUDIO Button [page 21]

Press to select a desired audio language or sound mode.

30. Numeric Buttons [page 17]

31. MODE Button [page 20]

32. DISC NUMBER Buttons [page 15]

Press to select a desired disc or disc tray directly.

–8–

Page 9

POWER Buttons

A-B REPEAT Button

REPEAT Button

MODE Button

SUBTITLE Button

DVD CD/MP3/JPEG/WMA

To switch the power between on and standby.

To mark a segment between A and B for repeated playback.

To mark a segment between A and B for repeated playback. (CD)

To repeat playback of a title or chapter.

To repeat playback of a track or disc. (CD)

To repeat playback of a track, group or disc. (MP3, JPEG, WMA)

RANDOM Button

To play back tracks in random order.

ZOOM Button

To set black level on/off.

To activate the 3D sound (Virtual surround system).

To program a specific playback order.

To activate the 3D sound (Virtual surround system). (CD, MP3, WMA)

To magnify part of the picture (x2/x4).

ANGLE Button

To access various camera angles on the disc.

To access various subtitles on the disc.

AUDIO Button

DISPLAY Button

To access various audio functions on the disc.

To select STEREO, L-CH or R-CH. (CD)

To display the current disc mode.

To search for a chapter, title, time or marker.

To return to a location on the disc rapidly.

OPEN/CLOSE Button

To search for a track.

To search for time or a marker. (CD)

To return to a location on the disc rapidly.

SEARCH MODE Button

Numeric Buttons

CLEAR Button

To open or close the disc tray.

To select a chapter or title directly.

To select a track directly.

To clear the markers.

To clear the numbers entered incorrectly.

To cancel the A point for A-B Repeat.

To clear the markers. (CD)

To clear the numbers entered incorrectly.

To cancel the A point for A-B Repeat. (CD)

FUNCTIONAL OVERVIEW

Tour of the remote control

Buttons on remote control work in different ways for DVD, Audio CD, MP3, JPEG and WMA : Refer to the following table for correct use.

English

–9–

Page 10

FUNCTIONAL OVERVIEW

DVDCD/MP3/JPEG/WMA

To call up the menu on a disc.

To call up the top menu on a disc.

To move the cursor and determine its position.

To return to the previous operation in the setup menu.

To move the cursor and determine its position.

To call up the setup menu.

To skip chapters/titles.

To skip tracks.

To begin fast forward/reverse search or slow forward/slow reverse.

To begin fast forward/reverse search. (CD, MP3, WMA)

To stop playback.

To begin playback.

To pause playback.

To advance playback frame by frame.

To pause playback.

To select a desired disc.

To select a desired disc directly.

To change discs during playback.

MENU Button

TOP MENU Button

ENTER, CURSOR Buttons

RETURN Button

SEARCH Buttons

SETUP Button

SKIP Buttons

STOP Button

PLAY Button

STILL/PAUSE Button

DISC SKIP Button

DISC NUMBER Buttons

DISC EXCHANGE Button

Tour of the remote control

–10–

Page 11

FUNCTIONAL OVERVIEW

Display

Stays on when repeat

Stays on when the repeat function is on.

Stays on when the A-B repeat function is on.

Stays on when the inserted disc is being played back.

title function is on.

Lights up when the inserted disc comes to a pause.

Stays on when repeat chapter function is on. Stays on when repeat track function is on. Lights up when a DVD is inserted into the tray.

Lights up when a CD is inserted into the tray.

Displays how long a current title or track has been played back. When a chapter or track has switched, the number of a new title, chapter or track is displayed.

The playing disc number flashes on.

English

Displays During Operation

Power on

No disc inserted

Tr ay open

Tr ay closed

Loading the Disc

Power off

Tr ay rotation

AC cord plugged in

Loading the Batteries

1. Open the battery compartment cover.

2. Insert two “AA” (R6P) batteries, with each one oriented correctly.

3. Close the cover.

NOTES

• Do not mix alkaline and manganese batteries.

• Do not mix old and new batteries.

Cautions On Batteries

• Use “AA” (R6P) batteries in this remote control unit.

• Replace the batteries with new ones approximately once a year, though this depends on the frequency with which the remote control unit is used.

• If the remote control unit does not operate close to the main unit, replace the batteries with new ones, even if less then a year has passed.

• The included batteries serve only for verifying operation. Replace them with new batteries as soon as possible.

• When inserting the batteries, be careful to do so in the proper direction, following the and marks

in the remote control unit’s battery compartment.

• To prevent damage or battery fluid leakage:

• Do not use a new battery with an old one.

• Do not use two different types of batteries.

• Do not short-circuit, disassemble, heat or dispose of batteries in flames.

• Remove the batteries when not planning to use the remote control unit for a long period of time.

• If the batteries should leak, carefully wipe off the fluid from the inside of the battery compartment, then insert new batteries.

–11–

Page 12

6 3 4 5 2 17

ROOM TO ROOM

HOOK UPS

Description - rear panel

1. DIGITAL OUT JACKS (OPTICAL/COAXIAL)

Use either an optical or coaxial digital cable (commercially available) to connect to a compatible Dolby Digital receiver. Use to connect to a Dolby Digital decoder or DTS decoder.

2. AUDIO OUT JACKS

Use an audio cable to connect to the Audio input jacks of A/V-compatible TV or wide screen TV, or Stereo system.

3. VIDEO OUT JACK

Use a video cable to connect to the Video input jacks on your A/V-compatible TV or wide screen TV, or Stereo system.

4. COMPONENT VIDEO OUT JACKS

Use a component video cable (commercially available) to connect these jacks if you have a TV with Component Video in jacks. These jacks provide CR/PR,CB/PBand Y video. Along with S-Video, Component Video provides the best picture quality.

5. S-VIDEO OUT JACK

Use the S-Video cable (commercially available) to connect this jack to the S-Video jack on your A/V-compatible TV or wide screen TV for a higher quality picture.

6. PROGRESSIVE switch

7. REMOTE CONTROL JACKS

Connecting the DENON Satellite Remote Control to these jacks enables you to operate more than one DENON components with one remote control.

When using the DENON Satellite Remote Control,

1. Connect the DENON Satellite Remote Control to the REMOTE CONTROL IN jack of this player. This allows you to operate this player with the Satellite Remote Control.

2. Connect another DENON component to the REMOTE CONTROL OUT jack of this player. This allows you to operate this player and the connected component with the same Satellite Remote Control.

Selecting Progressive Scan (525p/480p or Interlaced 525i/480i) Playback

¡If your TV is compatible with progressive scanning (525p/480p), connect the TV to the COMPONENT VIDEO OUT jacks of

the DVD player and set the Progressive switch on the back of the DVD player to “PROGRESSIVE”. Next, set your TV to the progressive scan mode.

If your TV is not compatible with progressive scan, keep the Progressive switch to “INTERLACE”.

¡Use a commercially available adaptor if the video input jacks of your TVs or monitors are the BNC type.

What is Progressive Scanning?

¡Unlike conventional interlace scanning, the progressive scan system provides less flickering and images in higher resolution

than that of traditional (525i/480i) television signals.

NOTE

• When the Progressive switch is set to “PROGRESSIVE”, no video signal will be output from the VIDEO OUT or S-VIDEO OUT jack.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

–12–

Page 13

HOOK UPS

The following show examples of connections commonly used to connect the DVD player to TV and other components. If using this DVD player to play back a DVD in a Dolby Digital Multi-channel surround or DTS surround format, the DVD player outputs a Dolby Digital or DTS data stream from its OPTICAL or COAXIAL DIGITAL OUT jacks. By hooking up the player to a Dolby Digital or DTS decoder, you can enjoy more convincing, realistic ambience with powerful and high-quality surrounding sound of a professional standard which can be heard in movie theaters. Use a commercially available audio optical or coaxial digital cable (not included) for the audio connections.

Notes

¡Be sure to turn off the power to all components in the system before connecting another component. ¡Refer to the Instruction Manuals for your TV, stereo system and any other components to be connected to the

DVD player.

Connection to an audio system

Method 1 Method 2

English

Dolby Digital decoder

Stereo system

AUDIO

DVD

• Method 1 DVD Player + Stereo system

• Method 2 DVD Player + Dolby Digital decoder or DTS decoder

NOTES

• If output Dolby Digital audio, connect to a Dolby Digital decoder, and set Dolby Digital to ON for audio output in the setup mode. (Refer to page 25)

• If output DTS audio, connect to a DTS decoder, and set DTS to ON for audio output in the setup mode. (Refer to page 25)

•

Unless connected to a Dolby Digital decoder, or a DTS decoder, set Dolby Digital or DTS to OFF for audio output in the setup

mode. Playing a DVD using incorrect settings may generate noise distortion, and may also damage the speakers. (Refer to page 25)

• The audio source on a disc in a Dolby Digital Multi-channel surround format cannot be recorded as digital sound by an MD or DAT deck.

• Set Dolby Digital and DTS to OFF for audio output in the setup mode for method 1 only. Playing a DVD using incorrect settings may generate noise distortion, and may also damage the speakers. (Refer to page 25)

• Harsh noise that could harm your ears or the speakers is generated when a DVD recorded in DTS is played while using a decoder, etc., that is not DTS-compatible.

• When playing a copyright-protected 96kHz PCM DVD, the digital sound will be down sampled at 48kHz, even if you set LPCM SELECT to OFF (Refer to page 25).

Audio Input Jacks

Audio cable

(supplied)

AUDIO OUT

(analog)

Digital Audio Input Jacks

Audio Coaxial

Digital cable

(commercially

available)

DIGITAL OUT

DTS decoder

Optical cable (commercially

available)

Optical cable (not supplied)

• Optical cable (not supplied) may be damaged when bent at sharp angles. Ensure cables are coiled in loops with a diameter of 6 inches (15 cm) or more when storing them.

• Use a cable which is 9.8 feet (3 m) or shorter.

• Insert cable plugs firmly into the connectors when making connections.

• If a plug has dust or is dirty, clean it with a soft cloth before inserting it into a connector.

–13–

Page 14

CB/PBYCR/PR

S-VIDEO IN

COMPONENT

VIDEO IN

HOOK UPS

Connection to a TV (for video)

Method 1 Method 2 Method 3

Good pictureBasic Audio Better picture Best picture

Audio

Cable

(supplied)

Video Cable

(supplied)

S-Video Cable

(commercially

available)

Component

Video Cable

(commercially

available)

DVD

AUDIO OUT

(analog)

• Method 1 DVD Player + TV with Video Input Jack

• Method 2 DVD Player + TV with S-Video Input Jack

• Method 3 DVD Player + TV with Component Video Jacks

NOTES

• If your TV is compatible with progressive scanning (525p/480p), connect the TV to the Component Video Output jacks of

the DVD player. Refer to page 12.

• Connect the DVD player directly to a TV. If the Audio/Video cables are connected to a VCR, pictures may be distorted due

to the copy protection system.

• S-Video output connector

The video signals are divided into color (C) and brightness (Y) signals, achieving a clearer picture. If the TV is equipped with a S-Video input connector, we recommend connecting it to the this product’s S-Video output connector using a commercially available S-Video connection cord.

VIDEO OUT

S-VIDEO OUT

COMPONENT VIDEO OUT

HOW TO CONNECT TO A TV WITHOUT AUDIO/VIDEO INPUT JACKS

If your TV does not have RCA type audio and video input jacks it is still possible to connect this DVD player to your TV’s 75-ohm coaxial antenna terminal using an optional Stereo Audio/Video RF Modulator, not included. Connect the audio and video outputs of the DVD player to the audio and video inputs on the RF Modulator, and then connect the coaxial output of the RF Modulator (usually marked “TO TV”) to the 75 ohm coaxial antenna terminal on your TV. Follow the instruction supplied with the RF Modulator for more details. If your TV’s 75 ohm coaxial antenna terminal is already occupied by an antenna or cable box connection, remove that cable from your TV’s antenna terminal and reconnect it to the coaxial antenna input terminal of the RF Modulator (usually marked “ANT IN”), then connect the RF modulator to your TV’s antenna terminal as described above.

NOTE

• The picture quality from DVD discs will not be as good if the DVD player is connected to the TV’s antenna terminal

through an RF Modulator.

–14–

Page 15

PLAYING A DISC

Basic Playback

WMAJPEGMP3CDDVD

Getting started

•Turn on the power of the TV, amplifier and any other components which are connected to the DVD player.

• Make sure the TV and audio receiver (commercially available) are set to the correct channel.

Press the POWER ON button.

• “P-ON” will appear briefly on the display panel.

Press the OPEN/CLOSE button to open disc loading tray.

Press the DISC SKIP button repeatedly or press the DISC NUMBER button.

• The desired disc tray moves to the front position.

Place the disc in the tray, with the label facing up.

• Repeat steps 3 and 4 to load more discs.

Right side tray

Press the PLAY button.

•The tray will close automatically, and playback will start from the first chapter or track of the disc. If the playback does not start automatically, press the PLAY button.

• If the disc has not been set on the tray, the DVD player will play the disc which is set on the right side tray.

• When you want to select the other disc, press the DISC SKIP button repeatedly or the DISC NUMBER button for your desired disc.

• When you playback the DVD with a title menu, it may appear on the screen. In this case, refer to “Title Menu”.

Press the STOP button to stop playback.

Left side tray

NOTES:

•A “prohibited icon” may appear at the top-right on the TV screen during operation, warning that a prohibited operation has been encountered by the DVD player or the disc.

•With DVDs that use some titles for playback program signals, playback may start from the second title, or it may skip these titles.

• During the playback of two layered disc, pictures may stop for a moment. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

• During the playback of a DVD-RW which has been recorded in the VR mode, the sound or picture may freeze momentarily depended on disc content.

•You can open the tray and change 2 discs during playback by pressing the DISC EXCHANGE button.

• Disc position will be displayed on the TV screen for about 5 minutes when you turn on the power or close the tray.

General Features

DVD

DVD may contain menus to navigate the disc and access special features. Press the appropriate Numeric buttons or use the Cursor buttons ( L / K / B / s ) to highlight your selection in the DVD main menu and press the ENTER but- ton to confirm.

NOTE:

• Unless stated, all operations described are based on remote control use. Some operations can be carried out using the menu bar on the TV screen.

Brightness of the Front Display

The brightness of the front display can be adjusted from the SETUP menu. Details are on page 24.

Pause

WMAJPEGMP3CDDVD

During playback, press the STILL/PAUSE button.

• Playback will pause and sound will be muted.

To continue playback, press the PLAY button.

Disc Menus

DVD

Press the MENU button.

• The DVD main menu will appear.

If the feature is not available, symbol may appear on the TV screen.

If disc menu is available on the disc, audio language, subtitle options, chapters for the title and other options will appear for selection.

Press the Cursor buttons ( L / K / B / s ) to select an item, and the ENTER button to confirm selection.

Title Menu

DVD

Press the TOP MENU button.

• The title menu will appear.

If the feature is not available, symbol may appear on the TV screen.

Press the Cursor buttons ( L / K / B / s ) to select an item, and the ENTER button to confirm the selection.

• Playback will begin at the selected Title.

CALLING UP A MENU SCREEN DURING PLAYBACK

• Press the MENU button to call up the DVD main menu.

• Press the TOP MENU button to call up the title menu.

NOTE:

• Contents of menus and corresponding menu operations may vary between discs. Refer to the manual accompanying the disc for details.

Step by Step Playback

DVD

During playback, press the STILL/PAUSE button.

• Playback will pause and sound will be muted.

The disc advances by one frame each time the

STILL/PAUSE button is pressed.

To exit step by step playback, press the PLAY but- ton.

English

–15–

Page 16

PLAYING A DISC

Resume

During playback, press the STOP button.

• Resume message will appear on the TV screen.

Press the PLAY button, playback will resume from

Resume ON

Press 'PLAY' to play from here. To play the beginning, press 'STOP' first and then 'PLAY'.

the point at which playback was stopped.

•To cancel resume, press the STOP button twice.

NOTES:

• The resume playback takes a little longer to take place compared to the normal playback.

•For MP3, JPEG or WMA, playback will resume from the beginning of the current track.

Fast Forward / Reverse Search

During playback, press the ggor hhbutton repeatedly to select the required forward or reverse speed: x2, x8, x50, x100.

•For Audio CDs, the speed is fixed at x16.

•For MP3 and WMA the speed is fixed at x8.

Button

Zoom

WMAJPEGMP3CDDVD

The Zoom function allows you to enlarge the video image and to pan through the enlarged image.

Press the ZOOM button during playback.

• Playback will continue.

Press the ZOOM button repeatedly to select the required zoom factor: x2, x4 or OFF.

x2 x4

Use the Cursor buttons ( L / K / B / s ) to move the zoomed picture across the screen.

DVD

WMAMP3CDDVD

100

To return to normal playback, press the PLAY button.

Slow Forward / Slow Reverse

During playback, press the STILL/PAUSE button.

Press the ggor hhbutton.

•

Slow motion playback will begin and sound will be muted.

Press the ggor hhbutton repeatedly to select the required speed: 1/16, 1/8, 1/2 of the normal playback.

To return to normal playback, press the PLAY button.

DVD

Button

To exit zoom mode, press the ZOOM button to OFF.

NOTES:

• Zooming function does not work while disc menu is shown.

• x4 zoom is not available on some discs.

1/16

1/8

1/2

–16–

Page 17

PLAYING A DISC

__/ 15

_:__:__ 1:23:45

Track Search

WMAJPEGMP3CD

There are three ways to begin playback on an Audio CD, MP3, JPEG or WMA disc at a specific track.

By using the Numeric buttons

Press the Numeric buttons to enter the desired track number.

• Playback will start at the selected track.

•For single digit tracks (1-9), press a single number (eg.

track 3, press 3).

•To play track 26, press +10, 2, 6.

By using the SEARCH MODE button

Press the SEARCH MODE button.

•The track search display appears.

Within 30 seconds, select a desired track number using the Numeric buttons. For single digits press 0 first.

• Playback will start at the selected track.

• Press the CLEAR button to erase the incorrect input.

By using the SKIP buttons

During playback, press the next track. Press it repeatedly to skip subsequent tracks. Press the current track. Press it repeatedly to go to the previous tracks.

•

Tr ack number will appear briefly on the front panel display.

• If any SKIP button is pressed while the playback is

paused, the playback will be paused again after skipping to the next track.

SKIP

button to go back to the beginning of the

SKIP

HH GG

button to move to the

NOTE:

• The SKIP H and G buttons are not available when

playback is stopped.

Title / Chapter Search

DVD

By using the SEARCH MODE button

Press the SEARCH MODE button for the title/chapter search.

NOTES:

• Depending on the disc being played, the Numeric buttons can be used to search for a desired chapter by entering the chapter number directly. Refer to the manual accompanying the disc.

• The SKIP H and G buttons are not available when playback is stopped.

•A disc that does not contain chapters within titles, the

SKIP H and G buttons change the titles.

Time Search

DVD

During playback, press the SEARCH MODE button

three times to display the Time Search on the TV screen.

Within 30 seconds, enter a

desired disc time with the Numeric buttons.

• Playback will start at the specified time.

Press the CLEAR button to erase the incorrect

input.

During playback, press the SEARCH MODE button

twice to display the Time Search on the TV screen.

Within 30 seconds, enter a desired disc time with

the Numeric buttons.

• Playback will start at the specified time.

Press the CLEAR button to erase the incorrect

input.

Repeat

• The REPEAT button is available only during playback.

REPEAT TITLE / CHAPTER

DVD

To activate the repeat function, press the REPEAT button during playback.

• The repeat mode changes as described below every time you press the button.

CHAPTER TITLEOFF

(repeat off)

(current chapter repeat) (current title repeat)

English

Enter the desired title/chapter number with the

Numeric buttons.

By using the SKIP buttons

During playback, press the chapter. Press it repeatedly to skip to subsequent chapters. Press the rent chapter. Press it repeatedly to go to the previous chapter

• Chapter number will appear briefly on the front display panel.

• If the SKIP H or G button is pressed while the playback is paused, the playback after skipping to the next chapter will be also paused.

SKIP

button to go back to the beginning of the cur-

SKIP

HH GG

button to move to the next

–17–

NOTES:

• Repeat title/chapter is not available with some scenes.

• The repeat setting will be cleared when moving to other title or chapter.

• Repeat playback does not function during A-B repeat playback.

Page 18

PLAYING A DISC

REPEAT TRACK

To activate the repeat function, press the REPEAT button during playback.

• The repeat mode changes as described below every time you press the button.

OFF

(repeat off)

TRACK DISC

(current track repeat) (entire disc repeat)

5 Disc Repeat

NOTES:

•

The repeat setting will be cleared when moving to other track

•

Repeat playback does not function during A-B repeat playback.

WMAJPEGMP3

OFF

(repeat off)

TRACK DISC

(current track

repeat)

5 Disc Repeat

• The repeat setting will be cleared when moving to other track or group.

A-B REPEAT

GROUP

(current folder

repeat)

(entire disc

repeat)

CDDVD

Press the A-B REPEAT button at your chosen starting point.

• A- appears briefly on the TV screen.

Press the A-B REPEAT button again at your chosen end point.

• A-B appears briefly on the TV screen, and the repeat sequence begins.

To exit the sequence, press the A-B REPEAT button.

A -

A - B

OFF

Press the Cursor buttons (▲ or ▼) to select a disc, then press the ENTER button.

• Press the CLEAR button to erase

the most recently entered pro-

PROGRAM

DISC

CD [AUDIO CD [AUDIO CD [AUDIO CD [AUDIO CD [AUDIO

CD [AUDIO

] ] ] ] ]

1/ 1

]

gram.

Press the Cursor buttons (▲ or ▼) to select a track, then press the ENTER button.

• Press the CLEAR button to erase

the most recently entered pro-

PROGRAM

CD [AUDIO]

1 2 3 4 5 6 7

1/2

1/1

gram.

Press the PLAY button to start programmed play- back.

NOTES:

• Press the STOP button once and then the PLAY button again, playback will restart from the point where the STOP button was pressed. (Program continued)

• Press the STOP button twice and then the PLAY button again, playback will restart from the track in the usual way. (Program cleared)

• The program setting will be canceled when the power is turned off or the disc tray is opened.

• Up to 99 tracks can be entered.

• If you wish to repeat the current track in the program, press the REPEAT button repeatedly until TRACK appears during playback. If you wish to repeat the entire program press the REPEAT button repeatedly until DISC appears during playback.

•If eight or more tracks were set in a program, use the SKIP H or G button to see all the tracks.

• Refer to page 21 for program playback of MP3, WMA, and JPEG.

Random Playback

This shuffles the playing order of tracks instead of playback in the original sequence.

When playing back tracks in a single disc randomly

In stop mode, press the RANDOM button once or press the MODE button twice.

Press the PLAY button to start random playback.

When playing back tracks in more than one discs randomly

In stop mode, press the RANDOM button twice or press the MODE button three times.

Press the PLAY button to start random playback.

RANDOM

CD [AUDIO]

RANDOM PROGRAM

--no indication--

NOTES:

• The A-B repeat section can only be set within the current title (for DVDs), or current track (for Audio CDs).

• A-B repeat is not available with some scenes in DVD.

•

To cancel the A point which was set, press the CLEAR button.

• A-B repeat playback does not function during title, chapter, track or all repeat playback.

Program Playback

You may determine the order in which tracks will play.

In stop mode press the MODE button.

• The PROGRAM screen will appear.

–18–

NOTES:

• If there are discs other than CD in the disc tray, the display will show “----” next to the disc number. If there is no disc in a tray, this area will be blank.

• If you wish to repeat the current track in the random selection, press the REPEAT button repeatedly until TRACK appears during playback. If you wish to repeat the entire random selection, press the REPEAT button repeatedly until DISC appears during playback.

•You cannot go back to the previous track during random playback.

• Refer to page 20 for random playback of MP3, WMA, and JPEG.

Page 19

PLAYING A DISC

MP3 / JPEG / WMA Playback

WMAJPEGMP3

This DVD player can reproduce images and sounds from data recorded in MP3, JPEG and WMA formats on CD-R and CD-RW discs. The DVD player can also run JPEG files stored on Kodak Picture CD. The user can enjoy picture images on the television set by reproducing Picture CDs. * Picture CD is a service to convert a photograph taken by

conventional film camera into digital data and write the data

on a CD. For details of Picture CD, contact a shop that deals with developing service of Kodak Inc.

This player recommends the use of files recorded at the following specifications:

Applicable MP3 file Remarks

Sampling frequency

Type

Applicable JPEG file Remarks

Size of image

Applicable WMA file Remarks

Sampling frequency

Bit rate 48–192kbps

Type WMA version 8

44.1kHz 48kHz

MPEG1 audio layer 3

Upper limit: 6300x5100 dots Lower limit: 32x32 dots

44.1kHz 48kHz

Information on MP3, JPEG and WMA discs

• A file with an extension of “.mp3 (MP3)” is called an “MP3 file”.

• A file with an extension of “.jpg (JPG)” or “.jpeg (JPEG)” is

called a “JPEG file”. The DVD player can run an image file conforming to the Exif* specification.

* This is a file format, Exchangeable Image File format

established by Japanese Electronic Industry Development Association (JEIDA).

• A file with an extension of “.wma (WMA)” is called a

“WMA file”.

• Files whose extension is other than “.mp3 (MP3)”, “.jpg

(JPG)”, “.jpeg (JPEG)” or “.wma (WMA)” will not be listed on the MP3, JPEG, or WMA menu.

• If the file is not recorded in MP3, JPEG or WMA format, noise

may be produced even if the file extension is either of “.mp3 (MP3)”, “.jpg (JPG)”, “.jpeg (JPEG)” or “.wma (WMA)”.

When a disc with MP3,JPEG or WMA files is inserted in the DVD player, the track menu will appear on the TV screen, and number of tracks is displayed on the front panel.

• It is prohibited to record MP3 sound on a digital device when connection is made digitally.

• MP3 files recorded at fixed bit rate of 112 kbps or higher are recommended.

• A JPEG image that extends beyond the screen is reduced so that it will be displayed within the screen.

• Those frequencies are applicable to WMA version 8 only, not to WMA version

• Ensure that the copyright function is set to off when preparing a WMA disc.

• A prohibition “disable” symbol will appear if the user attempts to run a non-reproducible file such as copyright-protected.

Place the disc in the tray with the label facing up.

For discs on which MP3, JPEG or WMA tracks are recorded:

• An MP3, JPEG or WMA track menu screen appears.

• A symbol of “ ” is shown on the top of the group name.

• A symbol of “ ” is shown on the top of MP3 files.

• A symbol of “ ” is shown on the top of JPEG files.

• A symbol of “ ” is shown on the top of WMA files.

• If the track extends beyond the scope of screen, a down

arrow “L” appears, indicating that the user can view another part on the next page. If an up arrow “K” appears, it indicates that the user can view another part on the previous page. The current page number and the number of total pages are shown on the right of the down arrow “L”.

• The system can recognize up to 255 groups (or folders)

and up to 256 tracks. (This applies to the case where mixed MP3, JPEG and WMA files are recorded.)

• If no MP3, JPEG or WMA files are found in the group, the

group is not displayed.

• The DVD player can reproduce data recorded as per ISO

9660 Level 1, Level 2 or Joliet on the disc.

• It can also run a disc on which data is recorded in a multi-

session.

• For more details of recording systems, see the instruction

manual for the CD-R / CD-RW drive or the writing software.

• For MP3 and WMA files recorded in Variable Bit Rate

(VBR), the unit may not display the actual elapsed time.

For discs of JPEG or Kodak Picture CD:

• A JPEG or Kodak Picture CD menu appears.

• If all menu items cannot be displayed in the screen scope,

“G” appears at the right bottom of the screen, indicating that the user can view remaining items on the next page. If “H” appears, it indicates that the user can view other items on the previous page. The track number of the currently highlighted item and the total tracks are shown at the center bottom of the screen.

• If “G” is shown at the right bottom, use the SKIP G but-

ton to view the next page. If “H” is shown at the left bot- tom, use the SKIP H button to view the previous page.

• It may take some time until all menu items are displayed

on the menu screen.

For MP3, JPEG or WMA, press the Cursor buttons (K or L), or for Kodak Picture CD, press the Cursor buttons (

s / B / K / L) to select a desired

group or track.

• To return to the previous screen, press the Cursor button

(s).

• If a group (folder) is selected, press the Cursor button (B) or ENTER button to go on to the track selection screen. Press the Cursor buttons (K or L) to choose a track, then press the PLAY or ENTER button.

• If a track is selected, press the PLAY or ENTER button to start playing back tracks. The selected track and the subsequent tracks will be played back.

• When selecting the folders –Press the Cursor button (B) when you want to go to the

next hierarchy.

–Press the Cursor button ({) when you want to go back

to the previous hierarchy (except for the top hierarchy).

• If an MP3 or WMA file is selected, reproduction will start from the selected track and go to the next one in turn.

• If a JPEG or Kodak Picture CD file is selected, an image will be reproduced from the selected track and go to the next one in turn.

English

–19–

Page 20

PLAYING A DISC

Press the STOP button to stop playback.

Notes on MP3, JPEG and WMA:

• Select “FIRST PLAY” and press the PLAY button, playback

from the top of the disc in the order of tracks and groups.

• The ninth and deeper hierarchies cannot be played.

• The name of group and track can be displayed in up to 25

characters. Alphabets, numerals underline, asterisk or space may not be displayed. Unrecognizable characters will be replaced with asterisks.

• Un-reproducible groups or tracks may be displayed

depending on the recording conditions.

• If the TOP MENU button is pressed when a file list is dis-

played, “FIRST PLAY” will be highlighted.

Notes on WMA:

• The DVD player can reproduce data recorded as ISO 9660

level 2 with 31 characters file name included punctuation marks. The name of file can be displayed up to 25 characters.

• Maximum of 8 subfolders can be recognized.

• This unit cannot play back copyright protected WMA files.

Notes on JPEG and Kodak Picture CD:

• A track is displayed for five seconds and then the next

track is displayed.

•Every press on the Cursor button (B) will turn the image

clockwise by 90 degrees when an image is displayed. A press on the Cursor button (s) will turn the image counterclockwise by 90 degrees.

• Progressive JPEGs (JPEG files saved in the progressive format) will not be played back on this DVD player.

• High resolution JPEG files take longer to be displayed.

Notes on Kodak Picture CD:

• A press on the STOP button will highlight the previously

displayed track on the menu screen. Press the STOP button again or press the TOP MENU button, and the menu screen displays tracks 1 to 6, where track 1 is highlighted.

Slide Show Mode

JPEG

You can switch to the slide show mode during playback.

Press the MODE button during playback.

• The slide show mode screen will appear.

• The slide show mode cannot be switched when it is stopped, or from the file list screen or the Picture CD menu screen.

Press the ENTER button.

• The slide show mode will change. 1 The entire image appears in one time. 2 The image appears gradually and then disappears.

Press the MODE button to exit.

On-Screen Information

WMAJPEGMP3

You can check each file during playback.

Press the DISPLAY button once during playback to show current Disc number.

CD[DATA]

Press the DISPLAY button again.

• The name of the file currently in play will be displayed.

TRACK 01

<Example: MP3>

Press the DISPLAY button for the third time to show the track number, the elapsed time (MP3 and WMA), the repeat status, and the playback status at the top of the screen.

• will be displayed when the repeat play has been selected.

T- indicates Track repeat

G-

indicates Group (folder) repeat

D- indicates Disc repeat

5- indicates 5 Disc repeat

Press the DISPLAY button for the forth time to exit.

• During program or random playback, each playback status will be displayed when you press the DISPLAY button. Then press the DISPLAY button again to exit.

TR 1/36 0:01:15

Track Selection

WMAJPEGMP3

Press the SEARCH MODE button during playback.

• The FILE LIST will appear.

Select a desired track using the Cursor buttons (L/K/B/s).

• Press the Cursor button (B) when you want to go to the next hierarchy.

• Press the Cursor button (s) when you want to go back to the previous hierarchy.

Press the PLAY button to start playing

NOTES:

• Press the SEARCH MODE button to exit.

• Some selections may require additional time to be recognized.

• During playback a desired track can be directly searched. Just press the track number with the Numeric buttons.

• If the pressed track number is not available, the “disable” symbol appears and the direct search mode is cancelled.

• Playback cannot be started from a desired time count.

• Pressing the SKIP button G or H will play the next or previous file.

• The SEARCH button is not effective for Picture CD.

Random Playback

WMAJPEGMP3

Press the RANDOM or MODE button while playback is stopped.

• The RANDOM screen will appear.

Press the PLAY button to play the tracks in random order.

•You cannot go back to the previous track during random playback.

•For a disc containing mixed MP3, JPEG and WMA files, random playback of those files will be performed.

RANDOM

CD [DATA]

RANDOM PROGRAM

--no indication--

–20–

Page 21

PLAYING A DISC

1.ENG Dolby D 5.1ch 48k/3

2.FRE Dolby D 5.1ch 48k/3

3.JPN Dolby D 5.1ch 48k/3

HELLO

Bon jour

Program Playback

WMAJPEGMP3

This function allows you to program a playback order of MP3, JPEG or WMA in a desired sequence.

Press the MODE button while playback is stopped.

• The PROGRAM screen will appear.

Press the Cursor buttons (K or L) to select a group, then press the ENTER button.

•A track selection screen appears.

Press the Cursor buttons (K or L) to select a track, then press the ENTER button to save it in a program.

• Press the CLEAR button to erase the incorrect input.

• The programmed track is displayed in the right-hand screen.

• If the entire program cannot be displayed at once on the screen, “L” appears to go to the next page.

• Pressing the Cursor button (s) ers that belong to the one-level upper hierarchy than the currently selected folder.

Press the PLAY button to start programmed play- back.

NOTES:

• Press the RETURN button, and the stop screen will show up with the program contents in memory.

• Press the STOP button once and then the PLAY button again, playback will restart from the point where the STOP button was pressed. (Program continued)

• Press the STOP button twice and then the PLAY button again, playback will restart from the track in the usual way. (Program cleared)

• The program setting will be cancelled when the power is turned off or the disc tray is opened.

• Up to 99 tracks can be set in a program.

DISC appears during playback.

• If an inser ted disc contains mixed MP3, JPEG and WMA files, program setting allows 99 tracks for combination of MP3, JPEG and WMA files.

•If eight or more tracks were set in a program, use the

SKIP H or G button to see all the tracks.

Audio Language

PROGRAM

MY COLLECTION

ABC DEF GHI JKL

1/1

ABC

PROGRAM

ABC

DEF GHI JKL MNO

1/2

DEF

PROGRAM

ABC

DEF GHI JKL MNO

1/2

DEF

will show a list of fold-

English

DEF

1/1

NOTES:

• The sound mode cannot be changed during playback of discs not recorded in double sound.

• Some discs allow to change audio language setting on the disc menu. (Operation varies between discs. Refer to the manual accompanying the disc.)

• Pressing the AUDIO button may not work on some DVDs with multiple audio languages (e.g. DVDs which allow audio language setting on the disc menu).

• If you choose a language that has a three-letter language code, the code will be displayed every time you change the Audio Language setting. If you choose any other languages, ‘---’ will be displayed instead (refer to page 26).

Stereo Sound Mode

Press the AUDIO button repeatedly during playback to select between STEREO, L-CH or R-CH.

STEREO - both right and left channels are active (stereo) L-CH - only left channel is active R-CH - only right channel is active

STEREO

L-CH

R-CH

Both right and left channels are active (stereo).

Only the left channel is active.

Only the right channel is active.

DVD

The DVD player allows you to select a language (if multiple languages are available) during DVD disc playback.

Press the AUDIO button during playback.

Press the AUDIO button repeatedly to select your desired language.

NOTES:

• If the Virtual Surround setting is ON, the sound mode will be fixed to STEREO, and can not be changed.

• Stereo sound mode will not be changed when playing DTS CD.

–21–

Page 22

PLAYING A DISC

Subtitle 1

Subtitle 2

OFF

1.ENG/6

2.FRE/6

OFF

Angle 1

Angle 2

Angle 8

1 / 8

2 / 8

8 / 8

9/49 0:00:00 -0:00:00

1/5 0:00:00 -0:00:00

Subtitle Language

DVD

The DVD player allows you to select a subtitle language (if multiple languages are available) during DVD playback.

Press the SUBTITLE button during playback.

Press the SUBTITLE button repeatedly to select your desired subtitle language.

• The selected language will be displayed on the display bar at the top of the screen.

To turn off subtitles, press the SUBTITLE button repeatedly until OFF appears.

NOTES:

• Some discs allow subtitle language setting on the disc menu. (Operation varies between discs, so refer to the manual accompanying the disc.)

• Pressing the SUBTITLE button may not work on some DVDs with multiple subtitle languages (e.g. DVDs which allow subtitle language setting on the disc menu).

• If the desired language is not shown after pressing the SUBTITLE button several times, the disc does not have subtitles in that language.

• If you choose a language that has a three-letter language code, the code will be displayed every time you change the Subtitle Language setting. If you choose any other languages, ‘---’ will be displayed instead. (Refer to page 26.)

Camera Angle

Changing the On-Screen Display

DVD

You can check information about the current disc by pressing the DISPLAY button on the remote control.

Press the DISPLAY button once during playback to show current disc number.

Press the DISPLAY button again during playback.

• Current chapter number/total chapters, elapsed time and remaining time of the current chapter, and current playback status will be displayed.

Press the DISPLAY button again.

• Current title number/total titles, elapsed time and remaining time of the current title, and current playback status will be displayed.

Press the DISPLAY button again.

• The bit rate (the amount of video data currently being read) and current playback status will be displayed.

• Current repeat setting appears on the display bar only when the repeat setting is active.

(C:Chapter repeat/ T: Title repeat/A B: A-B repeat)

• If you are playing a dual layered disc, the layer number will also be displayed ( L0: Layer 0 is played. L1: Layer 1 is played).

Press the DISPLAY button again to remove the display.

DVD

IIII

Some DVD discs contain scenes which have been shot simultaneously from various angles. You can change the camera angle when the ( ) mark appears on the screen.

Press the ANGLE button during playback.

• The selected angle will be displayed on the display bar at the top of the screen.

Press the ANGLE button repeatedly to select your desired angle.

NOTE:

• If the “ANGLE ICON” setting is “OFF” in the Display menu, the ( ) will not appear.

DVD

–22–

Press the DISPLAY button once during playback to show current disc number.

Press the DISPLAY button again.

• Current track number/total tracks, elapsed time and remaining time of the current track, and current playback status will be displayed.

• Current repeat setting appears on the display bar only when the Repeat setting is active.

(T:Track repeat/ D: Disc repeat/ 5: 5Disc repeat/ AB:A-B repeat)

Press the DISPLAY button again.

• Current track number/total tracks, elapsed time and remaining time of the entire disc, and current playback status will be displayed.

• Current repeat setting appears on the display bar only when the Repeat setting is active.

(T:Track repeat/ A: All tracks repeat/A B: A-B repeat)

Press the DISPLAY button again to remove the display.

• During program or random playback, each playback status will be displayed when you press the DISPLAY button. Then press the DISPLAY button again to exit.

Page 23

PLAYING A DISC

Marker Setup Screen

DVD

Use markers to memorize your favorite places on a disc.

Press the SEARCH MODE button four times during playback.

• The display screen and Markers will appear on the TV screen.

Press the Cursor buttons (s or B) to select 1, 2, 3, 4, 5, 6, 7, 8, 9, or 10 and ensure that “_ _ : _ _ : _ _” appears in the display.

When reaches the desired point, press the ENTER button.

• The title or track and elapsed playing time will appear in the TV screen.

To return to the Marker later, press the SEARCH MODE button four times during playback and the Cursor buttons (s or B) to choose the desired marker, then press the ENTER button.

NOTES:

• Opening the disc tray, turning off the power or selecting AC at step and pressing the ENTER button will erase all Markers.

•To clear a marker, using the Cursor buttons (s or B), position the cursor on to the marker number to be cleared and press the CLEAR button.

•You can mark up to 10 points.

Press the SEARCH MODE or RETURN button to

exit.

1 2 3 4 5 6 7 8 9 10

DVD

-- --:--:--

Black Level Setting

DVD

Adjust the Black Level Settings to make the black parts of

the picture as bright as you prefer.

Press the MODE button during playback.

Press the ENTER button to switch ON/OFF.

ON (Default) : Makes the dark

OFF : Shows the original picture

Press the MODE or RETURN button to exit.

parts brighter.

as recorded.

English

Virtual Surround

DVD

You can enjoy stereophonic visual space on your existing 2 channel stereo system.

Press the MODE button twice during playback.

Press the ENTER button to set it 1(Natural effect), 2(Emphasized effect) or OFF.

Press the RETURN button to exit.

OFF

Press the SEARCH MODE button three times during playback.

• The display screen and Markers will appear on the TV screen.

Press the Cursor buttons (s or B) to select 1, 2, 3, 4, 5, 6, 7, 8, 9, or 10 and ensure that “_ _ : _ _ : _ _” appears in the display.

When reaches the desired point, press the ENTER button.

• The title or track and elapsed playing time will appear in the TV screen.

To return to the Marker later, press the SEARCH MODE button three times during playback and the Cursor buttons (s or B) to choose the desired marker, then press the ENTER button.

NOTES:

• Opening the disc tray, turning off the power or selecting AC at step and pressing the ENTER button will erase all Markers.

•To clear a marker, using Cursor buttons (s or B), position the cursor on to the marker number to be cleared and press the CLEAR button.

•You can mark up to 10 points.

Press the SEARCH MODE or RETURN button to

exit.

Press the MODE button during playback.

Press the ENTER button to set 1(Natural effect), 2(Emphasized effect) or OFF.

Press the RETURN button to exit.

NOTES

• Select Virtual Surround OFF or adjust the volume down if the sound is distorted.

• Vir tual Surround will not be effective if the sound mode is set to something other than “STEREO” (for Audio CD playback only).

WMAMP3CD

–23–

Page 24

DVD SETUP

LANGUAGE

DIALOG ORIGINAL SUBTITLE OFF DISC MENU ENGLISH OSD ENGLISH

DISPLAY

TV ASPECT

4:3 LETTER BOX PANEL DISPLAY BRIGHT ANGLE ICON ON AUTO POWER OFF ON

LANGUAGE DIALOG ORIGINAL ENGLISH FRENCH SPANISH GERMAN ITALIAN SWEDISH L

LANGUAGE SUBTITLE OFF ENGLISH FRENCH SPANISH GERMAN ITALIAN SWEDISH L

LANGUAGE DISC MENU ENGLISH FRENCH SPANISH GERMAN ITALIAN SWEDISH DUTCH L

LANGUAGE OSD ENGLISH FRANÇAIS ESPAÑOL

DISPLAY TV ASPECT

4:3 LETTER BOX 4:3 PAN & SCAN 16

:9 WIDE

DISPLAY PANEL DISPLAY

BRIGHT DIMMER AUTO

DISPLAY

TV ASPECT

4:3 LETTER BOX PANEL DISPLAY BRIGHT ANGLE ICON ON AUTO POWER OFF ON

DISPLAY

TV ASPECT

4:3 LETTER BOX PANEL DISPLAY BRIGHT ANGLE ICON ON AUTO POWER OFF ON

In Setup menu, QUICK mode and CUSTOM mode are available. QUICK mode consists of the setting menus often needed, and you can make all settings in CUSTOM mode. You can make the settings of the items with mark in QUICK mode.

QUICK

Language Setting Display Setting

Language options are not available with some discs.

Press the SETUP button in stop mode.

Press the Cursor button (B) to select CUSTOM, then press the ENTER button.

• CUSTOM mode will appear.

Press the Cursor buttons (s or B) to select LANGUAGE, then

the ENTER button to confirm.

Press the Cursor buttons (K or L) to select the be- low items, then press the ENTER button.

DIALOG

SUBTITLE

DISC MENU

(Default : ORIGINAL)

• Sets the audio language.

(Default : OFF)

• Sets the subtitle language.

(Default : ENGLISH)

• Sets the language for DVD Menu.

OSD (Default : ENGLISH)

• Sets the language for the OnScreen display.

QUICK

You can change certain aspects of the DVD display screens, on-screen messages and the display panel on the front of the DVD player.

Press the SETUP button in stop mode.

Press the Cursor button (B) to select CUSTOM, then press the ENTER button.

•

CUSTOM mode will appear.

Press the Cursor buttons (s or B) to select DISPLAY, then the ENTER button to con- firm.

Press the Cursor buttons (K or L) to select an item, then press the ENTER button.

TV ASPECT

• Press the Cursor buttons (K or L)

for an item selection, then press the ENTER button. Select 4:3 LETTER BOX for a

• black bars appears on top and bottom of the screen.

• Select 4:3 PAN & SCAN for a full height picture with both sides trimmed. Select 16:9 WIDE if a wide-screen TV is connected to the

• DVD player.

PANEL DISPLAY

(Default : 4:3 LETTER BOX)

(Default :

QUICK

BRIGHT)

• Press the Cursor buttons (K or L) for an item selection (BRIGHT, DIMMER or AUTO) then press the ENTER button.

• When AUTO is selected, the display dims only during playback.

ANGLE ICON

• Press the ENTER button repeatedly to turn Angle mark ON or OFF.

(Default : ON)

Press the Cursor buttons (K or L) to select a set- ting, then press the ENTER button.

• If OTHERS is selected in the DIALOG, SUBTITLE or DISC MENU screen, press four-digit number to enter the code for the desired language. (Refer to the language code list on page 26).

•

Only the languages supported by the disc can be selected.

Press the SETUP button to exit.

NOTE:

• Language Setting for DIALOG and SUBTITLE is not avail-

able with some discs. Then use the AUDIO and SUBTI- TLE buttons. Details are on pages 21 and 22.

AUTO POWER OFF

(Default : ON)

• Press the ENTER button repeat-

edly to turn AUTO POWER OFF ON or OFF.

• It will turn the DVD player to off automatically after 35 minutes of no use.

Press the SETUP button to exit.

NOTES:

• Be sure to press the SETUP button, or the setting will not work.

•You can also choose the item by pressing the numbers.

–24–

Page 25

DVD SETUP

AUDIO

DRC

OFF DOLBY DIGITAL ON DTS ON LPCM SELECT OFF

RATINGS

RATING LEVEL ALL CHANGE

RATINGS

Please enter a 4-digit password.

RATINGS RATING LEVEL ALL 8 7 [NC-17] 6 [R] 5 4 [PG13] 3 [PG] L

AUDIO

DRC

OFF DOLBY DIGITAL ON DTS ON LPCM SELECT OFF

AUDIO

DRC

OFF DOLBY DIGITAL ON DTS ON LPCM SELECT OFF

AUDIO

DRC

OFF DOLBY DIGITAL ON DTS ON LPCM SELECT OFF

AUDIO

DRC

OFF DOLBY DIGITAL ON DTS ON LPCM SELECT OFF

Audio Setting

Choose the appropriate Audio settings for your equipment as it only affect during the playback of DVD discs of the DVD player.

Press the SETUP button in stop mode.

Press the Cursor button (B) to select CUSTOM, then press the ENTER button.

• CUSTOM mode will appear.

Press the Cursor buttons (s or B) to select AUDIO, then the ENTER button to confirm.

Press the Cursor buttons (K or L) to select an item, then press the ENTER button.

DRC (Dynamic Range Control) (Default : OFF)

•To compress the range of sound volume.

• DRC function is available only on the discs that are recorded in the Dolby Digital format.

DOLBY DIGITAL

(Default : ON)

QUICK

• Set to ON when the player is connected to Dolby Digital Decoder.

ON : Output by Dolby Digital OFF : Convert the Dolby Digital

to PCM

• This function is effective only for the COAXIAL and OPTICAL connections.

DTS (Default : ON)

• Set to ON when the unit is connected to DTS Decoder.

ON : Output by DTS sound OFF: No DTS sound will be out-

put.

• This function is effective only for the COAXIAL and OPTICAL connections.

LPCM SELECT

• Set to ON when outputting in 48kHz.

When playing disc with copyright protection

•Even if you select OFF, copyright protection will be activated and sound will be down sampled at 48kHz.

Press the SETUP button to exit.

(Default : OFF)

Ratings Control

Ratings Control limits playback of discs with unsuitable audience ratings. A four digit code established by the user will unlock the parental lock. This feature allows you to prevent your children from playing discs with objectionable scenes.

RATING LEVEL

Rating Level allows you to set the rating level of your DVD discs. Playback will stop if the disc’s ratings exceed the level you set.

Press the SETUP button in stop mode.

Press the Cursor button (B) to select CUSTOM, then press the ENTER button.

Press the Cursor buttons (s or B) to select RATINGS, then press the ENTER button.

Press the Numeric buttons to enter your four-digit password.

• When doing this for the first time, enter any four-digit number by pressing the Numeric buttons (except for 4737), then press the ENTER button. That number will be used as the password from the second time onward. Record your password in case you forget it.

Press the Cursor buttons (K or L) to select RATING LEVEL, then press the ENTER button.

Press the Cursor buttons (K or L) button to select the desired level, then press the

ENTER button.

Press the SETUP button to exit.

NOTE:

• This function may not work on some DVDs. Be sure if the RATINGS operates in the way you have set.

To Change the Password:

1) Follow the steps to above.

2) Press the Cursor buttons (K or L) to select CHANGE, then press the ENTER button.

3) Enter a new four-digit password, then press the ENTER but- ton.

4) Press the SETUP button to exit.

IF YOU FORGET THE PASSWORD

Press 4, 7, 3, 7 at step .

•

Password will be cleared and rating level will be set to ALL.

Repeat steps to to re-establish the parental lock.

CONTROL LEVELS

• ALL

Parental lock is canceled.

• Level 8

DVD software of any grade (adult/general/children) can be played back.

• Levels 7 to 2

Only DVD software intended for general use and children can be played back.

• Level 1

Only DVD software intended for children can be played back, with those intended for adult and general use prohibited.

–25–

English

Page 26

DVD SETUP

Language Code

Abkhazian 4748 Afar 4747 Afrikaans 4752 Albanian 6563 Amharic 4759 Arabic 4764 Armenian 5471 Assamese 4765 Aymara 4771 Azerbaijani 4772 Bashkir 4847 Basque 5167 Bengali;Bangla 4860 Bhutani 5072 Bihari 4854 Bislama 4855 Breton 4864 Bulgarian 4853 Burmese 5971 Byelorussian 4851

Cambodian 5759 Catalan 4947 Chinese [CHI] 7254 Corsican 4961 Croatian 5464 Czech 4965 Danish [DAN] 5047 Dutch [DUT] 6058 English [ENG] 5160 Esperanto 5161 Estonian 5166

Faroese 5261 Fiji 5256 Finnish [FIN] 5255 French [FRE] 5264

If you choose a Language that has a 3 letter language code, the code will be displayed every time you change the Audio or Subtitle language setting on pages 21 and 22. If you choose any other languages, ‘---’ will be displayed instead. (3 letter language code is written in bracket.)

A-B

C-E

F-H

Language Code Language Code Language Code

Frisian 5271 Galician 5358 Georgian 5747 German [GER] 5051 Greek [GRE] 5158 Greenlandic 5758 Guarani 5360 Gujarati 5367 Hausa 5447 Hebrew 5569 Hindi 5455 Hungarian [HUN] 5467

Icelandic [ICE] 5565 Indonesian 5560 Interlingua 5547 Interlingue 5551 Inupiak 5557 Irish [IRI] 5347 Italian [ITA] 5566 Japanese [JPN] 5647 Javanese 5669 Kannada 5760 Kashmiri 5765 Kazakh 5757 Kinyarwanda 6469 Kirghiz 5771 Kirundi 6460 Korean [KOR] 5761 Kurdish 5767

Laothian 5861 Latin 5847 Latvian;Lettish 5868 Lingala 5860 Lithuanian 5866 Macedonian 5957 Malagasy 5953

I-K

L-N

Malay 5965 Malayalam 5958 Maltese 5966 Maori 5955 Marathi 5964 Moldavian 5961 Mongolian 5960 Nauru 6047 Nepali 6051 Norwegian [NOR] 6061

Occitan 6149 Oriya 6164 Oromo(Afan) 6159 Panjabi 6247 Pashto;Pushto 6265 Persian 5247 Polish 6258 Por tuguese [POR] 6266 Quechua 6367 Rhaeto-Romance 6459 Romanian [RUM] 6461 Russian [RUS] 6467

Samoan 6559 Sangho 6553 Sanskrit 6547 Scots Gaelic 5350 Serbian 6564 Serbo-Croatian 6554 Sesotho 6566 Setswana 6660 Shona 6560 Sindhi 6550 Singhalese 6555 Siswat 6565 Slovak 6557 Slovenian 6558

O-R

Somali 6561 Spanish [SPA] 5165 Sundanese 6567 Swahili 6569 Swedish [SWE] 6568

Ta galog 6658 Tajik 6653 Tamil 6647 Tatar 6666 Te lugu 6651 Thai 6654 Tibetan 4861 Tigrinya 6655 Tonga 6661 Tsonga 6665 Tu rkish [TUR] 6664 Tu rkmen 6657 Tw i 6669

Ukrainian 6757 Urdu 6764 Uzbek 6772 Vietnamese 6855 Volapuk 6861 Welsh 4971 Wolof 6961 Xhosa 7054 Yiddish 5655 Yo r uba 7161 Zulu 7267

U-Z

–26–

Page 27

MAINTENANCE

Cleaning the Cabinet

• Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasives.

Cleaning Discs

• When a disc becomes dir ty, clean it with a cleaning cloth. Wipe the disc from the center out. Do not wipe in a circular motion.

• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or antistatic spray intended for analog records.

Cleaning the disc lens

• If the player still does not perform properly while referring to the relevant sections and to “TROUBLESHOOTING GUIDE” in this Operating Instruction, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

Disc Handling

• Use discs which have the following logos on them.

• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.

• Always store the disc in its protective case when it is not used.

• Note that discs with special shapes (hear t-shaped discs, octagonal discs, etc.) cannot be played on the this product. Do not attempt to play such discs, as they may damage the player.

English

–27–

Page 28

TROUBLESHOOTING GUIDE

If the DVD player does not perform properly when operated as instructed in this Operating Instruction, check the player, consulting the following checklist.

Problem Solution

No power –Check if the AC power cord is properly connected.

–Unplug the AC power cord once, and wait for 5-10seconds and

then plug it in again.

No sound or picture –Check if the TV is switched on.

–Check the video connection. –Check the VIDEO/AUDIO cable connections to the TV. –DTS sound cannot be produced with an analog connection.

Distorted picture –Sometimes a small amount of picture distortion may appear.

This is not a malfunction.

–Connect the DVD player directly to the TV.

Completely distorted picture or –Connect the DVD player directly to the TV. black/white picture with DVD –Make sure the disc is compatible with the DVD player.

No sound or distorted sound –Adjust the volume.

–Check that the speakers are connected correctly.

No audio at digital output –Check the digital connections.

–Check the audio settings.

No DTS sound output –Use a DIGITAL OUT jack when outputting the DTS sound. Picture freezes momentarily –Check the disc for fingerprints/scratches and

during playback clean with a soft cloth wiping from center to edge.

–Clean the disc.

Disc can’t be played –Clean the disc.

–Ensure the disc label is facing up. –Check if the disc is defective by trying another disc. –Cancel the parental lock or change the control level. –Insert a correct disc that plays on this player.

No return to start-up screen when –Reset the player by switching the player off, then on again. disc is removed

The player does not respond to – the remote control –Reduce the distance to the player.

Buttons do not work or player stops –To completely reset the player, unplug the AC cord from the AC responding outlet for 5-10 seconds.

Player does not respond to some –Operations may not be permitted by the disc. operating commands during playback Refer to the instructions of the disc.

DVD player cannot read –Use a commonly available CD/DVD cleaner to clean the lens CDs/DVDs before sending the DVD player for repair.

Angle does not switch –The angle cannot be switched for DVDs which do not contain

Playback does not start when the title is selected –Check the “RATINGS” setting. The password for rating level has been forgotten –Enter the default password “4737”, then your forgotten password

Aim the remote control directly at the sensor on the front of the player.

–Replace the batteries in the remote control. –Re-insert the batteries with their polarities (+/– signs) as indicated.

multiple angles. In some cases multiple angles are only recorded for specific scenes.

will be cleared.

NOTES:

• Some functions are not available in specific modes, but this is not a malfunction. Read the description in this Operating Instruction for details on correct operations.

• Playback from a desired track and random playback are not available during program playback.

• Some functions are prohibited on some discs.

–28–

Page 29

SPECIFICATIONS

SIGNAL SYSTEM

NTSC color

APPLICABLE DISCS

(1) DVD-Video discs

1-layer 12cm single-sided discs, 2-layer 12cm single-sided discs, 2-layer 12cm double-sided discs (1 layer per side) 1-layer 8cm single-sided discs, 2-layer 8cm single-sided

discs, 2-layer 8cm double-sided discs (1 layer per side) (2) DVD-R/DVD-RW (3) Compact discs (Audio CD)

12cm discs, 8cm discs (4) CD-R/CD-RW

S-VIDEO OUTPUT

Y output level: 1Vp-p (75Ω/ohms) C output level: 0.286Vp-p Output connectors: S connectors, 1 set

VIDEO OUTPUT

Output level: 1Vp-p (75Ω/ohms) Output connector: Pin jacks, 1 set

COMPONENT OUTPUT

Y output level: 1Vp-p (75Ω/ohms) PB/CB output level: 0.7Vp-p (75Ω/ohms)

R/CR output level: 0.7Vp-p (75Ω/ohms)

P Output connector: Pin jacks, 1 set

AUDIO OUTPUT

Output level: 2Vrms 2 channel (L, R) output connector: Pin jack, 1 set

AUDIO OUTPUT PROPERTIES

(1) Frequency response

1 DVDs (linear PCM) : 4Hz to 22kHz (48kHz sampling)

2 CDs : 4Hz to 20kHz (2) S/N ratio : 115dB (3)

Total harmonic distortion (4) Dynamic range : DVD: 100dB

: 4Hz to 44kHz (96kHz sampling)

: 1kHz CD: 0.003%

CD: 98dB

DIGITAL AUDIO OUTPUT

Optical digital output: Optical connector, 1 set Coaxial digital output: Pin jack, 1 set

POWER SUPPLY

AC 120V, 60Hz

POWER CONSUMPTION

17W (Standby: 0.6W)

MAXIMUM EXTERNAL DIMENSIONS

W: 17-1/8” (435mm) H: 4-3/32” (104mm) D: 14-9/16” (370mm) (including protruding parts)

MASS

9.48lbs (4.6kg)

REMOTE CONTROL UNIT

RC-1040 Infrared pulse type Supply: DC 3V, 2 R6P/AA batteries

English

–29–

Page 30

MEMO

Page 31

Printed in China 00D 511 4534 001

TOKYO, JAPAN

www.denon.com

Denon Brand Company, D&M Holdings Inc.

1VMN23040

E8630UD/E8631UD *****
