DEMA RAPID FIRE MODELS
6300, 6300-1, 6300-2, 6300-3, 6300-4 & 6300-5
5
6
8
7
9
1
2
18
3
4
13
29
14
12
15
23
24
25
11
16
29
11
26
18
18
17
15
10
30
12
41
20
14
28
27
13
19
21
22
ITEM
NO.
1 1 63-1 Valve Body POLYPROPYLENE
2 1 65-10 Coupling BRASS
3 1 66-93 Inlet BRASS
4 1 100-38 Strainer Washer VINYL/SS
5 2 44-116-6 #8 HI-LO Screw x 5/8” Lg. STNLS. STL.
6 1 63-2 Water Seal Retainer POLYPROPYLENE
7 1 63-8 O-Ring AFLAS
8 1 63-9 Extension Spring STNLS. STL.
9 2 66-93-8 Water Seal AFLAS
10 1 63-11 Plug POLYPROPYLENE
11 2 63-12 Gear Retainer POLYPROPYLENE
12 2 63-13 Detent POLYPROPYLENE
13 4 58-102 #6 HI-LO Screw X ¾” Lg. STNLS. STL.
14 2 63-14 Elbow POLYPROPYLENE
15 2 63-4 O-Ring AFLAS
16 1 24-24P7 Ball (.2188 dia.) TEFLON
17 1 63-15 Check Valve Body POLYPROPYLENE
18 3 63-7 O-Ring AFLAS
19 1 63-16 Drive Gear POLYPROPYLENE
20 1 63-17 Driven Gear POLYPROPYLENE
21 1 63-18 Knob POLYPROPYLENE
22 1 58-60 #6 HI-LO Screw X ½” Lg. STNLS. STL.
23 1 63-5 O-Ring AFLAS
24 1 63-6 O-Ring AFLAS
25 1 20-1-11RF Injector 2.7 GPM (Color, Gray) POLYPROPYLENE
26 1 63-3 O-Ring AFLAS
27 * 1 66-93-3 U-Cup AFLAS
28 1 63-19 Cap VINYL
29 2 66-93-7 Chemical Seal AFLAS
30 1 66-93-4 U-Cup AFLAS
41 1 25-29 O-Ring EPDM
QTY DEMA NO. DESCRIPTION MATERIAL
* For 6300-1.
