D-22
Standard Part Numbers
D
C
Deltrol
CONTROLS
Parts No. Voltage Duty Cycle Power
53724-80 6 VAC
53724-81 12 VAC 10.9
53724-82 24 VAC 43.4
53724-84 120 VAC 1090
53724-85 240 VAC 4300
53724-86 6 VAC
53724-87 12 VAC 7.0
53724-88 24 VAC 27.4
53724-90 120 VAC 724
53724-91 240 VAC 2880
53724-92 6 VAC
53724-93 12 VAC 1.7
53724-94 24 VAC 27.4
53724-96 120 VAC 173
53724-97 240 VAC 724
53723-80 6 VDC
53723-81* 12 VDC 35.0
53723-82* 24 VDC 141
53723-84 110 VDC 2880
53723-86 6 VDC
53723-87 12 VDC 14.8
53723-88 24 VDC 60
53723-90 110 VDC 1274
53723-92 6 VDC
53723-93 12 VDC 3.8
53723-94 24 VDC 14.8
53723-96 110 VDC 302
Continuous 6.5 VA
Intermittent 8.5 VA
Pulse 60 VA
Continuous
Intermittent
Pulse
4.2
Watts
9.6
Watts
40
Watts
Resistance
(Ohms)
2.75
1.7
0.420
8.7
3.8
0.91
Operation
Pull 31 3.5 2.4 1 0
Pull 53 5.2 3.3 1.5 0
Pull 73 19 14 7 0
Pull 30 4 1.8 0 0
Pull 38 10 4 0 0
Pull 49 27 15 0 0
Typical Force (oz). 100% Voltage, 77°, Stroke @
0.000” 0.125” 0.250” 0.500” 0.750”
(*) Normally Stocked
Non stocked items require a minimum order
Specications subject to change without notice
