C-6
Standard Part Numbers
D
C
Deltrol
CONTROLS
Parts No. Voltage Duty Cycle Power
53687-80 6 VAC
53687-81 12 VAC 7.6
53687-83 24 VAC 30.6
53687-94* 120 VAC 776
53687-97 240 VAC 3070
53688-80 6 VAC
53688-81 12 VAC 3.2
53688-83 24 VAC 13
53688-94* 120 VAC 327
53688-97 240 VAC 1370
53743-80 6 VAC
53743-81 12 VAC 1.18
53743-82 24 VAC 5
53743-83 120 VAC 124
53743-84 240 VAC 493
53685-80 6 VDC
53685-81 12 VDC 30.6
53685-83* 24 VDC 124
53685-93 110 VDC 2670
53685-97 220 VDC 11200
53686-80 6 VDC
53586-81 12 VDC 13
53686-83* 24 VDC 50.8
53686-93 110 VDC 1011
53686-97 220 VDC 4050
53745-80 6 VDC
53745-81 12 VDC 3.2
53745-82 24 VDC 13
53745-84 110 VDC 271
53745-85 220 VDC 1140
Continuous 6.8 VA
Intermittent 19.6 VA
Pulse 68 VA
Continuous
Intermittent
Pulse
4.7
Watts
12
Watts
45
Watts
Resistance
(Ohms)
1.92
0.78
0.3
7.6
3.2
0.78
Operation
Pull 33 5.9 4 2 0
Pull 57 13 9 4.5 0
Pull 95 32 24 10 0
Pull 38 4 1.9 0.5 0
Pull 50 11 5 2 0
Pull 68 34 17 6 0
Typical Force (oz). 100% Voltage, 77°, Stroke @
0.000” 0.125” 0.250” 0.500” 0.750”
(*) Normally Stocked
Non stocked items require a minimum order
Specications subject to change without notice
