Delta Elektronika SM 15-100, SM 52-30, SM 35-45, SM 120-13, SM 300-5 Product Manual

DELTA ELEKTRONIKA B.V.

DC POWER SUPPLIES

SM1500-se ries

• SM 15-100

• SM 35-45

• SM 52-30

• SM 52-AR-60

Vissersdijk 4, 4301 ND

Zierikzee, the Netherlands

www.DeltaPowerSupplies.com

Tel. [phone]

• SM 70-22

• SM 120-13

• SM 300-5

• SM 400-AR-8

PROD UCT MAN UAL

Con tents:
1 - Datasheet
2 - Safety Instructions
3 - General
4 - Installation
5 - Trouble Shooting
6 - Maintenance & Calibration
7 - EU Declaration

SM1500 SAFETY INSTRUCTIONS

2 SAFETY INSTRUCTIONS - SM1500-series

1 Caution

The following safety precautions must be observed during all phases of operation, service and repair of this equipment.
Failure to comply with the safety precautions or warnings in this document violates safety standards of design,
manufacture and intended use of this equipment and may impair the built-in protections. Delta Elektronika shall not be
liable for user’s failure to comply with these requirements.

2 Installation Category

The Delta Elektronika power supplies have been evaluated to installation category II (Over voltage category II).

3 Grounding of Mains Terminals (AC Power Terminals)

This product is a safety Class 1 unit. To minimize shoc k hazard, the unit must be connected to the AC Power Supply
mains through a three conductor power cable, with the ground wire firm ly connected to an electrical ground (safety
ground) at the power outlet.

For units designed to be hard-wired to the mains supply , the protective earth terminal must be connected to the safety
electrical ground before another connection is made. Any interruption of the protective ground conductor, or
disconnection of the protective earth terminal will cause a potential shock hazard that might cause personal injury.

4 Grounding of DC Power Terminals

If the DC power terminal of a unit is specified to sink or source to a maximum of 60VDC, and either the negative or
positive DC power terminal is grounded, the following connections can be considered safe:

- DC power terminals and sense connections

- programming/monitor/status-signals, interlock, Master/Slave-connections, ACF/DCF-relay

- all Delta Elektronika interfaces

Warning:

When the positive DC power terminal can exceed 60VDC in respect to the negative DC power terminal,
external measures must be taken to ensure safety isolation of the DC power terminals and sense connections.

Warning:

When the negative power output of the unit can exceed 60VDC / 42.4Vpk in respect to ground, additional
external measures must be taken to ensure safety isolation of the following:

- power out puts and sense connections

- pro gram ming/mon i tor/sta tus-sig nals, In ter lock, Mas ter/Slave-con nec tions, ACF/DCF-re lay

- in ter faces with op er a tional isolation

- non-isolated interfaces.

Caution 1: If a low voltage unit has both DC power terminals floating, or if the DC terminals are in series with an
external high AC or DC voltage, the lower DC power terminal can exceed the safe value in respect to ground as
specified in the above warning!

Caution 2: Although a high voltage unit is set to a safe voltage below 60VDC, for safety it must always be considered as
a high voltage unit! Wrong operation, a programming error or an external defect can result in an unsafe high DC output
voltage.

Caution 3: When programming a high voltage unit directly via a PC or via a network connection, either ground the
negative power output or use a safety isolated interface!

For more information and schematics regards Grounding and Safety, see the special application note "Safe operation of
a power supply" on the Delta Elektronika website.

additional

5 Fuses

Fuses must be changed by authorized Delta Elektronika service personnel only, for continued protection against risk of
fire.

6 AC Input Ratings

Do not use an AC Supply which exceeds the AC input voltage and frequency rating of this unit. The AC input voltage
and frequency rating of the Delta Elektronika power supply series ar e stated in the accompanying datasheet.

7 Live Circuits

Operating personnel should not remove the unit covers. No internal adjustment or component replacement is allowed by
non Delta Elektronika qualified personnel. Never replace components with the power cable connected. To avoid injuries,
always disconnect power, remove external voltage sources and dischar ge circuits before touching components.

8 Parts Substitutions & Modifications

Parts substitutions and modifications are allowed by authorized Delta Elektronika service personnel only. For repairs or
modifications the unit must be returned to a Delta Elektronika service facility.

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 2 - 1

SAFETY INSTRUCTIONS SM1500

!

9 Removal of (safety) covers

Safety cover(s) are used to cover potentially hazardous v oltages.
Observe the following when removing safety cover(s):

• Switch off the unit.

• Disconnect the unit from the mains supply or power outlet.

• Wait for 5 minutes to allow internal capacitors to discharge.

• Unscrew the screws and remove the cover(s).

• Always place the cover(s) back before connecting the unit to the mains supply again.

10 Environmental Conditions

The Delta Elektronika power supplies safety approval applies to the following operating conditions:

• Indoor use

• Ambient temperature : −20 to 50 °C

• Maximum relative humidity : 95%, non condensing, up to 40 °C

: 75%, non condensing, up to 50 °C

• Altitude : up to 2000 m

• Pollution degree : 2

Cau tion risk of elec tri cal Shock

Instruction manual symbol. The unit will be marked with this symbol when it is
necessary for the user to refer to the instruction manual

Pro tec tive ground con duc tor ter mi nal

Off (sup ply)

o

On (sup ply)

I

11 Canada

This product has been tested to the requirements of CAN/CS A-C22.2 No. 61010-1, second edition, including
Amendment 1, or a later version of the same standard incorporating the same level of testing requirements

12 cTUVus

WEEE (Waste Electrical & Electronic Equipment)

1 Correct Disposal of this Product

Applicable in the European Union.

This marking shown on the product, its packing or its literature indicates that
it should not be disposed with other wastes at the end of its working life, but
should be collected separately to recycle it responsibly to promote the
sustainable reuse of material resources.

Page 2 - 2 DELTA ELEKTRONIKA B.V. rev. August 2018

SM1500 GENERAL

3 GENERAL

1) OUT PUT

The SM15-100, SM35-45, SM52-30, SM52-AR-60, SM70-22, S M120-13,
SM300-5 and the SM400-AR-8 can ei ther be used as a con stant volt age
source with cur rent lim it ing or as a con stant cur rent source with volt age lim it ­ing. The change of mode oc curs sharply at the cross ing of the volt age and
cur rent set tings. Fig. 3 - 1 shows the out put ranges.

The SM52-AR-60 and the SM400-AR-8 fea ture an AUTORANGING fa cil ity
where the power sup ply au to mat i cally switches over be tween two cur rent
ranges. This switch ing, which is un no tice able for the user, re sults in a ver sa ­tile power sup ply with twice the out put voltage range. This means that for
the SM52-AR-60 the max i mum out put power of 1560 W is avail able at both
26 V and 52 V. For the SM400-AR-8 this is 1600 W at both 200 V and 400 V.

° DIS PLAY CV/CC SETTINGS FUNCTION

The set tings of the volt age and cur rent con trol (also when pro grammed) can
be ob served on the front panel me ters by press ing the Dis play CV/CC Set ­tings but ton. This al lows the cur rent limit to be set when op er at ing in the CV
mode with out short ing the out put ter mi nals, and the volt age limit to be set
when op er at ing in the CC mode with out open ing the load leads.

° OVER LOAD PRO TEC TION

The power sup ply is fully pro tected against all over load con di tions, in clud ing
short cir cuit.

2) IN PUT VOLT AGE

The power sup plies have a wide in put volt age range.

° At line volt ages be low about 120 V AC the out put power has to be de rated,

see page 1-2, "In put".

3) IN PUT CUR RENT

The unit has ac tive power fac tor cor rec tion (PFC). The in put cur rent will
there fore al most be a sine wave. T his means that the RMS-value and the
har monic dis tor tion of the in put cur rent will be rel a tively low.

4) STANDBY IN PUT POWER

The unit con sumes very lit tle power when in standby. This makes it pos si ble
to leave the in put power on when the out put is dis abled us ing the Out put
On/Off func tion (push but ton on front panel) or the Re mote Shut Down in put
(pin 5 on con nec tor CON E on the rear panel).

SM 15-100

SM 52-30

SM 70-22

SM 300-5

SM 35-45

SM 52-AR-60

SM 120-13

SM 400-AR-8

fig. 3 - 1

Out put ranges. Ev ery point in hatched

area can be used.

5) EFFICIENCY

The ef fi ciency is very high and con stant over a wide out put cur rent range.
High ef fi ciency means low power loss and low heat gen er a tion.

6) CV REG U LA TION

The CV-load reg u la tion should be mea sured di rectly on the out put ter mi nals
be cause a few cm of ca ble can have a volt age drop of sev eral mV (at high
cur rent!).

7) CC REG U LA TION

For ac cu rate CC-load reg u la tion, do not use ex ter nal volt age sens ing.
A volt age be tween S- and mi nus out put will cre ate an er ror of about 0.04 %
per volt.
A volt age be tween S+ and + is not crit i cal.The CC-stability is also af fected by
ex ter nal volt age sens ing.

Note: when the unit op er ates in CC-mode, the DCF-LED will be on. When
the unit is in CC-mode most of the time, it is pos si ble to dis able the LED with
DIP switch 3 on SW1 (rear panel).

8) RIP PLE & NOISE

The out put rip ple is very low with al most no spikes. The rip ple volt age has to
be mea sured di rectly on the out put ter mi nals us ing a probe with very short
con nec tions (to avoid pick up of mag netic fields (see fig. 3 - 2 and fig. 3 - 3).

At low tem per a tures like −20°C the rip ple in creases. By us ing high qual ity
elec tro lytic ca pac i tors the in crease is rel a tively low.

fig. 3 - 2

Mea sur ing rip ple volt age

WRONG !

fig. 3 - 3

Mea sur ing rip ple volt age

RIGHT !

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 3 - 1

GENERAL SM1500

V

A

Imon
0-5V

Vmon

0-5V

Return of

ref, prog, mon.

9) AN A LOG PRO GRAMMING

The out put volt age and cur rent can be pro grammed by an ex ter nal an a log
volt age. This pro gram ming is very ac cu rate and lin ear. The lev els are all
stan dard ized on 5 V.

The in puts have a pro tec tion cir cuit formed by a se ries re sis tor and a
par al lel zenerse (see fig. 3 - 4). The ca pac i tor lim its the speed to a safe
value. Note that the an a log in puts (and out puts) are not float ing, but the
com mon is con nected to the neg a tive out put ter mi nal. Wrong con ­nec tion of Ø can cause earth loops which can trip the fuse. Af ter re mov ing
the fault, the fuse will re set (PTC-fuse). For iso lated pro gram ming see
next para graph 10).

10) ISO LATED AN A LOG PRO GRAMMING

To pre vent earth loops which can cause pro gram ming er rors, use an iso ­lated pro gram ming source. If this is not pos si ble, use the op tional ISO
AMP CARD (δ-prod uct) which can be built in side the unit.
With the ISO AMP CARD earth loops be tween the unit and the pro gram -

Pro gram ming in puts (in ter nal cir cuit)

fig. 3 - 4

ming source are prevented.

11) ETHERNET / IEEE488 / RS232 PRO GRAMMING

The Delta Elektronika PSC-ETH, PSC-488 and the PSC-232 con trol lers
can be built in side the unit.

Volt age and cur rent can eas ily be pro grammed and read back. Also all
the sta tus out puts can be read by the com puter.

12) MON I TORING OUT PUTS

The mon i tor out puts give a volt age 0 - 5 V pro por tional to the out put cur ­rent or volt age. The out put cur rent can eas ily be mea sured us ing the
I-mon i tor (see fig. 3 - 6). The mon i tor out puts are buf fered with op-amp’s
and pro tected with se ries re sis tors and par al lel zeners (see fig. 3 - 7).
The ta ble in fig. 3 - 5 shows the im ped ance lev els of the mon i tor ing out ­puts.

For us ing Imon on a pul sat ing load, see para graph 20) of this chap ter.

13) +12 V ON PRO GRAMMING CON NEC TOR

The +12 V on the pro gram ming con nec tor can be used to sup ply ex ter nal
circuits. The out put is cur rent lim ited, but should not be over loaded. The
fuse F27_3 on pcb P647 could blow. The fuse F27_3 also pro tects the in ­ter nal cir cuit, in case an ex ter nal high volt age is ap plied by ac ci dent.
Note: this fuse is a spe cial 600 V type, al ways re place with the same
type.

14) STATUS OUT PUTS

All the sta tus out puts are logic out puts. Logic "0" means the out put is 0 V,
logic "1" means the out put is 5 V (Ro = 500 Ohm). This makes it pos si ble
to drive di rectly: an opto-coupler, a TTL gate or a CMOS gate.

The Limit Sta tus or LIM-status is "1" in case the out put volt age or cur rent
reaches the limit set ting. Which limit cir cuit is ac tive can be seen on the
front panel LED’s.

pin

De scrip tion, see par.12)...17) for details

1

Ø, re turn of ref er ence, prog. in puts and
mon i tor out puts (Ro = 1.2 Ohm).

2

cur rent mon i tor out put 0 - 5 V
(Ro = 1.2 Ohm, Io max = 4 mA)

3

cur rent pro gram ming in put (0 - 5 V),
Ri = 8 MOhm

4

CC sta tus out put, logic 1 = CC mode
(5 V / 500 Ohm)

5

Re mote ShutDown (4 - 12 V),
Ri = 5 kOhm

6

PSOL sta tus out put, logic 1 = PSOL
(5 V / 500 Ohm)

7

+12 V out put
(Ro = 3 Ohm, Io max = 0.2 A)

8

Ø, re turn of sta tus out puts, +12 V
and re mote ShutDown

9

ref er ence volt age 5.1 V
(Ro = 1.2 Ohm, Io max = 4 mA)

10

volt age mon i tor out put 0 - 5V
Ro = 1.2 Ohm, Io max = 4 mA)

11

volt age pro gram ming in put (0 - 5 V)
Ri = 8 MOhm

12

OT - sta tus out put, logic 1 = OT
(5 V / 500 Ohm)

13

LIM - sta tus out put, logic 1 = LIM
(5 V / 500 Ohm)

14

DCF - sta tus out put, logic 1 = DCF
(5 V / 500 Ohm)

15

ACF - sta tus out put, logic 1 = ACF

fig. 3 - 6

Ex ter nal me ters

us ing mon i tor out puts

Page 3 - 2 DELTA ELEKTRONIKA B.V. rev. August 2018

Buf fered mon i tor out puts

fig. 3 - 7

(in ter nal cir cuit)

(5 V / 500 Ohm)

fig. 3 - 5

Con nec tions AN A LOG PROG. CONNECTOR

SM1500 GENERAL

pin6
...
...
pin2
pin1

fig. 3 - 8 Location of out put ter mi nals and an a log pro gram ming con nec tor

Con nec tor D num ber ing

CON A In ter lock Con nec tor para graph 18)
CON B Mas ter Connector for Mas ter / Slave op er a tion (out put) para graph 31)
CON C Slave Connector for Mas ter / Slave op er a tion (in put) para graph 31)
CON D Re lay Out puts, con tacts 1 - 6 ACF / DCF para graph 15)
CON E An a log Pro gramming Connector para graph 9)
CON F PSC-ETH, user inputs

para graph 11)

PSC-232, from PC or pre vi ous PSC (op tional)

CON G PSC-ETH, user outputs

para graph 11)

PSC-232, to next PSC (op tional)

CON H PSC-ETH (op tional) or

para graph 10), 11)

PSC-488 (op tional) or

ISO AMP CARD (op tional)
SW 1 Var i ous set tings para graph 16)
SW 2 Set tings for PSC-488 and PSC-232 (op tional) -

fig. 3 - 9 Connectors and switches on the rear panel

The Over Tem per a ture Sta tus or OT sta tus is "1" in case of an over tem per a ture,
the OT LED will be on and the out put shuts down. As a pre-warning the OT LED
starts to blink when the unit runs hot but the sit u a tion of over tem per a ture is not
reached yet. The sta tus will still be low when the LED is blink ing.

The Cur rent Con trol Sta tus or CC-status out put is "1" when the unit is in
CC-mode.

The Power Sink Over Load Sta tus or PSOL-status out put is "1" when the op tional
Power Sink is over loaded or over heated.

The AC-Fail Sta tus or ACF-sta tus out put is "1" when the in put volt age is be low
115 V (peak, not rms) for more than 10 ms. Note that if you want the ACF-sta tus to
switch be fore the DCF-sta tus, the hold-up time has to be > 10 ms. This can be
achieved by re duc ing the load, see para graph 25) of this chapter.

The DC-Fail Sta tus or DCF-status out put is "1" when the out put volt age is ei ther
5% be low or above the set point.

When the unit is in CC-mode, DCF will al ways be "1", see pre vi ous paragraph 7).

15) STATUS RE LAY OUT PUTS

The power sup ply has 2 sta tus re lay out puts, with each a change-over c on tact.
They are con nected to con nec tor CON D. The pins 1, 2, 3 are con nected to the
DCF-re lay and pins 4, 5, 6 to the ACF-re lay (see fig. 3 - 10). Pin 1 is the lower
out put, clos est to SW1.

Sta tus re lay out puts on CON D.

fig. 3 - 10

This sit u a tion gives the re lay

po si tions dur ing fault con di tion.

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 3 - 3

GENERAL SM1500

Switch no. LEFT po si tion RIGHT po si tion De fault Set ting

SW 1 - 1 Pro gramming via 15pole con -

nec tor CON E (an a log).

Op tional pro gram ming with e.g.
PSC-232, PSC-488, ISO AMP CARD

Left

SW 1 - 2 ‘Out put On’ af ter mains on ‘Out put Off’ af ter mains on Right
SW 1 - 3 DCF LED enabled DCF LED dis abled (DCF sta tus and

Left

DCF re lay are still en abled)

SW 1 - 4 Par al lel Mas ter / Slave operation Se ries Mas ter / Slave operation Left

16) FUNC TION SWITCHES ON SW1

In the above ta ble the func tions of the DIP switches 1-4 of switch
SW1 (rear side) are ex plained. Also see fig. 3 - 11.

17) RE MOTE SHUT DOWN (RSD)

A volt age of +4 V...+12 V on the Re mote Shut Down in put on the
pro gram ming con nec tor CON E will switch off the out put of the unit.

It is also pos si ble to use a re lay con tact or a switch to shut the unit
down (see fig. 3-12).
In standby mode the power sup ply con sumes very lit tle power.

18) IN TER LOCK

The In ter lock con nec tor (CON A) has 2 in puts which have to be
con nected to gether to en able the unit.As soon this con nec tion is in ­ter rupted, the out put of the unit shuts down.It can be used in com bi ­na tion with door con tacts (safety pre cau tion) or as an emer gency
stop.
In case the con nec tion is in ter rupted the RSD LED will light. In con ­trast with Re mote Shut Down, also the DCF LED will be on, DCF
sta tus will be high and the re lay con tact will change. Once the in ­puts are re con nected, the out put will be on again.

The in ter lock cir cuit is at the same level as the an a log ground , the
S- and the - out put.The in ter lock cir cuit needs volt age free con tacts
and can not be con nected in par al lel or se ries with other in ter locks .

19) PRO GRAMMING SPEED

The rise and fall time is mea sured with a step wave form at the CV
prog. in put. P ro gram ming from a low to a high out put volt age is
nearly load in de pend ent, but pro gram ming down to a low volt age
takes more time on lighter loads. This is caused by the out put ca ­pac i tors, which can only be dis charged by the load be cause the
power sup ply can not sink cur rent. With the Power Sink op tion,
also the pro gram ming down speed is nearly load in de pend ent.

When hav ing a unit with a Fast Pro gram ming op tion, the rise and
fall time is 5 to 25 times faster (see datasheet).
source must be float ing or oth er wise an ISO AMP CARD must be
used, a non-float ing source will re sult in slope dis tor tion.

For a fast pro gram ming unit it is gen er ally not rec om mended to use
re mote sens ing or se rial / par al lel op er a tion. Con sult fac tory for ad ­vice. Note that the output rip ple is higher.

The pro gram ming

Right

SW1-4
SW1-3
SW1-2
SW1-1

Left

fig. 3 - 11 Set tings of DIP switch Sw1.

fig. 3 - 12

Re mote Shut Down us ing a re lay contact

fig. 3 - 13

Pul sating load current

20) PUL SATING LOAD

To avoid over heat ing the out put ca pac i tors, the AC com po nent of
the load cur rent should be lim ited (see fig. 3 - 13).

One method of de creas ing the AC cur rent through the out put ca ­pac i tor is by us ing a large ex ter nal elec tro lytic ca pac i tor in par al lel
with the load. Care must be taken so that the ca pac i tor in com bi na ­tion with the lead in duc tance will not form a se ries res o nant cir cuit!

When us ing re mote sens ing on a pul sat ing load (for in stance a
DC-mo tor), use a ca pac i tor in se ries wit h a re sis tor over the load
(see fig. 3 - 14). Like this the AC-com po nent caused by the pul sat ­ing of the load is fil tered.

Note: in case of a pul sat ing load, the I mon i tor volt age will not ex -
actly match the out put cur rent. This is mainly caused by the cur rent
through the out put ca pac i tors. Re mote sens ing will worsen this ef ­fect.

21) IN SU LA TION

For safety the in su la tion of the sep a rat ing com po nents (trans form ­ers) be tween in put and out put is tested at 3750 Vrms dur ing 1 min ­ute. This is tested be fore as sem bly.

Page 3 - 4 DELTA ELEKTRONIKA B.V. rev. August 2018

fig. 3 - 14

fig. 3 - 15

In su la tion test voltages

SM1500 GENERAL

Warn ing! The 3750 Vrms can not be tested af ter wards on the
as sem bled unit be cause the in su la tion be tween the com po ­nents on the in put side to the case (like the bridge rec ti fier) is
spec i fied at 2500 Vrms. Since the in su la tion out put - case is low
(only 600 V DC) the in su la tion of the pri mary com po nents to
case will break down when 3750 Vrms is ap plied be tween in put
and out put (2500 Vrms + 600 V DC < 3750 Vrms) (see also fig. 3

- 15).
Note: when test ing the in su la tion, take care to charge and dis -

charge the ca pac i tors be tween in put - case and out put - case
slowly (e.g. in one sec ond). This to prevent high peak cur rents,
which could de stroy the power sup ply. Make sure to dis charge
the ca pac i tors com pletely be fore us ing it again.

fig. 3 - 16

Op er ating tem per a ture ranges

22) RFI SUP PRES SION

Both the in put and out put have RFI fil ters, re sult ing in very low
con ducted RFI to the line and load. Due to the out put fil ter the
out put volt age is very clean, hav ing al most no spikes.

23) OP ER ATING TEMPERATURE

At full power the op er at ing tem per a ture range is –20 to +50 °C.
From 50 to 60 °C the out put cur rent has to be de rated lin early to
75 % at 60 °C (see fig. 3 - 16). These tem per a tures hold for nor ­mal use, i.e. the ven ti la tion open ings on the left and right side
must be free.

24) THER MAL PRO TEC TION

A ther mal switch shuts down the out put in case of in suf fi cient
cool ing.The OT sta tus will be high. Af ter cool ing down the unit
will start work ing again.

The OT-LED on the front panel will be on and the OT-status sig ­nal will be "1" in case of a trip ped ther mal pro tec tion.
As a pre-warning the OT-LED blinks (sta tus will still be low), this
will start be fore the power sup ply shuts down.

25) HOLD - UP TIME

The hold - up time de pends on the load and the out put volt age.
A lighter load or a lower out put volt age re sults in a lon ger hold ­up time (see fig. 3 - 17).

26) TURN ON DE LAY

The out put volt age is avail able about 0.5 s af ter mains switch on.

27) IN RUSH CUR RENT

The in rush cur rent is lim ited with a spe cial cir cuit.
Re peat edly switch ing on and off does not change the max i mum
peak cur rent.
Switching on and off at a fast rate can over heat the in rush cur ­rent lim iter. With the re sult that the unit does not start any more.
Af ter cool ing down (mains switched off) it will be OK again.

28) RE MOTE SENSING

The volt age at the load can be kept con stant by re mote sens ing.
This fea ture is not rec om mended for nor mal use but only when
the load volt age is not al lowed to vary a few mil li volts. Al ways
use a shielded ca ble for sens ing.

In or der to com pen sate f or the volt age drop acros s the load
leads, the unit will have to sup ply a higher volt age (see fig. 3 -

18): Uout = (volt age drop across each lead) + (volt age across the load).

fig. 3 - 17

Hold-up time vs Vout with Iout as a parameter

fig. 3 - 18

Re mote sens ing, volt age drop in load leads sub -

The volt age limit reads the volt age di rectly at the out put ter mi ­nals. The set ting for the limit must there fore be in creased by the
to tal volt age drop across the load leads.

The volt age dis play on the front panel and the volt age mon i tor
out put on CON E are con nected to the sense leads and there ­fore read the volt age across the load and not the volt age on the
out put ter mi nals.

The sense leads are pro tected against ac ci den tal in ter rup -
tion. The max i mum volt age be tween the out put ter mi nals and
the sense in puts is lim ited at 2.5 V.

For sens ing on a pul sat ing load, see par. 20) of this chap ter.

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 3 - 5

Mas ter / Slave se ries op er a tion

fig. 3 - 19

GENERAL SM1500

29) SERIES OP ER A TION

Se ries op er a tion is al lowed up to 600 V to tal volt age. The power sup plies can
be con nected in se ries with out spe cial pre cau tions.

For eas ier con trol, Mas ter / Slave op er a tion is rec om mended (see fig. 3- 19).
By us ing the Mas ter / Slave ser ies fea ture a dual track ing power sup ply can
be made with one unit as mas ter and one as slave.

For se ries op er a tion in com bi na tion with Power Sink op tion, all units must
have a Power Sink built in side oth er wise no power can be ab sorbed.

30) PAR AL LEL OP ER A TION

Par al leling of the units has no lim i ta tions. The power s up plies can be con ­nected in par al lel with out spe cial pre cau tions. For eas ier con trol, Mas ter /
Slave op er a tion is rec om mended (see fig. 3- 19 and fig. 3 - 20).

Nor mal par al lel op er a tion of Fast Pro gram ming units can give prob lems,
each com bi na tion has to be tested first, in com bi na tion with the load !

For par al lel op er a tion in com bi na tion with Power Sink op tion, only one unit
can have a Power Sink. Re fer to Power Sink man ual for de tails and re stric ­tions.

31) MASTER / SLAVE OP ER A TION

The Mas ter / Slave fea ture makes it pos si ble to use the power sup plies as
build ing blocks to form one large unit (see fig. 3 - 20).

Mixed par al lel - se ries op er a tion is also pos si ble, to a max i mum of 600 V.
The re sult ing com bi na tion of units be haves like one power sup ply and can be

man u ally con trolled or pro grammed on the mas ter. Fig. 3 - 21 shows a com ­puter con trolled M/S par al lel com bi na tion.

Con nect the dif fer ent units with stan dard RJ45 ca bles (see fig 3 - 22), us ing
CON B and CON C on the rear side. With DIP switch 4 of switch SW1 the Par ­al lel or Se ries mode can be se lected.

The slaves will fol low the mas ter. The re sult is true cur rent or volt age shar -

ing in the par al lel or se ries mode re spec tively.

Note: Mas ter / Slave par al lel op er a tion is not rec om mended for more
than 3 units or in com bi na tion with Fast Pro gram ming op tion.
Con sult fac tory for a so lu tion.

Mas ter / Slave parallel operation

The Mas ter / Slave com bi na tion can also

be pro grammed with the in ter faces

PSC-ETH, PSC-488 or the PSC-232

fig. 3 - 20

fig. 3 - 21

fig 3 - 22
Use stan dard UTP ca bles
(RJ45) for Mas ter / Slave
op er a tion.

Mas ter unit:
Con nect CON B

to Slave1.

Slave unit:
Con nect CON C

to Mas ter.
Con nect CON B

to Slave2.

Warn ing:

Never con nect CON C
to CON C !

See page 4 - 3 for more
de tails.

Page 3 - 6 DELTA ELEKTRONIKA B.V. rev. August 2018

SM1500 GENERAL

32) VOLT AGE AND CUR RENT LIMIT

The Volt age and Cur rent Lim its main tain the out put to a safe pre set value.
They do not trip, so no re set ting is needed af ter a fault. It can be very handy to
have hard ware lim its when the power sup ply is pro grammed.

The lim its can eas ily be set by press ing the DIS PLAY LIM ITS but ton and
ad just ing the limit po ten ti om eters with a screw driver. The LED’s next t o the
limit potmeters in di cate the ac tiv ity of each limit, also the LIM-sta tus out put will
be "1".

The Volt age Limit will pro tect your cir cuit from un wanted high volt ages. A high
out put volt age could be caused by ac ci den tal in ter rup tion of leads, ac ci den tally
turn ing up the volt age potmeter, a pro gram ming er ror or a de fect in the power
sup ply. The Volt age Limit cir cuit uses a sep a rate volt age di vider con nected di ­rectly to the out put ter mi nals.

The Cur rent Limit pro tects your cir cuit from un wanted high cur rents.
Note: In the Autoranging units the limit cir cuits are also used as "range lim its".
This can be con fus ing. Ex am ple: a SM52-AR-60 op er at ing in the range above
26 V will au to mat i cally re duce the limit set ting to a max i mum of 30 A.
Warn ing: if this unit op er ates in the range be low 26 V, this set ting is 60 A !
Take care the out put ca bling and the load can with stand such a high cur rent or
oth er wise re duce the limit set ting to a lower value.

33) PO TEN TI OM ETERS AND ENCODERS

° Stan dard: - CV and CC po ten ti om eters with knobs at front panel,

Volt age Limit and Cur rent Limit po ten ti om eters with
screw driver ad just ment at the front panel.

° Op tion P001: - Screw driver ad just ment for CV, C C, Volt age Limit and

Cur rent Limit at the front panel (see fig. 3 - 23).

° Op tion P220: - Dig i tal encoders for CV and CC set ting with a very long

life time and in tel li gent func tions (e.g. Keylock).
Set ting of CV-limit and CC-limit with screw driver ad just ­ment an a log po ten ti om eters at the front panel.

Screw driver ad just ment at front panel

fig. 3 - 23

34) COOLING

A low noise blower cools the unit. The speed of the fan de pends on the tem per ­a ture of the in ter nal heatsink. Normally at 50 °C am bi ent and full load the fan
will not work at full speed.

A spe cial fea ture is that the fan blows through a tun nel where the heatsink is
sit u ated, the del i cate con trol cir cuitry is sep a rated and will not be in the air flow
path (see fig. 3 - 24).

Be cause the air en ters at the left and ex its at the right side, it is pos si ble to stack
the power sup plies, no dis tance be tween the units is re quired. Only the ven ti la ­tion open ings at the left and right side should be free.

For long life the tem per a ture of the air en ter ing on the left side, should be
be low 35 °C un der nor mal con di tions. Un der ex treme conditions it should be
be low 50 °C.

Note: The con trol cir cuit makes the fan start in a pul sat ing mode, dur ing which
pe riod it can pro duce a high pitched sound. This is nor mal.

35) DI MEN SIONS

fig. 3 - 24

The fan blows through the tun nel,

where the heatsink is sit u ated

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 3 - 7

GENERAL SM1500

4 INSTALLATION

Warn ing: care fully read the chap ter "Safety In struc tions"

in this man ual be fore op er at ing the unit!

1) HU MID ITY & CON DEN SA TION

• Dur ing nor mal op er a tion, hu mid ity will not harm the power sup -

ply, pro vided the air is not ag gres sive. The heat nor mally pro ­duced in the power sup ply will keep it dry.

• Avoid con den sa tion in side the power sup ply, to pre vent

break-down. Con den sa tion can oc cur dur ing a pe riod the power
sup ply has been switched off (or op er at ing at no load) and the
am bi ent tem per a ture is in creas ing. Al ways al low the power sup ­ply to dry be fore switch ing it on again.

2) TEM PER A TURE & COOL ING

• The st or age tem per a ture range is –40 to +85 °C.

• The op er at ing tem per a ture range at full load is –20 to +50 °C.

This tem per a ture range only holds when the air-in takes and
air-out lets are un ob structed and the tem per a ture of the air-in take
is not higher than +50 °C.

• When the power sup ply is mounted in a cab i net, please note that

the tem per a ture of the air-in take should be kept low and avoid a
short cir cuit in the air flow i.e. the hot air leav ing the air-out lets
en ter ing the air-in takes again.

• Please note: a lower tem per a ture ex tends the life time of the

power sup ply.

3) 19" RACK MOUNT ING

• On both sides in the rack, mount a proper sup port slide that can

hold the weight of the unit. It is ad vised to use a sep a rate slide for
each unit.

• Af ter plac ing the unit(s) on the slide, add all 4 screws to mount the

front pan els of the power sup plies to the ver ti cal rack posts. Use
proper screws in tended for keep ing equip ment of this weight in
po si tion.

• As sum ing the rack is de lib er ately de signed for the weight, stack -

ing of the units is al lowed with out lim i ta tions. See pre vi ous para ­graph for cool ing in struc tions.

4) OP ER ATING THE UNIT FOR THE FIRST TIME

• Check there is no con den sa tion on the unit. If there is, al low some

time to dry.

• Check there is a link be tween + and S+ and be tween – and S– on

the SENSE BLOCK (on rear panel).

• Check there is a link be tween the in puts of the In ter lock (CON A,

rear panel).

• Set the CV and CC po ten ti om eters to min i mum (fully anti clock -

wise). For units with Op tion P220, this is not needed. These units
are set to start at 0 V - 0 A when op er ated for the first time.

• For rec om mended ca ble di am e ters and torque (see ta ble 4 -1).

• With high out put cur rent make sure to use low re sis tive con -

nec tions be tween the power sup ply and the load:

- Mount the ca ble lugs di rectly

on the tinned out put strips
fol lowed by a washer, a split washer and a nut (see fig. 4 - 1).
Al ways in this or der!

- Never place wash ers be tween the lugs and the strips
be cause this can re sult in ex ces sive heat!

- Only use nuts and wash ers sup plied with the unit.

• Switch on unit.

• Dis able the Key lock func tion, see next para graph 5) .

• Check the unit is not in Re mote CV or Re mote CC (LED’s for this

func tion should be off). Press the RE MOTE/LO CAL but ton un til
both LED’s are off.

• Turn on the out put by press ing the OUT PUT ON/OFF but ton.

• Turn both the CV and CC po ten ti om e ter a few turns clockwise.

A volt age should now be pres ent on the out put.

• By press ing the DIS PLAY CV/CC SETTING but ton, the me ters

will show the set ting of the CV and CC po ten ti om e ter.

Low re sis tive ca ble con nec tion by mount ing the

ca bles di rectly on the tinned out put strips

Unit Out put ca bles

SM15-100 16 M8 20
SM35-45 6 M8 20
SM52-30 5 M8 20
SM52AR60 10 M8 20
SM70-22 4 M8 20
SM120-13 2.5 M8 20
SM300-5 1 M8 20
SM400AR8 1.5 M8 20

Rec om mended ca ble di am e ters and

Pro gram ming by volt age:

left volt age -, right cur rent pro gram ming

Pro gram ming by cur rent

left volt age -, right cur rent pro gram ming

fig. 4 - 1

[mm2]

ta ble 4 - 1

mount ing torque

fig. 4 - 2

fig. 4 - 3

Bolts Torque

[Nm]

Page 4 - 1 DELTA ELEKTRONIKA B.V. rev. August 2018

SM1500 GENERAL

• By press ing the DIS PLAY LIMITS but ton, the volt me ter will

show the set ting of the CV-limit and the CC-limit
potentiometer.

• Check the cool ing of the unit is not ob structed.

5) KEY LOCK

• If the func tion KEYLOCK is ac ti vated, it is no lon ger pos si ble

to op er ate the RE MOTE/LO CAL but ton and the OUT PUT
ON/OFF but ton. This func tion can be use ful to pro tect the out ­put from ac ci den tal shut down. The func tion KEYLOCK does
not in flu ence the op er at ing of the CV, CC, CV-limit and
CC-limit po ten ti om eters.

• Units with dig i tal encoders:

For units with Op tion P220 also the dig i tal encoders for CV
and CC are dis abled with the Keylock func tion. T his means
set tings of the volt age and cur rent do not

change when the

fig. 4 - 4

Re mote con trol

encoders are op er ated. It is still pos si ble to op er ate the an a log
CV-limit and CC-limit po ten ti om eters.

• Ac ti vate Key lock:

Pressing the but tons DIS PLAY SET TINGS and DIS PLAY
LIMITS at the same time for more than 3 sec onds, ac ti vates
the func tion KEY LOCK. The mo ment this func tion is ac ti ­vated, the LED’s for RE MOTE CV / CC and for OUT PUT ON
will blink a few times.

• Dis able Key lock:

Pressing the same but tons again for 3 sec onds, dis ables the
Key lock function. The LED’s for RE MOTE CV / CC and for
OUT PUT ON will blink again to in di cate the new set ting.

6) AN A LOG PRO GRAMMING

• Set DIP switch 1 of SW1 in po si tion RIGHT to se lect CON E

for pro gram ming.

• Dis able Key lock.

• Set the unit in RE MOTE CV for volt age pro gram ming and/or in

RE MOTE CC for cur rent pro gram ming.
Use the RE MOTE/LO CAL but ton and push this but ton sev eral
times un til the right set ting is ac ti vated.
Note that pushing the RE MOTE/LO CAL but ton will shut down
the out put to avoid ac ci den tal dam age to the load.

• Con nect the pro gram ming volt age source( s) (0 - 5 V) to the

an a log pro gram ming con nec tor CON E on the rear panel (see
fig. 4 - 2 and fig. 4 - 3). Al ways use a shielded ca ble (max. 30
me ter) for pro gram ming.

• Turn the out put on again with the OUT PUT ON/OFF but ton

• If only the volt age is pro grammed, the max i mum cur rent can

still be set with the CC knob on the front panel and vice versa.
If this is not de sir able the unit can be or dered with Op tion P001
or Op tion P220 in or der to have a fixed set ting for the CV and
the CC knob on the front panel, see also par. 33) in pre vi ous
chap ter "De scrip tions".

• To avoid hum or noise, t he pro gram ming ca ble may have to

be twisted in some cases.

• To pro gram the unit by cur rent in stead of volt age, sim ply use a

par al lel re sis tor as a cur rent to volt age con verter.

• Pressi ng the DIS PLAY SET TINGS but ton will show the pro -

grammed val ues for CV and CC.

• CAU TION: The an a log in puts are not iso lated from the out put.

The Ø of the prog. in put (pin 1) is in ter nally con nected to the
S–, the S– is con nected to the neg a tive out put. To pro tect the
in ter nal wir ing a 650 mA self-resetting fuse is con nected in se ­ries (F27_1 on P647). To avoid earth loops, use an iso lated
pro gram ming source. If this is not pos si ble see next para ­graph 7), for us ing the op tional ISO AMP CARD.

fig. 4 - 5

Lo cal sens ing

fig. 4 - 6

Re mote sens ing with shielded wires

7) AN A LOG PRO GRAMMING WITH ISO AMP CARD

• For pro gram ming via the ISO AMP CARD, set DIP switch 1 on

SW1 in the po si tion OFF.

• When the ISO AMP CARD is built in side the unit, CON E has

Re mote sens ing, volt age drop in load leads sub -

fig. 4 - 7

tracts from max. out put

been covered. Use CON H in stead. The pin ning of CON H is
equal to the pin ning of CON E.

• For fur ther op er at ing in struc tions, see pre vi ous para graph 6).

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 4 - 2

INSTALLATION SM1500

8) Ethernet / IEEE488 / RS232 PRO GRAMMING

• Set DIP switch 1 on SW1 in po si tion OFF for pro gram ming

with the PSC-ETH, the PSC-488 or the PSC-232.
With DIP switch 1 in this po si tion, the sig nals Vprog (pin 11)
and Iprog (pin 3) are dis abled on CON E. All the other sig ­nals can still be used. For Ethernet pro gram ming CON H
must be used, CON F and G can be used for the user in­and out puts.
For IEEE488 also CON H must be used for pro gram ming.
For RS232 pro gram ming CON F and G must be used.

• Set the unit in RE MOTE CV for volt age pro gram ming

and/or in RE MOTE CC for cur rent pro gram ming us ing the
SCPI com mands (see man ual PSC) or us ing the RE ­MOTE/LO CAL but ton on the unit. Push this but ton sev eral
times un til the right set ting is ac ti vated. Set ting the unit in
RE MOTE or LO CAL will cause the out put to shut down to
avoid ac ci den tal dam age to the load. Turn it on again us ing
the SCPI com mand or with the OUT PUT ON/OFF but ton.

• Set DIP switch 1 on SW1 in po si tion ON to enable CON E

again for an a log pro gram ming.
In this po si tion volt age and cur rent pro gram ming on CON F
and H is dis abled. The other func tions and sig nals can still
be pro grammed and read back.

9) MON I TORING OUT PUTS

• The 5 V level is com pat i ble with most in ter faces.

• The mon i tor ing out puts can drive a me ter di rectly

(see fig. 4 - 4).

Sug gested circuit breakers for pro tec tion power sup ply
Model Type num ber

circuit breaker
SM15-100 HTI101 B 100 GE ­SM35-45 S281 UC-Z 50 ABB ­SM52-30 S281 UC-Z 32 ABB ex tra par al lel di ode

SM52AR60 S281 UC-Z 63 ABB ex tra par al lel di ode

SM70-22 S281 UC-Z 25 ABB ­SM120-13 S281 UC-Z 16 ABB ex tra par al lel di ode

SM300-5 S282 UC-Z 6

use with 2 poles

in se ries

SM400AR8 S282 UC-Z 10

use with 2 poles

in se ries

Brand Re marks

on out put needed
BYV255V-200

on out put needed
BYV255V-200

on out put needed
BYV255V-200

ABB ex tra par al lel di ode

on out put needed
2xBYT261PIV400

ABB ex tra par al lel di ode

on out put needed
2xBYT261PIV1000

ta ble 4 - 2

10) STATUS OUT PUTS

• The sta tus out puts have a sep a rate Ø con nec tion (pin 8) to

avoid un wanted off sets in the pro gram ming. This pin is pro ­tected with a 650 mA self re set ting fuse (F27_2 on P647).

11) RE MOTE SENSING

• Re move the links on the SENSE BLOCK (on rear panel)

and con nect sense leads (thin shielded mea sur ing wires)
to S+ and S– (see fig 4 - 5 and fig. 4 - 6).

• With r e mote sens ing the volt age on the load can be kept

con stant. The volt age drop in the load leads will be com ­pen sated. This fea ture is not rec om mended for nor mal use,
be cause it can eas ily give prob lems.

• Max. 2 V per load lead can be com pen sated. Note that the

volt age drop in the leads de creases the max. out put volt ­age rat ing. In fig. 4 - 7 it can be seen that on a 15 V power
sup ply only 11 V will be avail able on the load when 2x 2 V
com pen sa tion is used.

• In or der to pre vent in ter fer ence, it is ad vis able to twist the

sense leads. To min i mize the in duc tance in the load leads
keep the leads close to each other. The in duc tance of the
loads leads could give a prob lem with pul sat ing loads. In
this case a large elec tro lytic ca pac i tor (Cd) in se ries with a
damp ing re sis tor (Rd) both in par al lel with the load will (see
fig. 4 - 6). Check that the ca pac i tor Cd in com bi na tion with
the load leads and re sis tor Rd forms a well damped cir cuit.

• Since the volt me ter is in ter nally con nected to the sens ing

ter mi nals, it will au to mat i cally in di cate the volt age on the
load. Note that the volt age mea sured on the load will be

lower than on the out put ter mi nals.

• The Over Volt age Limit mea sures the volt age on the out put

ter mi nals, so the OVL set ting should be in creased by the
to tal volt age drop in the load leads.

fig. 4 - 8

Charg ing bat tery with a cir cuit breaker in se ries

fig. 4 - 9

Re mote ShutDown with switch

12) BAT TERY CHARGER

• The CV / CC reg u lated power sup plies are ideal bat tery

charg ers. Once the out put is set at the cor rect volt age the
bat tery will charge con stantly with out over charg ing.
This can be use ful for emer gency power sys tems.

• Pro tec tive mea sures

Use a CIR CUIT BREAKER in se ries in or der to pro tect the
power sup ply from ac ci den tal re verse con nec tion (see
fig. 4 - 8). The cir cuit breaker should have a DC volt age rat -

Mas ter / Slave se ries con nec tion

fig. 4 - 10

ing twice the bat tery volt age. Use the very fast type (Z), a

Page 4 - 3 DELTA ELEKTRONIKA B.V. rev. August 2018

SM1500 INSTALLATION

type meant for pro tect ing semi con duc tors (see ta ble 4

- 2).
The unit has a re verse di ode in par al lel with the out put,
this di ode and the wir ing can not with stand the thou ­sands of am peres sup plied by a wrongly con nected
bat tery.

13) RE MOTE SHUTDOWN

• The Re mote ShutDown can be op er ated on CON E by

a
volt age of +4 V...+12 V or by a re lay con tact be tween
Vref and Re mote Shut Down (pin 9 and 5) (see fig.
4 - 9).

• When the unit is pro grammed with an op tional PSC, a

soft ware com mand can be used for Re mote
ShutDown.

• In the Re mote ShutDown con di tion, the RSD LED will

light.
The DCF LED, DCF sta tus and the DCF re lay will be
off.

Im por tant: If the link from the In ter lock con nec tor (CON
A) has been re moved, the RSD LED will be on, but in
this
con di tion also the DCF LED, the DCF sta tus and the
DCF re lay will be on.

14) MASTER / SLAVE SERIES OP ER A TION

• Con nect out put ter mi nals and test sys tem in

nor mal se ries op er a tion. En sure that all (out put)
power con nec tions are re li able.

• The volt age drop in the con nect ing leads be tween the

units should be kept < 10 mV.

• Switch of f all units. Con nect units as shown in fig. 4 -

10.
On all units set switch SW1-4 in po si tion OFF to set the
units in M/S se ries mode (see page 3-4).

• Warn ing: never con nect CON C to CON C !

This can dam age the units.

• Use stan dard UTP ca bles (RJ45) to con nect the slaves

with the mas ter via CON B and CON C.

• Af ter turn ing the units on again, the slaves will be in Re -

mote CV mode and the Keylock, see pre vi ous para ­graph 5) is ac ti vated. This is be cause the unit
au to mat i cally de tects the pres ence of the RJ45 con ­nec tor in CON C (if this ca ble is con nected to an other
unit).

If the RJ45 con nec tor is re moved from CON C when
the unit is turned on, the out put will shut down to avoid
ac ci den tal dam age.
If the ca ble is in serted when the unit is turned on, the
out put shuts down, the unit changes to Re mote CV /
CC, the Key lock will be ac ti vated and the out put will
turn back on.
If DIP switch 4 of SW1 is op er ated when the unit is
turned on, the out put will shut down to avoid ac ci den tal
dam age.

• The max. num ber of slaves is only lim ited by the max.

to tal volt age of 600 V.

fig. 4 - 11

Mas ter / Slave par al lel connections

15) MASTER / SLAVE PAR AL LEL OP ER A TION

• Note: Mas ter / Slave par al lel is not rec om mended

for more than 3 units, con sult fac tory for us ing
more than 3 power sup plies in par al lel.

• First, con nect out put ter mi nals and test sys tem in

nor mal par al lel op er a tion. En sure that all power
con nec tions are re li able.

• Sec ond, switch off all units. To con nect the slaves with

the mas ter via CON B and CON C, use stan dard RJ45
con nec tors ac cord ing to fig. 4 - 11.
On all units put DIP switch 4 of SW1 in po si tion ON to
set the units in M/S par al lel mode. In this mode the
DCF LED, DCF re lay and DCF sta tus on the slaves are

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 4 - 4

Mas ter / Slave mixed se ries - par al lel connections

fig. 4 - 12

INSTALLATION SM1500

dis abled be cause the slaves are al ways in CC mode.

• Af ter turn ing the units on again, the slaves will be in

Re mote CC mode and the Keylock, see pre vi ous para graph 5) is
ac ti vated. This is be cause the unit au to mat i cally de tects the pres ­ence of the RJ45 con nec tor in CON C (if this ca ble is con nected to
an other unit).

If the RJ45 con nec tor is re moved from CON C when the unit is
turned on, the out put will shut down to avoid ac ci den tal dam age.
If the ca ble is in serted when the unit is turned on, the out put shuts
down, the unit changes to Re mote CV / CC, the Key lock will be ac ­ti vated and the out put will turn back on.
If DIP switch 4 of SW1 is op er ated when the unit is turned on, the
out put will shut down to avoid ac ci den tal dam age.

• Stack the units to cre ate a min i mum dis tance be tween the units.

Keep the load close to the mas ter.
Use cop per strips (pre ferred) or short thick ca bles to con nect the
units. Make sure the strips are mounted with a min i mum length to
keep the volt age drop be tween a unit and t he bus bar be low 10
mV. Also keep the strips close to each other to have a low in duc ­tance.
Not fol low ing these in struc tions can cause in sta bil ity.

• The S- and S+ could be con nected to the load if

de sired, but this is not rec om mended be cause of the com plex ity
and pos si ble instability.

16) PAR AL LEL OP ER A TION OF FAST

PRO GRAMMING VER SIONS:

• Mas ter / Slave op er a tion is not rec om mended.

• Nor mal par al lel op er a tion can give prob lems, each com bi na tion

has to be tested first in com bi na tion with the load.

17) MASTER / SLAVE MIXED SERIES /

PAR AL LEL OP ER A TION

• For com plex com bi na tions as mixed se ries - par al lel, al ways use a

MAS TER / SLAVE SE RIES ADAPTER.

• See fig. 4 - 12 for an ex am ple of how to con nect 2 units in se ries in

par al lel with 2 units in se ries, con trolled by 1 mas ter.

• Set the pro gram ming mode with the knob Re mote / Lo cal on the

front panel. The se rial slaves must be in Re mote CV- and
CC-mode. The par al lel slave must be in Re mote CC-mode and
the CV-potmeter must be fully opened.

• Note: A Mas ter / Slave com bi na tion can al ways be

pro grammed, also with the IEEE488/RS232 con trol ler
(PSC-448/PSC-232 (both δ-prod ucts)).

Page 4 - 5 DELTA ELEKTRONIKA B.V. rev. August 2018

SM1500 TROUBLE SHOOTING

5 TROUBLE SHOOTING

1 GEN ERAL

• In case y ou need as sis tance for re pair ing a unit, please con tact

our en gi neers us ing the ad dress "Sup ­[e-mail]".

• In case y ou want us to re pair the unit, please first f ill out the

RMA-form be fore send ing the unit to us. Add ing a de tailed fault
de scrip tion will help us to re pair the unit as soon as pos si ble.
On our website www.DeltaPowerSupplies.com the RMA-form
can be found un der 'Sup port'.

2 NO OUT PUT (man ual con trol)

• Check the LEDs ‘Re mote CV’ and ‘Re mote CC’ on the front

panel, they should be off. Dis able Keylock and press t he RE ­MOTE/LO CAL but ton to turn both LEDs off.

• The LED ‘O ut put On’ should be on. If this LED is off, dis able

Keylock and push the but ton ‘OUT PUT ON/OFF’.

• Check the c on nec tions on the SENSE BLOCK (at rear panel),

there should be a link be tween + and S+ and be tween – and S–
(see fig. 5 - 3).

• Check if there is a link in the In ter lock con nec tor (if not, the RSD

LED will be on).

• Set bot h the CV- and CC-limit po ten ti om e ter (at front panel) at

max i mum (fully clock wise).

• Turn both the CV and CC po ten ti om eters a few turns clock wise.

A volt age should be pres ent on the out put (for units with Op tion
P220 first re move the K eylock func tion be fore the CV and CC
knobs can be turned, see par. 5) in pre vi ous chap ter
"INSTALLATION").

• Dis con nect the ca bles from the out put and check if now there's a

volt age pres ent on the out put. If this is the sit u a tion, use a load
with a higher im ped ance or use a sec ond power sup ply in par al lel.

Lo ca tion of pro gram ming fuses on P647

P647 is sit u ated di rectly be hind the rear panel

fig. 5 - 1

3 PRO GRAM MING DOES NOT WORK OK

• Check the unit is in Re mote mode (Re mote CV and/or Re mote

CC LED should be on).

• The unit works OK in man ual con trol, but in pro gram ming

mode the out put volt age / cur rent has a large er ror.
Prob a bly the fuse in se ries with Ø (pin 1) of pro gram ming con nec ­tor trip ped, the fuse (F27_1 = 650 mA) is a self-re set ting type (see
fig. 5 - 1).

• To check the fuse (F27_1) mea sure the volt age be tween Ø and

the mi nus out put, dur ing the fault con di tion. The volt age should
only be a few mV, a high volt age means that an un wanted cur rent
is flow ing through pin 1 of the prog. con nec tor.
Please check why cur rent is flow ing through pin 1 (see next para ­graph) and fig. 5 - 2).

4 PRO GRAM MING OFF SETS

• Un wanted off sets in the pro gram ming can be caused by

earth loops.

Fig. 5 - 2 shows a typ i cal earthing prob lem. In case the load has a
con nec tion to ear th and the pro gram ming source as well, prob ­lems could oc cur. Im proper choice of the earthing point of t he
load can give a volt age drop of ∆V1. Con nect ing the mi nus or
zero to a sep a rate earth con nec tion can give a volt age drop of
∆V2. Be cause the in ter nal wires of the pro gram ming in put are
thin, the volt age drops ∆V1 and ∆V2 will be across the in ter nal
wir ing as well. Re sult ing in an er ror volt age in se ries with the pro ­gram ming volt age.

• The best so lu tion for this is to use a float ing pro gram ming

source, a float ing load or the op tional in ter nal ISO AMP CARD

(δ-prod uct).

fig. 5 - 2

Un wanted pro gram ming off sets

5 STA TUS OUT PUTS FAIL

• Check fuse F27_2 in se ries with Ø (pin 8 of CON E) (see fig. 5 - 1).

To check the fuse mea sure the volt age be tween Ø and the mi nus
out put, a high volt age means too much cur rent flow ing through
the fuse. F27_2 = 650 mA, self re set ting.

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 5 - 1

TROUBLE SHOOTING SM1500

6 MAS TER / SLAVE PAR AL LEL PROB LEMS

• Check the volt age drop of the wir ing be tween the mas ter and the

slaves is < 10 mV.

• Check the wir ing has a low in duc tance.

7 OUT PUT VOLT AGE IS HIGHER THAN SET VALUE

• Check con nec tions on SENSE BLOCK (on rear panel), For nor -

mal op er a tion there should be a link be tween + and S + and be ­tween – and S– (see also fig. 5 - 3). When re mote sens ing is used,
check the wires of the sens ing.

8 OT LED on

• The tem per a ture of the in ter nal heat sink is too high,

the out put has been shut down to avoid over heat ing.

• Check if the cool ing fan is run ning.

• Check if the air tem per a ture of the air in let (left) is be low 50 °C and

the air flow is not ob structed.

9 OT LED blinks

• The tem per a ture of the in ter nal heat sink is get ting too high, a fur -

ther in crease will shut down the power sup ply.

• Check if the cool ing fan is run ning prop erly.

• Check if the air tem per a ture of the air in lets (left) is be low 50 °C

and the air flow is not ob structed.

10 ACF LED on

• The in put volt age is too low or was in ter mit tent be cause of a bad

con nec tion. Dis con nect t he mains, wait a few min utes and try
again.

As soon as the ACF LED Iights, the set tings for Re mote CV, Re ­mote CC and Keylock will be saved. If the unit turns back on, it will
have the same set tings. For the set ting of Out put On/Off af ter
turn ing the unit back on, the po si tion of DIP switch 2 on SW1 is de ­ter min ing.
If the ACF sit u a tion lasts a few sec onds, the out put will shut down.
The ACF prob lem has to be solved first, be fore the out put can be
turned on again.

• In ter nal er ror, send unit for re pair. See pre vi ous para graph 1).

11 DCF LED on

• The out put volt age is be low the set volt age. This au to mat i cally

hap pens when the unit is in CC-mode (CC LED is on).
Also with an in ter rupted In ter lock con nec tor, the DCF LED will be
on.

• In ter nal er ror, send unit for re pair. See pre vi ous para graph 1).

fig. 5 - 3

For nor mal op er a tion links should be con nected

be tween S+ and + and be tween S– and –

12 PSOL LED on

• The Power S ink is in over load or the tem per a ture of the Power

Sink is too high. See datasheet of the Power Sink op tion for fur ­ther de tails.

13 NO LEDS on

• Check in put.

• Do not try to re pair, but send for re pair. See pre vi ous para graph

1).

14 Blink ing LEDs RE MOTE CV, RE MOTE CC and

OUT PUT ON

• This in di cates the Keylock func tion is ac ti vated, see pre vi ous

para graph 5) in "op er at ing man ual".

15 OTHER

• If the prob lem per sists, please fill out the RMA-form on our

website www.DeltaPowerSupplies.com

1).

Page 5 - 2 DELTA ELEKTRONIKA B.V. rev. August 2018

. See pre vi ous para graph

SM1500 MAINTENANCE & CALIBRATION

6 MAINTENANCE & CALIBRATION

1 GEN ERAL

• The SM- se ries power sup plies do not need any main te nance or

cal i bra tion.How ever, care must be taken that the cool ing unit is
not ob structed.

2 COOL ING FAN

• The built up of dust on the im pel ler of the fan and the heat sink fins

de pends on the en vi ron ment. Since the fan has over-ca pac ity,
dust will not pres ent a prob lem very quickly.

• The in ter nal con struc tion of the power sup ply is such that no dust

will reach the sen si tive con trol cir cuitry, only the heat sink in a tun ­nel will be cooled by forced air (see fig. 6 - 1).

• The ther mal pro tec tion will shut down the out put in case of over -

heat ing, so the power sup ply will not be dam aged.

• It is ad vis able to in spect the fan and the heat sink reg u larly.

3 GAL VANIC IN DUS TRY

• For us ing the power sup plies in the gal vanic in dus try it is strongly

rec om mended to take pre cau tions against an ag gres sive en vi ­ron ment.

• An ag gres sive en vi ron ment with acid, salt, etc. can harm the elec -

tronic com po nents. Some times even the cop per tracks on the
printed cir cuit boards dis solve.

• To avoid pr ob lems, the power sup plies should be mounted in a

rel a tively clean room, or mounted in a cab i net re ceiv ing clean air
with over pres sure, or a cab i net with a heat exchanger.

The fan blows through an in ter nal tun nel,

where the heatsink is sit u ated.

Al ways take care to have the air out let un ob -

fig. 6 - 1

structed.

4 CAL I BRA TION

• The power sup plies are fac tory cal i brated and nor mally need no

fur ther cal i bra tion.

• Only in spe cial sit u a tions, for ex am ple af ter re pair ing a unit, cal i -

bra tion can be nec es sary.

5 ME TER CAL I BRA TION

• DIG I TAL ME TERS

The full scale in di ca tion can be cal i brated with R25_31 and
R25_36 on P596 (see fig. 6 - 2).

6 SPE CIAL CAL I BRA TIONS

• The fol low ing cal i bra tions must be done by qual i fied per son nel

only. Wrong cal i bra tion causes mal func tion. These cal i bra tions
are only needed af ter spe cial re pairs.
Warn ing ! Dam age caused by a wrong cal i bra tion is not
war ranted.

• CAL I BRAT ING THE CUR RENT

MON I TOR OFF SET.
With R26_73 on P650 the off set of the CC mon i tor volt age can be
cal i brated (see fig. 6 - 3). The unit has to be un loaded, the out put
volt age has to be turned off us ing the OUT PUT ON/OFF but ton.
Mea sure the off set volt age of the CC mon i tor on the pro gram ming
con nec tor. Cal i brate the off set on a neg a tive value be tween –1
mV and zero mV.
Warn ing! wrong cal i bra tion can dam age the unit.

• CAL I BRAT ING MAX. CUR RENT RANGE or CAL I BRAT ING CC

MON I TOR FULL SCALE.
Short the out put us ing a low re sis tive ca ble. Mea sure the out put
cur rent with an ac cu rate shunt. The max i mum out put cur rent can
be cal i brated with R26_41. R26_41 is lo cated on P650 (see
fig. 6 - 3).

fig. 6 - 2

Me ter cal i bra tion with 25-turn potmeters on

P596

offset

full scale

Pro gram CC in put with ex actly 5.00 V.
Set out put volt age to a high value, en sur ing the power sup ply is in
CC mode. Cal i brate the cur rent with R26_41 ex actly on the rated
max. cur rent.
Warn ing! Wrong cal i bra tion can dam age the unit.

fig. 6 - 3

Cal i brating max. cur rent and off set on P650.

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 6 - 1

SM1500 EU DECLARATION

DELTA ELEKTRONIKA B.V.

DC POWER SUPPLIES

EU Dec la ra tion of Con for mity - SM1500-series

We

Delta Elektronika
Vissersdijk 4
4301 ND ZIERIKZEE
The Neth er lands

De clare un der sole re spon si bil ity that the fol low ing Power Sup plies:

SM 15-100
SM 35-45
SM 52-30
SM 52-AR-60
SM 70-22
SM 120-13
SM 300-5
SM 400-AR-8

Vissersdijk 4, 4301 ND

Zierikzee, the Netherlands

www.DeltaPowerSupplies.com

Tel. [phone]

Meet the in tent of Di rec tives

2014/30/EU Elec tro mag netic Com pat i bil ity (EMC)
2014/35/EU Low Volt age Di rec tive (LVD)
2011/65/EU Re duc tion of Haz ard ous Sub stances (RoHS2)

Com pli ance was dem on strated to the fol low ing spec i fi ca tion as listed in the of fi cial Jour nal
of the Eu ro pean Com mu ni ties:

EN 61000-6-3:2007 Ge neric Emis sions (res i den tial, light in dus trial)

EN 61000-3-2:2014 Power Har mon ics
EN 61000-3-3:2013 Volt age fluc tu a tion and flicker

EN 61000-6-1:2007 Ge neric Im mu nity (res i den tial, light in dus trial)
EN 61000-6-2:2005 Ge neric Im mu nity (in dus trial en vi ron ment)
EN 60950-1:2006 Safety of IT equip ment

+A1:2010 + A11:2009 + A12:2011 + A2:2013

EN 61010:2010 Safety of elec tri cal equip ment for mea sure ment, con trol and lab o ra tory use
EN 50581:2012 As sess ment of elec tri cal and elec tronic prod ucts with re spect to RoHS

Man ag ing di rec tor,
Zierikzee, Au gust 2018

rev. August 2018 DELTA ELEKTRONIKA B.V. Page 7 - 1
