Delta Electronics LMWM860A User Manual
LM-WM860A-R
Preliminary Product Specification
IEEE802.11n 2.4GHz WLAN Mini-PCI Adapter
Note: This document contains proprietary technical information in which is the property of the Delta Networks
Inc. and shall not be disclosed to others in whole or in part, reproduced, copied, or used as the basis for
design, manufacturing, or sale of apparatus without written permission of Delta Networks Inc.
Table Of Contents
1. REVISION HISTORY...................................................................................................................................................... 1
1.1. D
2. GENERAL DESCRIPTION ............................................................................................................................................ 2
2.1. F
2.2. M
2.3. IC S
2.4.
3. TECHNICAL SPECIFICATIONS .................................................................................................................................. 6
4. DELIVERY PACKAGE ................................................................................................................................................... 8
OCUMENT REVISION HISTORY
EATURES
ECHANICAL DESIGN
VID, DID, SVID
.................................................................................................................................................................... 2
OLUTION
................................................................................................................................... 1
.................................................................................................................................................. 3
............................................................................................................................................................... 4
AND
SPID
ASSIGNMENT
................................................................................................................... 5
Delta Networks Inc. ii
1. Revision History
Revision Date Remark
1.00 2009/0213 Product Initial
1.1. Document Revision History
Revision Date Remark
1.00 2009/02/13 Preliminary product spec
Delta Networks Inc. 1
2. General Description
LM-WM860A-R is compliant with mini PCI standard Adapter. The Atheros 802.11b/g/n IEEE802.11n technique
delivers up to 54Mbps (802.11g) or 300Mbps 11n data rate, the bandwidth support 20MHz and 40MHz for legacy
WLAN standard and also fulfilled high throughput data rate requirement on IEEE802.11n, it uses 2 sets of 2.4GHz
Tx / Rx antenna’s combinations, since the IEEE802.11b/g is CCK & OFDM modulation scheme and used CCK
modulation to follow backward compatible with IEEE802.11b, up to 54Mbps on single 2.4GHz frequency band. It
supports the Quality of Service for 802.11e. (WMM) feature to enable robust wireless streaming of audio and video
content while remaining compatible with any 802.11b/g devices.
2.1. Features
Form Factor – a compatible with Mini-PCI Adapter
32-bit 33 and 66MHz PCI v2.3 interface
Support for IEEE 802.11g standard, IEEE802.11b and IEEE802.11n compliant
Support 802.11e-compatible bursting, 802.11h, 802.11j and 802.11i
Security Cypher text WEP, TKIP and AES hardware encryption
2x2 MIMO technology improves effective throughput and range over existing 802.11b/g/n products
Frame aggregation with A-MPDU
Wake-on-Wireless feature supported
Supports spatial multiplexing, cyclic-delay diversity (CDD) and Maximal Ratio Combining (MRC)
Data rate 802.11b/g: 1,2,5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54-Mbps
and Atheros IEEE802.11n rate at 150Mbps (HT20MHz channel bandwidth; 300Mbps (for HT40MHz
channel bandwidth)
®
Drivers - Microsoft
Windows® 2000, XP and Vista and Linux
Delta Networks Inc. 2
