Delta Electronics LCP-10G3B4QDR User Manual
LCP-10G3B4QDR
10GBASE-LR SFP+ Optical Transceiver Preliminary
FEATURES
RoHS compliant
Compliant to SFP+ Electrical MSA SFF-8431
Compliant with SFF-8472 MSA
Standard LC duplex fiber-optic connector
2
C for integrated Digital Optical Monitoring
I
Power consumption ＜1W
Description
The LCP-10G3B4QDR is a hot pluggable
10Gbps small form factor plus transceiver
module integrated with the high performance
1310nm DFB Laser transmitter, high sensitivity
linear PD-TIA receiver for 10Gbps applications.
It is compliant with the SFF-8431 SFP+
Electrical Multi-source Agreement (MSA) with
five digital monitoring functions: Temperature,
Vcc, Tx optical power, Tx laser bias current and
Rx received optical power.
Applications
10G LAN switch
10G Ethernet switch/router
10G Fiber channel
SAN applications
Performance
LCP-10G3B4QDR: Link distance up to 10km
over 9um SMF
DELTA ELECTRONICS, INC.
1 Revision: 0B
2008/9/5
www.deltaww.com
Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit
Storage Temperature T
Supply Voltage Range @3.3V V
S
CC3
-40 85 ºC
-0.5 3.6 V
Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit
Case Operating Temperature T
Supply Voltage @3.3V V
C
CC3
-5 +70 ºC
3.135 3.30 3.465 V
Relative Humidity (non condensation) - 5 85 %
DC Common Mode Voltage V
CM
0 3.6 V
Low Speed Electrical Characteristics
(VCC=3.135V to 3.465V)
Parameter Symbol Min. Typ. Max. Unit Note
Total Supply Current I
CC
Power Consumption PC 1 W
V
TX_Fault, RX_LOS
TX_Disable
RS0, RS1
1. Shall be pulled up with 4.7k-10k ohms to 3.3 volt in the module.
OL
V
OH
V
IL
V
IH
V
IL
V
IH
300 mA
0 0.4 V
Host_Vcc-0.5 Host_Vcc+0.3 V
-0.3 0.8 V 1
2.0 VccT+0.3 V 1
-0.3 0.8 V 2
2.0 VccT+0.3 V 2
LCP-10G3B4QDR
2. Shall be pulled low to
GND with a ＞30k ohms resistor in the module.
DELTA ELECTRONICS, INC.
2 Revision: 0B
2008/9/5
www.deltaww.com
Optical Transmitter Characteristics (TC = -5 to 70 )℃℃
Parameter Symbol Min Typ Max Units Notes
Signaling speed (nominal) R 10.3125 Gb/s Signaling speed variation from nominal Center Wavelength Side Mode Suppression Ratio Optical Modulaion Amplitude Average output power AP -8.2 +0.5 dBm Extinction Ratio ER 3.5 dB Transmitter eye mask definition {X1, X2, X3, Y1, Y2, Y3}
Notes:
1. Even if the TDP < 1 dB, the OMA (min) must exceed this value.
λ
SMSR 30 dB
OMA -5.2 dBm
1260 1355 nm
{0.25, 0.40, 0.45, 0.25, 0.28, 0.40}
Transmitter eye mask definition
LCP-10G3B4QDR
±100
ppm
4. Optical Receive Characteristics
Parameter Symbol Min Typ Max Units Notes
Signaling speed (nominal) Ts 10.3125 Gb/s Signaling speed variation from nominal Center Wavelength Overload P Receiver sensitivity in OMA RSO -12.6 dBm [1] Stressed Receiver sensitivity in OMA LOS De-assert LOS LOS Assert LOS
Notes:
1. Measured with 2^31-1 PRBS for BER = 10
DELTA ELECTRONICS, INC.
λ
O
SRS -10.3 dBm [1]
(TC=0 ºC to 70 ºC)
1260 1355 nm
0.5 dBm
D
A
-18 dBm
-30 dBm
±100
-12
. Per IEEE802.3ae
3 Revision: 0B
ppm
2008/9/5
www.deltaww.com
SFP+ Transceiver Electrical Pad Layout
LCP-10G3B4QDR
DELTA ELECTRONICS, INC.
4 Revision: 0B
2008/9/5
www.deltaww.com
Module Electrical Pin Definition
Pin Logic Symbol Name/Description Note
1 VeeT Module Transmitter Ground 1
2 LVTTL-O TX_Fault Module Transmitter Fault 2
3 LVTTL-I TX_Disable Transmitter Disable; Turns off transmitter laser output 3
4 LVTTL-I/O SDA 2- write Serial Interface Data Line
5 LVTTL-I/O SCL 2- write Serial Interface Clock
6 MOD_ABS Module Absent, connected to VeeT or VeeR in the module 4
7 LVTTL-I RS0 Not Implement
8 LVTTL-O RX_LOS Receiver Loss of Signal Indication 2
9 LVTTL-I RS1 Not Implement
10 VeeR Module Receiver Ground 1
11 VeeR Module Receiver Ground 1
12 CML-O RD- Receiver Inverted Data Output
13 CML-O RD+ Receiver Non-Inverter Data Output
14 VeeR Module Receiver Ground 1
15 VccR Module Receiver 3.3V Supply
16 VccT Module Transmitter 3.3V Supply
17 VeeT Module Transmitter Ground 1
18 CML-I TD+ Transmitter Non-Inverted Data Input
19 CML-I TD- Transmitter Inverted Data Input
20 VeeT Module Transmitter Griund 1
Note:
1. The module signal ground pins, VeeR and VeeT, shall be isolated from the module case.
2. This pin is an open collector/drain output pin and shall be pulled up with 4.7k-10k ohms to Host_Vcc
on the host board. Pull ups can be connected to multiple power supplies, however the host board
design shall ensure that no module pin has voltage exceeding module VccT/R + 0.5V.
3. This pin is an open collector/drain input pin and shall be pulled up with 4.7k-10k ohms to VccT in the
Module.
4. This pin shall be pulled up with 4.7k-10k ohms to Host_Vcc on the host board.
LCP-10G3B4QDR
DELTA ELECTRONICS, INC.
5 Revision: 0B
2008/9/5
www.deltaww.com
