Delta Elec. Inc. Qumi Rev.02
Company Confidential VIVITEK___________________ Delta________________
1
2011/07/05
DATA PROJECTOR
SERVICE MANUAL
Qumi_DP274-A13VVxA
Qumi_DP274-A13VVxB
Page 2
Delta Elec. Inc. Qumi Rev.02
Company Confidential VIVITEK___________________ Delta________________
2
2011/07/05
CONTENTS
1.COMPLIANCE OF SAFE REPAIR........................................................................................4
1-1.Caution During Disassembling And Assembling.............................................................4
1-2.Lamp.............................................................................................................................. 4
1-3.Lens................................................................................................................................4
2.SPECIFICATIONS.................................................................................................................5
2-1.Summary Specifications................................................................................................. 5
2-2.Views the projector……..………….………………………………………..…………..….…6
2-3.Remote control...............................................................................................................8
2-4.Optical adjustment image size......................................................................................10
2-5.BLOCK DIAGRAM....................................................................................................... 11
3.TROUBLE SHOOTING...................................................................................................... 12
4. DISASSEMBLY AND ASSEMBLY ..........................................................…………........... 17
5. Firmware Download......................................................................................................... 28
5-1.
Projector USB Drivers Installation Guide………………………………….……………...28
5-2. DLP Projector Composer (firmware) User Guide…………………………….…………..33
5-3. Started with Download………………………………………………………………………34
5-4.Starting and Shutting down the Projector……………………………………………….....39
5-5.Setting an Access Password (Security Lock)………………………………….…………..41
5-6.DLP Projector security unlock……………………………………….………………………43
5-7.Factory Reset……………..…………………………………………………………..…….. 45
5-8. Status…………………………………………..…………………………………………………………45
6. Calibration…………………………….……………………………………..….………………..46
7. EDID…………………………………………………………………………………………….…50
8. Service Note..…………………………………..………………………………………………..59
9. LED Message…………………………………………………………………………………….60
10. Factory preset Display modes……………………………………………….……….…..…61
11. Projector Installation Notice……………………………………………………..…………..63
12. Projector Dimensions……………………………………………………………………...…64
13.FAN Control……………………………………………………………………………………..65
14. Spare parts list……………………………………………………………………………….…66
Page 3
Delta Elec. Inc. Qumi Rev.02
Company Confidential VIVITEK___________________ Delta________________
3
2011/07/05
Revised History
NO. Description
Date
00 Draft Edit 6-24-2011
01 Preliminary 6-28-2011
02
Page 33, Step of into MFG Mode method diagram modifies.
Page 15~16 list number remark. Page 66~71 Spare part list update
7-05-2011
Page 4
Delta Elec. Inc. Qumi Rev.02
Company Confidential VIVITEK___________________ Delta________________
4
2011/07/05
1. Important safety information
Be sure to read this Service Manual before providing services. In the projector, full
consideration is taken to ensure safety for fire, electric shock, injury, harmful radiation, and
substance. Therefore, observe the notice described in this Service Manual so that safety is
kept when providing services. Moreover, be sure to observe the notice described in the
Instruction Manual.
Pay attention to the following items during service inspection.
1-1 Cautions during disassembling and assembling
1. This equipment contains parts under high voltage. When making repairs, etc.
Be sure to pull out the power plug beforehand to insure safety.
2. Parts may be very hot immediately after use.
Make sure the equipment has cooled off sufficiently before carrying out repairs.
3. Make sure that parts and screws and wiring, etc. are returned to their original positions.
Tube, tape and other insulation materials have been used for safety reasons.
The internal wiring has been designed to avoid direct contact with hot parts or parts under
high voltage when using clamps or other tools.
4. The parts used in this device have special safety features such as flame-resistance and
anti-voltage properties. When replacing parts, always use parts supplied from the factory.
5. After finishing operations make sure that all parts and wires have been returned to their
original position and that there has been no deterioration of the area around the location that
was worked on.
6. Be sure to use a grounding strap (wrist band) during repair and inspection.
1-3 Lens
Do not look into a lens during projection. This damages your eyes.
Page 5
Delta Elec. Inc. Qumi Rev.02
Company Confidential VIVITEK___________________ Delta________________
5
2011/07/05
2. SPECIFICATIONS
2-1. Summary Specifications
Model
Qumi_DP274-A13VVxx
Display type
TI DLP DMD 0.45” , 12deg , S310 , WXGA Dark Chip3
Resolution
1280 x 800
Projection distance
762mm-2286mm
Projection screen size
25.43” to 76.34” inches
Throw ratio
1.55
Aspect Ratio
16:10
Vertical keystone
correction
+/- 15 degrees
Video compatibility
HDTV , NTSC , PAL , SECAM
Operation temperature
5° ~ 35°C
Dimensions (WxHxD)
160.0mm (W) x102.4mm (H) x32.3mm (D)
Weight
1.4 lbs typ.
AC Input
AC Universal 100 ~ 240, Typical @ 110VAC (100~240)/+-10%
w/Adaptor --- Normal:70W typ , ECO:20W typ
Power consumption
wo/Adaptor --- Normal:60W typ , ECO:18W typ
Stand By
<0.5 watts @110Vac 60Hz
LED Brightness
Bright Mode: 120~170 lumens
Audio speaker
AMP 1W speaker
Digital -- HDMI C type x 1
Analog -- Universal I/O x 1
(through a transferring line of universal I/O (24 pin) to D-SUB (15 pin)
Component -- Thru RGB_IN
AN in -- ψ3.5 mm phone jack for CVBS and Audio R/L
(through a transferring line of 4 contact phone jack to CVBS/ AUDIO R/L RCA jack)
USB connector type A x 1
Input terminals
Media Card -- Micro SD x 1
Output terminals
Audio Out -- 3.5mm earphone jack (Volume control) x 1
Page 6
Delta Elec. Inc. Qumi Rev.00
Company Confidential Vivitek ______________________ Delta____________
6
2011/06/24
2-2. Views the projector
Front/Top/Right View
Page 7
Delta Elec. Inc. Qumi Rev.00
Company Confidential Vivitek ______________________ Delta____________
7
2011/06/24
B. Rear/Top/Left view
Bottom view
Page 8
Delta Elec. Inc. Qumi Rev.00
Company Confidential Vivitek ______________________ Delta____________
8
2011/06/24
2-3. Remote control
Page 9
Delta Elec. Inc. Qumi Rev.00
Company Confidential Vivitek ______________________ Delta____________
9
2011/06/24
1.
Remove the battery compartment
cover by sliding the cover in the
direction of the arrow (A). Pull out the
cover (B).
2.
Insert the battery with the positive
side facing up.
3.
Replace the cover.
Caution:
1. Only use a 3V lithium battery (CR2025)
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the battery when not using the projector for prolonged periods.
Page 10
Delta Elec. Inc. Qumi Rev.00
Company Confidential Vivitek ______________________ Delta____________
10
2011/06/24
2-4. Optical Adjustment & Image Size
Projection Distance and Size Table
Page 11
Delta Elec. Inc. Qumi Rev.00
Company Confidential Vivitek ______________________ Delta____________
11
2011/06/24
2-5. Block Diagram
Page 12
Delta Elec. Inc. Qumi Rev.00
Company Confidential Vivitek ______________________ Delta____________
12
2011/06/24
3. TROUBLE SHOOTING
Carry out the following checks before disassembling the equipment.
Waiting
Power On
Connect the power cord
• Power Supply Unit malfunction
•Check the connection of
BATTERY DOCKING BD P31 to MB P700)
• Check MCU firmware is ok or not
•Check keypad connection ( MB P360 to Keypad P1)
< Stand-by >
Left: Blue
Right: Blue
< Power supply error >
Left: OFF
Right: OFF
Yes
No
No
Page 13
Delta Elec. Inc. Qumi Rev.00
Company Confidential Vivitek ______________________ Delta____________
13
2011/06/24
Tur n th e
power ON
Display
< Powering up >
Left: Blue
Right: Blue
< LED-Lit error >
Left: 3binks
< Normal operation >
Left: Off
Right: Off
No
< LED Thermistor error >
Left: 8 binks
• MB J0302 disconnected
• LED-Red NTC thermistor disconnected
• MB J0402 disconnected
• LED-Green NTC thermistor disconnected
• MB J0202 disconnected
• LED-Blue NTC thermistor disconnected
Ri
g
ht: 1 blinks
Ready:2blinks
Ready:3blinks
Yes
Yes
No
Y
T2 error, Red LED Drive malfunction
T3 error, Green LED Drive malfunction
T4 error, Blue LED Drive malfunction
Ready: 1 blinks
Read
y
:2 blinks
Read
y
:3blinks
Page 14
Delta Elec. Inc. Qumi Rev.00
Company Confidential Vivitek ______________________ Delta____________
14
2011/06/24
Y
No
Display
• MB (P361) of Fan disconnected
• Fan32 (System) malfunction
Right: 1 blink
Right: 2 blinks
• HDMI/B (P201) of Fan disconnected
• Fan1 (Blower) malfunction
< Fan error>
Left: 6 blinks
• Main Board Ass’y malfunction
• DMD Set malfunction
Does the LED
go off during
o
p
eration?
System OK
Normal operation
Projector logo screen
display
• Temperature protector operated due to the increase in temperature based
on operating environment
• Temperature protector operated due to blocked suction and exhaust holes
or dirty fan
• Power board Assy’s malfunction
• LED chip malfunction
• T1 sensor malfunction
<Over temperature >
Left: 3 blink
Right: OFF
No
No
Yes
No
No
Yes
Yes
Page 15
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
15
2011/07/05
Common problems and solutions
These guidelines provide tips to deal with problems you may encounter while using the projector. If the
problem remains unsolved, contact your dealer for assistance.
Often after time spent troubleshooting, the problem is traced to something as simple as a loose
connection. Check the following before proceeding to the problem-specific solutions.
• Use some other electrical device to confirm that the electrical outlet is working.
• Ensure the projector is turned on.
• Ensure all connections are securely attached.
• Ensure the attached device is turned on.
• Ensure a connected PC is not in suspend or sleep mode.
• Ensure the connected notebook computer is properly configured for an external display
Image Problems
Problem: No image appears on the screen
1.Verify the settings on your notebook or desktop PC.
2.Turn off all equipment and power up again in the correct order.
Problem: The image is blurred
1.Adjust the Focus on the projector.
2.Ensure the Qumi-to-screen distance is within the specified range.
3.Check that the Qumi lens is clean.
Problem: The image is wider at the top or bottom (trapezoid effect)
1.Position the Qumi so it is as perpendicular to the screen as possible.
2.Use the Keystone button on the remote control or projector to correct the problem.
Problem: The image is reversed
1.Check the orientation of the projection setting in the Installation I menu of the OSD.
Problem: The image is streaked
1.Set the Frequency and Tracing settings on the Computer menu of the OSD to the default
settings.
Page 16
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
16
2011/07/05
2.Connect the Qumi to anther computert to make sure that the problem is not caused by a
computer’s video card.
Problem: The image is flat with no contrast
1.Adjust the Contrast setting on the Image menu of the OSD.
Problem: The color of the projected image does not match the source image.
1.Adjust the Color Temperature and Gamma settings on the Image menu of the OSD
Remote Control Problems
Problem: The Qumi does not respond to the remote control
1.Direct the remote control towards remote sensor on the Qumi.
2.Ensure the path between remote and sensor is not obstructed.
3.Turn off any fluorescent lights in the room.
4.Check to see if the battery polarity is correct
5.Replace the batteries.
6Turn off other Infrared-enabled devices in the vicinity.
7.Have the remote control serviced.
Audio Problems
Problem: There is no sound
1.Adjust the volume on the remote control.
2.Adjust the volume of the audio source.
3.Check the audio cable connection.
4.Test the source audio output with other speakers.
5.Have the projector serviced.
Problem: The sound is distorted
1.Check the audio cable connection.
2.Test the source audio output with other speakers.
3.Have the projector serviced.
Page 17
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
17
2011/07/05
4. DISASSEMBLY AND ASSEMBLY
Review the Qumi and Removing the foot rubbers
Look the full set projector. Look at the IO side.
Look at the case of top side. Look at the keypad of top side.
D
I
S
A
S
S
E
M
B
L
Y
Remove the four foot rubbers. Review these rubbers.
Page 18
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
18
2011/07/05
Removing the Top Cover and replacing the keypad touch board
Remove the four screws. Review the four screws (S01).
Remove the Top cover like this.
Be careful this connector when you
assembly it.
D
I
S
A
S
S
E
M
B
L
Y
Review the Top Cover assy. Replace the keypad touch board like
this.
Page 19
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
19
2011/07/05
Removing the Main Board assy
Review the Qumi. Remove the four screws.
Review the four screws (S02).
Firstly, tilt one side of the main board
like this.
D
I
S
A
S
S
E
M
B
L
Y
Secondly, tilt the other side like this. Remove the main board like this.
Page 20
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
20
2011/07/05
Removing the Main Board assy
Be careful the Blower FAN connector
when you assembly.
Be careful these connectors when you
assembly it.
Be careful these connectors when you
assembly it.
Review the Main board assy.
D
I
S
A
S
S
E
M
B
L
Y
Review the Main board assy. Remove the four screws.
Page 21
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
21
2011/07/05
Removing the Main Board
Review the four screws (S02) and take
off the main board.
Be careful the two connectors when
you assembly.
Review the main board shielding. Remove the four screws.
D
I
S
A
S
S
E
M
B
L
Y
Remove the four screws (S03).
Review the
MULTI-MEDIA BD and HDMI+VGA BD
Page 22
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
22
2011/07/05
Main Board Review
Careful area of these connectors and
check these right positions connection
when you recover main board again.
Careful the connector and check the
right position connection when you
recover main board again.
D
I
S
A
S
S
E
M
B
L
Y
Main Board Review #Top side
P504 DMD Connector
P350 Keypad
P351 Axial FAN
Page 23
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
23
2011/07/05
Main Board Review
Main Board Review #Bottom side
D
I
S
A
SS
E
M
B
L
Y
Careful area of these connectors and
check these right positions connection
when you recover main board again.
Careful area of these connectors and
check these right positions connection
when you recover main board again.
P501 to HDMI+VGA board
P802 to power supply
J0402 to G LED
J0302 to R LED
J0202 to B LED
Page 24
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
24
2011/07/05
Removing the Fan & Battery Docking Board
Review the Qumi.
Take off the Axial fan like this.
Remove the three screws and careful the
aluminum foil when you assembly.
Review the BATTERY DOCKING BD and
the three screws (S04).
D
I
S
A
S
S
E
M
B
L
Y
Remove the two screws. Review the two screws (S04).
Page 25
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
25
2011/07/05
Removing the Fan & Speaker
Be careful these wires when you assembly
the Blower Fan.
Be careful this position when you take
off the Blower Fan.
Review the Blower Fan. Remove the speaker.
D
I
S
A
S
S
E
M
B
L
Y
Remove the four screws. Review the four screws (S04).
Page 26
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
26
2011/07/05
Removing the Optical Engine & Front Cover ASSY
Review the Optical Engine #1. Review the Optical Engine #2.
Remove the front cover like this.
Remove the front cover like this.
Review the front cover. Review the bottom Cover.
D
I
S
A
S
S
E
M
B
L
Y
Page 27
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
27
2011/07/05
Appendix. Screw torque
ITEM Screw Type P/N Screw Driver Torque (kg-cm)
S01 SCREW M M2*0.4*5 PAN C S18C NI 3105260800 1.1-1.6
S02
SCREW M M2.5*0.45*4 PAN C S18C
NI
3105145300 1.8-2.2
S03 SCREW T φ2*0.8*5 PAN C S20C NI 3105040600 2-3
S04 STAND OFF STEEL HEX 4.7*3.1 F 3461519701 3.3-3.7
Page 28
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
28
2011/07/05
5. Firmware Download
5-1. Projector USB Drivers Installation Guide
The document is to describe a Windows application software “DLP Composer Lite” for
projector firmware.
Its main purpose is to provide a detailed procedure of upgrading the application software of a
DLP projector.
The system requirement and the installation procedure of “DLP Composer Lite v10.0” are
also included in the document.
Note:
1.User must have administrative privileges on the target computer in order to
install the driver.
2.The installation target directory must not be write-protected.
User also required having the basic knowledge of Windows application installation.
Attention: This utility is for DLPTM DDP2000/2230/243x serial projectors.
System Requirement
1.IBM compatible PC (Desk Top).
2.Windows XP-SP2 operating system.
Page 29
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
29
2011/07/05
Install “DLP Composer Lite” to PC
Run the “DLP Composer Lite v10.0 Setup.exe”
.
The following pictures are illustrating the process of the Driver installation.
Start-up page:
Click on the “Next” button to continue.
or
Click on the “Cancel” button to cancel the installation.
Page 30
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
30
2011/07/05
Click on the “I accept agree to be bound by all the terms and conditions of this License
Agreement” point to continue.
Click on the “Next” button to continue.
Click on the “Next” button to continue.
The default installation direction is C:\Program Files\DLP Composer 10.0
Page 31
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
31
2011/07/05
Click on the “Browse” button to change the default directory for saving the drive file
somewhere else.
or
Click on the “Back” button to return to the previous page.
or
Click on the “Cancel” button to cancel the installation.
or
Click on the “Next” button to continue.
Click on the “Back” button to return to the previous page.
or
Click on the “Next” button to continue or
Click on the “Cancel” button to cancel the installation.
Page 32
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
32
2011/07/05
Please wait for the installation to complete.
Installation Completed:
Click on the “Finish” button with the Installation Completed.
Replicate the program file “FlashDeviceParameters.txt” to PC under path:
“C:\Program Files\DLP Composer Lite 10.0\”
Page 33
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
33
2011/07/05
5-2.
DLP Projector Composer (firmware) User Guide
The document is to describe a Window application software “DLP Composer Lite” for
projector firmware.
Its main purpose is to provide a detailed procedure of upgrading the application software of a
DLP projector.
The system requirement and the installation procedure of “DLP Composer Lite v10.0” are
also included in the document.
Note:
1.User must have administrative privileges on the target computer in order to
install the driver.
2.The installation target directory must not be write-protected.
User also required having the basic knowledge of Windows application installation.
Attention: This utility is for DLPTM DDP2000/2230/2430 serial series projectors.
System Requirement
1.IBM compatible PC (Desk Top).
2.Windows XP-SP2 operating system.
Note:
About Qumi enter the MFG Mode method, it's can't be entered by Qumi’s originally
attached remote control, but can enter by other kind of Vivitek’s remote control.
Please refer the corrective remote control graph shows as attached figures.
Page 34
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
34
2011/07/05
5-3. Started with Download
The section is to illustrate the procedure to upgrade the application software of a DLP
projector.
Step 1: Power on the projector, press the “power” button one time by remote control, then
press “UP” “RIGHT” “DOWN” “LEFT” button on the keypad or on the remote control, the
below OSD menu will display:
Step 2: Select the “USD Mode”, press “Right” key oh the keypad or remote control, select
the “DDP6401”.
Page 35
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
35
2011/07/05
Step 3: Launch the “DLP Composer Lite v10.0” from installed shortcut at
Program > DLP Composer(TM) Lite 10.0 > DLP Composer(TM) Lite 10.0.exe
Step 4: While executed, The window shall appear as the following picture.
Click on the “Edit” button to continue to the “DLP Composer Preferences” page.
Step 5: Make sure that the USB cable is firmly connected between projector and computer.
Page 36
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
36
2011/07/05
Step 6: Click on the “Communications” button to continue to the “Communications” page.
Note: Please make sure the setting in Communications as bellow picture
Page 37
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
37
2011/07/05
Step 7: At Flash Loader page, used the Brower button to select the correct file.
Then Pressed “Reset Bus” and next pressed “Start Download” to start upgrade flash.
Step 8:
A warning message box will appear for confirmation. Press <Y> to continue.
Page 38
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
38
2011/07/05
Step 9:
When the last warning message box appears, this is the last chance to cancel the update.
Press “Confirm” button to start the firmware update.
Complete the download, power off the projector, than press the “Right” key on the keypad all
along when power on the Qumi, until the “Left” key on the keypad blink three times, that
means the EPPORM is cleaned out.
Page 39
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
39
2011/07/05
5-4. Starting and shutting down the projector.
1.
Connect the AC power cord to the Qumi.
Connect the other end of the AC power
adapter to a wall outlet
Note: Adapter models mar vary
between regions.
2.
Then slide POWER switch to turn
on the Qumi.
3.
The Qumi splash screen displays and
connected devices are detected.
Page 40
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
40
2011/07/05
4.
If more than one input device is
connected, press the SOURCE button
on the remote control and use ▲▼ to
select the applicable devices or press ▲
and ▼ or
◄ and ► at the same time
on the keypad on the Qumi.
• VGA: Analog RGB
• Component: DVD input YCbCr / YPbPr, or
HDTV input YPbPr
• Composite Video: Traditional composite video
• HDMI: HDMI
•
USB: microSD card / USB disc
5.
Slide POWER switch to turn off the
Qumi.
Page 41
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
41
2011/07/05
5-5. Setting an Access Password (Security Lock)
To prevent unauthorized use of the Qumi, you can create a password. When the access
password function is enabled, the password must be entered after the Qumi has been turned
on.
Creating a password can be done by performing the following steps:
1
Press the MENU button on the remote
control or press MENU and
on
the keypad simultaneously to open the
On-Screen display OSD menu.
2
Move the cursor to move to the
Installation I menu down to select
Advanced.
3
Press the cursor ▲▼ button to select
Security Lock.
4
Press the cursor ◄► button to enable
or disable security lock function.
A password dialog box automatically
appears.
Page 42
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
42
2011/07/05
5
You can use the cursor buttons ▲▼◄►
either on keypad or IR remote control for
password entry. You can use any
combination including the same arrow five
times, but not less than five.
Press the cursor buttons in any order to set
the password. Push the MENU button to
exit the dialog box.
6.
The password confirm menu appears
when you power on the Qumi when the
Security Lock is enabled.
Enter the password in the order you set it
at step 5.
7.
Forget the password recovery (only used in the service center not to be in the end-user side)
Still pressed “MENU” key and plug the AC power cord when Power LED going to flashing=>
Phase a short time =>flash three times.
Page 43
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
43
2011/07/05
5-6. DLP Projector security unlock
When you forget the password,
Please input the wrong password five times by the remote control, then the projector will
display a “Hint code” on the screen.
Write down the recall code number.
Page 44
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
44
2011/07/05
Projector OSD for password check & reset
The document is to describe Windows application software “DLPunlock” for projector
password unlock. Its main purpose is to provide a way to reset the forgotten password; the
application will ship to the call-center and help the validated end-user to reset the password.
Page 45
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
45
2011/07/05
5-7. Factory Reset
Press the cursor ▲▼ button to move up and down in the Installation II menu. Select the
Factory Reset sub menu and press
(Enter) / ► to reset all the menu items to the factory
default values. (Expect Language and Security Lock).
5-8. Status
Press the cursor ▲▼ button to move up and down in the Installation II menu. Select the
Installation II sub menu and press
(Enter) / ► to enter the Status sub menu.
Page 46
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
46
2011/07/05
6. Calibration
Step of into Service Mode
Step 1 : Turn on the projector, press the” MENU “ button on the keypad or IR controller,
Then select “Installation II”, then press “ Down ” button and select “ Status ”
Step 2 ： Press “Enter” button on the keypad or on the remote controller, and will display below OSD
menu.
Page 47
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
47
2011/07/05
Step 3: Press “ Enter “ button twice by remote control, then press “ (UP) (DOWN)
(LEFT) (RIGHT)” by remote control, the service mode OSD as below shows:
Page 48
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
48
2011/07/05
6-1. ADC Adjust Procedure -- (Optional)
A. Function Description：
ADC Calibration – VGA ：Calibrating Analog RGB signal
Calibration Status ：Status of VGA calibrated value
B. Calibrate Analog RGB (1024x768@60Hz XGA):
Step 1 ： In Service Mode select ADC Calibration - VGA In this menu input pattern with
White(240,240,240) and Black(16,16,16) for calibrate VGA Source . After input ready
press “Enter” to calibration。
Input Pattern
Step 2 : After complete the OSD will show the picture as follow , if not complete, just close the OSD。
Note : Offset & Gain Value
Default After ADC
Offset 511
Gain 511
Step 3 : Compare internal white pattern and RGB source white pattern, if the brightness gap ratio of
these two source is bigger than 3.5%.
Page 49
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
49
2011/07/05
6-2. Calibrate Analog YUV
Equipment: VG828, must be take off H/V sync terminal from machine.
Step 1 ： In Service Mode select ADC Calibration - YUV. In this menu input pattern with 75﹪SMPTE
pattern for calibrate YUV Source and notice that the input source must be 480i format 。
After input ready press “Enter”key to proceed。
Input Pattern
Step 2 : After complete the OSD will show the picture as follow, if not complete, just close the OSD。
NOTE:
You can select Calibration Status – VGA or Calibration Status – YUV item to watch the
calibrated value at any time。
Page 50
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
50
2011/07/05
7. EDID
Analog
(08H-09H) ID Manufacturer Name _________________________ = DPC
(0AH-0BH) Product ID Code ______________________________ = 74A1(t)
(0CH-0FH) Last 5 Digits of Serial Number _______________ = UNUSE
(10H) Week of Manufacture __________________________ = 01
(11H) Year of Manufacture __________________________ = 2011
(12H) EDID Version Number __________________________ = 1
(13H) EDID Revision Number _________________________ = 3
(14H) VIDEO INPUT DEFINITION:
Analog Signal
0.700, 0.300 (1.000 Vp-p)
Error: (0-5) Incorrect Video Information Byte
(15H) Maximum Horizontal Image Size ________________ = mm
(16H) Maximum Vertical Image Size __________________ = mm
(17H) Display Gamma ________________________________ = 2.20
(18H) DPMS and Supported Feature(s):
Preferred Timing Mode
Display Type = R/G/B Color
(19H-22H) CHROMA INFO:
Red x - 0.698 Green x - 0.169 Blue x - 0.149 White x - 0.299
Red y - 0.300 Green y - 0.766 Blue y - 0.027 White y - 0.350
(23H) ESTABLISHED TIMING I:
720 x 400 @ 70Hz (IBM,VGA)
Page 51
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
51
2011/07/05
640 x 480 @ 60Hz (IBM,VGA)
640 x 480 @ 67Hz (Apple,Mac II)
640 x 480 @ 72Hz (VESA)
640 x 480 @ 75Hz (VESA)
800 x 600 @ 56Hz (VESA)
800 x 600 @ 60Hz (VESA)
(24H) ESTABLISHED TIMING II:
800 x 600 @ 72Hz (VESA)
800 x 600 @ 75Hz (VESA)
832 x 624 @ 75Hz (Apple,Mac II)
1024 x 768 @ 60Hz (VESA)
1024 x 768 @ 70Hz (VESA)
1024 x 768 @ 75Hz (VESA)
1280 x 1024 @ 75Hz (VESA)
(25H) Manufacturer's Reserved Timing:
1152 x 870 @ 75Hz (Apple,Mac II)
(38-53) Standard Timing Identification:
Standard Timing ID 1: 800 x 600 @120Hz
Standard Timing ID 2: 1024 x 768 @120Hz
Standard Timing ID 3: 1280 x 720 @120Hz
Standard Timing ID 4: 1280 x 800 @60Hz
Standard Timing ID 5: 1280 x 1024 @60Hz
Standard Timing ID 6: 1400 x 1050 @60Hz
Standard Timing ID 7: 1440 x 900 @60Hz
Standard Timing ID 8: 1600 x 1200 @60Hz
______________________________________________________________________
(36H-47H) Detailed Timing / Descriptor Block 1:
1280x800 Pixel Clock: 83.50 MHz
______________________________________________________________________
Horizontal Image Size: 0 mm Vertical Image Size: 0 mm
Refreshed Mode: Non-Interlaced Normal Display - No Stereo
Horizontal:
Active Count: 1280 pixels Blanking Count: 400 pixels
Sync Offset: 72 pixels Sync Pulse Width: 128 pixels
Border: 0 pixels Frequency: 49.70 kHz
Page 52
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
52
2011/07/05
Vertical:
Active Count: 800 lines Blanking Count: 31 lines
Sync Offset: 3 lines Sync Pulse Width: 6 lines
Border: 0 lines Frequency: 59.81 Hz
Digital Separate, Horizontal Polarity (-) Vertical Polarity (-)
______________________________________________________________________
(48H-59H) Detailed Timing / Descriptor Block 2:
1280x720 Pixel Clock: 74.25 MHz
______________________________________________________________________
Horizontal Image Size: 0 mm Vertical Image Size: 0 mm
Refreshed Mode: Non-Interlaced Normal Display - No Stereo
Horizontal:
Active Count: 1280 pixels Blanking Count: 370 pixels
Sync Offset: 110 pixels Sync Pulse Width: 40 pixels
Border: 0 pixels Frequency: 45.00 kHz
Vertical:
Active Count: 720 lines Blanking Count: 30 lines
Sync Offset: 5 lines Sync Pulse Width: 5 lines
Border: 0 lines Frequency: 60.00 Hz
Digital Separate, Horizontal Polarity (-) Vertical Polarity (-)
______________________________________________________________________
(5AH-6BH) Detailed Timing / Descriptor Block 3:
Monitor Range Limits:
Min Vertical Freq - 43 Hz
Max Vertical Freq - 120 Hz
Min Horiz. Freq - 30 kHz
Max Horiz. Freq - 100 kHz
Pixel Clock - 170 MHz
GTF - Not Used
______________________________________________________________________
(6CH-7DH) Detailed Timing / Descriptor Block 4:
Monitor Name:
PROJECTOR
(7EH) Block No: (01) Extension EDID Block(s)
(7FH) CheckSum OK
Page 53
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
53
2011/07/05
HDMI
(08H-09H) ID Manufacturer Name _________________________ = DPC
(0AH-0BH) Product ID Code ______________________________ = 74A1(t)
(0CH-0FH) Last 5 Digits of Serial Number _______________ = UNUSE
(10H) Week of Manufacture __________________________ = 01
(11H) Year of Manufacture __________________________ = 2011
(12H) EDID Version Number __________________________ = 1
(13H) EDID Revision Number _________________________ = 3
(14H) VIDEO INPUT DEFINITION:
Digital Signal
(15H) Maximum Horizontal Image Size ________________ = mm
(16H) Maximum Vertical Image Size __________________ = mm
(17H) Display Gamma ________________________________ = 2.20
(18H) DPMS and Supported Feature(s):
Preferred Timing Mode
Display Type = R/G/B Color
(19H-22H) CHROMA INFO:
Red x - 0.695 Green x - 0.168 Blue x - 0.148 White x - 0.289
Red y - 0.300 Green y - 0.766 Blue y - 0.027 White y - 0.351
(23H) ESTABLISHED TIMING I:
720 x 400 @ 70Hz (IBM,VGA)
640 x 480 @ 60Hz (IBM,VGA)
640 x 480 @ 67Hz (Apple,Mac II)
640 x 480 @ 72Hz (VESA)
640 x 480 @ 75Hz (VESA)
800 x 600 @ 56Hz (VESA)
Page 54
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
54
2011/07/05
800 x 600 @ 60Hz (VESA)
(24H) ESTABLISHED TIMING II:
800 x 600 @ 72Hz (VESA)
800 x 600 @ 75Hz (VESA)
832 x 624 @ 75Hz (Apple,Mac II)
1024 x 768 @ 60Hz (VESA)
1024 x 768 @ 70Hz (VESA)
1024 x 768 @ 75Hz (VESA)
1280 x 1024 @ 75Hz (VESA)
(25H) Manufacturer's Reserved Timing:
1152 x 870 @ 75Hz (Apple,Mac II)
(38-53) Standard Timing Identification:
Standard Timing ID 1: 800 x 600 @120Hz
Standard Timing ID 2: 1024 x 768 @120Hz
Standard Timing ID 3: 1280 x 720 @120Hz
Standard Timing ID 4: 1280 x 800 @60Hz
Standard Timing ID 5: 1280 x 1024 @60Hz
Standard Timing ID 6: 1400 x 1050 @60Hz
Standard Timing ID 7: 1440 x 900 @60Hz
Standard Timing ID 8: 1600 x 1200 @60Hz
______________________________________________________________________
(36H-47H) Detailed Timing / Descriptor Block 1:
1280x800 Pixel Clock: 83.50 MHz
______________________________________________________________________
Horizontal Image Size: 0 mm Vertical Image Size: 0 mm
Refreshed Mode: Non-Interlaced Normal Display - No Stereo
Horizontal:
Active Count: 1280 pixels Blanking Count: 400 pixels
Sync Offset: 72 pixels Sync Pulse Width: 128 pixels
Border: 0 pixels Frequency: 49.70 kHz
Vertical:
Active Count: 800 lines Blanking Count: 31 lines
Sync Offset: 3 lines Sync Pulse Width: 6 lines
Border: 0 lines Frequency: 59.81 Hz
Digital Separate, Horizontal Polarity (-) Vertical Polarity (-)
Page 55
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
55
2011/07/05
______________________________________________________________________
(48H-59H) Detailed Timing / Descriptor Block 2:
1280x720 Pixel Clock: 74.25 MHz
______________________________________________________________________
Horizontal Image Size: 0 mm Vertical Image Size: 0 mm
Refreshed Mode: Non-Interlaced Normal Display - No Stereo
Horizontal:
Active Count: 1280 pixels Blanking Count: 370 pixels
Sync Offset: 110 pixels Sync Pulse Width: 40 pixels
Border: 0 pixels Frequency: 45.00 kHz
Vertical:
Active Count: 720 lines Blanking Count: 30 lines
Sync Offset: 5 lines Sync Pulse Width: 5 lines
Border: 0 lines Frequency: 60.00 Hz
Digital Separate, Horizontal Polarity (-) Vertical Polarity (-)
______________________________________________________________________
(5AH-6BH) Detailed Timing / Descriptor Block 3:
Monitor Range Limits:
Min Vertical Freq - 43 Hz
Max Vertical Freq - 120 Hz
Min Horiz. Freq - 30 kHz
Max Horiz. Freq - 100 kHz
Pixel Clock - 170 MHz
GTF - Not Used
______________________________________________________________________
(6CH-7DH) Detailed Timing / Descriptor Block 4:
Monitor Name:
PROJECTOR
(7EH) Block No: (01) Extension EDID Block(s)
(7FH) CheckSum OK
Page 56
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
56
2011/07/05
Extended Block Type: CEA 861B
Detailed Timing Blocks start at Byte:(25H)
Native Format: (0x1)
(03H) DTV (Basic Audio)
(03H) YCbCr (4:4:4)
(03H) YCbCr (4:2:2)
Video Short Block Description:
(05H) 640 x 480 P 59.94/60Hz 4:3
(06H) 720 x 480 P 59.94/60Hz 4:3
(07H) 720(1440) x 576 I 50Hz 4:3
(08H) 720(1440) x 480 I 59.94/60Hz 4:3
(09H) 720(1440) x 480 I 59.94/60Hz 16:9
(0AH) 720(1440) x 576 I 50Hz 16:9
(0BH) 720 x 480 P 59.94/60Hz 16:9
(0CH) 720 x 576 P 50Hz 4:3
(0DH) 720 x 576 P 50Hz 16:9
(0EH) 1280 x 720 P 59.94/60Hz 16:9 Native Mode
(0FH) 1920 x 1080 I 59.94/60Hz 16:9
(10H) 1280 x 720 P 50Hz 16:9
(11H) 1920 x 1080 I 50Hz 16:9
(12H) 1920 x 1080 P 59.94/60Hz 16:9
(13H) 1920 x 1080 P 23.97/24Hz 16.9
(14H) 1920 x 1080 P 25Hz 16.9
(15H) 1920 x 1080 P 29.97/30Hz 16.9
(16H) 1920 x 1080 P 50Hz 16.9
Audio Short Block Description:
Page 57
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
57
2011/07/05
Numbers of Audio Channels (2)
(18H) Linear PCM(IEC60958)
Audio Supported: 32kHz, 44.1kHz, 48kHz
Audio Bit Rate: 24Bit
Speaker Short Block Description:
Playload(3 bytes 1CH-1EH)
Speakers (1CH): FL/FR
1DH: Reserved
1EH: Reserved
Vendor Specific Short Block Description:
Bytes: 03H, 0CH, 00H, 10H, 00H
(25H - 37H) Detailed Timing Descriptions:
1920x1080 Pixel Clock: 148.50 MHz
______________________________________________________________________
Horizontal Image Size: 0 mm Vertical Image Size: 0 mm
Refreshed Mode: Non-Interlaced Normal Display - No Stereo
Horizontal:
Active Count: 1920 pixels Blanking Count: 280 pixels
Sync Offset: 88 pixels Sync Pulse Width: 44 pixels
Border: 0 pixels Frequency: 67.50 kHz
Vertical:
Active Count: 1080 lines Blanking Count: 45 lines
Sync Offset: 4 lines Sync Pulse Width: 5 lines
Border: 0 lines Frequency: 60.00 Hz
Digital Separate, Horizontal Polarity (-) Vertical Polarity (-)
(37H - 49H) Detailed Timing Descriptions:
1920x1080 Pixel Clock: 148.50 MHz
______________________________________________________________________
Horizontal Image Size: 0 mm Vertical Image Size: 0 mm
Refreshed Mode: Interlaced Stereo
Horizontal:
Active Count: 1920 pixels Blanking Count: 280 pixels
Sync Offset: 88 pixels Sync Pulse Width: 44 pixels
Border: 0 pixels Frequency: 67.50 kHz
Vertical:
Active Count: 1080 lines Blanking Count: 45 lines
Page 58
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
58
2011/07/05
Sync Offset: 2 lines Sync Pulse Width: 5 lines
Border: 0 lines Frequency: 60.00 Hz
Digital Separate, Horizontal Polarity (-) Vertical Polarity (-)
(49H - 5BH) Detailed Timing Descriptions:
1920x1080 Pixel Clock: 148.50 MHz
______________________________________________________________________
Horizontal Image Size: 0 mm Vertical Image Size: 0 mm
Refreshed Mode: Interlaced Stereo
Horizontal:
Active Count: 1920 pixels Blanking Count: 720 pixels
Sync Offset: 528 pixels Sync Pulse Width: 44 pixels
Border: 0 pixels Frequency: 56.25 kHz
Vertical:
Active Count: 1080 lines Blanking Count: 45 lines
Sync Offset: 2 lines Sync Pulse Width: 5 lines
Border: 0 lines Frequency: 50.00 Hz
Digital Separate, Horizontal Polarity (-) Vertical Polarity (-)
(5BH - 6DH) Detailed Timing Descriptions:
720x480 Pixel Clock: 27.03 MHz
______________________________________________________________________
Horizontal Image Size: 0 mm Vertical Image Size: 0 mm
Refreshed Mode: Non-Interlaced Normal Display - No Stereo
Horizontal:
Active Count: 720 pixels Blanking Count: 138 pixels
Sync Offset: 16 pixels Sync Pulse Width: 62 pixels
Border: 0 pixels Frequency: 31.50 kHz
Vertical:
Active Count: 480 lines Blanking Count: 45 lines
Sync Offset: 9 lines Sync Pulse Width: 6 lines
Border: 0 lines Frequency: 60.01 Hz
Digital Separate, Horizontal Polarity (-) Vertical Polarity (-)
(7FH) CheckSum Valid
Page 59
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
59
2011/07/05
8. SERVICE NOTE
Cleaning the Qumi
Cleaning the Qumi to remove dust and grime will help ensure trouble-free operation.
1. The Qumi should be turned off and unplugged before cleaning. Failure to do so may result
in injury or damage to the system.
2. Use only a dampened cloth when cleaning. Do not allow water to enter the ventilation
openings on the projector.
3. If a little water gets into the projector interior while cleaning, leave unplugged in a
well-ventilated room for several hours before using.
4. If a lot of water gets into the projector interior when cleaning, have the projector serviced.
Cleaning the Lens
Optical lens cleaning solutions can be purchased from most camera and other retail stores. To
clean the Qumi lens, perform the following steps:
1. Apply a small amount of the optic lens cleaning solution to a clean soft cloth.
(Do not apply the cleaner directly to the lens.
)
2. Gently wipe the lens in a circular motion.
Caution:
1. Do not use abrasive cleaners or solvents.
2. To prevent discoloration or fading, avoid getting cleaner on the projector case
Page 60
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
60
2011/07/05
9. Power & READY LED Blink Code Message
Name Usage
Menu Open & exits the OSD
Up Cursor Navigates or changes setting in the OSD
Left Cursor Navigates or changes setting in the OSD
Down Cursor Navigates or changes setting in the OSD
Right Cursor Navigates or changes setting in the OSD
Enter Cursor Enter selection when OSD on
LED Error Messages
ERROR CODE MESSAGES
LEFT LED BLINK
(BLUE)
RIGHT LED
(BLUE)
T1 error, Inlet air(LED) 3 blinks OFF
T2 error, Red LED 3 blinks 1 blinks
T3 error, Green LED 3 blinks 2 blinks
T4 error, Blue LED 3 blinks 3 blinks
Fan 1 (Blower) error 6 blinks 1 blinks
Fan 2 (System)error 6 blinks 2 blinks
Red LED Thermistor error 8 blinks 1 blinks
Green LED Thermistor error 8 blinks 2 blinks
Blue LED Thermistor error 8 blinks 3 blinks
Page 61
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
61
2011/07/05
10. Factory Preset Display Modes
Table of Supported Frequency For 2D Standby mode
The projector can display several resolutions. The following table outlines the resolutions that
can be displayed by the projector.
S
IGNAL
R
ESOLUTION
H-S
YNC
(KHZ)
V-S
YNC
(HZ)
C
OMPOSITE
/ S-V
IDEO
C
OMPONEN
T
RGB DVI/HDMI
NTSC
—
15.734 60.0 O — — —
PAL/SECAM
— 15.625 50.0 O — — —
720 x 400 37.9 85.0 — — O O
640 x 480 31.5 60.0 — — O O
640 x 480 37.9 72.0 — — O O
640 x 480 37.5 75.0 — — O O
640 x 480 43.3 85.0 — — O O
800 x 600 35.2 56.0 — — O O
800 x 600 37.9 60.0 — — O O
800 x 600 48.1 72.0 — — O O
800 x 600 46.9 75.0 — — O O
800 x 600 53.7 85.0 — — O O
1024 x 768 48.4 60.0 — — O O
1024 x 768 56.5 70.0 — — O O
1024 x 768 60.0 75.0 — — O O
1024 x 768 68.7 85.0 — — O O
1280 x 800 49.7 60.0 — — O O
1280 x 800 62.8 74.9 — — O O
1280 x 800 71.6 84.8 — — O O
1280 x 1024 63.98 60 — — O O
1280 x 1024 79.98 75 — — O O
1280 x 1024 91.10 85 — — O O
1280 x 960 60.0 60 — — O O
1280 x 960 85.9 85 — — O O
1400 x 1050 65.3 60.0 — — O O
1440 x 900 70.6 75.0 — — O O
1440 x 900 55.6 60.0 — — O O
VESA
1600 x 1200 75 60 — — O O
Page 62
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
62
2011/07/05
640 x 480 35.0 66.68 — — O O
832 x 624 49.725 74.55 — — O O
1024 x 768 60.24 75.0 — — O O
Apple
Mac
1152 x 870 68.68 75.06 — — O O
480i 15.734 60 — O — O
SDTV
576i 15.625 50 — O — O
480p 31.469 60 — O — O
EDTV
576p 31.25 50 — O — O
720p 37.5 50 — O — O
720p 45.0 60 — O — O
1080i 33.8 60.0 — O — O
1080i 28.1 50.0 — O — O
1080p 67.5 60.0 — O — O
HDTV
1080p 56.3 50.0 — O — O
O: Frequency supported
—: Frequency not supported
* : Displayable level
The resolution of the panel is listed below:
Qumi - 1280 x 800 (WXGA)
Resolution other than native resolution may display uneven size of text or lines.
Page 63
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
63
2011/07/05
11. Projector Installation Notice
Allow at least a 50cm clearance around the exhaust vent
Make sure that the intake vents do not recycle hot air from the exhaust vent.
When operating the Qumi in an enclosed space, make sure that the surrouding air
temperature within the enclosure does not exceed operating temperature while the Qumi is
running, and the air intake and exhaust vents are unobstructed.
All enclosures should pass a certified thermal evaluation to make sure that the Qumi does not
recycle exhaust air, as this may cause the device shutdown even if the enclosure temperature
is with the acceptable operating temperature range.
Caution: Avoid using the Qumi in dusty environments.
Page 64
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
64
2011/07/05
12. Projector Dimensions
Page 65
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
65
2011/07/05
13. Fan Control Checking Table
Fan 1 Blower Fan
Fan 2 Axial Fan
Page 66
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
66
2011/07/05
14. Spare part list (Qumi_DP274-A13VVxx)
Item Type P/N Description Q’ty White Black
1 3392166105 TOP CASE PC V-0 WHITE
１
V
2 3392174705 TOP COVER PC V-0 BLACK
１
V
3 3398053404 CASE BOTTOM ASSY DP274-A13VVxA
１
V
4
Cover
3398053704 CASE BOTTOM ASSY DP274-A13VVxB
１
V
5 3245122202 FOOT SIRUB V-0 8.5*5.6*9 WHT
１
V
6
Rubber
3245120002 FOOT SIRUB V-0 8.5*5.6*9 BLK
１
V
7 3398053502 FRONT COVER ASSY
１
V V
8
Cover
3398053601 BACK COVER ASSY DP274
１
V V
9
IO
LABEL
3205225200 NAME PLATE ACRYLIC 116.5*22.6 T0.3 DP274
１
V V
10 Cover 3398055800 FRAME IO PC V-0 BLACK
1
V V
11 3622200211
DC FAN ASSY ASB02505HHA-SM02 L45 28.5 S
AXIAL FAN
１
V V
12
FAN
3622610411
DC FAN ASSY BUB0605HC-SM00 L35 60 S
BLOWER FAN
１
V V
13 5600601842 PWB ASSY MAIN BD QUMI M01
１
V V
14 5600601841 PWB ASSY BATTERY DOCKING BD QUMI V01
１
V V
15 5600601845 PWB ASSY TOUCH KEYPAD BD QUMI V01
１
V V
16 5600601946 PWB ASSY HDMI+VGA BD QUMI M02
１
V V
17 5600601843 PWB ASSY MULTI-MEDIA BD QUMI M01
１
V V
18
Board
5600601846 PWB ASSY S310 DMD BD QUMI V01
１
V V
19 0993101380
ADAPTER 100~240VAC 19VDC 3.42A 2.5
(White)
１
V
20
Adapter
0993101280
ADAPTER 100~240VAC 19VDC 3.42A 2.5
(Black)
１
V
21 E ngi n e 5 811117 177-S OPTICAL MODULE QUMI WXGA ASSY
１
V V
22
23 3517329701 GIFT BOX CRGD PAPER 264*197.5*62
１
V
24
Carton
3517329801 GIFT BOX CRGD PAPER 264*197.5*62
１
V
25 Bag POF 3502079300 BAG POF 380*275 CL
1
V V
26
Cord
3090290400
AC POWER CORD 2P 2* 0.75mm^2 L800 WHT
(For China)
１
V
Page 67
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
67
2011/07/05
27 3090290300
AC POWER CORD 2P 2* 0.75mm^2 L800 WHT
(For EU)
１
V
28 3090289900
AC POWER CORD 2P 2* 0.824mm^2 L800 WHT
(For USA and ROW)
１
V
29 3090290000
AC POWER CORD 2P 2* 0.75mm^2 L800 BLK
(For China)
１
V
30 3090290200
AC POWER CORD 2P 2* 0.75mm^2 L800 BLK
(For EU)
１
V
31
Cord
3090290100
AC POWER CORD 2P 2* 0.824mm^2 L800 BLK
(For USA and ROW)
１
V
32 3081333400 CABLE SIGNAL IO 24PIN VGA 30C L500 BLK
１
V V
33 3081333500
CABLE SIGNAL MINI HDMI HDMI 32C L500
WHT
１
V
34 3081333700 CABLE SIGNAL MINI HDMI HDMI 32C L500 BLK
１
V
35 3081335500 CABLE SIGNAL MINI HDMI MINI HDMI 32C
１
V
36 3081335300 CABLE SIGNAL MINI HDMI MINI HDMI 32C
１
V
37 3081335600 CABLE USB MINI 4P 2C L1000 WHT
１
V V
38 3081335400 CABLE AUDIO 3.5 AUDIO 3.5 AUDIO 30C L500
１
V V
39
Cable
3072443000
CONN ADP AV PHONE JACK/USB/APPLE
DOCK
１
V V
40 CD 3534174200 CD S/W PKG ASSY DP274 SERIES
１
V V
41 Case 3523502701 CARRYING CASE PA 170*110*35
１
V V
42 Remote 5041822200 REMOTE CONTROLLER 9KEYS QUMI VIVITEK
１
V V
43 3261386100
LABEL BARCODE PET 73*25
(for inside carton label)
１
V V
44 3262559100
LABEL LOGO PLE 45*25
(for inside carton of tear open label)
１
V V
45 3200793300
LABEL BARCODE PAPER 100*100
(foroutside carton label)
１
V V
46 3221106200 TAPE OPP 72mm CLEAR
１
V V
47 5012079400
CARD WARRANTY DP274 SERIES ZH
(for china)
１
V V
48 5012079200
CARD WARRANTY DP274 SERIES EN
(for USA)
１
V V
Page 68
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
68
2011/07/05
49 5012079800
CARD WARRANTY DP274 ASIA
(for USA & ROW)
１
V V
50 5012079300
CARD WARRANTY DP274 SERIES DE
(for EU & ROW)
1
V V
51 5012079100 CARD QUICK START DP274 SERIES
1
V V
Page 69
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
69
2011/07/05
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
17 18 19 20
Page 70
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
70
2011/07/05
21 22 23 24
25 26 27 28
TBD
29 30 31 32
TBD
33 34 35 36
37 38 39 40
41 42 43 44
Page 71
Delta Elec. Inc. Qumi Ver.02
Company Confidential Vivitek ______________________ Delta____________
71
2011/07/05
45 46 47 48
49 50 51
Loading...
