MICROWAVE OVEN
Instruction Manual
After Sales Support
Now you have purchased a Delta product you can rest
assured in the knowledge that as well as your 3 year parts
and labour warranty you have the added peace of mind of
dedicated helplines and web support:
calls are charged at 7p/min from a standard
landlinecalls from mobiles could be higher
Contents
Helpline No. UK/ North Ireland 0871 31 61 020 Rep. Ireland 1-800-992 508
1 Introduction 3
2 Package contents 4
3 Proper use 4
4 Symbols and key words used in these instructions 5
5 Safety instructions 6
6 About microwaves 11
7 Cooking and heating up in the microwave 12
8 Before the rst use of the microwave 15
9 An overview of the device 17
8 Operation 19
9 Cleaning and care 26
10 End of operation 27
11 Troubleshooting 28
12 Disposal 28
13 Technical specications 29
14029 EN Aldi UK RC4 Cover.ai 2 25.10.2012 11:06:04
1 Introduction
You have made an excellent choice with the purchase of this quality Delta® brand
product.
By doing so you now have the assurance and peace of mind which comes from
purchasing a product that has been manufactured to the highest standards of
performance and safety, supported by the high quality standards of Aldi.
We want you to be completely satisfied with your purchase, so this Delta®
product is backed by a comprehensive manufacturer’s 3 year warranty and an
outstanding after sales service through our dedicated Helpline.
We hope you will enjoy using your purchase for many years to come.
If you require technical support or in the unlikely event that your purchase is
faulty, please telephone our Helpline for immediate assistance. Faulty product
claims made within the 3 year warranty period will be repaired or replaced free
of charge provided that you have a satisfactory proof of purchase (keep your till
receipt safe!). However, be aware that the warranty will become null and void if
the product is found to have been deliberately damaged, misused or disassembled.
This does not affect your statutory rights.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
3
2 Package contents
WARNING!
Keep plastic packaging out of the reach of children. There is a
risk of suffocation!
After unpacking, ensure that the following parts have been supplied:
− Microwave oven
− Rotary plate
− Roller ring
− Operating instructions and warranty documents
3 Proper use
This device may only be used for warming up appropriate foodstuffs in
microwave-suitable containers and dishes.
This device is designed to be used in the household and for similar applications. It
is not intended, however, for use
− in commercial kitchens, for employees in shops, offices and other
commercial areas;
− on agricultural estates;
− by customers in hotels, motels and other residential facilities;
− in bed & breakfast accommodation.
Please note that we shall not be liable in cases of improper use:
• Do not modify the device without our consent and do not use any auxiliary
equipment which we have not approved or supplied.
• Use only spare parts and accessories which we have supplied or approved.
• Follow all the instructions in these operating instructions, especially the safety
information. Any other use is deemed improper and can cause personal injury
or damage to the product.
• Do not use the device in extreme environmental conditions.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
4
4 Symbols and key words used in these
instructions
DANGER!
Warning: immediate mortal danger!
WARNING!
Warning: possible mortal danger and/or serious irreversible
injuries!
CAUTION!
Please follow the guidelines to avoid injuries and/or property
damage!
CAUTION!
Please follow the guidelines to avoid property damage!
PLEASE NOTE!
Additional information on using the device.
•
PLEASE NOTE!
Please follow the guidelines in the operating instructions!
WARNING!
Warning: danger of electric shock!
WARNING!
Warning: danger of hot surfaces!
Bullet point/information on operating steps and results
Tasks to be performed
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
5
5 Safety instructions
CAREFULLY READ THE IMPORTANT SAFETY INSTRUCTIONS
AND KEEP THEM IN A SAFE PLACE FOR FURTHER USE!
People not permitted to use this device
• Keep the device and its accessories out of reach of children.
• This device may be used by children over the age of 8 and by
persons with reduced physical, sensory or mental abilities or
by those without experience and/or knowledge, if they are
supervised or have been instructed in the safe use of the device
and have understood the dangers that result from it. Children
must not play with the device. Cleaning and user maintenance
must not be carried out by children, unless they are aged 8 or
over and are supervised;
• Children younger than 8 should be kept away from the device
and the mains cable.
WARNING!
Keep plastic packaging and protective film out of the reach of
children. There is a risk of suffocation!
Setting up and electrical connection
• The microwave oven is designed as a free-standing device and
may not be integrated into kitchen units.
• Only connect the microwave to a properly installed and earthed
power socket with a voltage of 230V~50Hz using a safety plug
which has a 13 Amp fuse. Do not use an extension cable.
• Ensure that the power cable is undamaged and does not run
underneath the device or over any hot surfaces or sharp edges.
• The microwave must be set up on a level, stable surface, which is
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
6
able to carry the weight of the device as well as the food which is
to be prepared within it. Only set up the microwave in a safe, dry
environment.
• Do not place any objects on the microwave as these may become
hot during use.
clearance distance of 30cm to the top, 20cm at the rear and 20 cm
on both sides must be observed. The openings in the device must
To ensure adequate ventilation, a minimum safe
not be covered or blocked.
• Protect the device from water droplets or spray. If the device
does become wet then pull out the mains plug immediately.
• Ensure that the microwave is not placed near any heat source or
in an area where it could come into contact with water.
• The device is not designed to be operated with an external timer
or a separate remote control system.
Initial operation and use
WARNING
Improper use can lead to injuries and damage to the device.
Therefore, please observe the following safety advice:
• WARNING! The touchable surfaces may become very hot during
use. There is a risk of burning.
• WARNING! Liquids or other foods may not be heated in closed
containers as these could easily explode. Therefore, always
remove the seal on bottles and closable containers such as baby
bottles before heating.
• This device may only be used for warming up appropriate
foodstuffs in microwave-suitable containers and dishes.
• When warming up or cooking meals in flammable plastic or paper
containers it is necessary to monitor the microwave constantly
due to the risk of fire.
• The microwave is not intended for the preparation of foods
which require frying. The device is also not intended for drying
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
7
out objects. Caution! This could cause a fire!
• Never use the device when empty, i.e. without items to be
cooked inside.
• Only use the accessories that are enclosed or described as
suitable in these instructions.
• Never use dishes with metal trimmings, metal utensils or the grill
stand in microwave operation as this could damage the device
and/or the dishes.
• Use only microwave-suitable dishes. Look for markings such as
"Microwave-suitable" or "For the microwave" when purchasing.
• Do not remove any of the microwave's internal panels or
the inner coating of the viewing window as this could lead to
microwave radiation leakage.
• Never leave the device unattended during operation.
• WARNING! Delayed boiling! When heating liquids in the
microwave so-called "delayed boiling" can occur, i.e. the liquid
has reached boiling temperature without beginning to bubble as
boiling liquids normally do.
Agitation, for instance when removing the liquid from the device,
can lead to a sudden boiling up of the liquid. Therefore, take care
when moving the liquid container.
There is a risk of scalding!
Always place a glass or ceramic rod in liquids that are to be
heated up. This will hinder sudden, belated boiling of the liquid.
• With foods that have a firm skin, e.g. sausages or tomatoes, make
small slits in the skin so that they do not burst during cooking.
• Do not try to heat up eggs in their shells or pre-boiled eggs
unless in specially designed microwave-suitable containers.
• CAUTION! Eggs which are already boiled can explode, even after
being removed from the oven.
• Check the temperature before eating food cooked in the
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
8
microwave. Special care must be taken with baby food and
bottles. Always stir or shake the baby food before checking the
temperature to avoid burns.
• The device should be cleaned regularly and food residues should
be removed.
• Poor device hygiene can lead to damage to the surfaces, which
in turn can reduce the lifespan of the device and even lead to
dangerous situations.
• Observe the instructions for cleaning the device when cleaning
the door seals, the interior cooking area and the neighbouring
parts, see page 26.
Faults
WARNING!
Live components. There is a risk of electric shock.
Therefore, please observe the following safety advice:
• Avoid damaging the device or the power cable.
• Always check the power cable and the device before each use.
• If you detect any damage do not use the device under any
circumstances. Immediately remove the mains plug from the
socket.
• Ensure that a defective device is immediately repaired by a
specialist workshop. In order to reduce risks: if the mains cable
for this device is damaged then it must be replaced by the
Medion Service Centre or a similarly qualified person.
• WARNING! It is dangerous for untrained persons to carry out
repair or maintenance work that requires the removal of the
panels which are in place to prevent the escape of microwave
radiation.
• If you see smoke, keep the door closed to prevent fire from
breaking out, or to smother flames which have already broken
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
9
out, and immediately turn off the device by pressing the
button.
Then pull the mains plug out of the socket straight away.
• WARNING! If the housing, panels, door, door seals or the
door catch are damaged then do not use the device under any
circumstances. In order to reduce risks: have the device repaired
immediately by a specialist workshop or contact your Medion
Service Centre.
• WARNING! Never try to open and/or repair a device
component yourself. There is a risk of electric shock.
• In the event of a fault, contact our Service Centre or another
suitable specialist workshop.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
10
6 About microwaves
Microwaves are high-frequency electromagnetic waves which have a warming
effect on the food within the oven. Microwaves heat all non-metallic objects.
Therefore, do not place any metallic objects in the microwave. This heating effect
works better the higher the water content of the foodstuff.
To ensure optimal distribution of heat, let food stand for a minute or two in the
microwave after cooking.
The effect of microwaves on foodstuffs
• Microwaves penetrate foodstuffs to a depth of up to 3cm.
• They heat up water, fat and sugar molecules (foodstuffs with a higher water
content are heated more intensively).
• This heat then works its way – slowly – throughout the food and has a
defrosting, heating and cooking effect on the food.
• The cooking area and the air within are not heated (the food container is
heated mainly by the hot food).
• Each foodstuff requires a certain amount of energy to cook or defrost. As a
rule of thumb we can say: high output – short time or low output – long time.
The microwave oven
• A microwave generator, the so-called magnetron, generates the microwaves
and directs them into the cooking area.
• The inner walls and the viewing window reflect the microwaves inwards so
that they cannot escape from the interior.
• The microwave output and the cooking time can be set in several steps.
• After the cooking time has elapsed, or when the door is opened, the
magnetron turns off immediately.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
11
7 Cooking and heating up in the microwave
General notes
• To arrange food so that it cooks properly place the food with the largest
pieces towards the outer edge.
• Note the exact cooking or heating times.
• Choose the shortest available cooking or heating time and extend it if
necessary.
WARNING!
Overcooked food can start to smoke or even catch fire.
• Cover food during cooking or heating with a cover that is suitable for the
microwave. Covering the food helps avoid splashes; furthermore the food is
more evenly cooked.
• Foods such as chicken pieces or hamburgers should be turned once during
cooking to speed up cooking. Larger pieces such as joints or roasting chickens
must be turned at least once.
• It is also important to reposition food, e.g. with meatballs: After half of the
cooking time has expired, the food should be repositioned from top to
bottom and from the middle to the outside.
• After heating, stir the food if possible to ensure even temperatures, otherwise
let the food stand for a short time.
Microwave-suitable materials
You can buy special dishes and accessories for your microwave. Look for
markings such as "Microwave-suitable" or "For the microwave". You can also use
your existing dishes – if the material is suitable.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
12
Suitable materials
• Porcelain, glass ceramic and heatproof glass.
• Plastics which are heatproof and microwave-suitable (caution: plastics may
become discoloured by foods or become warped by the heat).
• Baking paper.
Materials that are partially suitable
• Stoneware and ceramics. Use clay containers only for defrosting and for short
cooking times because the air and water content of the material could cause
the clay to crack or break.
• Dishes with gold or silver décor should only be used when the manufacturer
has labelled it "microwave-suitable".
• Never use aluminium foil in large quantities. It can however be used e.g.
in small pieces to cover sensitive parts. You can also cover the corners of
containers to prevent overcooking as the microwave energy is primarily
concentrated on the corners. Maintain a distance of 2.5 cm between the foil
and the internal wall.
• Aluminium containers (e.g. those for ready-to-serve meals) are suitable, but
they must be at least 3cm high to be used in the microwave.
Unsuitable materials
• Metal, i.e. metal pots, pans and lids.
CAUTION!
Metal in the cooking area can lead to sparks! These can
damage the device or the viewing window!
Dishes with metal parts (handles, decoration or bottoms) or with gold or
•
silver décor can also lead to sparks during microwave operation.
• Crystal or lead crystal can shatter, coloured glass may become discoloured.
• Any materials which are not heatproof can lose shape or even burn.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
13
Please note!
To test whether a dish is suitable for use in the microwave, put
some water in the container and place it in the microwave.
Turn the time control knob to position 1. The device will now
operate in microwave operation for 1 minute. If you ascertain
that the container is hotter than the food, then it is not
suitable for the microwave. Microwave-suitable dishes are only
warmed by the heat of the food
Warning!
As soon as you notice sparks, flashes or even fire, then turn off
the microwave immediately using the button.
Overview of suitable materials
The following list is a general guide to help you choose the correct cooking
dishes:
Cooking dishes Microwave
Heatproof glass Yes
Non-heatproof glass No
Heatproof ceramic Yes
Microwave-suitable plastic dishes Yes
Kitchen paper Yes
Metal No
Aluminium foil/containers Suitable in some circumstances
Size and shape of microwave-suitable containers
Flat, broad containers are better than narrow, tall ones. "Flat" foods can be
cooked more evenly.
Round or oval containers are better than angular ones. There is a danger of local
overheating in the corners.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
14
8 Before the first use of the microwave
Setting up the device
Ensure that all packaging materials have been removed from inside the device and
the interior of the door.
Warning!
The panel in front of the magnetron on the right
side of the interior cooking area is not part of the packaging
and must not be removed!
Check the microwave for any damage – e.g. if the door is
crooked or bent, door seals and other seals are damaged,
hinges and the closing mechanism are defective or loose, or if
the interior of the device or the door are dented or damaged.
If you discover any damage, do not use the microwave. In this
case please contact our Medion Service Centre.
•
Do not place the microwave near to any heat sources, in a location prone
to wetness or high humidity, or in the immediate vicinity of inflammable
materials.
• The feet must not be removed.
Caution!
The microwave has been designed for household use and may
not be used outside!
Connect the microwave using the mains plug to a convenient and easily
•
accessible 230 V~50 Hz safety socket.
Cleaning the device for the first time
In order to remove the dust residue from the packaging and any other
possible residues from the manufacturing process, wipe out the interior and
the inner side of the viewing window with a slightly moist, soft cloth before
using the device for the first time. Ensure that no liquids penetrate into the
device and dry the surfaces completely afterwards.
Clean the glass rotary plate and the roller ring in warm water with a little
washing up liquid and then dry off these parts completely.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
15
Insert accessories
Do not use the microwave without properly installing the rotary plate.
Place the roller ring into the recess in the cooking area and then place the
rotary plate in the centre of the cooking area over the drive hub so that it
clicks into place on the three slots for the drive hub.
Please note!
During this initial heating period you may notice faint odours.
These smells are not dangerous and will disappear after a
short time. Ensure adequate ventilation e.g. by opening a
window.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
16
9 An overview of the device
Description of the parts
3
1
2
7
8
4 5
6
9
1) Door handle
2) Viewing window
3) Magnetron panel - DO NOT REMOVE!
4) Lighting
5) Mains cable
6) Operating field
7) Rotary hub
8) Door lock
9) Roller ring
10) Rotary plate
10
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
17
Operating field
1) Display field
Shows cooking time, output, operating status
and time
2) Output: Select the microwave output
3) Defrost: Select the defrost programme
according to time and weight
1
2
4) Clock: Set the time
5) Stop/Pause
Delete the entry or reset the settings.
Press once during cooking: Pauses the cooking
process. Press twice during cooking: Ends the
cooking process.
Hold down the button (approx. 3 seconds):
Activate/deactivate the child lock
6) Start/Quick start: Press once: Initiates a
selected cooking process
Press multiple times: Initiates the quick start
programme
7) Menu/Time: Control knob to enter the time,
weight and cooking time, as well as to set the automatic programmes
3
4
5
6
7
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
18
8 Operation
Each time a button is pressed, an acoustic signal (beep) sounds as confirmation.
Setting the time
If the microwave is being used for the first time or the power supply is broken,
the screen shows “0:00”. The time can now be set.
Press the button.
Turn the control knob until the correct hour setting appears on the display.
Press the button.
Turn the control knob until the correct minute setting appears on the display.
Press the button to confirm the settings.
Child lock
Press the button and hold it down for 3 seconds. You will hear an acoustic
signal (beep) and the display will show the symbol . The microwave´s
buttons and control knob will now have no function.
In order to deactivate the child lock, press the button and hold it down for
3 seconds until you hear a beep and the symbol for the child lock disappears
from the display field.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
19
Cooking with microwave energy
Follow these steps to cook using microwave energy alone:
Press the button once or multiple times to select the desired output. The
following applies:
Press the
button
Text on display field Output (in
watts)
1x P100 700 W
2x P80 560 W
3x P50 350 W
4x P30 210 W
5x P10 70 W
Turn the control knob until the correct cooking time is displayed. The
following time intervals are available:
0 to 1 minute in 5 second steps
1 minute to 5 minutes in 10 second steps
5 to 10 minutes in 30 second steps
10 to 30 minutes in 1 minute steps
More than 30 minutes in 5 minute steps
Press the button. The cooking process begins.
End of the cooking process
An acoustic signal (beep) will sound at the end of the cooking process. The
cooking process is now finished. Press the button or open the door. This will
reset the display once again.
CAUTION!
The food or the container can be extremely hot.
Therefore, always use oven gloves or a tea towel when
removing the food from the cooking area.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
20
Pausing the programme
If you want to e.g. turn or stir the food after half of the cooking process then you
need to pause the programme.
This is achieved by opening the door or pressing the button. The remaining
cooking time will continue to be shown on the display field.
In order to continue the cooking process, close the door again and press the
button.
Press the button twice to cancel the programme.
Quick start
If you press the button before setting the output of the device then the
cooking programme will begin in microwave operation with the highest output.
Quickly press the button a number of times in quick succession to extend
the cooking time. The longest cooking time is 95 minutes.
The cooking programme begins automatically after the butt on is pressed for the
last time.
Defrosting by time
Press the button twice.
dEF2 appears on the display.
Turn the control knob to set the defrosting time.
Press the button to start the defrosting process.
Defrosting by weight
The defrosting time and the output are automatically calculated as soon as the
weight of the food to be defrosted has been entered. A weight of between 100 g
and 2,000 g can be entered for the food to be defrosted.
Press the button once.
dEF1 appears on the display.
Turn the control knob to set the desired weight.
Press the button to start the defrosting process.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
21
Using several programmes
The device can carry out several programmes in succession. Up to 2 sequences
can be programmed to run automatically. For example, you can firstly defrost the
food and then cook it directly afterwards.
Press the button. Select defrosting by weight or time (see page 21).
The display will show dEF1 or dEF2 depending on the selection.
Turn the control knob to set the defrosting time or the weight.
Press the button and select the desired output using the control knob.
Press the button to confirm the selection.
Turn the control knob to set the cooking time.
Press the button to start both programmes.
Please note!
The automatic programmes can not be selected when using
this function.
Timer function
You can programme the microwave so that the cooking process starts at a
predetermined time.
Please note!
The timer function can only be used when the time has been
set (see page 19).
Up to two cooking programmes can be set using the timer function.
Firstly select the desired programme.
Then press the button.
The digits indicating the hours will flash.
Turn the control knob to set the hours.
Press the button.
The digits indicating the minutes will flash.
Turn the control knob to set the minutes.
Confirm your selection by pressing the button.
The activated timer function will be indicated by ":" being lit up on the display.
Once the entered starting time has been reached, the microwave will emit two
acoustic signals (beeps) and start the cooking process.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
22
Automatic cooking
It is not necessary to enter the cooking time or the output for automatic cooking.
The microwave oven calculates these values automatically depending on the food
to be cooked and its weight.
Turn the control knob step by step in a clockwise direction. The programme
number appears in the display field (e.g. “A-1” for automatic programme 1).
Select an automatic programme between 1 and 8 in this way. Confirm the
selected programme by pressing the button.
Turn the control knob step by step in a clockwise direction to set the desired
cooking weight. The values can be set according to the following tables:
Programme Weight Display Output in
watts
A-1
Heating
A-2
Vegetables
A-3
Fish
A-4
Meat
A-5
Pasta
A-6
Potatoes
A-7
Pizza
A-8
Soup
(with 450 ml water)
(with 800 ml water)
200 200 700
400 400
600 600
200 200 700
300 300
400 400
250 250 560
350 350
450 450
250 250 700
350 350
450 450
50
100
50 560
100
200 200 700
400 400
600 600
200 200 700
400 400
600 600
200 200 560
400 400
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
23
Press the button to start the cooking process.
If the food is not completely cooked, continue the cooking process in the
microwave oven for a further few minutes.
Note: Please note that the form, size and type of food can influence the cooking
process.
ProgrammeA-1: Automatic heating
The programme lasts between 2.5 and 7.5 minutes depending on the weight
setting.
Place the plate with the food that you want to heat up on the rotating plate
and start the programme by pressing the button.
ProgrammeA-2: Vegetables
The programme lasts between 4.5 and 8.5 minutes depending on the weight
setting. When cooking vegetables that have a high water content like tomatoes
or courgettes it is not necessary to add liquid. We recommend that you add a
little liquid to support the cooking process for other vegetables such as carrots or
broccoli. Ensure that the vegetable pieces have the same size as far as possible so
that the vegetables can cook evenly.
Place the vegetables in a dish/container suitable for microwave cooking.
If necessary, add a little liquid to the vegetables.
Cover the vegetables with a lid suitable for microwave cooking.
Start the cooking programme for vegetables by pressing the button.
Let the vegetables stand for about 3 minutes.
If the vegetables are not cooked after the programme has been completed then
continue the cooking process in the microwave oven.
ProgrammeA-3: Fish
The programme lasts between 4 and 7.5 minutes depending on the weight setting.
Place the fish on a plate suitable for microwave cooking and add a little fat or
butter. Season the fish according to the recipe or to your own tastes and start
the fish programme.
If the fish is not hot enough after the programme has been completed then
continue the cooking process in the microwave oven.
ProgrammeA-4: Meat
The programme lasts between 4 and 6.5 minutes depending on the weight setting.
Cook the meat without adding water or fat. It is possible to cook the meat in
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
24
sauce. Avoid prior salting because the salt will extract water from the meat during
cooking and it can become dry.
Place the meat onto a plate that is suitable for microwave use.
Start the cooking programme for meat by pressing the button.
If the meat is not hot enough after the programme has been completed then
continue the cooking process in the microwave oven.
ProgrammeA-5: Pasta
Set a value of between 20 and 23 minutes for the programme time based on the
weight.
Use a high container for cooking pasta. This will avoid problems with over
boiling. Use the same amount of water as you would for normal cooking.
Add the pasta and start the cooking programme for pasta.
Let the pasta stand for about 3 minutes.
If the pasta is still too hard after the programme has been completed then
continue the cooking process in the microwave oven.
ProgrammeA-6: Pota toes
We recommend using unpeeled potatoes for cooking. Pierce the potatoes in a
few places. Set a value of between 6.5 and 15 minutes for the programme time
based on the weight.
Place the unpeeled potatoes in a dish/container suitable for microwave
cooking. Use potatoes of the same size as far as possible. The potatoes should
not be touching each other where possible.
Start the cooking programme for potatoes by pressing the button.
If the potatoes are not cooked after the programme has been completed then
continue the cooking process in the microwave oven.
ProgrammeA-7: Pizza
We recommend that you use fresh pizza for baking in the microwave oven. Set a
value of between 1.5 and 3 minutes for the programme time based on the weight.
Place the pizza onto a plate that is suitable for microwave cooking.
Start the cooking programme for pizza by pressing the button.
If the pizza is not hot enough after the programme has been completed then
continue the cooking process in the microwave oven.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
25
ProgrammeA-8: Soup
The programme lasts between 2.5 and 4.5 minutes depending on the weight
setting.
Place the soup that you want to heat up on the rotary plate in the cooking
area. If you place multiple containers in the microwave oven then please
ensure that they are not touching each other.
Start the cooking programme for soups by pressing the button.
If the soup is not hot enough after the programme has been completed then
continue the cooking process in the microwave oven.
9 Cleaning and care
Damage can be caused to the device surfaces due to a lack of care. This can lead
to the lifespan of the device being reduced or to dangerous situations. Therefore,
clean the microwave oven regularly and remove all food residues.
• Before starting the cleaning process, switch off the microwave and remove the
mains plug.
• Keep the interior of the device clean. Wipe away splashes or spilled liquids
that come into contact with the interior walls with a damp cloth. A mild
cleaning solution can be used for stubborn dirt. Do not use sprays or other
corrosive cleaning products. These products can attack, scratch or dull the
door surface.
• The external surfaces should be cleaned with a damp cloth. In order to avoid
functional parts inside the microwave being damaged, ensure that no water
penetrates into the device through the ventilation openings.
• A mild cleaning solution should be used for cleaning the door parts, the
viewing window and, particularly, the closing mechanism including the seals.
Proceed here with extreme caution so that the parts do not become damaged.
• The operating field may not become wet. Clean it using a soft, damp cloth.
Leave the door open when cleaning the operating field to avoid accidentally
switching on the device.
• If mist should form on the interior or exterior surfaces of the device then
wipe it away with a soft cloth.
• Mist can form if the microwave is operated during periods of high humidity.
This is completely normal.
• Sometimes the rotary plate needs to be removed from the device to clean it.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
26
Rinse the plate in warm soapy water or in a dishwasher.
• Then dry the rotary plate thoroughly with a soft cloth. If you remove the
rotary plate from the rotary hub then ensure that it has been replaced
correctly after cleaning.
• The rotary hub and the base of the microwave should be cleaned regularly to
prevent loud noises from occurring.
• Simply wipe the base of the device with a mild cleaning solution. The rotary
hub can be cleaned in mild soapy water or in a dishwasher. Any remaining
aromas in the microwave oven can be removed by placing a glass of water
together with the juice and rind of a lemon in a deep container suitable for
microwave cooking and then heating it in the microwave for 5 minutes. Finally,
wipe the microwave thoroughly and dry it with a soft cloth.
• If you have to replace the light in the microwave oven, please contact a
qualified specialist workshop or the Medion Service Centre.
10 End of operation
After the end of the cooking process, the time will be displayed in the display
field. You can then open the door and remove the food. The device switches itself
off automatically when the cooking process is finished. Check that the interior
lighting for the microwave oven is switched on when the door is opened and then
automatically goes out after a while.
If you do not use the device for a long period of time, pull out the mains plug and
store the device in a dry location.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
27
11 Troubleshooting
Problem Possible cause Solution
The device does
not start the
cooking process.
The device does
not warm up.
Loud noises occur
when the rotary
plate turns.
The mains plug is not
properly inserted.
The fuse is blown or the
power interrupter has
tripped.
The socket is defective. Check the socket by plugging
The door is not closed. Close the door.
The rotary hub or the
base of the microwave
oven is dirty.
Pull out the mains plug, wait
10 seconds and then plug it
in again.
Exchange the fuse or reset
the power interrupter
(contact our service centre
for assistance here).
in another device.
Clean the device.
12 Disposal
Device
The device may not be disposed of with the normal household
rubbish.
Ensure that the device is disposed of in an environmentally
appropriate manner at the end of its product life. Locate for this
purpose e.g. the local collection point for old devices. Contact the
responsible local authorities to find out more about the disposal
options available.
Before disposal cut off the cable.
Packaging
Your microwave is wrapped in packaging to protect it against
transportation damage. Packaging materials are raw materials and can
therefore be reused or recycled.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
28
13 Technical specifications
Nominal voltage 230 V~ 50 Hz
Power output
Microwave: 1,050 W
Nominal
power (microwave): 700 W
Dimensions (W x H x D) in cm
Exterior dimensions: 43.9 x 25.8 x 35.5
Cooking area volume: 20 litres
Net weight: approx. 10.7 kg
Subject to technical changes.
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
29
Helpline No. UK/ Northern Ireland 0871 37 61 020 (calls are charged at 7p/min from
a standard landline; calls from mobiles could be higher) Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
30
02/09
3 YEAR WARRANTY CARD
MICROWAVE OVEN
Medion Electronics Ltd.
120 Faraday Park
Faraday Road
Dorcan
Swindon SN3 5JF
Wiltshire, UK
Name
Address
Email
Tel No
Product No. MD 14029 Black/MSN 5004 3194
Silver/MSN 5004 3195
White/MSN 5004 3196
Location of purchase
In order to deal with your enquiry as quickly and eciently as possible, we ask you to
contact our service hotline on the number detailed below.
UK / N. IRELAND HELPLINE NO
0871 37 61 020 REP. IRELAND HELPLINE NO 1-800-992 508
(calls are charges at 7p per min from a standard landline, calls from mobiles could be
higher)
Alternatively you can contact us via email by completing the Email product support form
which can be found on www.medion.co.uk
14029 EN Aldi UK RC4 Cover.ai 1 25.10.2012 11:05:5714029 EN Aldi UK RC4 Cover.ai 1 25.10.2012 11:05:57
Congratulations! You have made an excellent choice with the purchase of this quality
product. Our commitment to quality also includes our service. Should you, contrary to
expectations, experience defects due to manufacturing faults during private use
within 36 months of the date of purchase we shall be liable for warranty in accordance
with statutory warranty regulations provided that:
- The device was not put to use other than the intended
- was not overloaded
- was not used with the wrong accessories
- repairs were not carried out by any other than the intended workshop
The warranty certicate is only valid in connection with an acceptable proof of
purchase.
Please keep both in a safe place. This warranty does not aect your statutory rights.
This purchase is guaranteed for a period of three years beginning on the day of
purchase. Keep your purchase receipt safe as proof of date of purchase. The
guarantee can only be extended for the duration of any repair required.
During the warranty period defective devices can be returned to the service address
stated on the back cover of this document by rst calling the service hotline number
provided to arrange collection by an approved freight agent at no cost to you. We will
at our discretion, either repair or exchange the device in accordance with warranty
legislation.
Please enclose the following when sending your product in for repair:
1. Proof of purchase (receipt).
2. This warranty certicate with the fault report from overleaf complete with your
name, contact details and fault descrition.
If an acceptable proof of purchase is not enclosed the
repair will be charged in all cases. After the warranty has
expired defective devices can still be sent to the address
stated below. Any repairs outside of the warranty period
will be charged and can only be undertaken once
payment has been received.
Ensure that the product is sent well packed as no
responsability can be accepted for items lost or damaged
in transit.
This warranty does not aect your statutory right.
MICROWAVE OVEN
Loading...
