Delta DLT8144 Specifictions

SHOWERHEAD

= Adjustable H2Okinetic™ Spray (AH2O)

= Soft Full Spray (SF)

= Shampoo Rinsing Spray (SR)

= Shampoo Rinsing

Spray

w/Massage (SRM)

=

Full Spray w/Massage (FSM)

= High-Efficiency Spray (HE)

= Crossing Full Spray (CF)

= Crossing Full Spray w/Massage (CFM)

= Fast Massage (FM)

= Soft Drench w/Full Spray (SDF)

= Soft Drench Spray (SD)

= Pause (P)

= Full Body Spray (FB)

= Adjustable Full Spray (AF)

SR

CF

CFM

HE

SDF

AF

SRM

SF

FB

SD

P

FSM

FM

= Massage Spray (M)

M

= Slow Massage (SM)

SM

= H

2

Okinetic™ Spray (H2O)

H

2

O

= Soft Drench Spray w/Massage (SDM)

SDM

AH

2

O

H2Okinetic Technology® Showerhead
5-Spray Setting Showerhead

Touch-Clean® Nozzles

▲

52669

Submitted Model No.:

Specic Features:

4"

(102 mm)

Ø 6"

(152 mm)

Push Button Diverter

STANDARD SPECIFICATIONS:

• Maximum 1.75 gpm @ 80 psi, 6.6 L/min @ 550 kPa.

• Change spray modes with push button.

• ABS showerhead with f ive spray settings -- not a
positive shut-off.

• Metal ball connector for durability, easy installation.

• Ball connector swivel angle is 44° (22° per side).

• Standard 1/2"-14 NPT pipe f itting.

WARRANTY

•

Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.

•

5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.

COMPLIES WITH

• ASME A112.18.1 / CSA B125.1

• EPA WaterSense®

▲

Designate proper nish sufx

Spray Pattern

H2Okinetic

Spray

Full Body
Spray

Delta reserves the right (1) to make changes in specications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for nish options and product availability.

DSP-B-52669 Rev. A

Massage

Spray

Full Spray
w/ Massage

Pause

55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, Ontario Canada N5P 4L1
© 2016 Masco Corporation of Indiana
