Page 1

SHOWERHEAD

= Adjustable H2Okinetic™ Spray (AH2O)

= Soft Full Spray (SF)

= Shampoo Rinsing Spray (SR)

= Shampoo Rinsing

Spray

w/Massage (SRM)

Full Spray w/Massage (FSM)

= High-Efficiency Spray (HE)

= Crossing Full Spray (CF)

= Crossing Full Spray w/Massage (CFM)

= Fast Massage (FM)

= Soft Drench w/Full Spray (SDF)

= Soft Drench Spray (SD)

= Pause (P)

= Full Body Spray (FB)

= Adjustable Full Spray (AF)

CFM

SDF

SRM

FSM

= Massage Spray (M)

= Slow Massage (SM)

= H

Okinetic™ Spray (H2O)

= Soft Drench Spray w/Massage (SDM)

SDM

H2Okinetic Technology® Showerhead 5-Spray Setting Showerhead

Touch-Clean® Nozzles

▲

52666

Submitted Model No.:

Specic Features:

Push Button Diverter

STANDARD SPECIFICATIONS:

• Maximum 1.75 gpm @ 80 psi, 6.6 L/min @ 550 kPa.

• Change spray modes with push button.

• ABS showerhead with f ive spray settings -- not a positive shut-off.

• Metal ball connector for durability, easy installation.

• Ball connector swivel angle is 44° (22° per side).

• Standard 1/2"-14 NPT pipe f itting.

WARRANTY

•

(101 mm)

Lifetime limited warranty on parts (other than electronic parts and batteries) and finishes: or, for commercial users, for 5 years from date of purchase.

•

5 year limited warranty on electronic parts (other than batteries); or, for commercial users, for 1 year from the date of purchase. No warranty is provided on batteries.

COMPLIES WITH

• ASME A112.18.1 / CSA B125.1

• EPA WaterSense®

▲

Designate proper nish sufx

Spray Pattern

H2Okinetic

Spray

Full Body Spray

Delta reserves the right (1) to make changes in specications and materials, and (2) to change or discontinue models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or www.deltafaucet.com for nish options and product availability.

DSP-B-52666 Rev. A

Massage

Spray

Full Spray w/ Massage

Ø 6"

(152 mm)

Pause
