T17T097
T17T297
Submitted Model No.:
Specific Features:
7"
(178 mm)
Dia.
Designate Proper Finish Suffix
8" (203 mm)
min.
18" (457 mm)
max.
T17T497
(406 mm)
Face of plasterguard
should be flush with
finish wall line
2 3/4" (70mm)
16"
Supply
TUB AND SHOWER
FAUCET TRIM
Cassidy™ Series
TempAssure® Thermostatic
Valve Only (T17T097)
Shower Only (T17T297)
Tub/Shower (T17T497)
FEATURES:
TempAssure® 17T thermostatic valve cartridge
•
STANDARD SPECIFICATIONS:
•
Thermostatic wax element maintains the outlet
temperature to +3.6 F
•
Must also order Multi-Choice® Universal rough
0
separately (R10000)
•
Back-to-back installation capability
•
Solid brass forged body
•
Lever volume control handle; temperature
adjustment dial
•
Graphics indicate hot/cold temperature adjustment
•
Field adjustable to limit rotation into hot water zone
•
All parts are replaceable from the front of the valve
•
Adjusts for up to 1" wall thickness
•
Raincan showerhead
•
Available extension kit (RP75136 adds up to 1 3/8”
2.50 gpm max @ 80 psi.
installation depth
WARRANTY
• Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes; or
for commercial users, for 5 years from the date
of purchase.
• 5 year limited warranty on electronic parts (other
than batteries); or for commercial users, for 1 year
from the date of purchase. No warranty is provided
on batteries.
RP72565
RP75136 Available Extension Kit
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-B-T17T097 Rev. F
(Pull-Up Diverter)
6 1/2"
(165 mm)
3 "
(76 mm)
RP72568
Full Spray
Raincan Showerhead
4 1/4"
(108 mm)
9 3/8"
(239 mm)
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
•
ASSE 1016
Indicates compliance to
ICC/ANSI A117.1 - Valve control only
0 69 138 207 276 345 414 483 552 621
9
8
7
6
5
4
3
2
1
Flow (U.S. Gallons Per Minute)
0
0 10 20 30 40 50 60 70 80 90
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, Ontario
© 2016 Masco Corporation of Indiana
Pressure (kPa)
Tub Filler
Showerhead
Pressure (PSI)
34.1
30.3
Flow (Liters Per Minute)
26.5
22.7
18.9
15.1
11.4
7.6
3.8
0
Canada N5P 4L1
