Delta DLT7878 Specifications Sheet

59140▲

= Adjustable H2Okinetic™ Spray (AH2O)

= Soft Full Spray (SF)

= Shampoo Rinsing Spray (SR)

= Shampoo Rinsing

Spray

w/Massage (SRM)

=

Full Spray w/Massage (FSM)

= High-Efficiency Spray (HE)

= Crossing Full Spray (CF)

= Crossing Full Spray w/Massage (CFM)

= Fast Massage (FM)

= Soft Drench w/Full Spray (SDF)

= Soft Drench Spray (SD)

= Pause (P)

= Full Body Spray (FB)

= Adjustable Full Spray (AF)

SR

CF

CFM

HE

SDF

AF

SRM

SF

FB

SD

P

FSM

FM

= Massage Spray (M)

M

= Slow Massage (SM)

SM

= H

2

Okinetic™ Spray (H2O)

H

2

O

= Soft Drench Spray w/Massage (SDM)

SDM

AH

2

O

Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________

HANDSHOWER

H2Okinetic Technology® Handshower
5-Spray Setting Handshower

Touch-Clean® Nozzles

STANDARD SPECIFICATIONS:

• Maximum low rate 2.0 gpm (7.6 L/min) @ 80 PSI.

• Certified dual check valves for backflow protection.

• Change spray modes with pushbutton.

• Hand held shower with f ive spray settings - not a
positive shut-off.

1 5/16”

(33 mm)

10 1/16”

(256 mm)

1 7/16”

(36 mm)

10 1/2”

(266 mm)

H2Okinetic

Spray

Full Spray

Massage

Spray

Full Spray
w/ Massage

Pause

WARRANTY

• Lifetime limited warranty on parts (other than
electronic parts and batteries) and inishes; or,
for commercial users, for 5 years from the date
of purchase.

• 5 year limited warranty on electronic parts (other
than batteries); or for commercial users, for 1 year
from the date of purchase. No warranty is provided
on batteries.

COMPLIES WITH:

• ASME A112.18.1 / CSA B125.1

• EPA WaterSense®

▲ Designate proper finish suffix

Delta reserves the right (1) to make changes in specications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for nish options and product availability.

DSP-B-59140 Rev. A

55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, Ontario Canada N5P 4L1
© 2016 Masco Corporation of Indiana
