Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
52001-DS
2”
(51 mm)
8”
(203 mm)
52003-DS
24”
(610 mm)
Wall bar
52001-UF
52003-UF
24”
(610 mm)
Wall bar
52002-DS 52002-UF
24”
(610 mm)
Wall bar
24”
(610 mm)
Wall bar
ADA GRAB BAR
HAND HELD
SHOWERS
n ADA Certified Grab Bar
n ADA Slide Mechanism
n White Pushbutton Handshower
STANDARD SPECIFICATIONS:
•
ADA slide mechanism.
•
White pushbutton handshower.
•
24" 1 1/2" grab bar: 52001, 52002.
•
36" 1 1/2" grab bar: 52003.
•
60-82" stretchable hose: DS models.
•
70" ultraflex hose: UF models.
•
ADA certified grab bar.
• Maximum
2.50 gpm @ 80 psi, 9.5 L/min @ 550 kPa
36”
(914 mm)
Wall bar
36”
(914 mm)
Wall bar
WARRANTY
•
Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.
•
5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
Spray Patterns
Full Body
Spray
Pause
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-B-52001-DS Rev. B
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2015 Masco Corporation of Indiana
