75305
Submitted Model No.:
Specic Features:
HANDSHOWER
4-Spray settings handshower
Palm® shower
Touch-Clean® nozzles
Push button selection
75305
2.5 GPM
6 9/16"
( 167 mm )
4 1/8"
( 105 mm )
3 1/4"
( 83 mm )
3 13/16"
( 97 mm )
Full Spray
Fast Spray
Full Spray
w/ Massage
Pause
STANDARD SPECIFICATIONS:
• Maximum flow rate 2.5 gpm @ 80 PSI, 9.5L/min @ 552kPa.
• Fixed showerhead and palm shower all in one.
• Change spray modes with push button.
• Soft touch handle.
• Adjustable shower arm mount allows for hands-free
showering.
• 72"(1829mm) stainless steel hose.
WARRANTY
•
Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes; or
for commercial users, for 5 years from the date
of purchase.
•
5 year limited warranty on electronic parts (other
than batteries); or for commercial users, for 1 year
from the date of purchase. No warranty is provided
on batteries.
COMPLIES WITH
• ASME A112.18.1/CSA B125.1
72"
( 1829 mm )
Delta reserves the right (1) to make changes in specications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for nish options and product availability.
DSP-B-75305 Rev. C
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, Ontario Canada N5P 4L1
© 2015 Masco Corporation of Indiana
