Delta DLT7650 Specifications

BODY JET

= Adjustable H2Okinetic™ Spray (AH2O)

= Soft Full Spray (SF)

= Shampoo Rinsing Spray (SR)

= Shampoo Rinsing

Spray

w/Massage (SRM)

=

Full Spray w/Massage (FSM)

= High-Eciency Spray (HE)

= Crossing Full Spray (CF)

= Crossing Full Spray w/Massage (CFM)

= Fast Massage (FM)

= Soft Drench w/Full Spray (SDF)

= Soft Drench Spray (SD)

= Pause (P)

= Full Body Spray (FB)

= Adjustable Full Spray (AF)

SR

CF

CFM

HE

SDF

AF

SRM

SF

FB

SD

P

FSM

FM

= Massage Spray (M)

M

= Slow Massage (SM)

SM

= H2Okinetic™ Spray (H2O)

H

2

O

= Soft Drench Spray w/Massage (SDM)

SDM

2

O

50100▲

Submitted Model No.: _____________________________________________

Specific Features: ________________________________________________

2 1/2"

(64 mm)

Dia.

End of

1/2" Pipe

1 3/4" ± 1/8"

(44 mm ± 3 mm)

®

H2Okinetic
Spray (H2O)

1 3/4"

(45 mm)

Finished Wall

2 1/8" ± 1/8"

(54 mm ± 3 mm)

End of Pipe

Adapter

FEATURES:

• H2Okinetic® Body Jet

STANDARD SPECIFICATIONS

• 1.8 GPM, experience of 2.5 GPM

• Standard 1/2” rough-in

• 15˚ all around adjustment

WARRANTY

•

Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.

•

5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.

COMPLIES WITH:

• ANSI/

ASME A112.18.1 / CSA B125.1

▲ Designate proper finish suffix

Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.

DSP-B-50100 Rev. D

069 138 207 276 345 414 483 552 621

6

5

4

3

2

1

0

Flow (U.S. Gallons Per Minute)

0102030405060708090

Pressure (kPa)

Pressure (PSI)

22.7
Flow (Liters Per Minute)

18.9

15.1

11.4

7.6

3.8

0

55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2015 Masco Corporation of Indiana
