41550▲
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
*Load Bearing
Surface
7/8"
(22 mm)
Round Bar
?"
(? mm)
2"
(51 mm)
ACCESSORIES
■ Décor Assist™
■ Contemporary Toilet Paper Holder with
Assist Bar
STANDARD SPECIFICATIONS:
•
Wood blocking is preferable behind all wall
surfaces. If wood blocking is not available, the
supplied fasteners are recommended.
•
Mounting hardware and mounting template
included with product.
•
7/8" diameter assist bar.
•
Meets ADA load requirement when
properly installed.
• *
Maximum 300 lbs. as an assist bar on
indicated surface.
•
Pivoting tissue holder for easy loading.
6"
(152 mm)
8"
(203 mm)
Mounting Specifications
6"
(152 mm)
▲ Designate Proper Finish Suffix
4 3/4"
(121 mm)
From wall
WARRANTY
•
Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from defects
in material and workmanship.
•
5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-A-41550 Rev. A
Liberty Hardware Manufacturing Corporation
140 Business Park Drive
Winston-Salem, NC 27107
800.542.3789
www.libertyhardware.com
© 2013 LHMC, A Masco Company
