ROMAN
TUB/WHIRLPOOL
FAUCET TRIM
Cassidy™ Series
Three Hole Installation (T2797 Series)
Four Hole Installation (T4797 Series)
Rough-In Kit Must Also be Ordered to
Complete Installation (R4707 for four
hole and R2707 for three hole)
STANDARD SPECIFICATIONS:
•
Trim Only for two handle Roman Tub faucet for
concealed mounting.
•
10 3/32" (256 mm) long, 9 11/32" (237 mm) high
slip-on rigid spout.
•
Temperature and volume controlled with handles.
•
Rough-In kit must also be ordered to complete
installation (R4707 for four hole and R2707 for three
hole). There are separate specification sheets on
each rough-in kit if more details are required.
•
Three-setting H OkineticTM handshower - H OkineticTM
2
spray, massage spray and pause.
•
Handshower includes double check valves for
backflow prevention (T4797 Series).
• LHP - Less Handle Program. See handle options below.
•
Handshower flow rate 2.0 gpm @ 60 PSI.
WARRANTY
• Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes; or
for commercial users, for 5 years from the date
of purchase.
• 5 year limited warranty on electronic parts (other
than batteries); or for commercial users, for 1 year
from the date of purchase. No warranty is provided
on batteries.
2
T2797 Series & T4797 Series
Available LHP Handle Options
H695▲
1 5/16"
(33 mm)
H697▲
▲ Designate proper finish suffix
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-B-T2797-LHP Rev. D
3 13/16"
(97 mm)
59" HS Hose
H698▲
3 1/2"
(89 mm)
COMPLETE VALVE COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
