1159LF▲
Submitted Model No.:_______________________________________
Specific Features: __________________________________________
KITCHEN
FAUCETS
®
Trinsic
Single Handle Deck Mount
1 Hole Sink Applications
Series
Min. 2 1/2" (64 mm)
Clearance to Back Splash
Recommended
12 5/8"
(321 mm)
1 7/8"
(48mm)
Max. Desk
Thickness
1 31/32"
(50 mm)
7"
(178 mm)
11 5/16"
(287 mm)
18 3/16"
(462 mm)
1 5/16"~1 1/2"
(33~38 mm)
Hole Size
STANDARD SPECIFICATIONS:
Ceramic cartridge.
•
• 1 hole installation.
• 8 1/4" (210 mm) long, 7" (178 mm) high reach on
spout, swings 360°.
• Maximum 1 7/8" (48 mm) deck thickness.
• Color coded plug button on handle for
hot/cold identification.
•
Maximum flow rate 1.8 gpm @ 60 PSI.
WARRANTY
•
Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.
•
5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.
8 1/4"
(210 mm)
▲ Designate proper finish suffix
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-K-1159LF Rev. D
COMPLIES WITH
• ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC / ANSI A117.1
Verified compliant with 0.25% weighted
average Pb content regulations.
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, Ontario
© 2014 Masco Corporation of Indiana
Canada N5P 4L1
