SPECIALTY
Pressure (PSI)
Flow (Liters Per Minute)
®
FAUCETS
2121LF 2123LF
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
5 1/8"
(130 mm)
2 7/8"
(73 mm)
2 7/8"
(73 mm)
1 1/8"
(29 mm)
Max. Deck
Thickness
2121LF
2"
(51 mm)
6 1/4"
(159 mm)
360˚ Swing Spout
3 5/8"
(46 mm)
2 5/8"
(67 mm)
5 1/8"
(130 mm)
1/2"-14 NPSM
4" Centers
(102 mm)
6"
(152 mm)
■ Two Handle Laundry Faucet
■ Deck Mount
■ 2 or 3 Hole Sink Applications
■ 4" (102 mm) Centerset
STANDARD SPECIFICATIONS:
• Two handle deck faucets for exposed mounting on two
or three hole sinks.
• Spout swivels 360˚.
• 2121LF spout has hose thread.
• 2123LF spout has stream straightener.
• 4" (102 mm) centerset.
• Solid brass cast body.
• 6 1/4 (159 mm) long, 5 1/8" (130 mm) high spout
swings 360˚.
• Hot and cold stems are interchangeable.
• Control mechanism shall be of the rotating cylinder type
with stainless steel plate and 90˚ rotation, with replaceable
non-metallic seats operating in stainless steel lined sockets.
• 1/2"-14 NPSM threaded male shanks.
WARRANTY
•
Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.
•
5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.
2"
1 1/8"
(29 mm)
Max. Deck
Thickness
(51 mm)
6 1/4"
(159 mm)
360˚ Swing Spout
1/2"-14 NPSM
4" Centers
(102 mm)
6"
(152 mm)
2123LF
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-S-2121LF Rev. B
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
•
Verified compliant with .25% weighted
average Pb content regulations.
0 69 138 207 276 345 414 483 552 621
30
25
20
15
10
5
0
Flow (U.S. Gallons Per Minute)
0 10 20 30 40 50 60 70 80 90
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2013 Masco Corporation of Indiana
Pressure (kPa)
2121
2123
113.6
94.6
75.7
56.8
37.9
18.9
0
