Submitted Model No.: _____________________________________________
(
S
)
®
Specific Features: ________________________________________________
52102-▲PK 2.5 GPM Showerhead
Full Body
Spray
Pause
Fast
Massage
52625▲ 2.5 GPM Showerhead
Full Body
Spray
Fast
Massage
Shampoo
Rinsing Spray
Full Spray
w/Massage
Pause
3 25/64"
(86 mm)
Full Spray
w/Massage
Soft Drench
Spray
3"
(76 mm)
Soft Drench
Spray w/Massage
3"
(76 mm)
touch clean
showerhead
■ Touch-Clean® Nozzles to Remove
Mineral Deposits
Standard SpecificationS
•
One to seven spray showerhead.
•
Touch-Clean® nozzles to remove mineral deposits.
•
4" diameter spray face: 52625.
•
3 1/2" diameter spray face: 52678, 52635
•
3" diameter spray face: 52102.
•
2 7/8" diameter spray face: 52672.
•
2.5 GPM Maximum at 80 psi (9.5L/min @ 552 kPa
•
2.0 GPM Maximum at 80 psi (7.6L/min @ 552 kPa.
Warranty
• Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from defects
in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
52672-▲PK 2.5 GPM Showerhead
52672-▲20-PK 2.0 GPM Showerhead
Full Body
Spray
▲ Designate proper finish suffix
3 25/64"
(86 mm)
3 25/64"
(86 mm)
2 13/16"
(71 mm)
coMpLieS WitH:
•
ASME A112.18.1 / CSA B125.1
•
EPA WaterSense
0 69 138 207 276 345 414 483 552 621
6
5
4
3
2
. Gallons Per Minute)
1
0
Flow (U.
0 10 20 30 40 50 60 70 80 90
®
Pressure (kPa)
Pressure
PSI)
22.7
18.9
15.1
11.4
7.6
3.8
0
Flow (Liters Per Minute
55 E. 111th Street, Indianapolis, Indiana 46280
DSP-B-52102-PK Rev. A
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2012 Masco Corporation of Indiana
