Tub AND SHOWER
®
= Adjustable H2Okinetic™ Spray (AH2O)
= Soft Full Spray (SF)
= Shampoo Rinsing Spray (SR)
= Shampoo Rinsing
Spray
w/Massage (SRM)
=
Full Spray w/Massage (FSM)
= High-Efficiency Spray (HE)
= Crossing Full Spray (CF)
= Crossing Full Spray w/Massage (CFM)
= Fast Massage (FM)
= Soft Drench w/Full Spray (SDF)
= Soft Drench Spray (SD)
= Pause (P)
= Full Body Spray (FB)
= Adjustable Full Spray (AF)
SR
CF
CFM
HE
SDF
AF
SRM
SF
FB
SD
P
FSM
FM
= Massage Spray (M)
M
= Slow Massage (SM)
SM
= H
2
Okinetic™ Spray (H2O)
H
2
O
= Soft Drench Spray w/Massage (SDM)
SDM
AH
2
O
JETTED SHOWER™
TRIM
T17T086▲
T17T286▲
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
2"
(51 mm)
Square
7 1/8"
(181 mm)
Square
Face of plasterguard
should be flush with
finish wall line
T17T486▲
14 1/2"
(368 mm)
2 3/4" (70mm)
As
Desired
Inlet
8" (203 mm)
min.
18" (457 mm)
max.
■ Arzo® Bath Collection
®
■ TempAssure
Thermostatic
■ Valve Only Trim (T17T086 Series)
■ Shower Only Trim (T17T286 Series)
■ Tub/Shower Trim (T17T486 Series)
STANDARD SPECIFICATIONS:
•
TempAssure® 17T thermostatic valve cartridge.
•
Thermostatic wax element maintains the outlet
temperature to ±3.6ºF.
•
Must also order Multi-Choice® Universal
rough separately (R10000 Series).
•
Back-to-back installation capability.
•
Lever volume control handle; temperature
adjustment dial.
•
Graphics indicate hot/cold temperature adjustment.
•
Field adjustable to limit rotation into hot water zone.
•
All parts are replaceable from the front of the valve.
•
Adjusts for up to 1" wall thickness.
•
Available extention kit (RP75136) adds up to 1 3/8"
installation depth.
•
H20kinetic
WARRANTy
•
Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.
•
5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.
®
showerhead 2.0 gpm @ 80 PSI.
RP53419▲ (Pull-Up Diverter)
3"
6 1/2"
(165 mm)
RP75136 Available Extension Kit
▲ Designate Proper Finish Suffix
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-B-T17T086 Rev. D
(76 mm)
RP70171▲ H2O Showerhead
H2Okinetic
Spray
5 5/16"
(135 mm)
2 3/4"
(70 mm)
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
•
EPA WaterSense
Indicates compliance to
ICC/ANSI A117.1- Valve control only.
069 138 207 276 345 414 483 552 621
)etuniM reP snollaG .S.U( wolF
6
5
4
3
2
1
0
0102030405060708090
®
Pressure (kPa)
Pressure (PSI)
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2014 Masco Corporation of Indiana
Tub Filler
H2O Showerhead
22.7
18.9
15.1
11.4
olF
w
7.6
uniM reP sretiL(
3.8
)et
0
