Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
51504▲
28”
(711 mm)
60”-82"
(1524 mm-
2083 mm)
55424▲
60”-82"
(1524 mm-
2083 mm)
▲ Designate proper finish suffix
Spray Patterns
54424-▲PK
60”-82"
(1524 mm-
2083 mm)
59424-▲PK
9 3/4”
(248 mm)
1 1/2”
(38 mm)
54424-▲20-PK
60”-82"
(1524 mm-
2083 mm)
59424-▲20-PK
ACTIVETOUCH®
HANDSHOWER
n Three Spray Selection Buttons
n "Pause Control" Button
STANDARD SPECIFICATIONS:
•
2.5 gpm @ 80 psi, 9.5 L/min @ 552 kPa
•
2.0 gpm @ 80 psi, 7.5 L/min @ 552 kPa
•
Nine spray settings
•
Three spray selection buttons for a simple
one-handed push of a button
•
60"-82" stretchable metal hose: 51504,
55424, 54424
•
28" contemporary adjustable wall bar: 51504
•
Adjustable wall mount: 55424
•
Adjustable shower arm mount: 54424
WARRANTY
•
Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.
•
5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.
Full Body
Spray
Pause
u
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-B-51504 Rev. D
Full Spray
w/Massage
Soft Drench
Spray
Shampoo Rinsing Spray
w/Massage
Your Delta Faucet handshower incorporates a backflow protection system
that has been tested to be in compliance with ASME A112.18.3 and ASME
A112.18.1/CSA B125.1. It incorporates two certified check valves in series,
which operate independently and are integral, non-serviceable parts of the
wand assembly.
Fast
Massage
Soft Full
Spray
Shampoo
Rinsing Spray
Soft Drench Spray
w/Massage
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1 u
Indicates compliance to
ICC/ANSI A117.1
•
EPA WaterSense
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2015 Masco Corporation of Indiana
®
