Submitted Model No.: _______________________________________________
0
1
2
3
4
5
0102030405060708090
Pressure (PSI)
Flow (U.S. Gallons Per Minute)
6
069 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flow (Liters Per Minute)
®
Specific Features: __________________________________________________
52008-▲DS
(1524 mm
-2083 mm)
59456-▲PK
3 5/16”
(84 mm)
60-82"
24”
(610 mm)
53001-▲DS 54456-▲PK
24”
(610 mm)
60-82"
(1524 mm
-2083 mm)
60-82"
(1524 mm
-2083 mm)
Palm®
SHOWER
n Push Button Selection
n 60-82" Stretchable Metal Hose
STANDARD SPECIFICATIONS:
•
Change spray modes with pushbutton.
•
60-82" stretchable hose: 53001, 52008, 54456.
• Includes double check valves for
backflow prevention.
•
ADA compliant grab bar with concealed screw
mounting system: 53001, 52008.
•
2.5 gpm @ 80 psi (9.5 L/min @ 552 kPa).
WARRANTy
•
Lifetime Faucet and Finish Limited Warranty
to the original consumer purchaser to be free
from defects in material and workmanship.
•
5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
5 3/4”
(146 mm)
▲ Designate proper finish suffix
Your Delta Faucet handshower incorporates a backflow protection system
u
that has been tested to be in compliance with ASME A112.18.3 and ASME
A112.18.1/CSA B125.1. It incorporates two certified check valves in series,
which operate independently and are integral, non-serviceable parts of the
wand assembly.
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-B-52008-DS Rev. A
COMPLIES WITH:
• ASME A112.18.1/CSA B125.1
• ADAAG
Spray Patterns
Full Body
Spray
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2012 Masco Corporation of Indiana
Fast
Massage
u
Full Spray
w/Massage
Pause
