Page 1
0
1
2
3
4
5
0 10 20 30 40 50 60 70 80 90
Pressure (PSI)
Flow (U.S. Gallons Per Minute)
6
0 69 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flow (Liters Per Minute)
showerhead
®
■ 2.0 GPM Max @ 80 PSI
■ 1.5 GPM Max @ 80 PSI
■ H2O Kinetic Technology
®
52658-▲-PK
52659-▲-PK 52660-▲-PK
Submitted Model No.: _____________________________________________
Specific Features: ________________________________________________
52658-PK 1.5 GPM Showerhead
Full Body
Spray
52659-PK 2.0 GPM Showerhead
Full Body
Spray
4 7/16"
(113 mm)
3 29/32"
(99 mm)
3 29/32"
(99 mm)
Standard SpecificationS
•
Full spray function.
•
1.5 GPM Maximum at 80 PSI.
•
2.0 GPM Maximum at 80 PSI.
•
H2O Kinetic Technology
®
Warranty
• Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from defects
in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
52660-PK Adjustable Between 1.5 & 2.0 GPM Showerhead
Full Body
Spray
▲ Designate proper finish suffix
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-B-52658-PK Rev. A
coMpLieS WitH:
•
ASME A112.18.1 / CSA B125.1
4 7/16"
(113 mm)
3 29/32"
(99 mm)
4 1/2"
(114 mm)
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2011 Masco Corporation of Indiana
