72172▲
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
2 3/4
(70 mm)
1 5/8
(41 mm)
3 7/64"
(78 mm)
Dia.
2 13/32"
(61 mm)
Dia.
1 7/8"
(48 mm)
Max.
PUSH POP
ASSEMBLY
■ Push Pop Assembly Less Overflow Holes
STANDARD SPECIFICATIONS:
•
All metal construction push pop
•
Tailpiece chrome plated for all finishes
•
For use with sinks without overflow
3 45/64"
(94 mm)
▲ Designate Proper Finish Suffix
1 5/16"
(32 mm)
Dia.
WARRANTY
•
Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.
•
5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.
COMPLIES WITH:
• ASME A112.18.2 / CSA B125.2
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-L-72172 Rev. C
