25938
Flow (U.S. Gallons Per Minute)
Flow (Liters Per Minute)
25938LF
LAVATORY
FAUCETS
Lahara®Bath Collection
Two Handle Deck Mount
3 Hole Sink Applications
4" Centerset
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
1/2"-14 NPSM
10 1/2"
(267 mm)
4" Centers
(102 mm)
6 5/16"
(160 mm)
3 1/4"
(83 mm)
4"
(102 mm)
2 7/16"
(61 mm)
2 1/8"
(54 mm)
Dia.
4"
(102 mm)
4 15/16"
(126 mm)
2 5/16"
(59 mm)
1 5/8"
(42 mm)
to
2 1/4"
(57 mm)
6 7/16"
(163 mm)
1 3/8" (35 mm)
Max. Deck
Thickness
STANDARD SPECIFICATIONS:
• Solid brass fabricated body.
• 4" (102 mm) centerset.
• 4 15/16" (126 mm) long, 6 7/16" (163 mm)
high rigid spout.
• 1/4 turn handle stops.
• Hot and cold stems are interchangeable.
•
Control mechanism is a replaceable 90
rotating cylinder.
o
• 1/2"-14 NPSM threaded male inlet shanks.
• Models have drain with pop-up type fitting
with plated flange and stopper.
WARRANTY
• Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from
defects in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
U
P
®
C
®
COMPLIES WITH:
•
ASME A112.18.1/ CSA B125 1
•
4 7/8"
(124 mm)
ASME A112.18.2 / CSA B125.2
Indicates compliance to
ICC/ANSI A117.1
•
EPA Water Sense
•
LF model verified to <0.25% Pb average
wetted surface regulations.
4 1/32"
(102 mm)
Designate proper finish suffix
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-L-25938 Rev. C
1 3/8"
(35 mm)
Dia.
1 1/4" (32 mm) Dia.
0 69 138 207 276 345 414 483 552 621
6
5
4
3
2
1
0
0 10 20 30 40 50 60 70 80 90
55 E. 111th Street, Indianapolis, Indiana 46280
395 Matheson Blvd. E., Mississauga, ON L4Z 2H2
© 2009 Masco Corporation of Indiana
Pressure (kPa)
Pressure (PSI)
.
22.7
18.9
15.1
11.4
7.6
3.8
0
