Delta CBKB2670 Owner Manual
= Pause (P)
P
ACTIVTOUCH
®
SLIDE BAR
HAND SHOWER
■ 9-Spray Setting Hand Shower
▲
51549
Submitted Model No.:
Specic Features:
3 11/16"
(93 mm)
24 5/8"
(625.5 mm)
1 1/2"
(38 mm)
10"
(254 mm)
2 13/16"
(71 mm)
19 9/16"
(498 mm)
Full Body
Spray
Fast Massage
Spray
Full Spray
w/ Massage
Shampoo
Rinse Spray
Shampoo
Rinse Spray
w/ Massage
FEATURES:
• Touch-Clean® Nozzles
• ActivTouch® Hand Shower
STANDARD SPECIFICATIONS
• Max flow rate 1.75 gpm @ 80 psi, 6.6 L/min @ 550 kPa
• Certif ied dual neoperl check valves for backf low protection
• Three spray selection buttons for a simple one-handed
operation
• Soft touch non-slip grip
• Hand held shower with nine spray settings -- pause is a
non-positive shut-off
• 60-82" ( 1524 mm - 2083 mm)stretchable metal hose
• Slide bar bracket for hands-free showering
• Slide bar w/adjustable slide (allows for adjustable shower
height). Not to be used as a grab bar.
WARRANTY
•
Parts and Finish - Lifetime limited warranty; or for
commercial purchasers, 10 years for multi-family
residential (apartments and condominiums) and
5 years for all other commercial uses, in each case
from the date of purchase.
•
Electronic Parts and Batteries (if applicable) - 5
years from the date of purchase; or for commercial
purchasers, 1 year from the date of purchase. No
warranty is provided on batteries.
6 1/2"
(165 mm)
60" - 82"
(1524 mm-2083 mm)
22 3/4"
(578 mm)
▲ Designate proper nish sufx
Delta reserves the right (1) to make changes in specications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for nish options and product availability.
DSP-B-51549 Rev. E
Soft Drench
Spray
Soft Full Spray
Soft Drench Spray
w/Massage
Pause
HAND SHOWER
DOUCHE À MAIN
REGADERA DE MANO
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1 u
•
ASME A112.18.3
•
EPA WaterSense
Your Delta Faucet hand shower incorporates a
u
backflow protection system that has been tested
to be in compliance with ASME A112.18.3 and
ASME A112.18.1/CSA B125.1. It incorporates
two certified check valves in series, which
operate independently and are integral,
non-serviceable parts of the wand assembly.
Delta Faucet Company
55 E. 111th Street, Indianapolis, IN 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2019 Delta Faucet Company
®
