Submitted Model No.: _____________________________________________
Specific Features: ________________________________________________
52634-▲18-PK 1.75 GPM Shower Head
52634-▲18VP-PK 1.75 GPM Shower Head
52634-▲15-BG 1.5 GPM Shower Head
HAND SHOWER/
SHOWER HEAD
■ High Velocity Eco Spray
■ Five Spray Settings
54434-▲18-PK 1.75 GPM
60”-82"
(1524 mm-
2083 mm)
3 21/32"
(93 mm)
59434-▲18-PK 1.75 GPM
59434-▲15-BG 1.5 GPM
3 23/64"
(85 mm)
FEATURES:
• Touch-Clean® nozzles
STANDARD SPECIFICATIONS
• Maximum 1.75 gpm at 80 psi, 6.6 L/min @ 550 kPa
• Maximum 1.5 gpm at 80 psi, 5.7 L/min @ 550 kPa
• High velocity eco spray
• 60"-82" (1524 mm - 2083 mm) stretchable metal hose
(54434-18-PK)
• Five spray settings - pause is a non-positive shut-off
• ADA compliant hand shower when installed per accessibility
guidelines of the act (59434-18-PK, 54434-18-PK)
• Vandal Resistant (52634-18VP-PK)
WARRANTY
•
Parts and Finish - Lifetime limited warranty; or for
commercial purchasers, 10 years for multi-family
residential (apartments and condominiums) and
5 years for all other commercial uses, in each case
from the date of purchase.
•
Electronic Parts and Batteries (if applicable) - 5
years from the date of purchase; or for commercial
purchasers, 1 year from the date of purchase. No
warranty is provided on batteries.
HAND SHOWER
DOUCHE À MAIN
REGADERA DE MANO
▲ Designate proper finish suffix
Spray Patterns
Full Body
Spray
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-B-52634-18-PK Rev. C
Fast
Massage
Pause
Full Spray
w/Massage
High-Efficiency
Spray
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
• EPA WaterSense
Delta Faucet Company
55 E. 111th Street, Indianapolis, IN 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2018 Delta Faucet Company
®
