Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
59462-▲B-PK
2.5 GPM
2 7/8”
(73 mm)
8”
(203 mm)
59462-WH18-PK
1.75 GPM
Full Body
Spray
Pause
Full Body
Spray
59462-▲B18-PK
1.75 GPM
59462-▲B15-BG
1.5 GPM
Full Body
Spray
Pause
Full Body
Spray
Pause
59462-WH-PK
2.5 GPM
Full Body
Spray
HAND SHOWER
FEATURES:
• Touch-Clean® Nozzles
STANDARD SPECIFICATIONS:
• Maximum 2.5 gpm @ 80 psi, 9.5 L/min @ 550 kPa
(59462-B-PK, 59462-WH-PK)
• Maximum 1.75 gpm @ 80 psi, 6.6 L/min @ 550 kPa
(59462-B18-PK, 59462-WH18-PK)
• Maximum 1.5 gpm @ 80 psi, 5.7 L/min @ 550 kPa
(59462-B15-PK)
• Pause flow by pressing the button on the handle -
pause is a non-positive shut-off (59462-B-PK, 59462-B18-PK,
59462-B15-BG)
• Certified dual check valves for backflow protection
• ADA compliant hand shower when installed per accessibility
guidelines of the act
WARRANTY
•
Parts and Finish - Lifetime limited warranty; or for
commercial purchasers, 10 years for multi-family
residential (apartments and condominiums) and
5 years for all other commercial uses, in each case
from the date of purchase.
•
Electronic Parts and Batteries (if applicable) - 5
years from the date of purchase; or for commercial
purchasers, 1 year from the date of purchase. No
warranty is provided on batteries.
▲ Designate proper finish suffix
Your Delta Faucet handshower incorporates a backflow protection system
u
that has been tested to be in compliance with ASME A112.18.3 and ASME
A112.18.1/CSA B125.1. It incorporates two certified check valves in series,
which operate independently and are integral, non-serviceable parts of the
wand assembly.
HAND SHOWER
DOUCHE À MAIN
REGADERA DE MANO
COMPLIES WITH:
• ASME A112.18.1/CSA B125.1
• ASME A112.18.3
Indicates compliance to
ICC/ANSI A117.1
• EPA WaterSense® - Applies to 59462-B18-PK,
59462-WH18-PK, and 59462-B15-BG only
u
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-B-59462-B-PK Rev. H
Delta Faucet Company
55 E. 111th Street, Indianapolis, IN 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2019 Delta Faucet Company
