19802Z-▲-DST
19802Z-▲-DST with
optional escutcheon
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
4 1/2"
(113 mm)
2 7/8"
(73 mm)
2 1/2"
(64 mm)
Max. Deck
Thickness
3/8"
Compression
Fittings
(175 mm)
2 3/8"
(60 mm)
6 7/8"
8 1/2"
(216 mm)
(233 mm)
37 3/8"
(949 mm)
9 1/8"
Min. 2 1/2" (64 mm)
Clearance to Back Splash
35"
(889 mm)
15 3/4"
(400 mm)
1 5/16" - 1
1/2"
(33-38 mm)
Hole Size
9 7/8"
(252 mm)
KITCHEN FAUCETS
■ Lenta™ Collection
■ Single Handle Pull-Down
FEATURES:
• Touch-Clean® Technology
• DIAMOND Seal® Technology
•
MagnaTite® Docking System
•
3-Function Pull-Down w/ShieldSpray
STANDARD SPECIFICATIONS:
•
Max flow rate 1.8 gpm @ 60 psi, 6.8 L/min @ 414 kPa
•
One or three hole mount (escutcheon
optional, included)
•
Diamond coated ceramic cartridge
• 3/8" O.D. straight, staggered PEX supply lines
•
Spout rotates 360°
•
Hot/cold indicator markings
• Dual integral check valves in sprayer assembly
• Three-function wand; Aerated stream, spray or
ShieldSpray™
WARRANTY
•
Parts and Finish - Lifetime limited warranty; or for
commercial purchasers, 10 years for multi-family
residential (apartments and condominiums) and
5 years for all other commercial uses, in each case
from the date of purchase.
•
Electronic Parts and Batteries (if applicable) - 5
years from the date of purchase; or for commercial
purchasers, 1 year from the date of purchase. No
warranty is provided on batteries.
TM
16 1/4"
(413 mm)
9"
(226 mm)
1/2"
(13 mm)
7 3/8"
(187mm)
(203 mm)
Centers
8"
10 3/4"
(273 mm)
2 1/2"
(64 mm)
Max. Deck
Thickness
3x 1 5/16" -
1 1/2"
(33-38 mm)
Hole Size
▲ Designate proper finish suffix
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-K-19802Z-DST Rev. A
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
•
ASME A112.18.6
Indicates compliance to
ICC/ANSI A117.1
•
Verified compliant with .25% weighted
average Pb content regulations.
Delta Faucet Company
55 E. 111th Street, Indianapolis, IN 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2019 Delta Faucet Company
