VENTILATION FAN
MODELS VFB25ACH / VFB25ADH / VFB25AEH
80HS / 80-110DS / 110F / 130HS
TABLE OF CONTENTS
Package Contents
General Safety Information
Preparation and Wiring Diagrams
Assembly Instructions - New Construction
Assembly Instructions - Existing Construction
Grille Installation
Operation
Care and Maintenance
Troubleshooting
Dimensions
Product Specications
Warranty
2
3
4
5
7
10
10
12
13
13
14
14
READ AND SAVE THESE INSTRUCTIONS
Address: 46101 Fremont Boulevard, Fremont, CA 94538
US Toll Free Number:
1-888-979-9889 – Technical Support
1-877-685-4384 – Customer Sales Support
www.deltabreez.com
MFG Model
VFB080D4H1 / VFB110D4X1
VFB110D4A1 / VFB130D4H1
Page 2
PACKAGE CONTENTS
PAR T DESCRIPTION QTY
1
1
2
3
4
5
5
Fan Body 1
Grille 1
Suspension Bracket I 1
Suspension Bracket II 1
Suspension Bracket III 1
Duct Connector 1
2
HARDWARE CONTENTS
(Images are to scale)
A
× 8
3
Long Wood Screw ( ø 4 x 25mm)
B
× 3
Short Machine Screw (M4 x 12mm)
4
5
6
2 3
Page 3
GENERAL SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
GENERAL SAFETY INFORMATION
1. Make sure that the electric service supply voltage is AC
120V, 60Hz.
2. Follow all local electrical and safety codes, as well as
the National Electrical Code (NEC) and the Occupational
Safety and Health Act (OSH Act).
3. Always disconnect the power source before working on
or near the ventilating fan, motor or junction box.
4. Protect the power cord from sharp edges, oil, grease,
hot surfaces, chemicals or other objects.
5. Do not kink the power cord.
6. Do not install the unit where ducts are confugured as
shown in Fig.A.
7. Provide suction parts with proper ventilation.
8. This unit is UL Listed for use over a bathtub or shower
when installed in a GFCI protected branch circuit.
9. These ventilating fans are intended for residential usage
only.
10. This product is designed for ceiling installation only. Do
not mount this product in a wall.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
2. Before servicing or cleaning the unit, switch the power o
at the service panel and lock the service disconnecting
means to prevent the power from being switched on
accidentally. When the service disconnecting means
cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
3. Installation work and electrical wiring must be done by
a qualied person(s) in accordance with all applicable
codes and standards, including re-rated construction.
4. Sucient air is needed for proper combustion and
exhausting of gases through the ue (chimney) of fuel
burning equipment to prevent backdrafting. Follow the
heating equipment manufacturer’s guideline and safety
standards such as those published by the National
Fire Protection Association (NFPA), and the American
Society for Heating Refrigeration and Air Conditioning
Engineers (ASHRAE) and local code authorities.
5. When cutting or drilling into the wall or ceiling, do not
damage electrical wiring and other hidden utilities.
6. Ducted ventilating fans must always be vented to the
outdoors.
7. If this unit is to be installed over a tub or shower, it
must be marked as appropriate for the application
and be connected to a GFCI (Ground Fault Circuit
lnterrupter) – protected branch circuit.
8. Do not use this unit with any other solid-state control
device. Solid-state controls may cause harmonic
distortion, which can cause a motor humming noise.
9. NEVER place a switch where it can be reached from a
tub or shower.
10. Not to be installed in a ceiling thermally insulated to a
value greater than R40. (This is required for installation
in Canada only).
Turning angle too large
Too many elbows
Fig. A
Duct shrink
Elbow near the body
Body
Minimum 18 in.
.
CAUTION
1. For general ventilating use only. Do not use to exhaust
hazardous or explosive materials and vapors.
2. Not for use in cooking areas. (Fig.B)
3. This product must properly connect to the grounding
conductor of the supply circuit.
4. To reduce the risk of injury to persons, install the fan at
least 8.2 feet (2.5m) above the oor.
Cooking area
Do not install above or
inside this area
45
°
Cooking
Equipment
Fig. B
45
°
oor
Page 4
PREPARATION
Tools Required for Assembly (not included): Hammer,
Flathead Screwdriver, Wire Nuts, Nails, Duct Tape, Phillips
Head Screwdriver, Utility Knife
Helpful Tools (not included): Electric Drill, Drill Bits
WARNING: Turn o electricity at breaker box before
beginning installation.
Carefully remove unit from carton.
Check area above installation location to be sure that
wiring can run to the planned location and that duct work
can be run. Make sure the area is sucient for proper
ventilation.
Inspect duct work and wiring before proceeding with
installation.
Before installation, provide inspection and future
maintenance access at a location that will not interfere
with installation work.
You may need the help of a second person to install this
fan: one person on the attic side and one on the room
side.
Note: Installations may vary depending on how the previous
bath fan was installed. Supplies necessary for the installation
of your bath fan are not all included.
However, most are available at your local home improvement
or hardware store.
DIMENSION REQUIREMENTS
Ceiling Opening
length width height
10 1/4 in. 10 1/4 in. 8 1/2 in.
Housing Dimension
length width height
9 5/8 in. 9 5/8 in. 8 in.
Proper insulation around the fan to minimize building heat
loss and gain. 4” circular duct is recommended for installation.
The ducting from this fan to the outside of building has a
strong eect on air ow, noise and energy use of the fan.
Use the shortest, straightest duct routing possible for best
performance, and avoid installing the fan with smaller ducts
than recommended. Insulation around the ducts can reduce
energy loss and inhibit mold growth. Fans installed with
existing ducts may not achieve their rated air ow.
Roof cap
(with built-in
Short piece of flexible
duct helps alignment
and absorbs sound
Fan housing
Seal gap
around
housing
The fan will operate most eciently when located where
2~3 ft straight run
before elbow
Caulk termination
to duct
damper)
or
Wall cap
Wall cap
(with built-in
(with built-in
damper)
damper)
the shortest possible duct run and minimum number of
elbows will be needed.
Use a roof cap or wall cap that has a built-in damper to
reduce backdrafts.
External timer can be used. Please contact Delta Breez
customer service and consult with a licensed electrician
for compatibility
Humidity sensing models :
Locate unit above (GFCI-protected circuit required) or
within 5 feet of the shower head.
Locate unit away from heating or cooling sources which
can aect humidity levels.
Do not locate near window. Unit may respond to
the outdoor humidity level.
Unit must be installed in ceiling to properly sense
moisture.
Locate unit only on at ceilings up to 12 feet high for
proper sensing.
WIRING DIAGRAM
JUNCTION BOX
BLACK
WHITE
GREEN
SWITCH BOX
OFF
ON
POWER SWITCH
WHITE
SWITCH BOX
120 VAC
LINE IN
GROUND
(bare)
WIRING
PLATE
GRD
BLACK
ON/OFF SWITCH
(purchase separately)
L
N
POWER
SWITCH
4 5
Page 5
ASSEMBLY INSTRUCTIONS
NEW CONSTRUCTION – ATTACHING TO THE JOIST
BEFORE INSTALLATION
Turn o power source. Review all safety precautions.
1. If spacing between joists is 12 in. apart, use four
long wood screws (provided) to attach the fan body
1
to ceiling joists.
Hardware
A
Long wood screw
1
A
2. For joist spacing 16 in. - 24in., insert suspension
bracket I 3 into the bracket cover on the duct
connector side. Then, attach suspension bracket II
4
and bracket III 5 to the back of the fan body 1.
3. Secure the fan body 1 to the joist with suspension
brackets 3 , 4 , 5 using long wood screws.
Hardware
A
Long wood screw
2
3
1
5
4
3
1
4
5
A
Page 6
a
b
c
ASSEMBLY INSTRUCTIONS
a
4. Secure the suspension brackets 3 , 4 , 5 to the
fan body 1 using a short machine screw.
Hardware
B
Short machine screw
5. Remove the fan junction box cover a . Using wire
nuts (not supplied), connect house wires to fan
wires b as shown in the wiring diagram on page 4.
Reattach fan junction box cover c .
4
1
3
4
5
Short
machine screw
5
6. Connect a 4 in. circular duct a (not supplied)
and vent to the outside. Secure it with duct tape
(not supplied) or clamp (not supplied) to make the
connection secure and air tight.
7. Turn on power source. Check fan for any abnormal
sound or vibration.
6
6 7
Page 7
ASSEMBLY INSTRUCTIONS
EXISTING CONSTRUCTION
NOTE: ATTACHING DIRECTLY TO THE JOIST(S)
FROM BELOW WILL BE THE BEST INSTALLATION.
BEFORE INSTALLATION
Turn o power source. Review all safety precautions.
1. Remove existing fan.
2. Measure the opening to ensure it is large enough to
accommodate the new fan body
(10 1/4 in. x 10 1/4 in.).
3. If this fan is not replacing an old fan, be sure to cut
a 10 1/4 in. x 10 1/4 in. opening for the fan body 1 .
1
2
3
10 1/4 in.
10 1/4 in.
Install from below, no need for suspension
brackets (no attic access)
4. A piece of wood (not supplied) is screwed in from
below through the ceiling board. Suggested size is
1 in. x 3 in. x 14 in. Position the screws far enough
away from the edge of the ceiling board that it does
not crumble and give way. Put screws in both ends
of wood beyond the 10 1/4 in. hole. Keep screws in
range of grille.
4
Wood support
Wood support screwed in from
underneath. Screw is far enough away
from the edge of sheetrock to prevent
crumblimg.
Page 8
ASSEMBLY INSTRUCTIONS
3 1/2 in.
5. Place the duct connector 6 through the ceiling cut
out. Connect a 4 in. circular duct (not supplied) a
and vent to the outside. Secure it with duct tape
(not supplied) or clamp (not supplied) to make
connection secure and air tight. Attach the duct
connector to the ceiling with one long wood screw.
Hardware
A
Long wood screw
6. Remove fan junction box cover a. Using wire
nuts (not supplied), connect house wires to fan
wires b as shown in the wiring diagram on page 4.
Reattach fan junction box cover c.
7. Insert fan body 1 into the ceiling cut out making
sure to align the duct connector with the fan body
1
.
5
a
A
6
6
b
c
a
7
8. Secure the fan body 1 from below using long
wood screws (provided). Insert at least 4 screws
through the ange and drywall into the joists.
Hardware
A
Long wood screw
9. Turn on the power source. Check fan for any
abnormal sound or vibration.
1
8
1
8 9
A
Page 9
ASSEMBLY INSTRUCTIONS
machine screw
a
b
c
a
Install from above with suspension brackets
(attic access)
*ONLY IF UNABLE TO ATTACH DIRECTLY TO JOIST(S)
1. For joist spacing 16 in. - 24in., insert suspension
bracket I 3 into the bracket cover on the duct
connector side. Then, attach suspension bracket II
4
and bracket III 5 to the back of the fan body 1 .
2. Secure the fan body 1 to the joist with suspension
brackets 3 , 4 , 5 using long wood screws.
Hardware
A
Long wood screw
3. Secure the suspension brackets 3 , 4 , 5 to the
fan body 1 using a short machine screw.
Hardware
B
Short machine screw.
1
3
1
5
4
2
1
4
5
A
3
3
1
4
4. Remove the fan junction box cover a . Using wire
5. Connect a 4 in. circular duct a (not supplied)
6. Turn on power source. Check fan for any abnormal
nuts (not supplied), connect house wires to fan
wires b as shown in the wiring diagram on page 4.
Reattach fan junction box cover c .
and vent to the outside. Secure it with duct tape
(not supplied) or clamp (not supplied) to make the
connection secure and air tight.
sound or vibration.
5
Short
4
5
Page 10
GRILLE INSTALLATION
Attach grille 2 by pinching mounting springs a and
a
1
insert into the narrow rectangular slots in fan body 1 .
2
OPERATION
Single Speed Model:
Turn the POWER switch ON to operate at single speed mode.
Humidity Sensor Models:
1. Humidity Sensing Mode: Flip wall switch to “ON” position. The LED indicator light in the fan will be BLUE. The
fan will automatically start when the humidity level in the room is above the user-adjustable set-point.
If humidity level is below the user-adjustable set-point, until a 10-minute time delay has elapsed the fan will
stop automatically. Factory setting is around 60%RH and humidity tolerance is about ±10%. The humidity
switch may need to be adjusted regionally. Longtime operation will inuence the detecting precision as dust
accumulates.
110F
VFB25ACH, VFB25ADH, VFB25AEH, 80HS, 130HS
1
Humidity preset control
%RH
Blue LED Light
80
50
2. Full Speed Mode: Cycle wall on/o switch.
The LED indicator light in fan will be AMBER.
Amber LED Light
3. Fan O: Move wall on/o switch to “OFF” position.
%RH
80
50
2
3
10 11
Page 11
OPERATION
Dual Speed Model:
1. Low Speed Mode: Flip wall switch to “ON” position.
The LED indicator light in the fan will be GREEN.
Green LED Light
2. Full Speed Mode: Cycle wall on/o switch.
The LED indicator light in fan will be AMBER.
Amber LED Light
80-110DS
1
2
3. Fan O: Move wall on/o switch to “OFF” position.
3
Page 12
CARE AND MAINTENANCE
See safety information before proceeding. Routine maintenance should be done at least once a year.
• Never use solvents, thinner or harsh chemicals when cleaning the fan.
• Do not allow water to enter the motor.
• Do not immerse metal parts in water.
• Do not immerse resin parts in water over 140º Fahrenheit.
Turn o power source. Review all safety precautions.
1. To remove grille 2 , squeeze springs and pull down.
2. Wash and clean the grille 2 in a sink and dry with a cloth.
3. Remove dust and dirt from the fan body 1 with
a vacuum cleaner.
1
2
2
2
3
Vacuum
1
cleaner
4. Dampen cloth with dust detergent and wipe the fan body
1 . Then wipe dry with a clean cloth.
5. Replace grille 2 back onto fan body 1 .
6. Turn on power source to operate fan again.
12 13
4
1
5
2
Page 13
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The fan is not turning on 1. Power o
2. Faulty switch
3. Faulty wire connection
The fan seems louder
1. CFM too great
than it should
2. Damper not working
properly or damaged
3. Bend in duct too close
to fan discharge
4. Fan discharge reduced
to t smaller duct
5. Fan body not securely
attached
The fan is not clearing
the room
1. Insucient intake
airfow within room
2. Insucient CFM
1. Make sure power supply is on.
2. Test or replace switch.
3. Check wire in switch box.
1. Be sure the CFM rating on the fan matches the
size of your room.
2. Check damper to ensure it is opening and
closing properly. If the damper has become
damaged, please call Customer Service.
3. Be sure you do not have any sharp bends in
duct closer than 18 in. to the fan discharge.
4. Use recommended size ducting to reduce fan
noise.
5. Be sure the fan is securely attached to your
ceiling joists.
1. Be sure a door or window is slightly ajar or
opened to allow airow. The fan is not able to
draw air out of the room without enough airow
to draw in from.
2. Be sure the CFM rating on the fan matches the
requirements for your room size.
The fan keeps running
even though the house
humidity level is lower
than set humidity level
DIMENSIONS
1. Our sensor tolerance
is +/-10% RH
2. Outdoor humidity is
back drafting to the fan
3/8
12
1. Continue to let the fan run since it is good to
keep venting the house and the electric bill is
minimal (approximately less than $10 per year).
2. Turn the fan o when not in use.
3/8
12
3/4
8
1/2
1
Ø4
5/8
9
Unit: Inch
Page 14
PRODUCT SPECIFICATIONS
Model No.
80HS / VFB25ACH /
VFB080D4H1
130HS / VFB25AEH
VFB130D4H1
80-110DS /
VFB110D4X1
110F /
VTB110D4A1
VFB25ADH 110-220 V 50-60 Hz 110 14.2 0.22 7.52 Humidity Sensing
Voltage
110-220 V 50-60 Hz 80 7.2 0.12 7.52 Humidity Sensing
110-220 V 50-60 Hz 130 22 0.36 7.52 Humidity Sensing
110-220 V 50-60 Hz
110-220 V 50-60 Hz 110 14.2 0.22 7.52 Single Speed
(V)
Frequency
(Hz)
Air Flow @ 0.1"SP
(CFM)
110 16
80 7.7 Low Speed
Power @ 0.1"SP
(W)
Max Current
(Amps)
0.22 7.52
Weight
(lb.)
Note
Full Speed
Note: Design and specications subject to change without notice.
WARRANTY
DELTA ELECTRONICS THREE YEAR LIMITED WARRANTY
Delta Electronics Inc. (“Delta Electronics”) warrants to the original consumer purchaser in the USA that the
Breez ventilation fan products will be free from defects in material or workmanship. This warranty is limited to
three (3) years from the original date of purchase.
Limitations and Exclusions
1. During the warranty period, a replacement for any defective product will be supplied free of charge for
installation by the consumer. The warranty provided herein does not cover charges for labor or other costs
incurred in the troubleshooting, repair, removal, and installation service.
2. All returns of defective parts or products must include the product model number, and must be made
through an authorized Delta Electronics distributor. Authorized returns must be shipped prepaid. Repaired
or replacement products will be shipped by Delta Electronics F.O.B. shipping point.
3. Delta Electronics shall not be liable for any indirect, incidental, consequential, punitive, or special damages
arising out of or in connection with products use or performance, regardless of the form of action whether
in contract, tort (including negligence), strict product liability or otherwise.
4. This warranty does not extend to uorescent lamp starters and tubes.
5. The warranty does not cover if user does not comply with manufacturer’s installation manual.
6. To qualify for warranty service, you must notify Delta Electronics at the address or telephone number
below.
7. Delta Electronics shall have no liability to the original owner-user with respect to any defect caused
by abuse, misuse, neglect, improper transportation or storage, improper testing, improper installation,
improper operation, improper use, improper maintenance, improper repair, improper alteration, improper
modication, tampering or accident of products or parts thereof, or unusual deterioration or degradation of
products or parts thereof due to a physical environment beyond the requirement of products' specications.
Address: 46101 Fremont Boulevard, Fremont, CA 94538
US Toll Free Number:
1-888-979-9889 – Technical Support
1-877-685-4384 – Customer Sales Support
www.deltabreez.com
14 14
Loading...
