Delta 7888 Instruction Manual

Conforms to

ASTM F1169-10a Full

Size Crib & F1821

Safety Standards

Style #:

Lot:

Date:

___________
___________
___________

A

4 in 1 Crib

Consumer Care:

www.DeltaChildren.com

Delta Children’s Products

114 West 26th Street
New York, NY 10001

Tele.212-645-9033

FACTORYREV

THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.

To register your product for important safety alerts and updates to your product please
visit www.DeltaChildren.com and click on Product Registration.

When contacting Delta Consumer Care please reference
the above information. Before contacting Delta Consumer
Care please ensure that the information above matches the
information found on the label on the Crib End bottom rail,
please reference the information found on the product
when contacting Delta Consumer Care.

Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.

ADULT ASSEMBLY REQUIRED

Due to the presence of small parts during assembly, keep out of
reach of children until assembly is complete.

December 7, 2012, 23343, R4

©2012 DELTA ENTERPRISE CORP.

WARNING:

*Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding

under an infant.
*Failure to follow these warnings and the assembly instructions could result in serious injury or death.

DO NOT use this crib if you cannot exactly follow the accompanying instructions.

*To reduce the risk of SIDS, pediatricians recommend healthy infants be placed on their backs to
sleep, unless otherwise advised by your physician.
*Strangulation Hazard: STRINGS CAN CAUSE STRANGULATION! Do not place items with a string
around a child's neck, such as hood strings or pacifier cords. Do not suspend strings over a crib or
attach strings to toys.
*Strangulation Hazard: To help prevent strangulation tighten all fasteners. A child can trap parts of
the body or clothing on loose fasteners.
*Strangulation Hazard: Do not place crib near window or patio door where cords from blinds or
drapes may strangle a child.
*Fall Hazard: When child is able to pull to a standing position, set mattress to lowest position and
remove bumper pads, large toys and other objects that could serve as steps for climbing out. This crib
has an adjustable mattress support. For the convenience of the parent when the baby is very small, the
mattress support may be used in the highest position. Important: with the mattress support and
mattress in the highest position, be absolutely sure that the top of the front crib side is at least 3 inches
higher than the top surface of the mattress. If it is not, lower the mattress support and the mattress to
the next highest position.
*Fall Hazard: Stop using crib when child begins to climb out or reaches a height of 35in. (89cm),
whichever occurs first. The child should be placed in a youth or regular bed.
*Check this product for damaged hardware, loose joints, loose bolts or other fasteners, missing parts,

or sharp edges before and after assembly and frequently during use. Securely tighten loose bolts and
other fasteners. Do not use crib if any parts are missing, damaged or broken. Contact Delta

Children's Products for replacement parts and instructional literature if needed. Do not substitute parts.
*Follow warnings on all products in a crib.
*If refinishing, use a non-toxic finish specified for children's products.
*Never use plastic shipping bags or other plastic film as mattress covers because they can cause
suffocation.
*Infants can suffocate in gaps between crib sides and a mattress that is too small.
*Ensure a safe environment for the child by checking regularly, before placing the child in the crib, that
every component is properly and securely in place.
*To avoid head injury, do not allow any child to play underneath the crib.
*Never add an accessory such as a bassinet or changing table that extends over the sleeping area.

*In Canada Only - Use a crib mattress that is no thicker than 15 cm and is of such a size that, when it
is pushed firmly against any side of the crib, it does not leave a gap of more than 3 cm between the
mattress and any part of the sides of the crib. Do not use this crib for a child who can climb out of it or
who is taller than 90 cm.

CAUTION:

ANY MATTRESS USED IN THIS CRIB SHALL
BE AT LEAST 27 1/4 BY 51 5/8 IN. WITH A
THICKNESS NOT EXCEEDING 6 IN.

3

TODDLER BED

WARNING

INFANTS HAVE DIED IN TODDLER BEDS FROM ENTRAPMENT.

Openings in and between bed parts can entrap head and neck of a small child.
NEVER use bed with children younger than 15 months.
ALWAYS follow assembly instructions.
The maximum user weight is 50lbs (22.7kg)

WARNING

STRANGULATION HAZARD

NEVER place bed near windows where cords from blinds or drapes may strangle a child.
NEVER suspend strings over a bed.
NEVER place items with a string, cord, or ribbon, such as hood strings or pacifier cords,
around a child's neck. These items may catch on bed parts.

CAUTION

ENTRAPMENT HAZARD

To avoid dangerous gaps, any mattress used in this bed shall be a full-size crib mattress
at least 51 5/8 in (1310mm) in length, 27 1/4 in (690mm) in width and 4 in (100mm) in
thickness. The mattress thickness must not exceed 6 in (150mm).

NOTES ON ASSEMBLY:

-During the assembly process whenever using screws or bolts, check each by placing the screw/bolt on
the diagram of the item which is drawn actual size and design. Be sure to use the proper size and shape
specified in the instructions.

-To assemble this unit you may be required to place the unit on it’s side and face. It is strongly
recommended that assembly is done on a soft, non-abrasive surface to avoid damaging the finish.

NOTES ON CARE AND MAINTENANCE:

- Do not scratch or chip the finish.

- Inspect the product periodically, contact Delta Children's Products for replacement parts or questions.

- Do not store the product or any parts in extreme temperatures and conditions such as a hot attic or a
damp, cold basement. These extremes can cause a loss of structural integrity.

-To preserve the luster of the high quality finish on your product, it is recommended to place a doily or
felt pad under any items you place on the finish.

-Clean with a damp cloth, then a dry cloth to preserve the original luster and beauty of this fine finish.

-Do not use abrasive chemicals.

-Do not spray cleaners directly onto furniture.

-Lift slightly when moving on carpeting to prevent leg breakage.

-Use of a vaporizer near furniture will cause wood to swell and finish to peel.

NOTES ON USE:

Keep children and others safe by following these simple rules:

- Do not allow any child to play on furniture

- Do not allow climbing on any piece of furniture.

- Do not allow hanging from any piece of furniture.

- Always monitor your child’s activity when in the nursery.

PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT.

A. Top Rail x 2

C. Left Crib End x 1

D. Right Crib End x 1

F. Mattress Support x 1

4

E. Front Side x 1

B. Back Side x 1

G. Stabilizer Bar x 1

POUCH ATTACHED TO MATTRESS SUPPORT

- KEEP INSTRUCTIONS IN THIS POUCH
AFTER ASSEMBLY.
WARNINGS RELATED TO THE SAFE USE OF
THIS CRIB ARE PRINTED ON THE POUCH.

H. Guardrail x 1

Part # 14892

C3. Left Back Post

D3. Right Back Post

C1. Left End Panel

D1. Right End Panel

C2. Left Front Post

D2. Right Front Post

N. M6 x 65 mm Bolt x 10

Used to factory assemble Parts C&D
as originally shipped

PARTS: HARDWARE AND TOOLS.

5

M. Adapter Plate x 2

M4 Allen Wrench Supplied

K. M6 x15 mm Bolt x 4

L. Φ4x30 mm Metal Pin x 4

J. M6 x 45 mm Bolt x 12

No drills necessary. Do not
use power screwdriver.

Part # 5466

Part # 5460

Part # 5493

Part # 1177

Part # 5686

6

Step 1

Section 1: Crib Assembly

Parts and tools required to complete step.

N. M6 x 65 mm Bolt x 10

M4 Allen Wrench
Supplied

C1, D1

C3, D3

C2, D2

N Left Crib End Shown

N

N

N

N

Parts Pre-Assembled in the facotry, Ensure ALL bolts are TIGHT.

C3. Left Back Post

D3. Right Back Post

C1. Left End Panel

D1. Right End Panel

C2. Left Front Post

D2. Right Front Post

Attach (1) Crib End Panel (Part C1) to (1) Left Back Post (Part C3) and (1) Left Front Post (Part C2)
using(5) M6x65mm Bolts (Part N). Tighten with the M4 Allen Wrench. Repeat on the other Crib End
(Parts D1, D2 &D3).

NOTE: AFTER ASSEMBLY, THE “STEPPED HOLES” IN BOTH POSTS ARE ON THE SAME SIDE.
