3
ENGLISH
When using electrical appliances, basic safety precautions should always be followed,
including the following:
• Read all instructions.
• This appliance is designed to dehumidify domestic living areas, and must not be used for
other purposes.
• The appliance must not be modified in any way, as any modifications may be extremely
dangerous.
• If the appliance requires repair, always contact a Service Centre authorized by the
manufacturer. Always insist on original spare parts. Repairs carried out by non-qualified
personnel may be dangerous and render the warranty null and void.
• This appliance must be used by adults only. Do not allow children to play with the
appliance.
• The appliance must be adequately grounded. Have your electrical circuit checked by a
qualified electrician.
• Do not use extension power cables.
• Always remove the plug from the socket before performing cleaning or maintenance
operations.
• Do not move the appliance by pulling the power cable.
• Do not install the appliance in areas containing gas, oil or sulphur. Do not install the
appliance near sources of heat.
• Do not place heavy or hot objects on the top of the appliance.
• Clean the air filter at least once weekly.
• The appliance must always remain upright or laid on one side during transportation.
Remember to drain the tank before transporting the appliance..
• After transporting the appliance, wait 24 hours before using it.
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS
5748007700GB 5-06-2003 17:47 Pagina 3
4
Description/Accessories
1
2
Air intake
Air outlet
3
5
6
7
1. Control panel cover
2. Control panel
3. Tank door
4. Condensate collection tank
5. Air intake grille
6. Air filter
7. Lifting carry handle
Accessory
Description No. provided
rubber bung
condensate drain hose 2 m (6.5 ft)
1
4
5748007700GB 5-06-2003 17:47 Pagina 4
5
ENGLISH
C
ondensate can be drained in one of two ways:
A) Draining into the tank
The condensate can be drained directly into the tank located inside the appliance (fig. 1).
The tank can be easily removed and has a handle making it simple to carry and empty.
B) Continuous external draining
If the appliance is to be operated for long periods of time but you are unable to empty the tank,
you are recommended to use the continuous drain facility.
1) Remove the rubber bung from the spout (Fig. 2).
2) Make a hole in the tank inside the spout using a fine drill bit 8 mm (1/4” or 3/8”) (Fig. 2).
3) To fit the rubber hose to the spout, open the door, remove the tank, pass the drain hose
provided through the space between the door (at a slight angle) and the bottom of the
appliance, reposition the tank and fit the hose onto the spout (Fig. 3).
4) Close the door.
5) Make sure the hose is levelled down otherwise the water will remain in the tank. Check
there are no kinks in the hose.
N.B.: Keep the rubber bung. You will need it to plug the hose or close the spout if you
revert to draining into the tank (see point A).
Installation
fig. 1
fig. 2
fig. 3
5748007700GB 5-06-2003 17:47 Pagina 5
6
Tank control system
This dehumidifier is fitted with a special device to ensure correct operation.
A red indicator light on the control panel comes on to warn the user when:
1. the tank is full . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .empty the tank
2. the tank is missing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .replace the tank
3. the tank is in the wrong position . . . . . . . . . . . . . . . . . . .position the tank correctly
4. in continuous drain: the hose is not levelled properly . .remove the obstruction
Once the cause has been eliminated, the light goes out and the appliance resumes operation.
Description of controls
Dehumidifying
indicator light
OFF position:
appliance off
Humidistat knob
Power indicator light
indicates that the appliance
is connected to the mains
“Tank full / no tank”
indicator light
Dehumidifying standby light
lights up for the first three minutes
in dehumidifying mode
Air filtration
indicator light
Functions selector
5748007700GB 5-06-2003 17:47 Pagina 6
7
ENGLISH
How to dehumidify
1) Plug the appliance into a mains socket. The power light comes on to show the appliance
is connected to the mains.
2) Check that the “tank full/no tank” indicator light is off.
3) Turn the humidistat to the “CONTINUOUS” (continuous operation) position and the function
selector switch to one of the two DEHUMIDIFICATION positions : 1 = min. 2 = max.
The dehumidification pause light comes on during the first three minutes (safety device),
followed by the dehumidification light.
When the humidity in the room has reached the required level, slowly turn the humidistat knob
anticlockwise until the dehumidifying light goes out. The dehumidifier will then keep the
humidity in the room at the selected level automatically.
Note: When dehumidifying, the appliance not only dehumidifies but also slightly warms the air
(1-2°C (2-3°F) hotter than room temperature)
How to ventilate
Turn the function selector switch to one of the two VENTILATION positions : 1 = min. 2
= max.
The ventilation light comes on
TO TURN THE UNIT OFF COMPLETELY, SET THE FUNCTION SELECTOR TO THE OFF POSITION AND
UNPLUG FROM THE POWER SOCKET.
7
Selecting operating modes
5748007700GB 5-06-2003 17:47 Pagina 7
8
Cleaning/Warnings
Maintenance
Always remove the plug from the power socket before perfor ming any cleaning or
maintenance operations. For safety reasons, never wash the dehumidifier using a water jet.
Cleaning the cabinet
• Clean the appliance using a damp cloth then dry with a dry cloth.
• Never use petrol, alcohol or solvents to clean the appliance.
• Never spray the appliance with insecticides or similar. These could cause the paint to flake or
plastic parts to warp.
Cleaning the air filter
If the filter is dirty, air circulation is compromised and the efficiency of the dehumidifying and
air filtration functions decreases. It is therefore good practice to clean the filter at regular
intervals. The frequency depends on the duration and conditions of operation. If the unit is
used constantly or systematically, you are recommended to clean the filter once a week.
•To remove the air filter, extract by pulling it as shown in fig. 4.
•Use a vacuum cleaner to remove dust accumulations from
the filter. If the filter is very dirty, wash in warm water and rinse
several times. The temperature of the water should not
exceed 104°F (40˚C). After washing the filter, allow to dry
completely before putting it back in the appliance.
If the appliance is not used for long periods
• Unplug from the main socket.
• Empty the tank.
•Clean and reposition the filter.
• Cover the appliance so that dust does not build up.
fig. 4
8
5748007700GB 5-06-2003 17:47 Pagina 8
9
ENGLISH
Problem Cause Remedy
The appliance does not
work in dehumidifying
mode (indicator light off)
The appliance operates in
dehumidifying mode (light
on) but the humidity is not
reduced
•the appliance is not
plugged in
•there is no current
•the humidistat is on
minimum
•the tank is full of water
•the tank is incorrectly
positioned or missing
•filter clogged
•the temperature or
humidity of the home is
too low
•room too large
•too many sources of
humidity in room (boiling
pots etc.)
•the compressor is off
because the defrosting
device has cut in (yellow
light ON)
•plug into the mains
•check the power supply
•set the humidistat to the
required level
•empty the tank
•gently place the tank in
the correct position
•clean the filter
•in certain conditions, it is
normal for the appliance
not to dehumidify (see
“Technical characteristics”
•switch the appliance off,
wait 30 minutes then turn
on again. We suggest to
heat the room. (see “Brief
notes on humidity” If the
problem is not solved, call
the Technical Service
Centre.
Check the following points before calling your local Technical Service Centre.
Tr oubleshooting
The appliance doesn’t work
for about 3 minutes from
turning on the appliance
•the appliance’s security
system has intervened
•wait for 3 minutes
5748007700GB 5-06-2003 17:47 Pagina 9
10
Power supply voltage See rating label
Absorbed power dehumidifying only “
Maximum absorbed power “
Maximum absorbed current “
Refrigerant “
Air treated (min/max) 210/300 m
3
/h (120/180 CFM)
Defrosting device electronic
Humidistat yes
Fan speeds 2
Compressor protection device yes
Air filter yes
Dimensions LxHxD 365x610x375mm (14.4”x24”x14.7”)
Weight (net) 21,5 Kg (55 lbs)
Tank capacity 5.5 litres (11.6pt)
Operating limits: Dehumidifying
• temperature 7° - 32° (44°F -89°F)
•relative humidity 30 - 95%
Technical Characteristics
5748007700GB 5-06-2003 17:47 Pagina 10
ENGLISH
Warranty
FOR UNITED STATES ONLY:
LIMITED WARRANTY
What Does This Warranty Cover? We warrant each appliance to be free from defects in
material and workmanship. Our obligation under this warranty is limited to replacement or
repair, free of charge at our factory or authorized service centers, of any defective part or
parts thereof other than parts damaged in transit, which shall be returned to us,
transportation prepaid. This warranty shall apply only if the appliance is used in accordance
with the factory directions which accompany it, and on an Alternating Current (AC) circuit.
How Long Does The Coverage Last? This warranty runs for one year from the date of delivery
and applies only to the original purchaser.
What Does This Warranty Not Cover? This warranty does not cover defects or damage of the
appliance which result from repairs or alterations to the machine outside our factory or
authorized service centers, nor shall it apply to any appliance which has been subject to abuse,
misuse, negligence or accidents. Also, consequential and incidental damages resulting from
the use of this product or arising out of any breach of contract or breach of this warranty are
not recoverable under this warranty. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation may not apply to you.
How Do You Get Service? If repairs become necessary or spare parts are needed, please write to:
If repairs become necessary or spare parts are needed, plese write to:
De’Longhi America Inc.
Park 80 West Plaza One
Saddle Brook, N.J. 07663
or call Service Tel. No. 800-322-3848
The above warranty is in lieu of all other express warranties and representations; All implied
warranties are limited to the applicable warranty period set forth above. This limitation does
apply if you enter into an extended warranty in connection with De’Longhi. Some states do
not allow limitations on how long an implied warranty lasts, so the above exclusionsmay not
apply to you. De’Longhi does not authorize any other person or company to assume for it any
liability in connection with the sale or use of its appliance.
How Does State Law Apply? This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
