DeLOCK USB hub, 4x USB-A 3.0, USB-C 3.0 plug User Manual

Delock External USB 3.1 Gen 1 Hub USB Type-C™ > 4 x USB
Type-A + 1 x USB Type-C™ PD

Description

The USB hub by Delock is the mobile companion for
laptops or tablets with USB Type-C™ connection. Up to 4
USB Type-A devices can be connected to the hub. The
hub has a USB Type-C™ Power Delivery port to connect
the laptop or tablet to charge it. In addition it also supplies
the USB Type-A females with power.

Note

The hub can also be used without a power supply. Due to the low power supply, it can’t be
guaranteed that all four ports can operate simultaneously.

Specification

• Connector:
1 x SuperSpeed USB (USB 3.1 Gen 1) USB Type-C™ male >
3 x SuperSpeed USB (USB 3.1 Gen 1) Type-A female
1 x SuperSpeed USB (USB 3.1 Gen 1) Typ-A female - Battery Charging specification
BC1.2
1 x USB Type-C™ Power Delivery female (optional for power supply)

• Chipset: VIA VL813

• Data transfer rate up to:
SuperSpeed USB 5 Gbps,
Hi-Speed 480 Mbps,
Full-Speed 12 Mbps,
Low-Speed 1.5 Mbps

• USB cable directly on the hub (length ca. 7 cm)

• Dimensions (LxWxH): ca. 92 x 39 x 12 mm

• Plug & Play

Item No. 62793

EAN: 4043619627936

Country of origin: China

Package: Retail Box

System requirements

• Windows 7/7-64/8.1/8.1-64/10/10-64, Windows 10 Mobile,
Linux ex Kernel 3.17.x / Kernel 4.x.x, Mac OS 10.11.4, Android 6.0.1

• Laptop or tablet with a USB Type-C™ or Thunderbolt™ 3 port

Package content

• Hub USB

• User manual
