Page 1
Delock Thunderbolt™ 3 Docking Station 5K - HDMI / USB 3.0 /
USB-C™ / SD / LAN
Description
This Thunderbolt™ 3 docking station by Delock can be
connected to a computer with a Thunderbolt™ 3 port and
provides a variety of interfaces. The Thunderbolt™ 3 port
supports a resolution up to 5K and is compliant to USB,
therefor it is possible to connect all USB Type-C™
devices. Two 4K monitors can be operated simultaneously
at the Thunderbolt™ 3 and HDMI outputs. Five built-in
USB Type-A ports allow the use of peripherals, and
connections for a headset and gigabit network, as well as
an SD card reader, complete the features. A connected
laptop such as the Macbook or Chromebook will be
charged during operation.
Specification
• Connectors:
front side:
1 x USB 3.0 Type-A female
1 x USB 3.0 Type-A female - Battery Charging specification BC1.2
1 x SD / SDHC / SDXC slot
1 x Headset 3.5 mm 4 pin jack
back side:
1 x Thunderbolt™ 3 female (connection to computer)
1 x Thunderbolt™ 3 female
1 x HDMI-A 19 pin female
3 x USB 3.0 Type-A female
1 x Gigabit LAN 10/100/1000 Mbps RJ45 jack
1 x DC jack
• Video outputs supports: extended and mirror
• Resolution up to:
Windows:
1 x 5120 x 2880 @ 60 Hz (depending on the system and the connected hardware)
2 x 3840 x 2160 @ 60 Hz (depending on the system and the connected hardware)
Mac:
2 x 3840 x 2160 @ 30 Hz (depending on the system and the connected hardware)
• Transmission of audio and video signals
• Output power for host: max. 60 W
• Metal housing
• Rubber pads for safe grip and secure stand
• Colour: silver
• Dimensions (LxWxH): ca. 230 x 87 x 27 mm
Item no. 87725
EAN: 4043619877256
Country of origin: China
Package: Retail Box
Power supply specification
• Wall power supply
• Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 1.8 A
• Output: 20 V / 6.75 A
• Ground outside, plus inside
• Dimensions:
inside: ø ca. 2.5 mm
outside: ø ca. 5.5 mm
length: ca. 10 mm
System requirements
• Windows 8.1/8.1-64/10/10-64, Mac ex OS 10.12
• PC or laptop with a free Thunderbolt™ 3 port
© 2018 by Delock . All names and symbols mentioned here are property of the respective producer. Printing errors,
changes and errors excepted.
www.delock.com
87725
1 / 3
23.08.2018
Page 2
Package content
• Thunderbolt™ 3 docking station
• Thunderbolt™ 3 cable, length ca. 50 cm
• Power supply
• User manual
Images
© 2018 by Delock . All names and symbols mentioned here are property of the respective producer. Printing errors,
changes and errors excepted.
www.delock.com
87725
2 / 3
23.08.2018
Page 3
General
Function: Battery Charging BC1.2
Supported operating system: Windows 8.1 32-bit
Windows 8.1 64-bit
Windows 10 32-bit
Windows 10 64-bit
ex Mac OS 10.12
Supported memory card: SD
SDHC
SDXC
Interface
Output: 1 x 3.5 mm 4 pin stereo jack female
1 x RJ45 jack
1 x HDMI-A 19 pin female
1 x SD slot
1 x USB 3.0 Type-A female - Battery Charging specification BC1.2
4 x USB 3.0 Type-A female
1 x DC jack
1 x Thunderbolt™ 3 female
Input: 1 x Thunderbolt™ 3 USB Type-C™ 24 pin male
Technical characteristics
Maximum screen resolution: 5120 x 2880 @ 60 Hz
Signal transmission: video
audio
Physical characteristics
Housing material: metal
Length: 230 mm
Width: 87 mm
Height: 27 mm
Colour: silver
Power supply
Type: Euro wall power supply
Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 1.8 A
Output: 20 V / 6.75 A
Connector: DC plug 5.5 mm x 2.5 mm
