DeLOCK PCIe adapter, 2x USB-C, 1x DisplayPort-In, PCIe 3.0 x1 User Manual
Delock PCI Express Card > 1 x external USB Type-C™ 3.1
female + 1 x external USB Type-C™ 3.1 (DP Alt Mode) female
Description
This PCI Express card by Delock expands the PC by two
external USB-C™ ports. Different USB-C™ devices, such
as docking stations, card readers, external housings etc.,
can be connected to the card. By using the included cable,
the DisplayPort connector of the PCI Express card can be
connected to a DisplayPort output of a graphics card on
the motherboard. Therefore one USB-C™ port will be DP
Alt Mode capable. A monitor can be connected to this port
in order to transmit video and audio signals.
Specification
• Connectors:
external:
1 x SuperSpeed USB 10 Gbps (USB 3.1 Gen 2) USB Type-C™ female
1 x SuperSpeed USB 10 Gbps (USB 3.1 Gen 2) USB Type-C™ female (DP Alt Mode
capable)
1 x DisplayPort 20 pin female (for DP Alt Mode function)
internal:
1 x PCI Express x1, V3.0
• Chipset: Asmedia ASM1142
• Data transfer rate up to:
SuperSpeed USB 10 Gbps,
SuperSpeed USB 5 Gbps,
Hi-Speed 480 Mbps,
Full-Speed 12 Mbps,
Low-Speed 1.5 Mbps
• DisplayPort 1.2 specification
• Resolution up to 3840 x 2160 @ 60 Hz (depending on the system and the connected
hardware)
• Power supply via PCI Express interface
• Electrical power per port: max. 7.5 watt (5 V / 1.5 A)
• Supports eXtensible Host Controller Interface (xHCI) specification 1.1
Item no. 89582
EAN: 4043619895823
Country of origin: China
Package: Retail Box
System requirements
• Windows 7/7-64/8.1/8.1-64/10/10-64, Linux ex Kernel 4.4.x
• PC with one free PCI Express slot
• Graphics card with DisplayPort output (to support DP Alt Mode)
Package content
• PCI Express card
• DisplayPort cable
• Low profile bracket
• Driver CD
• User manual
© 2018 by Delock . All names and symbols mentioned here are property of the respective producer. Printing errors,
changes and errors excepted.
www.delock.com
89582
1 / 3
04.12.2018
