Delock LoRa Antenna 868 MHz SMA Plug 0 dBi omnidirectional
(RG-174, 3 m) roof mount outdoor black
Description
This antenna by Delock allows the usage of the 868 MHz
frequency range indoors and outdoors. It is compatible to
ZigBee 868 MHz and Z-Wave 868 MHz.
Specification
• Connector: 1 x SMA plug
• Frequency range: 868 MHz
• Antenna gain: 0 dBi
• Impedance: 50 Ohm
• Polarisation: linear, vertical
• VSWR: 2.0
• Transmission power: 10 W
• Operating temperature: -30 °C ~ 70 °C
• Colour: black
• Housing material: ABS UV resistant
• Screw mounting with 13.5 mm hole diameter
• Thread length: ca. 18 mm
• Protection class: IP67
• Cable: coaxial
• Cable type: RG-174
• Cable color: black
• Cable loss: ca. 1.0 dB @ 868 MHz per meter
• Cable diameter: ca. 2.7 mm
• Cable length incl. connector: ca. 3 m
• Dimensions (LxD): ca. 75.0 x 53.5 mm
Item no. 89533
EAN: 4043619895335
Country of origin: Taiwan, Republic of
China
Package: Poly bag
System requirements
• Device with a free SMA jack
Package content
• Antenna
© 2017 by Delock . All names and symbols mentioned here are property of the respective producer. Printing errors,
changes and errors excepted.
www.delock.com
89533
1 / 4
13.12.2017
Images
© 2017 by Delock . All names and symbols mentioned here are property of the respective producer. Printing errors,
changes and errors excepted.
www.delock.com
89533
2 / 4
13.12.2017
General
Mounting type: standard
Screw mounting with 12.5 mm hole diameter
Protection category: standard
IP67
Suitable for outdoor: standard
yes
Interface
connector: standard
1 x SMA plug
Technical characteristics
Frequency range: standard
2.400 - 2.500 GHz
Antenna gain: standard
3 dBi
Gain: standard
3 dBi
Impedance: standard
50 Ω
Operating temperature: standard
-30 °C ~ 70 °C
Polarisation: standard
linear vertical
Power handling: standard
10 W
VSWR: standard
2.0
Physical characteristics
Antenna type: standard
omnidirectional
Cable category: standard
coaxial
Cable type: standard
RG-174 U
Cable attenuation: standard
1.5 dB @ 1.5 GHz per meter
Cable colour: standard
black
Cable diameter: standard
2.7 mm
Cable length incl. connector: standard
3 m
Colour: standard
black
© 2017 by Delock . All names and symbols mentioned here are property of the respective producer. Printing errors,
changes and errors excepted.
www.delock.com
89533
3 / 4
13.12.2017
Thread type: standard
M12
Dimensions (LxØ): standard
75.0 x 53.5 mm
