Delock Adapter Displayport 1.1 male > VGA / HDMI / DVI female
Passive black

Description

This Displayport adapter by Delock enables you to extend
your system by one VGA, HDMI and DVI interface. Thus
you can connect different devices like e.g. TV, beamer, PC
monitor etc. Only one monitor can be used on the adapter,
not several at the same time.

Specification

• Connector:
1 x Displayport 20 pin male >
1 x VGA 15 pin female
1 x HDMI-A 19 pin female
1 x DVI-D (Single Link) 24+1 female

• Chipset: PS8312, PTN3392

• Displayport 1.1a specification

• High Speed HDMI specification

• DVI-D (Single Link) 24+1 port with screw nuts (VGA not wired)

• Passive converter (level shifter), suitable only for graphics cards with DP++ output

• Supports a resolution up to 1920 x 1200 / 1080p @ 60 Hz (depending on the system
and the connected hardware)

• Power consumption: ca. 100 mW

• 1 x ferrite core

• Cable length ca. 16 cm without connector

• Colour: black

• OS independent, no driver installation necessary

Item No. 62656

EAN: 4043619626564

Country of origin: China

Package: Retail Box

Powered by TCPDF (www.tcpdf.org)

System requirements

• A free Displayport DP++ female port

Package content

• Adapter Displayport to VGA / HDMI / DVI

Images

© 2017 by Delock. All names and symbols mentioned here are property of the respective producer. Printing errors, changes
and errors excepted.

www.delock.com

62656

1 / 1

13.01.2017
