Delock Card Reader IDE 40 pin female to Compact Flash

Description

This Card Reader by Delock enables the application of a
Compact Flash card via 40 pin IDE interface. Since this
Card Reader is bootable you can also use the it also as HDD
and install a operating system. The Card Reader can be
plugged directly and horizontal to a free IDE male port of
the motherboard without using an additional connecting
cable.

Specification

• IDE 40 pin to CF Card

• 40 pin 2.54 mm standard IDE female connector

• For Compact Flash type I, type II and Micro-drive

• Master or Slave mode selection

• 2 x mounting holes

• +5 V floppy disk drive power connector

• Supports DMA and Ultra DMA modes. A compatible flash
media card will be required to use these modes.

• Size: 60 mm x 43 mm

Item No. 91647

EAN

Country of origin

4043619916474

China

System requirements

• Windows 2000/XP/Vista, Linux 2.6

• A free IDE 40 pin connector

Package content

• IDE-CF Card Reader

Package

• Poly bag

Images
