DeLOCK 89289 User Manual

Delock eSATA + USB 3.0 Quad SATA 3 Gb/s Port Multiplier with RAID

Description

The Delock port multiplier by IOI enables the connection of
four internal SATA devices to one USB 3.0 or eSATA port.
For the usage of HDDs / SSDs you can use different
hardware RAID settings.

Specification

• IOI item number: ESU3-QS201-R5-SEH

• Connector:
4 x internal SATA (for device)
1 x internal 4 pin Floppy power
1 x external eSATA (host)
1 x external USB 3.0 (host)

• SCSI-I form factor

• Data transfer rate of SATA ports up to 3 Gb/s

• LED indicators for power, alarm (RAID status) and link

• Switch for RAID settings

• Supports RAID 0, 1, 3, 5, 10, JBOD, Clone

• Supports Multiple RAID

• Supports hard drives with more than 2 TB

• Supports NCQ

• Supports Hot Plug

• Dimension (LxWxH): ca. 83.3 x 64.8 x 24.56 mm

Item No. 89289

EAN

Country of origin

4043619892891

Taiwan, Republic of
China

System requirements

• PC or notebook with a free USB or eSATA port

Package content

• Port multiplier

• Y-power cable

• Software CD with RAID Manager

• User manual

Package

• White Box

© 2013 by Delock. All names and symbols mentioned here are property of the respective producer. Printing errors, changes and errors excepted.

www.delock.com
