Delock WLAN 802.11 b/g/n antenna N plug 7,5 dBi directional gray
outdoor
Description
This WLAN antenna can be connected to your WLAN
device with N connector in order to receive or to
send signals. By the directivity you can specifically improve
transmission and reception conditions.
Specification
• WLAN Antenne extern
• N plug screw interface: 2.4 ~ 2.5 GHz
• Gain: 7,5 dBi
• VSWR: 2,0 max.
• HPBW horizontal: 70°
• HPBW vertical: 65°
• front to back ratio 15 dB
• Power handling 10 W (cw)
• Input impedance: 50 Ohm
• Cable length: 1 m
• Cable type: ULA 198
• Housing colour: white
• Protecting class: IP-X5 waterproof
• Material: ABS, UV resistant
• Operation temperature: -20 °C ~ 80 °C
• Humidity: 95 % @ 55 °C
• Ligthning protection: DC ground
• Dimension: 122 x 122 x 47 mm
• Mounting kit: wall mount / window mount
Item No. 88455
EAN
Country of origin
4043619884551
Taiwan, Republic of
China
Package content
• Antenna
• Mounting kit
Package
• Box
