Delock WLAN 802.11 b/g/n antenna RP-SMA 9 dBi omnidirectional joint

Description

This Wireless LAN antenna can be connected to your
device with RP-SMA interface, in order to send and receive
signals.

Specification

• WLAN antenna externally with flexible joint, rotatable

• RP-SMA male

• Frequency range: 2.4 GHz

• Gain: 9 dBi

• VSWR: 2.0 max.

• Impedance: 50 Ohm

• Housing material: ABS UV protected

• Operating temperature: -10 °C ~ 55 °C

• Dimension: with joint 384.1 mm
without joint 352.1 mm

• Ø: 12.6 mm (top)

13.5 mm (base)

Item No. 88450

EAN

Country of origin

4043619884506

Taiwan, Republic of
China

Package content

• WLAN antenna

Package

• Poly bag
