DeLOCK 88410 User Manual
Delock WLAN 802.11 b/g/n antenna RP-SMA 6.5 dBi omnidirectional joint
with magnetic stand
Description
This Wireless LAN antenna can be connected to your
device with RP-SMA interface, in order to send and receive
signals. Due to the three tilt stages of the flexible antenna
and the magnetic stand you can place the antenna
individually.
Specification
• Omni directional antenna
• RP-SMA screw interface
• With flexible joint – three step
• Compatible to IEEE 802.11n and IEEE 802.11 b/g, 802.3, 802.3u
• Frequency range: 2.4 GHz - 2.5 GHz
• Gain: 6.5 dBi
• Impedance: 50 Ohm
• Operating temperature: -10°C to +55°C
• 1 m connecting cable
• Stand with magnetic and rubberized bottom side
• Dimension: with flexible joint 298 mm, without flexible joint 260 mm
• Antenna connected inseparably with stand
Item No. 88410
EAN
Country of origin
4043619884100
Taiwan, Republic of
China
Package content
• WLAN antenna
Package
• Blister
© 2013 by Delock. All names and symbols mentioned here are property of the respective producer. Printing errors, changes and errors excepted.
www.delock.com
1
