DATA SHEET

Slot bracket USB 3.0 pin header 19 pin 2 x internal
> 4 x USB 3.0-A female external

Description

This slot bracket by Delock can be
installed into a standard PC slot and
expands your system by four external
USB 3.0-A ports. Thus you can connect
different USB 3.0 devices, like e.g.
external enclosure, Card reader,
memory etc. Since the USB 3.0-A
interface is compatible to its forerunners
USB 2.0 and USB 1.1, you can still use
your existing USB devices.

Ref.

EAN

Country of origin

Customs tariff number

82974

4043619829743

China

84718000

Images

Specification

• Connector: internal 2 x 19 pin USB 3.0 pin header female
external 4 x USB 3.0-A female

• Cable gauge: 28 AWG

• Current output: max. 900 mA per each USB port

• Voltage: 5 V

• Data transfer rate up to: Super-Speed 5 Gb/s,
High-Speed 480 Mb/s,
Full-Speed 12 Mb/s,
Low-Speed 1.5 Mb/s

• Downwards compatible to USB 2.0 and USB 1.1

• Cable length: ca. 40 cm (without connector)

System requirement

• PC with a free slot

• Mainboard with two free 19 pin USB 3.0 pin header connector

Note

: For operation of four devices at the same time,
which require more than 900 mA for
each device, you may need to connect an
additional power supply for the connected device.

Package content

• Slot bracket

Package

• Delock poly bag

© 2011 by Delock. All names and symbols mentioned here are property of the respective producer.
Printing errors, changes and errors excepted.
